2000 Acura Integra display

Audi
o Syste m

Operatin g th e C D Change r
(Optional )
A Compact Disc changer is available for your car. It holds up to six discs,providing several hours ofcontinuous entertainment. You
operate this CD changer with thesame controls used for the in-dash
CD player.
Load the desired CDs in the
magazine and load the magazine in
the changer according to the instructions that came with the unit.Play only standard round discs. Odd-
shaped CDs may jam in the drive or
cause other problems.
To select the CD changer, press the CD button. The disc and track
numbers will be displayed. A "0" will
flash for the track number as the CD is loaded, then it will change to a
non-flashing "1".
To select a different disc, press the

appropriate preset button (1 — 6). If

you select an empty slot in the magazine, the changer will, after
finding that slot empty, try to load
the CD in the next slot. This continues until it finds a CD to load
and play.
If you load a CD in the in-dash player
while the changer is playing a CD, the system will stop the changer and
begin playing the in-dash CD. To select the changer again, press the
CD button. Play will begin where it
left off. Use the CD button to switch
between the player and the changer.
If you eject the in-dash CD while it is
playing, the system will automatically switch to the CD changer and begin
play where it left off. If there are no CDs in the changer, the display will
flash. You will have to select another mode (AM or FM) with the button. When you switch back to CD mode,
the system selects the same unit (in-dash or changer) that was playing
when you switched out of CD mode.
To use the SKIP, REPEAT, and RANDOM functions, refer to the in-
dash player operating instructions.
Comfor t and Convenienc e Feature s

Audi
o Syste m
C D Playe r Erro r Indication s
If you see an error indication in the display while operating the CD
player, find the cause in the chart to
the right. If you cannot clear the error indication, take the car to your
Acura dealer.
Comfort an d Convenienc e Feature s

Audi
o Syste m
C D Change r Erro r Indication s
If you see an error indication in the display while operating the CD
changer, find the cause in the chart
to the right. If you cannot clear the error indication, take the car to your
Acura dealer.
Comfor t an d Convenienc e Feature s

Audi
o Syste m
Tap e Searc h Function s
With a cassette playing, you can use the FF, REW, TMS, or REPEAT
function to find a desired program.
FF/RE W — Fast Forward and
Rewind move the tape rapidly. Press and release the side of the
TUNE bar to fast forward the tape, or the side to rewind. You will
see FF or REW flashing in the
display. To stop fast forward or
rewind, press the PLAY button. If
the system reaches the end of the
tape while in fast forward or rewind, it automatically stops that function,
reverses direction, and begins to play.
PLAY BUTTO N

Comfor t an d Convenienc e Feature s
PRO
G BUTTO N
DOLB Y ON/OF F
BUTTO N REPEA
T BUTTO N
FAS
T FORWARD /
REWIN D
TM
S

Audi
o Syste m
TM S — The Tape Music Search
function allows you to find the
beginning of a song or passage. To activate TMS, press the SEEK bar. Press the side to advance to the
beginning of the next song or passage, or the side to return to
the beginning of the current song or
passage. FF or REW will flash in thedisplay as the tape moves. When the
system reaches the beginning of the
next song or passage (FF), or the
beginning of the current one (REW), it goes back to PLAY mode.
REPEA T — The Repeat function
continuously replays the current song or passage. Press the REPEAT
button to activate it; you will see RPT displayed as a reminder. When the
system reaches the end of the song
or passage currently playing, it will
automatically go into rewind.
When it senses the beginning of the same song or passage, the system
returns to PLAY mode. It will PLA
Y BUTTO N
continue to repeat this same
program until you deactivate REPEAT by pressing the button

again.
The TMS and REPEAT functions
use silent periods on the tape to find
the end of a song or passage. These
features may not work to your satisfaction if there is almost no gap
between selections, a high noise
level between selections, or a silent
period in the middle of a selection.

Comfor t an d Convenienc e Feature s

FAS
T FORWARD /
REWIN D
TM
S

PRO G BUTTO N

REPEAT BUTTO N
DOLB Y ON/OF F BUTTO N

Audi
o Syste m
Thef t Protectio n
Your car's audio system will disable itself if it is disconnected from
electrical power for any reason. Tomake it work again, the user must
enter a specific five-digit code in the
Preset buttons. Because there are
hundreds of number combinations
possible from five digits, making the system work without knowing the
exact code is nearly impossible.
You should have received a card that lists your audio system's codenumber and serial number. It is best
to store this card in a safe place at
home. In addition, you should write
the audio system's serial number in
this Owner's Manual. If you should
happen to lose the card, you must obtain the code number from your
Acura dealer. To do this, you will need the system's serial number. If your car's battery is disconnected
or goes dead, or the radio fuse is
removed, the audio system will disable itself. If this happens, you
will see "Code" in the frequency display the next time you turn on the
system. Use the Preset buttons to
enter the five-digit code. If it is
entered correctly, the radio will start

playing.

If you make a mistake entering the
code, do not start over or try to
correct your mistake. Complete the
five-digit sequence, then enter the correct code. You have three tries to
enter the correct code. If you are
unsuccessful in three attempts, you must then leave the system on for
one hour before trying again. You will have to store your favorite
stations in the Preset buttons after
the system begins working. Your original settings were lost when
power was disconnected.
Comfor t an d Convenienc e Feature s

Engin
e Oi l
The oil container may also display the API Certification seal. Make sure
it says "For Gasoline Engines." The SAE numbers tell you the oil's
viscosity or weight. Select the oil for
your car according to this chart. An oil with a viscosity of 5W-30 is
preferred for improved fuel economyand year-round protection in your
Acura. You may use a 10W-30 oil if the temperature in your area never

goes below 20°F ( — 7°C).

Maintenanc e
AP
I CERTIFICATIO N SEA L Ambien
t Temperatur e

Batter
y

If your car's battery is disconnected or goes dead, the audio system will
disable itself. The next time you turn
on the radio you will see "Code" in
the frequency display. Use the Preset buttons to enter the five-digit
code (see page 119).
Charging the battery with the cables
connected can seriously damage your
car's electronic controls. Detach the
battery cables before connecting the
battery to a charger.

Maintenance

NOTIC
E
