6.Ball bearing ◆ Removing and installing=>Page 34-74
7.Circlip
◆ Determining
thickness =>
Adjusting input
shaft, Page 35-23 8.Drive shaft ◆ Removing and installing=>Page 34-69
◆ Dismantling and assembling =>
Page 35-1
◆ Adjusting =>
Page 35-23
◆ Servicing input
shaft bearings
=> Page 35-1
9.Bolt - 25 Nm
10.Locking plate
◆ For multi-
function sender
11.Multi-function sender 12.Connector for multi-
function sender
13.Bolt - 10 Nm
14.Cover for selector
shaft
◆ Removing and installing=>Page 34-98
15.Locking unit for 5th gear and reverse gear Page 2 of 35-Speed Manual Gearbox 01A 4WD4.3.2014vw-wi://rl/A.en-GB.4B-S-S01AA.wi::21141335.xml?xsl=2

(arrows) for the intermediate bearing
and remove the propshaft with the
assembly device.
Note:
Only transport and store propshaft when
extended. Installing Installation is carried out in the reverse
order; note the following:
Notes:
◆ → To avoid imbalance the flanges of the propshaft -arrow A- and of the
rear final drive -arrow B- must be
fitted so that the factory colour
markings or the subsequently made
markings are aligned.
◆ If a new propshaft is installed and if
the factory colour marking on the
flange of the rear final drive is no
longer visible the radial run-out on
the propshaft flange must be
measured => Page 39-87 and the
colour marking on the propshaft
aligned with the new marking on the
flange.
◆ Renew gaskets on flange shafts
(detach protective foil and stick
gasket onto flange shaft).
◆ After removing the propshaft from
the rear final drive, the additional
balance disc (thicker washer) that
may be located between the lock
plate and the bolt head must not be
reinstalled.
◆ It is essential that the locking fluid
remaining in the threads in the
flange shafts on the gearbox and
rear final drive is cleaned out after
removing the propshaft. Otherwise
there is a danger that the new bolts
will seize when they are screwed in
and then shear if they have to be
removed later.
◆ The threaded holes can be cleaned Page 3 of 45-Speed Manual Gearbox 01A 4WD4.3.2014vw-wi://rl/A.en-GB.4B-S-S01AA.wi::21141363.xml?xsl=2

with a thread tap.
◆ Replace propshaft bolts (self-
locking).
‒ Tension free alignment of exhaust
system
=> 4-cylinder Engine (5-valve turbo), Mechanical Components; Repair group 26; Removing and installing parts of exhaust system; Stress-free alignment of exhaust system
=> 6-cylinder Engine (5-valve), Mechanical Components; Repair group 26; Removing and installing parts of exhaust system; Stress-free alignment of exhaust system
Tightening torques
1) Replace bolt Component Nm
Intermediate bearing to body 25
Propshaft to manual gearbox 1) 55
Propshaft to rear final drive 1) 55
Heat shield for propshaft to
Torsen differential cover 25
Front cross member under
exhaust system to body 25
Nuts for clamp 40 Page 4 of 45-Speed Manual Gearbox 01A 4WD4.3.2014vw-wi://rl/A.en-GB.4B-S-S01AA.wi::21141363.xml?xsl=2
