Tilt steering wheel
To change the steering wheel angle,
hold the steering wheel, pull the lock
release lever toward you, tilt the steer-
ing wheel to the desired angle and re-
turn the lever to its original position.
When the steering wheel is in a low posi-
tion, it will spring up as you release the
lock release lever.
CAUTION

Do not adjust the steering wheel
while the vehicle is moving.
After adjusting the steering wheel,
try moving it up and down to make
sure it is locked in position.
Outside rear view mirrorsÐ
Adjust the mirror so that you can see
the side of your vehicle in the mirror.
Be careful when judging the size or dis-
tance of any object seen in the outside
rear view mirror on the passenger 's side.
It is a convex mirror with a curved sur-
face. Any object seen in a convex mirror
will look smaller and farther away than
when seen in a flat mirror.
On some models, when you push the
back window defogger switch, the heater
panels in the outside rear view mirrors will
quickly clear the surface. To turn on the
back window defogger, see ºBack window
and outside rear view mirror defoggersº in
Chapter 1- 4.
CAUTION
Do not adjust the mirror while the
vehicle is moving. It may cause the
driver to mishandle the vehicle and
an accident may occur resulting in
personal injuries.
On some models, since the mirror
surfaces can get hot, keep your
hands off them when the defogger
switch is on.

4RUNNER ()83
NOTICE
Do not operate the back window wip-er if the back window is dry. It mayscratch the glass.
To defog or defrost the back window,
push the switch with the back window
closed.
The key must be in the ºONº position.
The thin heater wires on the inside of the
back window will quickly clear the surface.
An indicator light will illuminate to indicate
the defogger is operating.
On some models, heater panels in the
outside rear view mirrors will also quickly
clear the surfaces.
Push the switch once again to turn the
defogger off.
The system will automatically shut off af-
ter the defoggers have operated about 15
minutes. Make sure you turn the defoggers off
when the surfaces are clear. Leaving the
defoggers on for a long time could cause
the battery to discharge, especially during
stop- and- go driving. The defoggers are
not designed for drying rain water or for
melting snow.
CAUTION
On some models, since the mirror
surfaces can get hot, keep your
hands off them when the defogger
switch is on.
NOTICE
When cleaning the inside of the back
window, be careful not to scratch ordamage the heater wires.
Back window and outside rear
view mirror defoggers

4RUNNER ()11 7
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1- 7
Car audio system and
Air conditioning system
Car audio system
Reference
Using your audio system:
some basics
Using your audio system:
controls and features
Car audio system operating hints
Air conditioning system
Controls
Air flow selector settings
Operating tips
Instrument panel vents

Rear heater system
Type 1: AMF M ETR radio/cassette player/
compact disc auto changer controller
Type 2: AMF M ETR radio/cassette player/
compact disc auto changer controller Car audio systemÐ
ÐReference

4RUNNER ()
160
ÐRear heater system
1. Fan Speed Selector
2. Temperature Selector
Fan speed selector
Push the switch toward ºHIº or ºLOº.
Temperature selector
Place the lever anywhere except the ºOFFº
position.

4RUNNER ()
220
Cleaning the interior
CAUTION
Do not wash the vehicle floor with
water, or allow water to get onto the
floor when cleaning the vehicle interi-
or or exterior. Water may get into
audio components or other electrical
components above or under the floor
carpet (or mat) and cause a malfunc-
tion; and it may cause body corro-
sion.
Vinyl interior
The vinyl upholstery may be easily
cleaned with a mild soap or detergent
and water.
First vacuum over the upholstery to re-
move loose dirt. Then, using a sponge or
soft cloth, apply the soap solution to the
vinyl. After allowing it to soak in for a few
minutes to loosen the dirt, remove the dirt
and wipe off the soap with a clean damp
cloth. If all the dirt does not come off,
repeat the procedure. Commercial foam-
ing- type vinyl cleaners are also available
which work well. Follow the manufacturer 's
instructions.
NOTICE
Do not use solvent, thinner, gasoline
or window cleaner on the interior.
Carpets
Use a good foam- type shampoo to
clean the carpets.
Begin by vacuuming thoroughly to remove
as much dirt as possible. Several types of
foam cleaners are available; some are in
aerosol cans and others are powders or
liquids which you mix with water to pro-
duce a foam. To shampoo the carpets,
use a sponge or brush to apply the foam.
Rub in overlapping circles.
Do not apply waterÐthe best results are
obtained by keeping the carpet as dry as
possible. Read the shampoo instructions
and follow them closely.
Seat belts
The seat belts may be cleaned with
mild soap and water or with lukewarm
water.
Use a cloth or sponge. As you are clean-
ing, check the belts for excessive wear,
fraying, or cuts.
NOTICE
Do not use dye or bleach on thebeltsÐit may weaken them.
Do not use the belts until they be-come dry.
Windows
The windows may be cleaned with any
household window cleaner.
NOTICE
When cleaning the inside of the win-
dows, be careful not to scratch ordamage the heater wires on the rear window.
Air conditioning control panel, car au-
dio, instrument panel, console panel,
and switches
Use a soft damp cloth for cleaning.
Soak a clean soft cloth in water or luke-
warm water then lightly wipe off dirt.

