GAUGES, METERS AND SERVICE REMINDER INDICATORS
58

Low fuel level warning light
The gauge is displayed when the ignition switch is
on and indicates the approximate quantity of fuel
remaining in the tank.
It is a good idea to keep the tank over 1/4 full.
If the fuel level approaches ºEº or the low fuel level
warning light comes on, fill the fuel tank as soon as
possible.
On inclines or curves, due to the movement of fuel in the
tank, the fuel gauge needle may fluctuate or the low fuel
level warning light may come on earlier than usual.
If the fuel tank is completely empty, the malfunction
indicator lamp comes on. Fill the fuel tank immediately.
The indicator lamp goes off after driving several times.
If the indicator lamp does not go off, contact your Lexus
dealer as soon as possible.
See the inner back cover for fuel capacity and
recommended fuel selection.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
67
(e) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn
off the engine, and check for the cause. Look first at the
engine drive belt.
If it is loose or broken, the generator will not charge
the battery properly.
 If the belt is O.K., there is a problem somewhere in the
charging system.
The engine ignition will continue to operate, however,
until the battery is discharged. Turn off the air
conditioning, blower, radio, etc., and drive directly to the
nearest Lexus dealer or repair shop.
NOTICE
Do not continue driving if the engine drive belt is broken or loose.
(f) Malfunction Indicator Lamp
This lamp comes on in the following cases.
a. The fuel tank is completely empty. (See ºFuel gaugeº
on page 57 for instructions.)
b. The fuel tank cap is not tightened securely. (See
ºFuel tank capº on page 110 for instructions.)
c. There is a problem somewhere in your engine
electrical system, automatic transmission electrical
system or electronic throttle control system.
If it comes on while you are driving in case ªc.º, have your
vehicle checked/repaired by your Lexus dealer as soon
as possible.
(g) ºABSº Warning Light
This light warns that there is a problem somewhere in
your anti±lock brake system.
If the light comes on while you are driving, have your
vehicle checked by your Lexus dealer as soon as
possible.
The light will come on when the ignition key is turned to
ºONº, and will go off after about a few seconds.
When the ºABSº warning light is on (and the brake
system warning light is off), the brake system operates
conventionally but anti±lock brake system is not
assisting brake performance so that the wheels could
lock up during a sudden brake or braking on slippery

SECTION 1 ± 5
105
INSTRUMENTS AND CONTROLS
Exterior equipment
Hood105
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Trunk lid 107 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Fuel tank cap 110 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Moon roof 113 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HOOD
15L001
To open the hood, pull the hood lock release lever
under the instrument panel. The hood will spring up
slightly.

EXTERIOR EQUIPMENT
11 0
15L018±1
1 If you do not want to activate the trunk lid
opener system, push in the main switch.
2
To activate the system, insert the master key
and turn it counterclockwise.
To protect things put in the trunk, when you have your
vehicle parked, push in the main switch.
FUEL TANK CAP

EXTERIOR EQUIPMENT
11 2
CAUTION
Do not smoke, cause sparks or allow open flames
when refuelling. The fumes are flammable.
 When opening the cap, do not remove the cap
quickly. In hot weather, fuel under pressure could
cause injury by spraying out of the filler neck if the
cap is suddenly removed.
15L007-1
2. To remove the fuel tank cap, turn the cap slowly
counterclockwise, then pause slightly before
removing it. The removed cap can be stored on the
back side of the fuel filler door.
It is not unusual to hear a slight swoosh when the cap is
opened. When installing the cap, turn the cap clockwise
until you hear a click.
If the cap is not tightened securely, the malfunction
indicator lamp comes on. Make sure the cap is tightened
securely.
The indicator lamp goes off after driving several times.
If the indicator lamp does not go off, contact your Lexus
dealer as soon as possible.

EXTERIOR EQUIPMENT
11 3
CAUTION
Make sure the cap is tightened securely to prevent
fuel spillage in case of an accident.
 Use only a genuine Lexus fuel tank cap for
replacement. It has a built±in check valve to reduce
fuel tank vacuum.
In case the opener is not actuated
15L008-2
Pull the manual lever toward the back.
This is used in case the fuel filler door cannot be opened
due to a discharged battery or other trouble.MOON ROOF

DRIVING TIPS
324
Do not rest your foot on the brake pedal while
driving. It can cause dangerous overheating,
needless wear, and poor fuel economy.
 To drive down a long or steep hill, reduce your
speed and downshift. Remember, if you ride
the brakes excessively, they may overheat and
not work properly. See page 288.
 Be careful when accelerating, upshifting,
downshifting or braking on a slippery surface.
The abrupt change in engine speed, such as
sudden acceleration or engine braking, could
cause the vehicle to spin or skid.
 Do not drive in excess of the speed limit. Even
if the legal speed limit permits it, do not drive
over 140 km/h (85 mph) unless your vehicle has
high±speed capability tires. Driving over 140
km/h (85 mph) may result in tire failure, loss of
control and possible injury. Be sure to consult
a tire dealer to determine whether the tires on
your vehicle are high±speed capability tires or
not before driving at such speeds.
 Do not continue normal driving when the
brakes are w et. If they are wet, your vehicle will
require a longer stopping distance, and it may
pull to one side when the brakes are applied.
Also, the parking brake will not hold the vehicle
securely.WINTER DRIVING TIPS
Make sure you have a proper freeze protection of
engine coolant.
Your coolant must contain ethylene±glycol type coolant
for a proper corrosion protection of aluminum
components. Use ºToyota Long Life Coolantº or
equivalent. See ºChecking the engine coolant levelº on
page 409 for instructions.
NOTICE
Do not use alcohol type antifreeze or plain water
alone.
When it is extremely cold, we recommend to use 60%
solution for your Lexus, to provide protection down to
about ±50 C (±58 F). Do not use more than 70%
solution for better coolant performance.
Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so
it must be in top shape to provide enough power for
winter starting. Page 443 tells you how to visually
inspect the battery. Your Lexus dealer and most service
stations will be pleased to check the battery charge
level.
Make sure the engine oil viscosity is suitable for the
cold weather.

ENGINE
398± COOLING SYSTEM
Capacity
Coolant type
10.8 L (11.4 qt., 10.4 lmp.qt.)
ºToyota Long Life Coolantº or equivalent
With ethylene±glycol type coolant for a proper
corrosion protection of aluminum components
Do not use alcohol type antifreeze or plain water
alone.
± FUELFuel type
Octane rating
Only UNLEADED
91 (Research octane number 96) or higher
± IGNITION SYSTEMSpark plug ± Make DENSO NGK
± Gap
SK20R11
IFR6A11
1.1 mm (0.043 in.)
