Part B: Owner Checks and Services
Listed in this part are owner checks and services which
should be performed at the intervals specified to help
ensure the safety, dependability and emission control
performance of your vehicle.
Be sure any necessary repairs are completed at once.
Whenever any fluids or lubricants are added to your
vehicle, make sure they are the proper ones, as shown in
Part D.
At Each Fuel Fill
It is important for you or a service station attendant to
perform these underhood checks at each fuel fill.
Engine Oil Level Check
Check the engine oil level and add the proper oil if
necessary. See ªEngine Oilº in the Index for
further details.Engine Coolant Level Check
Check the engine coolant level and add DEX
-COOL

coolant mixture if necessary. See ªEngine Coolantº in
the Index for further details.
Windshield Washer Fluid Level Check
Check the windshield washer fluid level in the
windshield washer tank and add the proper fluid if
necessary. See ªWindshield Washer Fluidº in the Index
for further details.
At Least Once a Month
Tire Inflation Check
Make sure tires are inflated to the correct pressures.
See ªTiresº in the Index for further details.
Cassette Deck Service
Clean cassette deck. Cleaning should be done every
50 hours of tape play. See ªAudio Systemsº in the Index
for further details.

yellowblue
7-41 At Least Twice a Year
Restraint System Check
Make sure the safety belt reminder light and all your
belts, buckles, latch plates, retractors and anchorages are
working properly. Look for any other loose or damaged
safety belt system parts. If you see anything that might
keep a safety belt system from doing its job, have it
repaired. Have any torn or frayed safety belts replaced.
Also look for any opened or broken air bag coverings,
and have them repaired or replaced. (The air bag system
does not need regular maintenance.)
Wiper Blade Check
Inspect wiper blades for wear or cracking. Replace blade
inserts that appear worn or damaged or that streak or
miss areas of the windshield. Also see ªWiper Blades,
Cleaningº in the Index.
Weatherstrip Lubrication
Silicone grease on weatherstrips will make them last
longer, seal better, and not stick or squeak. Apply
silicone grease with a clean cloth. During very cold,
damp weather more frequent application may be
required. (See ªRecommended Fluids and Lubricantsº in
the Index.)Manual Transmission Check
Check the transmission fluid level; add if needed.
See ªManual Transmission Fluidº in the Index. Check
for leaks. A fluid loss may indicate a problem. Have the
system inspected and repaired if needed.
Automatic Transmission Check
Check the transmission fluid level; add if needed. See
ªAutomatic Transmission Fluidº in the Index. A fluid
loss may indicate a problem. Check the system and
repair if needed.
Hydraulic Clutch System Check
Check the fluid level in the clutch reservoir. See
ªHydraulic Clutch Fluidº in the Index. A fluid loss in
this system could indicate a problem. Have the system
inspected and repaired at once.

yellowblue
7-42 At Least Once a Year
Key Lock Cylinders Service
Lubricate the key lock cylinders with the lubricant
specified in Part D.
Body Lubrication Service
Lubricate all hood hinges, hood latch assembly,
secondary latch, pivots, spring anchor, release pawl,
door hinges, fuel door hinge, endgate hinges, outer
tailgate handle pivot points, tailgate hinges, tailgate
mounted spare tire carrier (if equipped), glove box,
console doors, moving seat hardware and folding seat
hardware. Part D tells you what to use. More frequent
lubrication may be required when exposed to a
corrosive environment.Starter Switch CheckCAUTION:
When you are doing this check, the vehicle could
move suddenly. If it does, you or others could be
injured. Follow the steps below.
1. Before you start, be sure you have enough room
around the vehicle.
2. Firmly apply both the parking brake (see ªParking
Brakeº in the Index if necessary) and the regular brake.
NOTE: Do not use the accelerator pedal, and be
ready to turn off the engine immediately if it starts.
3. On automatic transmission vehicles, try to start the
engine in each gear. The starter should work only in
PARK (P) or NEUTRAL (N). If the starter works in
any other position, your vehicle needs service.
On manual transmission vehicles, put the shift lever
in NEUTRAL (N), push the clutch down halfway
and try to start the engine. The starter should work
only when the clutch is pushed down all the way to
the floor. If the starter works when the clutch isn't
pushed all the way down, your vehicle needs service.

yellowblue
7-43
Brake-Transmission Shift Interlock (BTSI) Check
(Automatic Transmission)
CAUTION:
When you are doing this check, the vehicle could
move suddenly. If it does, you or others could be
injured. Follow the steps below.
1. Before you start, be sure you have enough
room around the vehicle. It should be parked on a
level surface.
2. Firmly apply the parking brake (see ªParking Brakeº
in the Index if necessary).
NOTE: Be ready to apply the regular brake
immediately if the vehicle begins to move.
3. With the engine off, turn the key to the RUN
position, but don't start the engine. Without applying
the regular brake, try to move the shift lever out of
PARK (P) with normal effort. If the shift lever
moves out of PARK (P), your vehicle's BTSI
needs service.Ignition Transmission Lock Check
While parked, and with the parking brake set, try to turn
the ignition key to LOCK in each shift lever position.

With an automatic transmission, the key should turn
to LOCK only when the shift lever is in PARK (P).

