AFTER REPAIR
Side sensor programming not carried out
DF033
present
None.NOTES
The absence of this fault corresponds to the absence of programming for the side sensors identification
by the air bag computer (this identification enables the computer to check that the side sensors are the
correct ones for the vehicle).
This bargraph is normally illuminated when the computer is new (it is sold without identification).
Carry out the identification programming for the side sensors using the "Side sensor programming"
command on the fault finding tool.
Erase the computer memory then switch off the ignition
Carry out a check again using the fault finding tool
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-67

Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Disrupted driver’s side sensor signal (or in open circuit)
DF036
present
None.NOTES
Lock the computer using the command on the fault finding tool.
Check that the driver’s side sensor is connected correctly and check its connection.
Check the condition of the connections on the computer (tracks 20 and 21).
Check the condition of the 50 track connector (locking system, connector,...).
Replace the wiring if the fault persists.
Reconnect the computer and the driver’s side sensor then switch on the ignition.
Erase the computer memory then switch off the ignition. Carry out a check using
the fault finding tool and, in the absence of a fault, unlock the computer.
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-70

Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Driver’s side sensor identification
DF037
present
None.NOTES
This fault is normally present when the computer detects an inconsistency between the recognition signal
emitted by the side sensor and the programming which it has received.
Either the side sensor is not adapted to the vehicle, or the computer comes from another vehicle.
If the sensor has been replaced, fit another sensor adapted to the vehicle.
If the computer comes from another vehicle, use the "Side sensor programming" command on the fault
finding tool to change the computer’s programming.
Erase the computer memory then switch off the ignition
Carry out a check using the fault finding tool and, in the absence of a fault,
unlock the computer.
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-71

Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Driver’s side sensor
DF038
present
None.NOTES
Replace the driver’s side sensor
Erase the computer memory then switch off the ignition
Carry out a check using the fault finding tool and, in the absence of a fault,
unlock the computer.
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-72

Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Driver’s side sensor circuit
DF039
present
None.NOTES
Lock the computer using the fault finding tool command.
Check that the driver’s side sensor is connected correctly and check its connections.
Check the condition of the connections on the computer (tracks 20 and 21).
Check the condition of the 50 track connector (locking system, connections,...).
Replace the wiring if the fault persists.
Reconnect the computer and the driver’s side sensor then switch on the ignition.
Erase the computer memory then switch off the ignition Carry out a check using
the fault finding tool and, in the absence of a fault, unlock the computer.
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-73

Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Passenger’s side sensor circuit
DF040
present
None.NOTES
Lock the computer using the command on the fault finding tool.
Check that the passenger side sensor is connected correctly and check its connections.
Check the condition of the connections on the computer (tracks 22 and 23).
Check the condition of the 50 track connector (locking system, connections,...).
Replace the wiring if the fault persists.
Reconnect the computer and the passenger side sensor then switch on the ignition
again. Erase the computer memory then switch off the ignition.
Carry out a check using the fault finding tool and, in the absence of a fault, unlock
the computer.
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-74

Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Disrupted passenger’s side sensor signal(or in open circuit)DF041
present
None.NOTES
Lock the computer using the command on the fault finding tool.
Check that the passenger side sensor is connected correctly and check its connections.
Check the condition of the connections on the computer (tracks 22 and 23).
Check the condition of the 50 track connector (locking system, connections,...).
Replace the wiring if the fault persists.
Reconnect the computer and the passenger side sensor then switch on the ignition
again.Erase the computer memory then switch off the ignition. Carry out a check using the
fault finding tool and, in the absence of a fault, unlock the computer.
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-75

Downloaded from www.Manualslib.com manuals search engine 1AB8651.0
AFTER REPAIR
Passenger’s side sensor identification
DF042
present
None.NOTES
This fault is normally present when the computer detects an inconsistency between the recognition signal
emitted by the side sensor and the programming which it has received.
Either the side sensor is not adapted to the vehicle, or the computer comes from another vehicle.
If the sensor has been replaced, fit another sensor adapted to the vehicle.
If the computer comes from another vehicle, use the "Side sensor programming" command on the fault
finding tool to change the computer’s programming.
Erase the computer memory then switch off the ignition
Carry out a check using the fault finding tool and, in the absence of a fault,
unlock the computer.
FAULT FINDING - INTERPRETATION OF FAULTS
WIRING
Air bags and seat belt pretensionersSIDE
88
88-76
