1999 LINCOLN CONTINENTAL wipers

HEADLAMP CONTROL
Rotate the headlamp control to the
first position to turn on the parking
lamps only. Rotate to the second
position to also turn on the
headlamps.
The exterior lamps will illuminate when the ignition is ON and the
windshield wiper control is in the interval, LO or HI position.
The instrument panel lighting will dim noticeably approximately 15
seconds after the wipers are turned on. The lights will remain in this
state until 30 seconds after the wipers are turned off.
Daytime running lamps (DRL) (if equipped)
Turns the headlamps on with a reduced output. To activate:
²the engine must be running and
²the headlamp control is in the OFF or Parking lamps position.
Always remember to turn on your headlamps at dusk or during
inclement weather. The Daytime Running Light (DRL) System
does not activate your tail lamps and generally may not provide
adequate lighting during these conditions. Failure to activate your
headlamps under these conditions may result in a collision.
High beams
Push forward to activate.
P
0FF
HI
LO
F
S
OFF
Controls and features
24

WINDSHIELD WIPER/WASHER CONTROLS
Rotate the windshield wiper control
to the desired interval, low or high
speed position.
The bars of varying length are for
intermittent wipers. When in this
position rotate the control upward
for fast intervals and downward for
slow intervals.
Push the control on the end of the
stalk to activate washer. Push and
hold for a longer wash cycle. The
washer will automatically shut off
after ten seconds of continuous use.
Windshield wiper/washer features
The exterior lamps will illuminate when the ignition is ON and the
windshield wiper control is in the interval, LO or HI position.
The instrument panel lighting will dim noticeably approximately 15
seconds after the wipers are turned on. The lights will remain in this
state until 30 seconds after the wipers are turned off.
TURN SIGNAL CONTROL
²Push down to activate the left
turn signal.
²Push up to activate the right turn
signal.
Cornering lamps (if equipped)
When the turn signal is used when the headlamps are on, the cornering
lamps will light either the right or left side depending on the direction of
the turn.
HI
LO
F
S
OFF
HI
LO
F
S
OFF
HI
LO
F
S
OFF
Controls and features
48

2. Locate the compass module
mounted at the base of mirror.
3. Turn the ignition to the ON
position.
4. Insert an appropriate diameter
rod (paperclip) into the right switch
access hole underneath the compass
module and gently press for 1 to 2
seconds until ZONE and the current
zone setting are displayed on the upper right corner of the mirror.
5. Release the switch, then slowly press it down again. Press the switch
repeatedly until the correct zone setting for your geographic location is
displayed on the upper right corner of the mirror.
6. To exit the zone setting mode, release pressure from the switch for
greater than two seconds.
Compass calibration adjustment
Perform this adjustment in an open area free from steel structures and
high voltage lines.
For optimum calibration, turn off all electrical accessories (heater/air
conditioning, wipers, etc.) and make sure all vehicle doors are shut.
1. Start the vehicle.
2. Locate the compass module
mounted on the base of mirror.
3. Insert an appropriate diameter
rod (paperclip) into the left switch
access hole underneath the compass
module.
4. Gently press the switch for 1 to 2
seconds until CAL and a direction
are displayed on the upper right
corner of the mirror. (To exit CAL before performing a compass
adjustment, turn the ignition to OFF.)
Controls and features
72

If the battery has been disconnected or a new battery has been installed,
the clock and the preset radio stations must be reset once the battery is
reconnected.
²Always dispose of automotive
batteries in a responsible manner.
Follow your local authorized
standards for disposal. Call your
local authorized recycling center
to find out more about recycling
automotive batteries.
CABIN AIR FILTER
The cabin air filter restricts the entry of airborne dust and pollen
particles. The filter is located just in front of the windshield under the
cowl vent screen on the passenger side of the vehicle.
To replace the filter, perform the following procedure:
1. In order to gain better access to the filter, turn the ignition key to ON,
then turn the wipers on. When the wipers reach the middle of the
windshield (wipers in straight up position), turn the ignition to OFF.
LEAD
RETURN
RECYCLE
Maintenance and care
166

replacement/additional
transmitters ...............................84
replacing the batteries .............83
Safety belts
(see Safety restraints) .................9
Safety restraints
cleaning the safety
belts ..................................100,193
extension assembly ..................99
for children ......................108,109
lap belt ......................................98
warning light and chime .....9,100
Seat belts (see Safety
restraints) .....................95,96,97,98
Seats ............................................92
child safety seats ....................110
cleaning ............................193,194
Seats-easy access/easyout
feature .........................................95
Servicing your vehicle ..............152
Spark plugs, specifications .......195
Specification chart,
lubricants ...................................196
Speed control ..............................50
Speedometer ...............................11
Starting your vehicle .........115,117
jump starting ............146,147,149
Steering wheel ............................49
tilting .........................................53
Tachometer .................................11
Tires ...............168,169,170,171,172
changing ..................................142
checking the pressure ............172
replacing ..................................173rotating ....................................172
snow tires and chains ............174
tire grades ...............................172
treadwear ................................171
Towing
wrecker ....................................151
Transaxle
fluid, refill capacities ..............195
Transmission .............................162
fluid, checking and adding
(automatic) ......................162,163
Trunk ...........................................82
remote release lever .................77
Turn signal ..................................10
Universal transmitter
(see garage door opener) ....67,68,
69,70
Vehicle dimensions ...................197
Vehicle Identification Number
(VIN) ..........................................200
Vehicle loading .....130,132,133,134
Ventilating your vehicle ...........119
Warning chimes .............................6
Washer fluid ..............................158
Water, Driving through .............130
Wheels
anti-theft lug nuts ..................145
Windows .................................74,75
Windshield washer fluid and
wipers
checking and cleaning ............168
operation ...................................48
replacing wiper blades ...........168
Index
204
