Be careful not to burn yourself, as the
engine oil may be hot.4. Wipe the engine oil filter mounting surface
with a clean rag.
Be sure to remove any old rubber gasket
remaining on the mounting surface of the
engine.
5. Coat the rubber gasket on the new filter
with clean engine oil.
6. Screw in the oil filter until a slight resistance
is felt, then tighten additionally more than
2/3 turn.
Oil filter tightening torque:
10.85 to 15.19 ft-lb
(14.7 to 20.6 N×m)
7. Start the engine and check for leakage
around the oil filter. Correct as required.
8. Turn the engine off and wait several min-
utes. Check the oil level. Add engine oil if
necessary.
IWhen engine is running, keep hands,
jewelry and clothing away from any
moving parts such as cooling fan and
drive belt.
IAutomatic transmission fluid is poi-
sonous and should be stored care-
fully in marked containers out of the
reach of children.
TEMPERATURE CONDITIONS
FOR CHECKINGIThe fluid level should be checked using the
HOT range on the dipstick after the follow-
ing conditions have been met:
a) the engine should be warmed up to
operating temperature.
b) the vehicle should be driven at least 5
minutes.
c) the automatic transmission fluid should
be warmed to between 122 and 176ÉF
(50 and 80ÉC).
IThe fluid can be checked at fluid tempera-
tures of 86 to 122ÉF (30 to 50ÉC) using the
COLD range on the dipstick after the en-
gine is warmed up and before driving. How-
ever, the fluid should be re-checked using
the HOT range.
1. Park the vehicle on a level surface and set
the parking brake.
2. Start the engine and then move the selector
lever through each gear range. Move the
selector lever to P (Park) position after you
have moved it through all ranges.
SDI0748
AUTOMATIC TRANSMISSION
FLUID
8-10
Do-it-yourself
Z
01.1.22/A32-D/V5.0
X

CHECKING PARKING BRAKEFrom the released position, pull the parking
brake lever up slowly and firmly. If the number
of clicks is out of the range listed above, see
your NISSAN dealer.
CHECKING BRAKE PEDALWith the engine running, check the distance
between the upper surface of the pedal and
the metal floor. If it is out of the range shown
above, see your NISSAN dealer.Self-adjusting brakesYour vehicle is equipped with self-adjusting
brakes.
The disc-type brakes self-adjust every time the
brake pedal is applied.
See your NISSAN dealer and have it
checked if the brake pedal height does
not return to normal.Brake pad wear indicatorsThe disc brake pads on your vehicle have
audible wear indicators. When a brake pad
requires replacement, it will make a high
pitched scraping or screeching sound when
the vehicle is in motion whether or not the
brake pedal is depressed. Have the brakes
checked as soon as possible if the wear indi-
cator sound is heard.
Under some driving or climate conditions, oc-
casional brake squeak, squeal or other noise
may be heard. Occasional brake noise during
light to moderate stops is normal and does not
affect the function or performance of the brake
system.
Proper brake inspection intervals should
be followed.For additional information, see
ªPeriodic maintenance schedulesº in the ª9.
Maintenanceº section for maintenance inter-
vals.
SDI0125
DI1020MD
PARKING BRAKE AND BRAKE
PEDAL8-20
Do-it-yourself
Z
01.1.22/A32-D/V5.0
X

ENGINE COMPARTMENTIf any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition key and headlight
switch are OFF.
2. Open the engine hood.
3. Remove the fusible link cover.
4. Remove the fuse with the fuse puller.
5. If the fuse is open, replace it with a new
fuse.
6. If a new fuse also opens, have the electricalsystem checked and repaired by your
NISSAN dealer.
Fusible linksIf any electrical equipment does not operate
and fuses are in good condition, check the
fusible links. If any of these fusible links are
melted, replace only with genuine NISSAN
parts.
SDI0126
SDI0128
8-22
Do-it-yourself
Z
01.1.22/A32-D/V5.0
X

