key is returned beyond the vertical po-
sition toward the rear of the vehicle to
remove the key, the system may be
deactivated. If the indicator light fails to
glow for 30 seconds, unlock the door
once and lock it again.
IEven when the driver and/or passengers
are in the vehicle, the system will acti-
vate with all doors, hood and trunk lid
locked and ignition key off. Turn the
ignition key to ACC to turn the system
off.
Theft warning system operationThe warning system will give the following
alarm:
IThe headlights blink and the horn sounds
intermittently.
IThe alarm automatically turns off after 2 to
3 minutes. However, the alarm reactivates
if the vehicle is tampered with again. The
alarm can be shut off by unlocking a door or
trunk lid with the key, or by pressing the
button on the multi-remote controller.
The alarm is activated by:
IOpening the door or trunk lid without using
the key (even if the door is unlocked by
releasing the door inside lock switch) oropening the trunk lid by operating the
opener release button.
IOpening the hood.
IPushing in or pulling out of the key cylinder
on the door or trunk lid.
How to stop alarmThe alarm will stop only by unlocking a door or
trunk lid with the key, or by pressing the
button on multi-remote controller. The
alarm will not stop if the ignition switch is
turned to ACC or ON.
If the system does not operate as de-
scribed above, have it checked by your
NISSAN dealer.
NISSAN VEHICLE IMMOBILIZER
SYSTEMThe Nissan Vehicle Immobilizer System will
not allow the engine to start without the use of
the registered Nissan Vehicle Immobilizer Sys-
tem key.
If the engine fails to start using the registered
Nissan Vehicle Immobilizer System key (for
example, when interference is caused by an-
other Nissan Vehicle Immobilizer System key,
an automated toll road device or automated
payment device on the key ring), restart theengine using the following procedures:
1. Leave the ignition switch in the ON position
for approximately 5 seconds.
2. Turn the ignition switch to the OFF or LOCK
position and wait approximately 5 seconds.
3. Repeat step 1 and 2 again.
4. Restart the engine while holding the device
(which may have caused the interference)
separate from the registered Nissan Ve-
hicle Immobilizer System key.
If the no start condition still occurs, NISSAN
recommends placing the registered Nissan
Vehicle Immobilizer System key on a sepa-
rate key ring to avoid interference from
other devices.
Statement related to section 15 of FCC
rules for Nissan Vehicle Immobilizer Sys-
tem (CONT UNIT-IMMOBILIZER, ANT
ASSY-IMMOBILIZER)
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions;
(1) This device may not cause hanmful
interference, and (2) this device must ac-
cept any interference received, including
interference that may cause undesired op-
eration.
Instruments and controls
2-13
Z
01.1.22/A32-D/V5.0
X

Properly secure all cargo to help prevent
it from sliding or shifting. Do not place
cargo higher than the seatbacks. In a
sudden stop or collision, unsecured
cargo could cause personal injury.Pull the armrest forward and lay it horizontal.
Then release the lever (inset) and pull the tray
forward (if so equipped). In this condition you
are able to gain access to the trunk room.
SIC0883
Instruments and controls
2-23
Z
01.1.22/A32-D/V5.0
X

It is possible to lock/unlock all doors, to open
the driver's and front passenger's windows, to
release the trunk lid and to turn on or off the
interior light by using the remote controller
from outside the car.
Be sure to remove the key from the vehicle
before locking the doors and leaving it.
The remote controller can operate at a dis-
tance of approximately 49 ft (15 m) from the
vehicle. (The effective distance depends upon
the conditions around the vehicle.)
As many as four remote controllers can be
used with one vehicle. For information con-
cerning the purchase and use of additional
remote controllers, contact your NISSAN
dealer.Listed below are conditions or occur-
rences which will damage the remote
controller.
IDo not allow the remote controller to
become wet.
IDo not drop the remote controller.
IDo not strike the remote controller
sharply against another object.
IDo not place the remote controller foran extended period in an area where
temperatures exceed 140ÉF (60ÉC).
HOW TO USE MULTI-REMOTE
CONTROL SYSTEM
Locking doors1. Remove the ignition key.
2. Close all of the doors.
3. Push the
button on the multi-remote
controller.
4. All of the doors lock.
5. The hazard indicators flash twice.
When the
button is pushed with all doors
locked, the hazard indicator flashes twice as a
reminder that the doors are already locked.
Unlocking doors1. Push the
button on the multi-remote
controller. Only the driver side door un-
locks.
2. Push thebutton on the multi-remote
controller again within 5 seconds. The pas-
senger doors unlock.
3. The interior light will stay on for 30 secondswhen the interior light switch is in the center
qposition.
The interior light can be turned off without
waiting for 30 seconds by inserting the key into
the ignition or locking the doors with the multi-
remote controller or by pushing the interior
light button to OFF.
Opening the driver's and front
passenger's windows1. Push the
button on the multi-remote
controller for longer than 1.5 seconds after
the driver's door is unlocked.
2. The driver's and front passenger's windows
open.
The driver's and front passenger's windows
also open after all doors are unlocked with
the multi-remote controller.
The driver's and front passenger's win-
dows cannot be closed by using the
multi-remote controller.
Releasing the trunk lid1. Push the
button on the multi-remote
controller for longer than 0.5 second with
the key removed from the key cylinder.
2. The trunk lid opens.
3-6
Pre-driving checks and adjustments
Z
01.1.22/A32-D/V5.0
X

