Power distribution box
The power distribution
box is located in the
engine compartment.
The power distribution
box contains high-
current fuses that
protect your vehicle's
main electrical systems
from overloads.
Always disconnect the battery before
servicing high current fuses.
Always replace the cover to the Power
Distribution Box before reconnecting the
battery or refilling fluid reservoirs.
If the battery has been disconnected and
reconnected, refer to theBatterysection of the
Maintenance and Carechapter.
Roadside emergencies
123
Fuse/
Relay
LocationFuse
Amp
RatingDescription
18 30A* Anti-Lock Brake Module
19 15A* Horn Relay, Powertrain Control
Module (PCM)
20 15A* Headlamp Switch, Autolamp
Park Relay
21 Ð Not Used
22 30A* Autolamps Relay, Multifunction
Switch, Headlamp Switch
23 Ð Blower Motor Relay
24 Ð Starter Relay
25 Ð A/C Clutch Relay
26 30A* Generator
27 10A* A/C Clutch Relay
28 15A* Heated Oxygen Sensors,
Canister Vent
29 Ð Fuel Pump Relay
30 Ð PCM Relay
31 Ð Low Speed Cooling Fan Relay
32 Ð PCM Diode
33 Ð A/C Clutch Diode
34 Ð Not Used
* Mini Fuses ** Maxi Fuses
Relays
Relays are located in the power distribution box and
should be replaced by qualified technicians.
Roadside emergencies
125
Lights, warning and
indicator ...................... 6
air bag ...................... 11
anti-lock brakes
(ABS) ........................ 9
anti-theft ................... 9
brake ........................ 10
charging system ...... 10
cruise indicator ....... 10
door ajar .................... 7
low coolant ................ 9
low fuel ...................... 8
oil pressure ............. 10
safety belt ................. 7
service engine soon .. 7
speed control .......... 44
turn signal indicator . 6
Locks
childproof ................ 51
Lumbar support,
seats ...................... 72,73
Mirrors ....................... 48
heated ...................... 51
side view mirrors
(power) ................... 50
Moon roof .................. 48
Motorcraft parts ...... 162
Octane rating .......... 161
Overdrive ................. 106
Parking brake .......... 103
Power distribution box
(see Fuses) ............. 123
Power door locks ...... 50
Power steering ........ 104
fluid, checking and
adding ............. 146,147
Radio ................ 29,30,31
32,33,34,35,36
Relays ............... 119,125
Remote entry
system ................... 56,58
illuminated entry .... 58locking/unlocking
doors ........................ 57
replacement/additional
transmitters ............. 59
replacing the
batteries .................. 59
Roof rack ................. 117
Safety Compliance
Certification Label .. 187
Safety defects,
reporting .................. 204
Safety restraints ........ 80
cleaning the safety
belts .................. 83,179
extension
assembly .................. 82
for children ........ 88,89
lap belt ............... 78,79
warning light and
chime ....................... 82
Seat belts (see Safety
restraints) ............. 74,75
76,77,78
Seats .......................... 70
child safety seats .... 90
cleaning ................. 179
Servicing your
vehicle ............... 135,136
Spark plugs,
specifications ........... 180
Specification chart,
lubricants ................. 183
Speed control ............ 41
Starting your
vehicle .............. 96,97,98
jump
starting .... 129,130,132
preparing to start
your vehicle ....... 66,68
Steering wheel
tilting ....................... 46
Tires ........... 153,154,155