During the normal day-to-day operation of the
vehicle, general maintenance should be per-
formed regularly as prescribed in this section.
If you detect any unusual sounds, vibrations or
smell, be sure to check for the cause or have
your NISSAN dealer do it promptly. In addition,
you should notify your NISSAN dealer if you
think that repairs are required.
When performing any checks or maintenance
work, see ªMaintenance precautionsº in the ª8.
Do-it-yourselfº section.EXPLANATION OF MAINTENANCE
ITEMSAdditional information on the following
items with ª*º is found in the ª8. Do-it-
yourselfº section.Outside the vehicleThe maintenance items listed here should be
performed from time to time, unless otherwise
specified.
Tires*:Check the pressure with a gauge pe-
riodically when at a service station, including
the spare, and adjust to the specified pressure
if necessary. Check carefully for damage, cuts
or excessive wear.
Wheel nuts*:When checking the tires, makesure no nuts are missing, and check for any
loose nuts. Tighten if necessary.
Tire rotation*:Tires should be rotated every
7,500 miles (12,000 km).
Wheel alignment and balance:If the vehicle
pulls to either side while driving on a straight
and level road, or if you detect uneven or
abnormal tire wear, there may be a need for
wheel alignment.
If the steering wheel or seat vibrates at normal
highway speeds, wheel balancing may be
needed.
Windshield wiper blades*:Check for cracks
or wear if they do not wipe properly.
Doors and engine hood:Check that all doors
and the engine hood operate smoothly as well
as the trunk lid or back hatch. Also make sure
that all latches lock securely. Lubricate if nec-
essary. Make sure that the secondary latch
keeps the hood from opening when the pri-
mary latch is released.
When driving in areas using road salt or other
corrosive materials, check lubrication fre-
quently.
Inside the vehicle
The maintenance items listed here should be
checked on a regular basis, such as when
performing periodic maintenance, cleaning the
vehicle, etc.
Lights*:Make sure that the headlights, stop
lights, tail lights, turn signal lights, and other
lights are all operating properly and installed
securely. Also check headlight aim.
Warning lights and chimes:Make sure that
all warning lights and chimes are operating
properly.
Windshield wiper and washer*:Check that
the wipers and washer operate properly and
that the wipers do not streak.
Windshield defroster:Check that the air
comes out of the defroster outlets properly and
in good quantity when operating the heater or
air conditioner.
Steering wheel:Check for changes in the
steering conditions, such as excessive free
play, hard steering or strange noises.
Seats:Check seat position controls such as
seat adjusters, seatback recliner, etc. to en-
sure they operate smoothly and that all latches
lock securely in every position. Check that the
head restraints move up and down smoothly
GENERAL MAINTENANCE
Maintenance
9-3
Z
01.1.22/A32-D/V5.0
X

Octane rating tipsIn most parts of North America, you should use
unleaded gasoline with an octane rating of at
least 87 or 91 AKI (Anti-Knock Index) number.
However, you may use unleaded gasoline with
an octane rating as low as 85 AKI number in
these high altitude areas [over 4,000 ft (1,219
m)] such as: Colorado, Montana, New Mexico,
Utah, Wyoming, northeastern Nevada, south-
ern Idaho, western South Dakota, western
Nebraska, and that part of Texas which is
directly south of New Mexico.
Using unleaded gasoline with an octane
rating lower than stated above can cause
persistent, heavy spark knock. (Spark
knock is a metallic rapping noise.) If se-
vere, this can lead to engine damage. If you
detect a persistent heavy spark knock even
when using gasoline of the stated octane
rating, or if you hear steady spark knock
while holding a steady speed on level
roads, have your dealer correct the condi-
tion. Failure to correct the condition is
misuse of the vehicle, for which NISSAN is
not responsible.
Incorrect ignition timing will result in knocking,
after-run or overheating. This in turn may
cause excessive fuel consumption or damageto the engine. If any of the above symptoms
are encountered, have your vehicle checked at
a NISSAN dealer or other competent service
facility.
However, now and then you may notice
light spark knock for a short time while
accelerating or driving up hills. This is no
cause for concern, because you get the
greatest fuel benefit when there is light
spark knock for a short time under heavy
engine load.10-4
Technical and consumer information
Z
01.1.22/A32-D/V5.0
X