With a manual transmission, the key should turn to
LOCK only when you press the key release button.
On all vehicles, the key should come out only in LOCK.

yellowblue
7-45
Part C: Periodic Maintenance
Inspections
Listed in this part are inspections and services which
should be performed at least twice a year (for instance,
each spring and fall). You should let your dealer's
service department or other qualified service center do
these jobs. Make sure any necessary repairs are
completed at once.
Proper procedures to perform these services may be
found in a service manual. See ªService and Owner
Publicationsº in the Index.
Steering, Suspension and Front Drive Axle
Boot and Seal Inspection
Inspect the front and rear suspension and steering
system for damaged, loose or missing parts, signs of
wear or lack of lubrication. Inspect the power steering
lines and hoses for proper hook
-up, binding, leaks,
cracks, chafing, etc. Clean and then inspect the drive
axle boot seals for damage, tears or leakage. Replace
seals if necessary.
Exhaust System Inspection
Inspect the complete exhaust system. Inspect the body
near the exhaust system. Look for broken, damaged,
missing or out
-of-position parts as well as open seams,
holes, loose connections or other conditions which could
cause a heat build
-up in the floor pan or could let
exhaust fumes into the vehicle. See ªEngine Exhaustº in
the Index.
Engine Cooling System Inspection
Inspect the hoses and have them replaced if they are
cracked, swollen or deteriorated. Inspect all pipes,
fittings and clamps; replace as needed. Clean the outside
of the radiator and air conditioning condenser. To help
ensure proper operation, a pressure test of the cooling
system and pressure cap is recommended at least once
a year.

yellowblue
7-47
Part D: Recommended Fluids
and Lubricants
NOTE: Fluids and lubricants identified below by name,
part number or specification may be obtained from
your dealer.
USAGE
FLUID/LUBRICANT
Engine OilEngine Oil with the American
Petroleum Institute Certified For
Gasoline Engines ªStarburstº
symbol of the proper viscosity. To
determine the preferred viscosity
for your vehicle's engine, see
ªEngine Oilº in the Index.
Engine Coolant50/50 mixture of clean, drinkable
water and use only GM
Goodwrench

DEX-COOL
or
Havoline
DEX-COOL

Coolant. See ªEngine Coolantº in
the Index.
Hydraulic Brake
SystemDelco Supreme 11
Brake Fluid
(GM Part No. 12377967 or
equivalent DOT
-3 Brake Fluid).
USAGEFLUID/LUBRICANT
Windshield
Washer SolventGM Optikleen
Washer Solvent
(GM Part No. 1051515)
or equivalent.
Hydraulic Clutch
SystemHydraulic Clutch Fluid (GM Part
No. 12345347 or equivalent
DOT
-3 Brake Fluid).
Parking Brake
Cable GuidesChassis Lubricant (GM Part
No. 12377985 or equivalent) or
lubricant meeting requirements of
NLGI # 2, Category LB or
GC
-LB.
Power Steering
SystemGM Power Steering Fluid (GM
Part No. 1052884
- 1 pint,
1050017
- 1 quart, or equivalent).
Manual
TransmissionSynchromesh Transmission Fluid
(GM Part No. 12345349
or equivalent).
Automatic
TransmissionDEXRON
-III Automatic
Transmission Fluid.
Key Lock
CylindersMulti-Purpose Lubricant,
Superlube
(GM Part
No. 12346241 or equivalent).

9-yellowblue
9-1
Section 9 Index
A
ccessory Power Outlets 2-67 . . . . . . . . . . . . . . . . . . . . . . . .
Adding Equipment to the Outside of Your Vehicle 6-3 . . . . . .
Adding Sound Equipment 3-41 . . . . . . . . . . . . . . . . . . . . . . . .
Add-On Equipment 4-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Bag
Adding Equipment 1
-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How Does it Restrain 1-28 . . . . . . . . . . . . . . . . . . . . . . . . . .
How it Works 1-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Location 1-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Readiness Light 1-25, 2-77 . . . . . . . . . . . . . . . . . . . . . . . . .
Servicing 1-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System 1-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What Makes it Inflate 1-27 . . . . . . . . . . . . . . . . . . . . . . . . . .
What You See After it Inflates 1-28 . . . . . . . . . . . . . . . . . . .
When Should it Inflate 1-27 . . . . . . . . . . . . . . . . . . . . . . . . .
Air Cleaner Filter 6-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning 3-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning Refrigerants 6-66 . . . . . . . . . . . . . . . . . . . . .
Alignment and Balance, Tire 6-47 . . . . . . . . . . . . . . . . . . . . . .
Aluminum Wheels, Cleaning 6-55 . . . . . . . . . . . . . . . . . . . . . .
Antenna, Fixed 3-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock Brake System Warning Light 2-80, 4-7 . . . . . . . . .
Anti-Lock Brakes 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appearance Care 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appearance Care and Materials 6-57 . . . . . . . . . . . . . . . . . . . . Arbitration Program 8
-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Armrest, Storage 2-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ashtrays 2-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio Steering Wheel Controls 3-40 . . . . . . . . . . . . . . . . . . . .
Audio Systems 3-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic Headlamp System 2-49 . . . . . . . . . . . . . . . . . . . . . .
Automatic Transmission
Check 7
-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 2-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Park Mechanism Check 7-44 . . . . . . . . . . . . . . . . . . . . . . . .
Shifting 2-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your Engine 2-19 . . . . . . . . . . . . . . . . . . . . . . . . . .
Axle
Front 6
-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear 6-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Backglass Wiper, Blade Replacement 6-41 . . . . . . . . . . . . . .
Battery 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charge Light 2-77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement, Keyless Entry 2-8 . . . . . . . . . . . . . . . . . . . . .
Run-Down Protection 2-52 . . . . . . . . . . . . . . . . . . . . . . . . .
Warnings 5-3, 5-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
