plates) the hub splines.
Remove corrosion
and apply only a very thin coating of grease G 000 100 to the
splines. Then move clutch plate to and for on input shaft until
hub moves freely on
shaft. Excess grease
must be removed.
◆ Pressure plates are
protected against
corrosion and
greased. Only the
contact surface may be cleaned, otherwise the service life of the
clutch will be
considerably
reduced.
◆ Tighten securing
bolts in small steps in
diagonal sequence to
avoid damaging
centring holes in
pressure plate and
centring pins on
flywheel.
‒ Remove the gearbox
to work on the
clutch=>Page 34-35.
1.Flywheel/dual mass
flywheel
◆ Ensure that
centring pins
are a tight fit.
◆ Contact
surface for
clutch lining must be free of grooves, oil
and grease
◆ Observe
removal
instructions for
the weight-
optimised dual-
mass flywheel
=>Fig.2
◆ Removing and
installing:
=> Relevant
engine
workshop
manual,
Mechanical
components;
Repair group
13 Page 2 of 75-Speed Manual Gearbox 01A 4WD4.3.2014vw-wi://rl/A.en-GB.4B-S-S01AA.wi::21141315.xml?xsl=2
‒ Install lower engine/gearbox securing bolts and bolts for starter. For this
purpose, insert the starter.
=> Electrical System; Repair group 27; Removing and installing starter
‒ Bolt drive shafts to flange shafts.
=> Running Gear, FWD and 4WD; Repair group 40
‒ The threaded bores in the flange
shaft of the manual gearbox for the
propshaft must be cleaned of
remaining locking fluid with a thread
tap before assembling
‒ Replace front gaskets at propshaft
=> Page 39-79 and at drive shafts.
‒ Attaching propshaft => Page 39-84.
‒ Check selector rod and push rod,
adjust if necessary => Page 34-11.
‒ Tension free alignment of exhaust
system
=> 4-cylinder Engine (5-valve turbo), Mechanical Components; Repair group 26; Removing and installing parts of exhaust system; Stress-free alignment of exhaust system
=> 6-cylinder Engine (5-valve), Mechanical Components; Repair group 26; Removing and installing parts of exhaust system; Stress-free alignment of exhaust system
‒ Check oil level in manual gearbox => Page 34-56.
‒ Electrical connections and routing:
=> Current Flow Diagrams, Electrical Fault-
finding and Fitting Locations binder
‒ Connect the battery.
Notes:
◆ If the battery is reconnected, please
ensure that the vehicle equipment
(radio, radio/navigation system,
clock, electric window lifters) is
activated as described in the
operating instructions.
◆ Deactivate the service mode of the
telematics control unit.
=> Radio, Telephone and Navigation Page 2 of 45-Speed Manual Gearbox 01A 4WD4.3.2014vw-wi://rl/A.en-GB.4B-S-S01AA.wi::21141329.xml?xsl=2
