7B1-64 AUTOMATIC TRANSMISSION (4 A / T)
1. A / T vehicle (output) speed sensor
ªNº reference
line
Center line on
manual valve shaft
G16 / J20
1. Service wire
2. PCM connectors disconnected
Switch
position
TRANSMISSION RANGE SWITCH (SENSOR)
INSPECTION & ADJUSTMENT
1) Shift select lever to ªNº range.
2) Check that center line on manual valve shaft and ªNº reference
line on switch are aligned. If not, loosen switch bolt and align
them.
3) Check that engine starts in ªNº and ªPº ranges but it doesn't start
in ªDº, ª2º, ªLº or ªRº range. Also, check that back-up lamp lights
in ªRº range.
4) If faulty condition cannot be corrected by adjustment, discon-
nect transmission range switch coupler and check that continu-
ity exists as shown by moving select lever.
Terminal No.54982310765498231076
P
R
N
D
2
L
A / T OUTPUT SPEED SENSOR
INSPECTION
Check A / T output speed sensor for resistance between terminals
of sensor or PCM coupler.
A / T output speed sensor
resistance value : 387 ± 473
at 20
C, 68
F
O / D CUT SWITCH
INSPECTION
Check O / D cut switch for operation referring to step 4 of Diag. Flow
Table B-2 in this section.
If malfunction is found, replace.
SOLENOID VALVES
(Shift solenoid valves & TCC solenoid valve)
INSPECTION
With couplers of PCM disconnected and using service wire as
shown at the left, check each solenoid valve for clicking sound.
G16 / J20 Engines
Shift solenoid valve - A (#1)C51-1-2
Shift solenoid valve - B (#2)C51-1-1
TCC (Lock-up) solenoid valveC51-1-8

YH4
GRAND
VITARA
7B1-66 AUTOMATIC TRANSMISSION (4 A / T)
14
2
3
INSTALLATION
Reverse removal procedure to install solenoid valves and noting
the following points.

For details of solenoid valve installation, refer to ªUnit Repairº
section. Use new gasket and O-ring.

Install oil tubes in such order as shown in figure.

For details of oil pan installation, refer to ªUnit Repairº section.
Use new oil pan gasket.

Tighten universal joint flange bolts & nuts and exhaust pipe brack-
et bolts to specified torque.

Fill A / T fluid and check fluid level according to procedure de-
scribed in ªCHANGING FLUIDº previously.

Check for fluid leakage after warming up A / T.
THROTTLE POSITION SENSOR
INSPECTION
Refer to SECTION 6E1 / 6E2 for inspection.
POWER / NORMAL CHANGE SWITCH
INSPECTION
Check Power / Normal change switch for operation referring to Step
4 of Diag. Flow Table B-4 in this section.
If malfunction is found, replace.

YH4
GRAND
VITARA
7B1-76 AUTOMATIC TRANSMISSION (4 A / T)
12) Remove engine to transmission nuts.
13) Disconnect connectors from VSS, output speed sensor, input
speed sensor, TR switch, shift & TCC solenoid valves and oth-
er electrical parts, and release their wire harness from clamps.
14) Apply transmission jack and take off rear mounting member by
removing its bolts.
15) With transmission (and transfer if equipped) assembly held up
on jack, move them to the rear and lower them including torque
converter.
WARNING:
Transmission (and transfer if equipped) assembly may
tilt rearward on jack. It is recommended to use an auxil-
iary arm of jack for the purpose of safety.
AFTER DISMOUNTING
WARNING:
Be sure to keep transmission (and transfer if equipped) as-
sembly horizontal throughout the work. Should they be
tilted, torque converter may fall off and cause personal inju-
ry and A / T fluid may flow out.
1) Remove breather hoses.
2) Remove transfer by removing its bolts, if equipped.

YH4
GRAND
VITARA
1. Speed sensor assembly
2. Transfer
7D-4 TRANSFER
SPEEDOMETER DRIVEN GEAR
REMOVAL
1) Lift up vehicle horizontally or rear up.
2) Disconnect speed sensor coupler at transfer case.
3) Remove bolt and take off speed sensor from transfer.
INSTALLATION
1) Make sure that O-ring and speed sensor have not been dam-
aged.
2) Inspect speedometer driven gear for abnormal wear of gear
teeth or bend of shaft portion and replace it if necessary.
3) Make sure its smooth rotation.
4) Install speed sensor assembly to transfer and connect coupler
as it was.
Tightening Torque
(a): 6 N
.m (0.6 kg-m, 4.5 lb-ft)
ENGINE REAR MOUNTING
Refer to ªON-VEHICLE SERVICEº of Section 7A.

