Installation is carried out in the reverse
order; note the following:
‒ → Insert the master cylinder so that
seal -1- and the washer lie behind
the mounting bracket and tighten
bolts -2- to 20 Nm.
‒ Press connection pipe -3- with guide
-arrow A- into recess -arrow B- on
mounting bracket. A second mechanic is required for the next
step.
‒ → Slide the complete pedal cluster
forwards towards the cross panel,
insert the bolt -arrow 3- and tighten it finger tight. The second mechanic should guide the pipe into the master cylinder starting from the plenum
chamber. Old version with internal torx socket-head bolts:
‒ → Tighten the retaining bolts for the
brake servo -arrows- to 25 Nm.
New version with external torx socket-
head bolts: ‒ → Tighten the retaining bolts for the Page 4 of 65-Speed Manual Gearbox 01A 4WD4.3.2014vw-wi://rl/A.en-GB.4B-S-S01AA.wi::21141312.xml?xsl=2

brake servo -arrows- to 25 Nm. ‒ → Screw in the bolt for the brake
fluid reservoir -1- and attach the
connector for fluid level.
All models: ‒ → Tighten the hexagon socket head
bolt -arrow B- for securing pedal
cluster to dash panel crossmember
to 25 Nm. ‒ Connect clutch pedal to master Page 5 of 65-Speed Manual Gearbox 01A 4WD4.3.2014vw-wi://rl/A.en-GB.4B-S-S01AA.wi::21141312.xml?xsl=2

cylinder. Clip pin onto clutch pedal.
‒ → Press retaining clip -C- home.
‒ Push pipe -B- into master cylinder
until it audibly locks in place.
‒ Insert rubber grommet -D- over
connection pipe/supply hose -A- into
the cross panel.
‒ Push supply hose -A- for the brake
fluid reservoir on to limit stop.
‒ Remove special tool 3094.
‒ After installing the master cylinder,
bleed the clutch system =>Page 30-30.
‒ If fitted, check the adjustment of the
clutch pedal switch -F 36 => Page
30-8.
‒ Install storage compartment for
driver's side: => General Body Assembly, Interior; Repair group 68; Storage compartments, covers; Removing driver's storage compartment Page 6 of 65-Speed Manual Gearbox 01A 4WD4.3.2014vw-wi://rl/A.en-GB.4B-S-S01AA.wi::21141312.xml?xsl=2

Servicing clutch mechanism Bleeding clutch system Special tools, testers and auxiliary items required
◆ Brake filler and bleeder unit V.A.G
1869
or
◆ Brake filler and bleeder unit V.A.G
1238 B
Notes:
◆ The clutch system must be bled after performing work on the hydraulic clutch mechanism.
◆ Top up brake fluid reservoir to "max"
marking with brake fluid before
bleeding clutch system.
◆ Open the bleeder valve before
switching on the bleeder unit.
◆ When performing the following steps,
ensure that no brake fluid escapes
onto the gearbox.
‒ Pull clutch pedal back to its normal rest position.
‒ Connect brake filler and bleeder unit
V.A.G 1238 B or V.A.G 1869, but do
not switch on at this stage.
‒ Remove shield, if fitted, from
underneath gearbox. ‒ → Connect bleeder hose -A- to slave
cylinder (arrow) and open bleeder
valve.
‒ Connect bleeder hose to pressure
hose of fluid collector bottle.
‒ Switch on the bleeder appliance and
allow about 100 cm3 of brake fluid to
drain out.
‒ Working pressure 2.5 bar
Note:
Ensure bleeder hose is correctly fitted during
bleeding operation.
‒ Close bleeder valve and tighten to 4.5
Nm.
‒ Depress clutch pedal several times
after completion of bleeding process.
‒ Bleed again if necessary. Page 1 of 15-Speed Manual Gearbox 01A 4WD4.3.2014vw-wi://rl/A.en-GB.4B-S-S01AA.wi::21141313.xml?xsl=2

Servicing clutch release mechanism Servicing clutch release mechanism 1.Gearbox 2.Ball stud
◆ Tighten to 25
Nm
◆ Lubricate with MoS2-grease 3.Intermediate piece 4.Dished washer
◆ Smaller
diameter
(convex side)
to guide
sleeve
5.O-ring
◆ Replacing
6.Replace input shaft sealing ring
◆ is available
as a
replacement
part together with the guide sleeve -Item
7-
◆ Pack space
between
sealing and
dust lips half-
full with
sealing grease G 052 128 A1.
7.Guide sleeve ◆ Is available as
a replacement
part together
with the
sealing ring -
Item 6-
◆ Installation
position: The
oil drain bore
points
downwards.
◆ Before removing/fitting in order to
protect the
sealing ring -
Item 6- pull
shrink-fit hose
over the
splines on the
input shaft
8.Retaining spring Page 1 of 65-Speed Manual Gearbox 01A 4WD4.3.2014vw-wi://rl/A.en-GB.4B-S-S01AA.wi::21141314.xml?xsl=2

◆ Secure to clutch release lever
9.Torx socket head
bolt - 35 Nm
◆ Self-locking
◆ Replacing
10.Clutch release
lever
◆ Before
installing,
coat contact
surface of
clutch slave
cylinder push
rod with
copper grease, e.g. Z 381 351 TE. 11.Release bearing ◆ With or
without
plastic ring, depending on version
=>Fig.1
◆ Cement
detached plastic ring => Fig.1
◆ Do not wash
out bearing,
only wipe
◆ Replace
noisy
bearings
◆ Engage
retaining
latches at the
release
bearing in
contact
release lever 12.Slave cylinder
◆ Do not Page 2 of 65-Speed Manual Gearbox 01A 4WD4.3.2014vw-wi://rl/A.en-GB.4B-S-S01AA.wi::21141314.xml?xsl=2

operate clutch
pedal after slave cylinder has been
removed.
◆ Removing => Fig.2
◆ Detach from
hose/pipe
assembly =>
Fig.3
◆ Installing =>
Fig.4 and
Fig.5
◆ When
installing, press in slave cylinder far
enough so
that securing
bolt can be
fitted easily.
◆ Follow
correct work
sequence
when
bleeding =>
Page 30-30
◆ Tighten bleed valve to 4.5
Nm 13.Hexagon socket-head bolt - 23Nm
◆ Slave
cylinder to
gearbox
◆ Self-locking
◆ Always
replace
14.Bracket
◆ For hose/pipe assembly
◆ Attached
together with
the slave cylinder to the gearbox
◆ Installing =>
Fig.5
15.Push rod
◆ Lubricate end of push rod
with copper grease, e.g. Z 381 351 TE Page 3 of 65-Speed Manual Gearbox 01A 4WD4.3.2014vw-wi://rl/A.en-GB.4B-S-S01AA.wi::21141314.xml?xsl=2
