2000 BMW 323Ci CONVERTIBLE sensor

Contents

Overview
Controls and features

Cockpit16
Instrument cluster18
Indicator and warning lamps20
Multifunction steering wheel
(MFL)24
Hazard warning flashers25
Warning triangle25
First-aid kit25
Refueling26
Fuel specifications27
Tire inflation pressure27

Opening and closing:

Keys32
Electronic vehicle
immobilizer33
Central locking system34
Opening and closing – from
outside34
Opening and closing – from
inside38
Luggage compartment lid39
Luggage compartment40
Alarm system42
Electric power windows44
Manual convertible top45
The fully automatic convertible
top49
Wind deflector51

Adjustments:

Seats53
Seat and mirror memory57
Steering wheel58
Mirrors58
Car Memory, Key Memory60

Passenger safety systems:

Safety belts61
ISOFIX Attachment of the
child seat62
Airbags63
Child restraints66
Installing a child restraint
system67
Rollover protection system68

Driving:

Steering/Ignition lock70
Starting the engine70
Switch off the engine71
Parking brake72
Manual transmission73
Automatic transmission with
Steptronic74
Turn signal indicator/
Headlamp flasher77
Washer/Wiper system/
Rain sensor77
Rear window defroster79
Cruise control80

Everything under control:

Odometer82
Tachometer82
Energy Control82
Fuel gauge83
Coolant temperature gauge83
Service Interval Display83
Check Control84
Clock84
Onboard computer85

Technology for safety and
driving convenience:

Park Distance Control (PDC)87
Dynamic Stability Control
(DSC)88
Tire Pressure Control (RDC)89

Contents

Contents

Owner service procedures
Advanced technology
Technical data

Replacement procedures:

Onboard tool kit152
Windshield wiper blades152
Lamps and bulbs152
Changing a wheel159
Battery162
Fuses165

In case of electrical
malfunction:

Fuel filler door165
Fully automatic convertible
top166

Assistance, giving and
receiving:

Jump-starting168
Towing the vehicle169Adaptive Transmission Control
(ATC)172
Airbags173
Dynamic Stability Control
(DSC)173
Radio reception174
Safety belt tensioner174
Interior rearview mirror with
automatic dimmer175
Rain sensor176
Tire Pressure Control (RDC)177
Self-diagnostics178
Rollover protection system179
Xenon lamp179Engine data182
Dimensions183
Weights184
Capacities185
Electrical system186
Drive belts 186

27n
IndexDataTechnologyRepairsCar careControlsOverview
Fuel specifications Tire inflation pressure Use unleaded gasoline only.
Recommended fuel: premium with a
minimum octane rating of 91 AKI.
BMW engines are equipped with knock
sensors and will adapt automatically
to different octane ratings, provided
that the minimum octane requirement
(87 AKI) is met.
Fuels with higher octane ratings will
provide enhanced performance and
lower fuel consumption, while the use
of fuels with low octane ratings will have
the opposite effect.
Do not use leaded fuels. The use
of leaded fuels will cause perma-
nent damage to the system's oxygen
sensor and the catalytic converter.<
AKI = Anti Knock Index
You will find the inflation pressures on
the inside door pillar (visible with door
open).Check tire pressuresAll pressure specifications are stated
in psi (kilopascal) with cold tires (cold =
ambient temperature). Refer to the next
page as well.
For vehicles with Tire Pressure Control
(RDC)
*:
After correcting the tire inflation pres-
sure, reactivate the system. Refer to
page 89.
462de197
Check tire inflation pressures reg-
ularly – at least every two weeks
and before beginning a longer trip.
Otherwise, incorrect tire pressure can
lead to driving instability or to tire dam-
age and accidents.
Check the tire pressure in the space-
saver tire as well.<

Overview
Controls and features
Operation, care
and maintenance
Owner service procedures
Technical data
Index Advanced technology
31n
IndexDataTechnologyRepairsCar careControlsOverview
Driving:
Steering/Ignition lock70
Starting the engine70
Switching off the engine71
Parking brake72
Manual transmission73
Automatic transmission with
Steptronic74
Turn signal indicator/Headlamp
flasher77
Washer/Wiper system/
Rain sensor77
Rear window defroster79
Cruise control80
Everything under control:
Odometer82
Tachometer82
Energy Control82
Fuel gauge83
Coolant temperature gauge83
Service Interval Display83
Check Control84
Clock84
Onboard computer85
Technology for safety and
convenience:
Park Distance Control (PDC)87
Dynamic Stability Control
(DSC)88
Tire Pressure Control (RDC)89Lamps:
Parking lamps/Low beams91
Instrument lighting91
High beams/Parking lamps92
Fog lamps92
Interior lamps92
Reading lamps93
Controlling the climate for
pleasant driving:
Automatic climate control94
Seat heating99
Cabin conveniences:
Glove compartment99
BMW Universal
Transmitter *100
Storage compartments102
Cellular phone103
Ashtray front103
Cigarette lighter104
Ashtray rear104
Loading and transporting:
Ski bag105
Cargo loading106
Luggage rack for the
hardtop108