YH4
GRAND
VITARA
1. Wood block
2. Dash panel
t: 45 mm / 1.8 in.
H: 200 mm / 8 in.
W: 100 ± 150 mm / 4 ± 6 in.
1. Transmission jack
2. Engine rear mounting member
3. Gear shift lever case
4. Bolt
TRANSFER 7D-5
TRANSFER ASSEMBLY
Dismounting and remounting of transfer and transmission together
as a unit is described in Section 7A for Manual Transmission or 7B1
for Automatic Transmission, but it is also possible to dismount and
remount transfer assembly by itself as described below.
DISMOUNTING
IN ENGINE ROOM
1) Disconnect negative (±) cable from battery.
2) Remove distributor assembly (if equipped).
3) Place wood block between engine and dash panel so that it
serves as stopper when engine, transmission and transfer unit
hangs down as rear mounting member is removed.
CAUTION:
Make sure to use wood block to prevent contact which
may occur between dash panel and CMP sensor case
(G16), CMP sensor (J20) or intake manifold (H25), and fan
and shroud.
IN CABIN
1) Remove console box.
2) Remove shift lever of transmission and transfer.
ON LIFT
1) Drain transfer oil.
2) Remove rear propeller shaft.
3) Remove front propeller shaft.
4) Disconnect exhaust center pipe.
5) Disconnect speed sensor coupler.
6) Place transmission jack and remove mounting member.
7) Lower transmission jack gradually and check to ensure that
wood block serves as stopper between engine and dash panel.
8) Remove bolts for gear shift lever case.
9) Pull off breather hose.

YH4
GRAND
VITARA
TRANSFER 7D-7
09940-53111
Bearing installer
UNIT REPAIR
Refer to the same section of UNIT REPAIR MANUAL mentioned in FOREWORD of this manual.
TIGHTENING TORQUE SPECIFICATIONS
FasteningportionTightening torqueFastening ortionN.mkg-mlb-ft
Oil filler / level and drain plugs232.317.0
Engine rear mounting bolts505.036.5
Universal joint flange bolts505.036.5
Speed sensor bolt60.64.5
REQUIRED SERVICE MATERIALS
MATERIALRECOMMENDED
SUZUKI PRODUCTUSE
Lithium greaseSUZUKI SUPER GREASE A
(99000-25010)

Oil seal lips and O-rings.

Splines of propeller shaft.

Select return system.

Shift control lever.
SPECIAL TOOL

YH4
GRAND
VITARA
8C
INSTRUMENTATION / DRIVER INFORMATION 8C-1
GENERAL DESCRIPTION8C- 2 . . . . . . . . . . . . . .
Cautions in Servicing 8C- 2. . . . . . . . . . . . . . . . .
Symbols and Marks 8C- 2. . . . . . . . . . . . . . . . . . .
Wiring Color Symbols 8C- 2. . . . . . . . . . . . . . . . .
Abbreviations 8C- 2. . . . . . . . . . . . . . . . . . . . . . . .
Joint Connector 8C- 2. . . . . . . . . . . . . . . . . . . . . .
Fuse Box and Relay 8C- 2. . . . . . . . . . . . . . . . . .
Power Supply Diagram 8C- 2. . . . . . . . . . . . . . . .
Combination Meter 8C- 2. . . . . . . . . . . . . . . . . . .
DIAGNOSIS8C- 4 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speedometer and VSS 8C- 4. . . . . . . . . . . . . . . .
Fuel Meter / Fuel Gauge Unit 8C- 4. . . . . . . . . . . .
Engine Coolant Temp. (ECT) Meter and
Sensor 8C- 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Pressure Light 8C- 4. . . . . . . . . . . . . . . . . . . .
Brake and Parking Brake Warning
Light 8C- 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Light Remainder Warning Buzzer 8C- 5. . . . . . . Seat Belt Warning Light (If Equipped) 8C- 5. . .
Ignition Key Remainder Warning
Buzzer (If Equipped) 8C- 5. . . . . . . . . . . . . . . . .
Cigarette Lighter and Accessory Socket 8C- 5.
ON-VEHICLE SERVICE8C- 6 . . . . . . . . . . . . . . . .
Ignition (Main) Switch 8C- 6. . . . . . . . . . . . . . . . .
Combination Meter 8C- 7. . . . . . . . . . . . . . . . . . .
Speedometer and VSS 8C- 8. . . . . . . . . . . . . . . .
Fuel Meter / Fuel Gauge Unit 8C- 9. . . . . . . . . . . .
Engine Coolant Temp. (ECT) Meter and
Sensor 8C-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Pressure Light 8C-11. . . . . . . . . . . . . . . . . . . .
Brake and Parking Brake Warning
Light 8C-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Key Remainder (If Equipped) /
Light Remainder Warning Buzzer 8C-12. . . . . .
Door Switch 8C-13. . . . . . . . . . . . . . . . . . . . . . . . .
Seat Belt Warning Light (If Equipped) 8C-13. . .
SECTION 8C
INSTRUMENTATION/DRIVER INFORMATION
WARNING:
For vehicles equipped with Supplemental Restraint (Air Bag) System

Service on and around the air bag system components or wiring must be performed only by an autho-
rized SUZUKI dealer. Refer to ªAir Bag System Components and Wiring Location Viewº under ªGener-
al Descriptionº in air bag system section in order to confirm whether you are performing service on
or near the air bag system components or wiring. Please observe all WARNINGS and ªService Precau-
tionsº under ªOn-Vehicle Serviceº in air bag system section before performing service on or around
the air bag system components or wiring. Failure to follow WARNINGS could result in unintentional
activation of the system or could render the system inoperative. Either of these two conditions may
result in severe injury.

Technical service work must be started at least 90 seconds after the ignition switch is turned to the
ªLOCKº position and the negative cable is disconnected from the battery. Otherwise, the system may
be activated by reserve energy in the Sensing and Diagnostic Module (SDM).