4RUNNER ()261
Drive belt tension measured with Borroughs
drive belt tension gauge No. BT- 33- 73F
(used belt), Ibf:
3RZ- FE engineGenerator belt
11 5 20
Air conditioning compressor belt
100 20
Power steering pump belt
100 +25
-15
5VZ- FE engine Generator belt
100 20
Air conditioning compressor belt
100 20
Power steering pump belt
100 +20
-15
ENGINE LUBRICATION
Oil capacity (drain and ref ill),
L (qt., Imp. qt.):
3RZ- FE engineWith filter 5.4 (5.7, 4.8)
Without filter 4.7 (5.0, 4.1) 5VZ- FE engine
With filter 5.2 (5.5, 4.6)
Without filter 4.9 (5.2, 4.3)
Oil grade: API grade SJ, ºEnergy- Conservingº or
ILSAC multigrade engine oil is recom-
mended.
Recommended oil viscosity (SAE):
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.): 3RZ- FE engine With rear heater
11.0 (11.6, 9.7)
Without rear heater 10.0 (10.6, 8.8) 5VZ- FE engine
With rear heater 9.0 (9.5, 7.9)
Without rear heater 8.0 (8.5, 7.0)
Coolant type:
ºToyota Long Life Coolantº or equivalent
With ethylene- glycol type coolant for a
proper corrosion protection of aluminum
components
Do not use alcohol type antifreeze or
plain water alone.
BATTERY
Open voltage *
at 20 C (68 F):
12.6Ð12.8 V Fully charged
12.2Ð12.4 V Half charged
11.8Ð12.0 V Discharged
* : Voltage that is checked 20 minutes after
the key is removed with all the lights
turned off
Charging rates: 5 A max.
CLUTCH
Pedal freeplay, mm (in.): 5Ð15 (0.2Ð0.6)
Fluid type: SAE J1703 or FMVSS No.116 DOT 3

4RUNNER ()
264
Fuses
Engine compartment (U.S.A.)
Fuses (type A) 1. ALT- S 7.5 A: Charging system
2. PWR OUTLET 15 A: Power outlets
3. RR HTR 10 A: Rear air conditioning
system
4. MPX- B 15 A: Power back window,
back door lock, back window wiper,
open door warning (back door), power
door lock control system, back window
defogger, horns, theft deterrent systemEngine compartment (Canada)
5. DOME 15 A: Interior lights, personal
lights, luggage compartment light,
clock, car audio system, gauges and
meters, ignition switch light, vanity mir-
ror light, daytime running light
6. OBD 7.5 A: On- board diagnosis sys-
tem
7. EFI 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
8. HEAD(RH) 10 A: Right- hand headlight,
gauges and meters
9. HEAD(LH) 10 A: Left- hand headlightInstrument panel
10. TAIL 10 A: Tail lights, license plate
lights, instrument panel lights
11. A.C 10 A: Air conditioning system
12. MIR HTR 10 A: Outside rear view mir-
ror heaters
13. DEFOG 15 A: Back window defogger
14. FOG 15 A: Front fog lights
15. DRL 7.5 A: Daytime running light sys-
tem
16. HEAD (HI RH) 10 A: Right- hand head-
light (high beam), gauges and meters

4RUNNER ()265
17. HEAD (HI LH) 10 A:
Left- hand head-
light (high beam)
18. HEAD (LO RH) 10 A: Right- hand
headlight (low beam)
19. HEAD (LO LH) 10 A: Left- hand head-
light (low beam)
20. ECU- IG 10 A: Cruise control system,
anti- lock brake system, electronically
controlled automatic transmission sys-
tem, power antenna, power window,
electric moon roof, power back window,
back window defogger, back window
wiper
21. TURN 10 A: Turn signals lights, emer-
gency flashers
22. WIPER 20 A: Windshield wipers and
washer, power door lock control sys-
tem, back window defogger, horns,
theft deterrent system
23. 4WD 20 A: A.D.D. control system,
four- wheel drive control system, rear
differential lock system
24. ACC 15 A: Car audio system, power
antenna, clock, power rear view mirror
control, cigarette lighter, SRS airbag
system, seat belt pretensi oners, elec-
tronically controlled automatic transmis-
sion system, power outlets, theft deter-
rent system 25. GAUGE 10 A:
Gauges and meters,
back window defogger, daytime running
light system, air conditioning system,
cruise control system, rear differential
lock system, electronically controlled
automatic transmission, back- up lights
26. IGN 10 A: SRS airbag system, seat
belt pretensioners, multiport fuel injec-
tion system/sequential multiport fuel in-
jection system, discharge warning light
27. ECU- B 7.5 A: Gauges and meters,
SRS airbag system, seat belt preten-
sioners
28. HORN,HAZ 15 A: Horns, emergency
flashers
29. STA 7.5 A: Starting system
30. STOP 10 A: Stop lights, high- mounted
stoplight
Fuses (type B)
31. HEATER 50 A: Air conditioning system,
all components in ºA.Cº fuse
32. AM1 40 A: Starting system, all compo-
nents in ºACCº, ºGAUGEº, ºTURNº,
ºECU- IGº, ºWIPERº, º4WDº fuses
33. J/B 50 A: All components in ºPOWERº,
ºHORN,HAZº, ºSTOPº, ºECU- Bº fuses 34. AM2 30 A:
Starting system, multiport
fuel injection system/sequential multi-
port fuel injection system, all compo-
nents in ºSTAº, ºIGNº fuses
35. POWER 30 A: Power window, power
back window, electric moon roof, power
seat, back door lock
Fuses (type C)
36. ABS 60 A: Anti- lock brake system
37. ALT 120 A: Charging system, all com-
ponents in ºAM1º, ºHEATERº, ºTAILº,
ºRR HTRº, ºALT- Sº, ºDEFOGº, ºMIR
HTRº and ºACCº fuses