Do not drive with the trunk lid open. This
could allow dangerous exhaust gases to
be drawn into the vehicle. See ªPrecau-
tions when starting and drivingº in the
ª5. Starting and drivingº section for ex-
haust gas.
OPENER OPERATIONType A:
The trunk lid release lever is located on the
outside of the driver's seat. To open the trunk
lid, pull up the trunk lid release lever. To close,push the trunk lid down securely.
Type B:
The trunk lid release button is located under
the driver's arm rest.
To open the trunk lid, push the release button.
To close, push the trunk lid down securely.
SPA0093
TRUNK LID
Pre-driving checks and adjustments
3-9
Z
01.1.22/A32-D/V5.0
X

Cancel leverWhen the lever is in the cancel position, the
trunk lid cannot be opened with the trunk lid
release lever or handle. It can be opened only
with the key.
KEY OPERATIONTo open the trunk lid, turn the key clockwise.
To close, lower and push the trunk lid down
securely.
OPENER OPERATIONType A:
To open the fuel filler lid, pull the opener lever.
To lock, close the fuel filler lid securely.
Type B:
To open the fuel filler lid, push the opener lever
down. To lock, close the fuel filler lid securely.
SPA0095
SPA0094
SPA0096
FUEL FILLER LID
3-10
Pre-driving checks and adjustments
Z
01.1.22/A32-D/V5.0
X

During the normal day-to-day operation of the
vehicle, general maintenance should be per-
formed regularly as prescribed in this section.
If you detect any unusual sounds, vibrations or
smell, be sure to check for the cause or have
your NISSAN dealer do it promptly. In addition,
you should notify your NISSAN dealer if you
think that repairs are required.
When performing any checks or maintenance
work, see ªMaintenance precautionsº in the ª8.
Do-it-yourselfº section.EXPLANATION OF MAINTENANCE
ITEMSAdditional information on the following
items with ª*º is found in the ª8. Do-it-
yourselfº section.Outside the vehicleThe maintenance items listed here should be
performed from time to time, unless otherwise
specified.
Tires*:Check the pressure with a gauge pe-
riodically when at a service station, including
the spare, and adjust to the specified pressure
if necessary. Check carefully for damage, cuts
or excessive wear.
Wheel nuts*:When checking the tires, makesure no nuts are missing, and check for any
loose nuts. Tighten if necessary.
Tire rotation*:Tires should be rotated every
7,500 miles (12,000 km).
Wheel alignment and balance:If the vehicle
pulls to either side while driving on a straight
and level road, or if you detect uneven or
abnormal tire wear, there may be a need for
wheel alignment.
If the steering wheel or seat vibrates at normal
highway speeds, wheel balancing may be
needed.
Windshield wiper blades*:Check for cracks
or wear if they do not wipe properly.
Doors and engine hood:Check that all doors
and the engine hood operate smoothly as well
as the trunk lid or back hatch. Also make sure
that all latches lock securely. Lubricate if nec-
essary. Make sure that the secondary latch
keeps the hood from opening when the pri-
mary latch is released.
When driving in areas using road salt or other
corrosive materials, check lubrication fre-
quently.
Inside the vehicle
The maintenance items listed here should be
checked on a regular basis, such as when
performing periodic maintenance, cleaning the
vehicle, etc.
Lights*:Make sure that the headlights, stop
lights, tail lights, turn signal lights, and other
lights are all operating properly and installed
securely. Also check headlight aim.
Warning lights and chimes:Make sure that
all warning lights and chimes are operating
properly.
Windshield wiper and washer*:Check that
the wipers and washer operate properly and
that the wipers do not streak.
Windshield defroster:Check that the air
comes out of the defroster outlets properly and
in good quantity when operating the heater or
air conditioner.
Steering wheel:Check for changes in the
steering conditions, such as excessive free
play, hard steering or strange noises.
Seats:Check seat position controls such as
seat adjusters, seatback recliner, etc. to en-
sure they operate smoothly and that all latches
lock securely in every position. Check that the
head restraints move up and down smoothly
GENERAL MAINTENANCE
Maintenance
9-3
Z
01.1.22/A32-D/V5.0
X