11 Index
A
ABS (Anti-lock brake system) ......................... 5-18
Air bag
Warning labels........................................... 1-15
Warning light ...................................... 1-15, 2-8
Air bag system
(See supplemental restraint system) ........ 1-11
Side (See supplemental side air bag
system) ...................................................... 1-12
Air cleaner housing filter ................................. 8-17
Air conditioner
Air conditioner operation ...................... 4-3, 4-9
Air conditioner service ................ 4-3, 4-9, 4-12
Air conditioner specification
label .......................................... 4-3, 4-9, 10-11
Air conditioner system refrigerant and
lubrication recommendations ............... 4-3, 4-9
Heater and air conditioner (automatic)
(if so equipped) ........................................... 4-9
Heater and air conditioner controls ............. 4-3
Servicing air conditioner .............................. 4-3
Air conditioning system refrigerant and
lubricant recommendations ............................. 10-6
Air flow charts ............................................ 4-6, 4-9
Alcohol drugs and driving ................................. 5-3
AM-FM radio with cassette player .................. 4-12
AM-FM radio with cassette player and
compact disc player ........................................ 4-12
AM-FM radio with compact disc player .......... 4-12Ambient temperature switch (AMB),
Air conditioner ................................................. 4-11
Anchor point locations
Top tether strap ......................................... 1-31
Antenna
Manual ....................................................... 4-24
Power ........................................................ 4-24
Anti-lock Brake System (ABS) ........................ 5-18
Appearance care
Exterior appearance care ............................ 7-2
Interior appearance care ............................. 7-4
Armrest ............................................................. 1-6
Ashtray (See cigarette lighter and ashtray) .... 2-21
Audio system .................................................. 4-12
Automatic
Automatic transmission fluid (ATF) ........... 8-10
Driving with automatic transmission............ 5-7
Sunroof ...................................................... 2-26
Avoiding collision and rollover .......................... 5-3
B
Battery............................................................. 8-13
Battery replacement, (See multi-remote control
system) ............................................................. 3-7
Before starting the engine ................................ 5-6
Belts (See drive belts) .................................... 8-15
Brake
Anti-lock brake system (ABS) ................... 5-18
Brake and clutch fluid................................ 8-12Brake booster ............................................ 8-21
Brake pedal ............................................... 8-20
Brake pedal check..................................... 8-20
Parking brake check ........................ 5-12, 8-20
Parking brake operation ............................ 5-12
System....................................................... 5-18
Warning light ............................................... 2-8
Break-in schedule ........................................... 5-15
Bulb check/instrument panel ............................ 2-7
Bulb replacement ............................................ 8-24
C
Capacities and recommended fuel/
lubricants......................................................... 10-2
Car phone ....................................................... 4-25
Cassette player (See audio system) .............. 4-15
Cassette tape operation ................................. 4-12
Catalytic converter, Three way catalyst............ 5-2
CB radio or car phone .................................... 4-25
Child restraints ................................................ 1-24
Installation on front passenger seat .......... 1-32
Precautions on child restraints .................. 1-24
Top tether strap anchor point locations .... 1-31
With top tether strap.................................. 1-30
Child safety ..................................................... 1-19
Child safety rear door lock................................ 3-4
Chimes ............................................................ 2-11
Cigarette lighter (accessory) and ashtray....... 2-21
Circuit breaker, Fusible link ............................ 8-22
Z
01.1.22/A32-D/V5.0
X

Cleaning exterior and interior ........................... 7-4
Clock ............................................................... 2-27
Clutch
Clutch pedal .............................................. 8-21
Fluid ........................................................... 8-12
Cold weather driving ....................................... 5-20
Compact Disc (CD) player (See audio
system) ........................................................... 4-23
Compact disc (CD) player operation .............. 4-12
Compact spare tire ......................................... 8-35
Console box .................................................... 2-25
Controls
Audio controls............................................ 4-12
Audio controls (rear).................................. 4-12
Audio controls (steering wheel)................. 4-12
Heater and air conditioner controls ............. 4-3
Heater and air conditioner controls
(automatic)................................................... 4-9
Heater and semiautomatic air
conditioner ................................................... 4-3
Coolant
Capacities and recommended fuel/
lubricants ................................................... 10-2
Changing engine coolant ............................ 8-6
Checking engine coolant level .................... 8-5
Corrosion protection ......................................... 7-5
Cruise control.................................................. 5-13
Cup holder ...................................................... 2-24
DDaytime running light system ......................... 2-18
Defogger switch, Rear window and outside
mirror defogger switch .................................... 2-16Dimensions and weights ................................. 10-8
Door ajar warning light...................................... 2-8
Drive belts ....................................................... 8-15
Driving
Cold weather driving ................................. 5-20
Driving with automatic transmission............ 5-7
Driving with manual transmission ............. 5-11
Precautions when starting and driving ........ 5-2
E
Economy, Fuel ................................................ 5-15
Emission control information label ................ 10-10
Emission control system warranty ................ 10-18
Engine
Before starting the engine ........................... 5-6
Block heater .............................................. 5-21
Capacities and recommended fuel/
lubricants ................................................... 10-2
Changing engine coolant ............................ 8-6
Changing engine oil .................................... 8-8
Changing engine oil filter ............................ 8-9
Checking engine coolant ............................. 8-5
Checking engine oil level ............................ 8-7
Coolant temperature gauge ........................ 2-5
Engine compartment check locations ......... 8-4
Engine cooling system ................................ 8-5
Engine oil..................................................... 8-7
Engine oil and oil filter recommendation... 10-5
Engine oil viscosity .................................... 10-5
Engine serial number .............................. 10-10
Engine specifications................................. 10-7
If your engine overheats ........................... 6-10
Starting the engine ...................................... 5-7Exhaust gas (Carbon monoxide) ...................... 5-2
F
F.M.V.S.S. certification label......................... 10-10
Filter, Air cleaner housing filter ....................... 8-17
Flashers (See hazard warning flasher
switch) ............................................................. 2-19
Flat tire .............................................................. 6-2
Floor mat cleaning ............................................ 7-4
Fluid
Automatic transmission fluid (ATF) ........... 8-10
Brake and clutch fluid................................ 8-12
Capacities and recommended fuel/
lubricants ................................................... 10-2
Engine coolant............................................. 8-5
Engine oil..................................................... 8-7
Power steering fluid................................... 8-11
Window washer fluid ................................. 8-12
Fog light switch ............................................... 2-18
Front manual seat adjustment .......................... 1-2
Front power seat adjustment ............................ 1-4
Fuel
Capacities and recommended fuel/
lubricants ................................................... 10-2
Filler cap .................................................... 3-10
Filler lid ...................................................... 3-10
Filler lid and cap ........................................ 3-10
Filler lid opener lever................................. 3-10
Fuel economy ............................................ 5-15
Fuel octane rating ..................................... 10-3
Fuel recommendation................................ 10-3
Gauge .......................................................... 2-5
Fuses .............................................................. 8-21
Z
01.1.22/A32-D/V5.0
X
11-2

