1999 TOYOTA AVALON Owners Manual

’99 AVALON (USA/CANADA)−U
1
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLS—
Chapter 1 −1
Overview of instruments
and controls
 Instrument panel overview
 Instrument cluster overview
 Indicator symbols on the
instrument panel
ProCarManuals.com

’99 AVALON (USA/CANADA)−U
2
Instrument panel overview
1. Side vents
2. Side defroster outlets
3. Tilt steering lock release lever
4. Automatic transmission selector lever
(column shift)
5. Center vents
6. Electric moon roof switch or front interior light, and front personal lights
7. Power door lock switches
8. Power window switches
9. Seat heater switches
10. Glove box 11. Cup holder
12. Automatic transmission selector lever (floor shift)
13. Lower vent
14. Parking brake release lever
15. Parking brake pedal
16. Hood lock release lever
ProCarManuals.com

’99 AVALON (USA/CANADA)−U
3
1. Instrument panel light control dial
2. Headlight and turn signal switch and
front fog light switch
3. Wiper and washer switches
4. Driving pattern selector button
5. Thermometer
6. Clock
7. Emergency flasher switch
8. Car audio
9. Auxiliary box
10. Rear window and outside rear view mirror defoggers switch
11. Ashtray and cigarette lighter
12. Air conditioning controls
13. Ignition switch
14. Cruise control switch
15. Traction control system off switch
16. Power rear view mirror control switch
17. Headlight cleaner switch
ProCarManuals.com

’99 AVALON (USA/CANADA)−U
4
Instrument cluster overview
1. Engine coolant temperature gauge
2. Tachometer
3. Service reminder indicators and
indicator lights 4. Odometer and two trip meters
5. Speedometer
6. Fuel gauge
7. Trip meter reset knob
8. Theft deterrent system/Engine
immobiliser system indicator light
ProCarManuals.com

’99 AVALON (USA/CANADA)−U
5
Indicator symbols on the instrument panel
Brake system warning light∗
1
Seat belt reminder light∗1
Discharge warning light∗1
Malfunction indicator lamp∗1
Low oil pressure warning light∗1
Anti-lock brake system warning light∗1(type A)
(type B)
Open door warning light
∗1
Rear light failure warning light∗1
(type A)
(type B)
SRS airbag warning light
∗1
Low fuel level warning light∗1
Traction control system off indicator/warning
light∗1
Low windshield washer and headlight cleaner
fluid level warning light∗1
ProCarManuals.com

’99 AVALON (USA/CANADA)−U
6
Overdrive
−off indicator light
Cruise control indicator light
∗ 2
Automatic transmission indicator lights
∗1: For details, see ”Service reminder indicators and warning
buzzers” in Chapter 1 −5.
∗
2: If this light flashes, see ”Cruise control” in Chapter 1 −6.
Driving pattern indicator light Headlight high beam indicator light
Slip indicator light
Turn signal indicator lights
ProCarManuals.com

’99 AVALON (USA/CANADA)−U
7
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLS—
Chapter 1 −2
Keys and Doors
 Keys
 Engine immobiliser system
 Side doors
 Power windows
 Trunk lid
 Hood
 Theft deterrent system
 Fuel tank cap
 Electric moon roof
Your vehicle is supplied with two kinds
of key.
1. Master key—This key works in every lock.
2. Sub key—This key will not work in the glove box and trunk.
To protect things locked in the glove box
or trunk when you have your vehicle
parked, leave the sub key with the atten-
dant.
Since the doors and trunk lid can be
locked without a key, you should always
carry a spare master key in case you
accidentally lock your keys inside the ve-
hicle.KEY NUMBER PLATE
Your key number is shown on the plate.
Keep the plate in a safe place such as
your wallet, not in the vehicle.
If you should lose your keys or if you
need additional keys, duplicates can be
made by a Toyota dealer using the key
number.
We recommend you to write down the key
number and keep it in safe place.
Keys (without engine
immobiliser system)
ProCarManuals.com

’99 AVALON (USA/CANADA)−U
8
Your vehicle is supplied with the two
kinds of key.
Master key (black)—This key works in ev-
ery lock. Your Toyota dealer will need it
to make you a new key with built −in
transponder chip.
Sub key (gray)—This key will not work in
the glove box and trunk.
The master key and sub key each have
a transponder chip in their key head
which is very important for the system
function, so be careful not to lose these
keys. If you make your own duplicate key,
you will not be able to cancel the system
or start the engine.
To protect things locked in the glove box
or trunk when you have your vehicle
parked, leave the sub key with the atten-
dant.
Since the doors and trunk lid can be
locked without a key, you should always
carry a spare master key in case you
accidentally lock your keys inside the ve-
hicle.
NOTICE
When using a key containing a trans-
ponder chip, observe the following
precautions:
 When starting the engine, do not
use the key with a key ring resting
on the key grip and do not press
the key ring against the key grip.
Otherwise the engine may not start,
or may stop soon after it starts.
When starting the engine, do not
use the key with other transponder
keys around (including keys of oth-
er vehicles) and do not press other
key plates against the key grip.
Otherwise the engine may not start,
or may stop soon after it starts. If
this happens, remove the key once
and then insert it again after taking
off other transponder keys (includ-
ing keys of other vehicles) from the
ring or while gripping or covering
them with your hand to start the
engine.
Keys (with engine
immobiliser system)
