1999 Lexus LS400 torque

COMFORT ADJUSTMENT
203
16L040±1

1Bolt 2Anchor bracket 3Spacer
4. Insert a 15 mm (0.6 in.) spacer, and tighten down the
anchor bracket for your child restraint system with a bolt.
Torque the bolt to 16.5 ± 24.7 N´m (1.68 ±2.52 kgf´m,
12.2 ± 18.2 ft´lbf.).
To comply with Canadian Motor Vehicle Safety
Standards, this model sold in Canada is provided with a
bracket set in the glove box, designed for use with any
of the 3 anchor locations shown in the illustration.
DRIVING POSITION MEMORY SYSTEM
The micro computer can memorize the position of the
driver's seat, the height of the shoulder belt anchor of the
driver's seat belt, and the positions of the tilt and
telescopic steering, and outside rear view mirrors. Two
different driving position profiles can be entered into the
computer's memory.
Recording a driving position in the computer's memory
can only be done when the ignition key is in the ºONº
position and the selector lever is in the ºPº position.
Setting a driving position
16L055

IN CASE OF AN EMERGENCY
363
CAUTION
When lowering the vehicle, make sure all portions of
your body and all other persons around will not be
injured as the vehicle is lowered to the ground.
 As soon as possible after changing wheels, have the
wheel nuts tightened by torque wrench at 103 N´m
(10.5 kgf´m, 76 ft´lbf.).
40L015±1
10. Reinstall the wheel ornament.
Put the wheel ornament into position and then tap it
firmly with the side or heel of your hand to snap it into
place.

CHASSIS
416± STEERING
Freeplay
Power steering fluid
Less than 30 mm (1.2 in.)
Automatic transmission fluid DEXRONII or III
± TIRES AND WHEELS
Tire size
Tire inflation pressure Recommended cold tire inflation pressureVehicle load up to four occupants
Vehicle loaded up to vehicle capacity weight
Wheel size
Wheel nut torque
P225/60R16 97V
Front 200 kPa (2.0 kgf/cm
2 or bar, 29 psi)
Rear 200 kPa (2.0 kgf/cm2 or bar, 29 psi)
Front 220 kPa (2.2 kgf/cm
2 or bar, 32 psi)
Rear 220 kPa (2.2 kgf/cm2 or bar, 32 psi)
For sustained high speeds above 160 km/h (100
mph), in countries where such speeds are permitted
by law, add 80 kPa (0.9 kgf/cm
2, 0.8 bar, 12 psi) to the
front tires and rear tires, but never exceed the
maximum cold tire pressure molded on the tire
sidewall.
16 x 7 JJ
103 N´m (10.5 kgf´m, 76 ft´lbf.)