37n
IndexDataTechnologyRepairsCar careControlsOverview
Opening and closing – from outsideSwitching on the interior lampsAfter locking the vehicle, press button 2
again.Switching off the tilt sensor
alarm system
* and interior motion
sensor
*
Press button 2 again immediately after
locking.
For additional information, refer to
page 43.46cde057
Opening the luggage
compartment lid Press button 3.
The luggage compartment lid will open
slightly, regardless of whether the lid
was previously locked or unlocked.
Before and after a trip, be sure
that the luggage compartment lid
was not opened unintentionally.<46cde058
System interferenceThe proper functioning of the remote
control system may be affected by
other units or equipment operating in
the immediate vicinity of your vehicle.
If this should occur, you can still open
and close the vehicle using the master
key in both the door and luggage com-
partment locks.For US owners onlyThe transmitter and receiver units comply
with part 15 of the FCC (Federal Commu-
nication Commission) regulations. Oper-
ation is governed by the following:
FCC ID: LX8EWS
LX8FZVS
LX8FZVE
Compliance statement:
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
>This device may not cause harmful
interference, and
>this device must accept any interfer-
ence received, including interference
that may cause undesired operation.
Any unauthorized modifications or
changes to these devices could
void the user's authority to operate this
equipment.<

42n
Alarm system
*
The conceptThe vehicle alarm system responds:
>When a door, the hood or the lug-
gage compartment lid is opened
>Movements inside the vehicle
>To a change in the vehicle's tilt –
if someone attempts to steal the
wheels or tow the vehicle without
authorization, for example
>If there is an interruption of battery
voltage.
The system responds to unauthorized
vehicle entry and attempted theft by
simultaneously activating the following:
>Sounding an acoustical alarm for
30 seconds
>Activating the hazard warning
flashers for approx. five minutes
>Flashing the high beams on and off in
tandem with the hazard warning
flashers.
To activate and deactivate the
alarm systemWhen the vehicle is locked or unlocked
by using a key or the remote control,
the alarm system is also armed or dis-
armed at the same time.
The interior protection and tilt sensor
alarm systems are activated approx.
30 seconds after you have shut the last
door.
If the alarm system has been armed
correctly, the hazard warning flashers
flash once.
You can have one signal set as
acknowledgment when arming
and disarming.<
You can also open the luggage com-
partment lid when the system is armed
by pressing button 3 of the remote con-
trol (refer to page 37). When it is closed,
the lid is once again secured.
Indicator lamp displaysThe indicator lamp is located under the
inside rearview mirror.
>When the indicator lamp flashes con-
tinuously, the system is armed>The indicator lamp flashes when it
is armed. Doors, the hood or luggage
compartment lid are not closed
properly. Even if you do not close the
alerted area, the remaining areas are
deadlocked, and the indicator lamp
flashes continuously after 10 seconds.
However, the interior protection
system is not activated>If the indicator lamp goes out when
the system is disarmed, no manipula-
tion or attempted intrusions have
been detected in the period since the
system was armed46cus033

43n
IndexDataTechnologyRepairsCar careControlsOverview
Alarm system
*
>If the indicator lamp flashes for
10 seconds when the system is dis-
armed, an attempted entry has been
detected in the period since the sys-
tem was armed.
Following triggering of an alarm, the
indicator lamp will flash continuously.Avoiding an unintentional alarm The tilt sensor alarm system and interior
protection system can be deactivated.
Doing this prevents a false alarm from
being triggered (in garages with eleva-
tor ramps, for instance), or when the
vehicle is transported by trailer or train:
Lock the vehicle twice (= arm the sys-
tem). Press button 2 on the remote
control twice in succession or lock the
vehicle twice with the key (refer to
page 34).
The indicator lamp lights up briefly and
then flashes continuously. The tilt sen-
sor alarm system and interior protection
system are deactivated until canceled.
Re-arm the anti-theft alarm system to
re-activate the tilt sensor alarm system
and interior protection system.
Interior protection systemThe transmitter and receiver of the inte-
rior protection system are located in the
front area of the center console, hidden
from the driver, and in the rear area of
the center console under a cap.
However, deactivate the interior protec-
tion system (see previous column) when
children or animals are to remain in the
vehicle.
For US owners onlyThe transmitter and receiver units com-
ply with part 15 of the FCC (Federal
Communication Commission) regula-
tions. Operation is governed by the
following:
FCC ID: LTQSDR2G5
Compliance statement:
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
>This device may not cause harmful
interference, and
>this device must accept any interfer-
ence received, including interference
that may cause undesired operation.
Any unauthorized modifications to
these devices could void the
user's authority to operate the equip-
ment.c

48n
Manual convertible top
Starting from either ignition key
position 1 or with a door open:
If the side windows are closed, lower
them slightly by depressing the respec-
tive button. After closing the convertible
top, either close the side windows or
put them at the height desired.c
5 Do not position the rear convertible
top bar vertically until the convertible
top has been swung forward as far as
possible
6 Press the convertible top compart-
ment lid down from above. The lid
locks for the convertible top are
equipped with sensors that carry out
the closing procedure
In order to avoid any pinching,
move the convertible top com-
partment lid from above only.c
The central locking system auto-
matically unlocks when the con-
vertible top compartment lid is closed,
i. e., the luggage compartment lid is no
longer locked and can be opened
again.c
7 Using the locking handle, pull the
front convertible top frame onto the
windshield frame, and lock the con-
vertible top by turning the handle
until you hear it engage
8 Close the windows that were slightly
lowered, or position them at the de-
sired height.
The rear convertible top bar will be
automatically pressed onto the convert-
ible top compartment lid, and because
of the pressure, will be sealed off when
closed.Should the convertible top start to
flutter at higher speeds, increase
the airflow into the passenger area via
the ventilation controls to avoid creat-
ing a vacuum.c
