Page 270 of 432
STARTING AND DRIVING
252ºABSº warning light
Page 271 of 432

STARTING AND DRIVING
253
This light comes on when the ignition key is turned to the
ºONº
position. After about a few seconds, the light will go
off.
If either of the following conditions occurs, this indicates a
malfunction somewhere in the parts monitored by the
warning light system. Contact your Lexus dealer as soon as
possible to service the vehicle.
The light does not come on as described above, or remains
on.
The light comes on while driving.
Even if the anti±lock brake system should fail, the brake
system will still operate conventionally. But when the ºABSº
warning light is on (and the brake system warning light is off),
anti±lock brake system is not assisting brake performance so
that the wheels could lock up during a sudden brake or
braking on slippery road surfaces. Have your vehicle
checked by your Lexus dealer as soon as possible.
Drum±in±disc type parking brake system
Your vehicle has a drum±in±disc type parking brake system.
This type of brake system needs bedding±down of the brake
shoes periodically or whenever the parking brake shoes
and/or drums are replaced.
Have your Lexus dealer perform the bedding±down.
Page 331 of 432

MAINTENANCE
313
Vehicle interior
Items listed below should be checked regularly, e.g. while
performing periodic services, cleaning the vehicle, etc.
Lights
Make sure the headlight, stop lights, tail lights, turn signal
lights, and other lights are working. Check headlight aim.
Service reminder indicators and warning buzzers
Check that all service reminder indicators and warning
buzzers function properly.
Steering wheel
Check that it has the specified freeplay. Be alert for changes
in steering condition, such as hard steering, excessive
freeplay or strange noise.
Seats
Check that all front seat controls such as seat adjusters,
seatback recliner, etc. operate smoothly. Check that the head
restraints move up and down smoothly and that the locks hold
securely in any latched position.
Seat belts
Check that the seat belt system s uch as buckles, retractors and
anchors operate properly and smoothly. Make sure the belt
webbing is not cut, frayed, worn or damaged. Accelerator pedal
Check
the pedal for smooth operation and uneven pedal ef fort
or catching.
Brake pedal
Check the pedal for smooth operation and the proper
clearance and freeplay. Check the brake booster function.
Brakes
At a safe place, check that the brakes do not pull to one side
when applied.
Parking brake
Check that the lever has the proper travel and that, on a safe
incline, your vehicle is held securely with only the parking
brake applied.
Automatic transmission ºParkº mechanism
On a safe incline, check that your vehicle is held securely with
the selector lever in ºPº position and all brakes released.
Page 390 of 432

CHASSIS
372
REPLACING WHEELS
When to replace your wheels
If you have wheel damage such as bending, cracks or
heavy corrosion, the wheel should be replaced.
If you fail to replace damaged wheels, a tire may slip off a
wheel or they may cause loss of handling control.
Replacement with used wheels is not recommended as they
may have been subjected to rough treatment or high mileage
and could fail without warning. Also, bent wheels which have
been straightened may have hidden structural damage and
therefore should not be used. Never use an inner tube in a
leaking wheel which is designed for a tubeless tire.
Wheel selection
When replacing wheels, care should be taken to ensure
that they are equivalent to those rem oved in load capacity,
diameter, rim width, and offset.
Correct replacement wheels are available at your Lexus
dealer.
A wheel of a different size or type may adversely affect
handling, wheel and bearing life, brake cooling,
speedometer/odometer calibration, stopping ability,
headlight aim, bumper height, vehicle ground clearance, and
tire or snow chain clearance to the body and chassis.
ALUMINUM WHEEL PRECAUTIONS
After driving your vehicle the first 1600 km (1000 miles),
check that the wheel nuts are tight.
If you have rotated, repaired, or changed your tires, check
that the wheel nuts are still tight after driving 1600 km
(1000 miles).
When using tire chains, be careful not to damage the
aluminum wheels.
Use only the Lexus wheel nuts and wrench designed for
your aluminum wheels.
When balancing your wheels, use only Lexus balance
weights or equivalent and a plastic or rubber hammer.
As with any wheel, periodically check your aluminum
wheels for damage. If damaged, replace immediately.
Page 395 of 432
Engine compartment
ELECTRICAL COMPONENTS
377
No.FUSEAMPERECIRCUIT
1ENGINE7.5Charging system
2HTR10Air conditioning system, rear
window defogger
3WIPER20Windshield wipers and washer
4ST7.5
Starting system, cruise control
system, multiport fuel injection
system/sequential multiport fuel
injection system, instrument panel
lights
5IGN7.5
Discharge warning light, multiport
fuel injection system/sequential
multiport fuel injection system,
SRS airbag system
6PANEL7.5Instrument panel lights, glovebox
light
7MIR±HTR10Outside rear view mirror defogger
8TURN7.5Turn signal lights
9STOP15Stop lights, cruise control system
cancel device
10CIG15
Cigarette lighter, theft deterrent
system, shift lock system, SRS
airbag system, instrument panel
lights
Page 396 of 432
ELECTRICAL COMPONENTS
378
No.FUSEAMPERECIRCUIT
11RADIONO.27.5Radio, cassette tape player,
compact disc player, power
antenna, power rear view mirrors
12TAIL7.5Tail lights, parking lights, side
marker lights, license plate lights
13ECU±IG15
Cruise control system, power
steering control system, shift lock
system, anti±lock brake system,
SRS airbag system, power door
lock system, preset steering system,
traction control system,
electronically controlled
hydraulic±driven cooling system,
passenger 's seat control system
14GAUGE10
Gauges and meters, service
reminder indicators and warning
buzzers (except discharge and open
door warning lights), back±up
lights, electronically controlled
automatic transmission system,
automatic transmission overdrive
system, headlight
15ECU±B15SRS airbag system, power rear
view mirrors
16OBD7.5On±board diagnosis system
17FOG15Fog lights
18SEAT±HT R15Seat heater
Page 397 of 432

ELECTRICAL COMPONENTS
379
No.FUSEAMPERECIRCUIT
19PWR30Preset steering, electronic
moon roof, power windows,
theft deterrent system
20IG SW40Starting system
21DOOR30
Theft deterrent system, seat
control system, fuel opener
control system, power door
lock system
22DOME10
Interior light, personal lights,
door courtesy lights, ignition
switch light, open door
warning light, trunk light,
electronic moon roof system,
preset steering system, seat
belt reminder system, cruise
control system, air
conditioning system, inside
rear view mirror, door lock
and theft deterrent system,
foot light, power rear view
mirror, locking with wireless
remote control system,
passenger 's seat control
system.
23EFI30Multiport fuel injection
system/sequential multiport
fuel injection system
24HAZ±HORN15Emergency flashers, horns
No.FUSEAMPERECIRCUIT
25RADIONO.120Radio, cassette tape player,
compact disc player, power
antenna
26TEL15Telephone
27ALT
SENCING7.5Charging system
28ETCS15Traction control system
29HEAD(RH±LWR)*115Right±hand headlight (low
beam)
30HEAD(LH±LWR)*215Left±hand headlight (low
beam)
30DRL7.5Daytime Running Light
System
29HEAD(RH±LPR)15Right±hand headlight (high
beam)
30HEAD(LH±LPR)15Left±hand headlight (high
beam)
31INJ30SC300
Starting system
*1 SC300: HEAD (RH)
*2 SC300: HEAD (LH)