M
Maintenance
Battery ....................................................... 8-13
Explanation of maintenance items..... 9-3, 9-10
General maintenance........................... 9-2, 9-3
Inside the vehicle ................................. 9-2, 9-3
Maintenance precautions ............................ 8-2
Outside the vehicle .............................. 9-2, 9-3
Periodic maintenance schedules ................ 9-5
Seat belt maintenance .............................. 1-23
Manual antenna .............................................. 4-24
Manual front seat adjustment ........................... 1-2
Meters and gauges ........................................... 2-3
Mirror
Inside mirror .............................................. 3-12
Outside mirror............................................ 3-13
Outside mirror control................................ 3-13
Outside mirrors .......................................... 3-13
Multi-remote control system.............................. 3-5
NNew vehicle break-in ...................................... 5-15
OOdometer .......................................................... 2-4
Oil
Capacities and recommended fuel/
lubricants ................................................... 10-2
Changing engine oil .................................... 8-8
Changing engine oil filter ............................ 8-9
Checking engine oil level ............................ 8-7Engine oil..................................................... 8-7
Engine oil viscosity .................................... 10-5
Outside mirror ................................................. 3-13
Outside mirror control ..................................... 3-13
Outside mirrors ............................................... 3-13
Overdrive switch ............................................. 5-10
Overheat, If your vehicle overheats................ 6-10
P
Parking
Brake check............................................... 8-20
Parking brake check.................................. 5-12
Parking brake operation ............................ 5-12
Parking/parking on hills ............................. 5-12
Parking/parking on hills .................................. 5-16
Periodic maintenance schedules ...................... 9-5
Personal light .................................................. 2-28
Power
Front seat adjustment ................................. 1-4
Power antenna .......................................... 4-24
Power door lock .......................................... 3-3
Power steering fluid................................... 8-11
Power steering system .............................. 5-17
Power windows ......................................... 2-25
Pre-tensioner seat belt system ....................... 1-14
Precautions
Cruise control precautions ........................ 5-13
Maintenance precautions ............................ 8-2
On child restraints ..................................... 1-24
On seat belt usage .................................... 1-17
On supplemental restraint system .............. 1-6
Precautions when starting and driving ........ 5-2Push starting ..................................................... 6-9
R
Radio
AM-FM radio with cassette player ............ 4-12
AM-FM radio with cassette player and
compact disc player .................................. 4-12
AM-FM radio with compact disc player..... 4-12
Cassette player operation ......................... 4-12
CB radio or car phone ..................... 4-12, 4-25
Compact disc (CD) player operation......... 4-12
Readiness for inspection/maintenance (I/M) test
(USA only) .................................................... 10-18
Rear door lock, Child safety rear door lock...... 3-4
Rear window and outside mirror defogger
switch .............................................................. 2-16
Registering your vehicle in another country ... 10-9
Remote keyless entry, (See multi-remote
control system) ................................................. 3-5
Reporting safety defects (USA only) ............ 10-18
Rollover ............................................................. 5-3
SSafety
Child seat belts.......................................... 1-19
Reporting safety defects (USA only)....... 10-18
Towing safety .......................................... 10-14
Seat adjustment
Front manual seat adjustment .................... 1-2
Front power seat adjustment ...................... 1-4
Seat belt extenders......................................... 1-23
Seat belt maintenance .................................... 1-23
Z
01.1.22/A32-D/V5.0
X
11-4