Fusible links .................................................... 8-22
GGarage door opener, Integrated HomeLinkUniversal Transceiver ..................................... 2-30
Gas cap .......................................................... 3-10
Gauge ............................................................... 2-3
Engine coolant temperature gauge ............. 2-5
Fuel gauge .................................................. 2-5
Odometer..................................................... 2-4
Speedometer ............................................... 2-4
Tachometer ................................................. 2-4
General maintenance ................................ 9-2, 9-3
Glove box........................................................ 2-24
Glove box lock ................................................ 2-24
HHazard warning flasher switch........................ 2-19
Head restraints ................................................. 1-5
Headlamps, (Bulb replacement) ..................... 8-25
Headlight switch .............................................. 2-17
Headlights, (Bulb replacement) ...................... 8-25
Heated seats................................................... 2-20
Heater
Engine coolant heater ............................... 5-21
Heater and air conditioner (automatic)
(if so equipped) ........................................... 4-9
Heater and air conditioner controls ............. 4-3
Heater operation.......................................... 4-3
Operation, Semiautomatic air conditioner ... 4-4
HomeLink
Universal Transceiver .................. 2-30
Hood, release ................................................... 3-8Horn ................................................................ 2-19
How to stop alarm, Theft warning .................. 2-13
I
Ignition switch ................................................... 5-4
Automatic transmission models .................. 5-4
Key positions ............................................... 5-6
Manual transmission models....................... 5-5
Indicator lights and chimes (See warning/
indicator lights and chimes) .............................. 2-9
Inside mirror .................................................... 3-12
Inspection/maintenance (I/M) test................. 10-18
Instrument panel ............................................... 2-2
Integrated HomeLink
Universal
Transceiver ..................................................... 2-30
Interior and cargo light .................................... 2-28
Interior light ..................................................... 2-28
Interior light replacement ................................ 8-26
J
Jump starting .................................................... 6-7
KKeyless entry, (See multi-remote control
system) ............................................................. 3-5
Keys .................................................................. 3-2
LLabel, Air conditioner specification label ...... 10-11
Label, Emission control information label ..... 10-10Label, F.M.V.S.S. certification label.............. 10-10
Labels
Air bag warning labels............................... 1-15
Air conditioner specification label ........ 4-3, 4-9
Engine serial number .............................. 10-10
Vehicle identification number (VIN)........... 10-9
Lamp replacement .......................................... 8-24
License plate, Installing front license plate... 10-11
Light
Air bag warning light ................................. 1-15
Bulb replacement ...................................... 8-24
Fog light switch ......................................... 2-18
Headlamps (Bulb replacement)................. 8-25
Headlight switch ........................................ 2-17
Headlights (Bulb replacement) .................. 8-25
Interior and cargo light .............................. 2-28
Interior light................................................ 2-28
Personal light............................................. 2-28
Trunk light.................................................. 2-29
Vanity mirror light ...................................... 2-29
Warning/indicator lights and chimes .... 2-7, 2-9
Lights, Exterior and interior light
replacement .................................................... 8-26
Loading information (See vehicle loading
information) ................................................... 10-12
Lock
Door locks ................................................... 3-3
Glove box lock........................................... 2-24
Power door lock .......................................... 3-3
Trunk lid lock opener lever.......................... 3-9
Low fuel warning light ....................................... 2-9
Z
01.1.22/A32-D/V5.0
X
11-3

STI0167
Hood release 3-8Meters and gauges 2-3
Trunk release (Type B) 3-9
Trunk release (Type A) 3-9
Seat belt 1-17
Key 3-2
Fuel 3-10, 10-2
Spare tire 6-2, 8-35 Audio system 4-12
Air conditioner 4-3 Engine oil 8-8Engine coolant 8-5 Windshield washer fluid 8-12
Seat 1-2
Z
01.1.22/A32-D/V5.0
X
