MOTOCRAFT PART NUMBERS
Component 2.0L SOHC I4 engine 2.0L DOHC Zetec engine
Air filter element FA-1643 FA-1643
Fuel filter FG-862 FG-862
Battery BXT-58 BXT-58
Oil filter FL-400±A FL-2005
PCV valve EV-224 EV-224
Spark plugs* AGSF-34EE** AZFS-32PP**
* Refer to Vehicle Emissions Control Information (VECI) decal for spark
plug gap information.
** If a spark plug is removed for inspection, it must be reinstalled in the
same cylinder.If a spark plug needs to be replaced, use only spark plugs
with the same service part number suffix letter as shown on the engine
decal.
REFILL CAPACITIES
FluidFord Part
NameApplication Capacity
Brake fluid High
Performance
DOT 3 Motor
Vehicle Brake
FluidAll Fill to line on
reservoir
Engine coolant
1Premium Engine
CoolantAutomatic
transaxles6.0L
(6.3 quarts)
Manual
transaxles5.0L
(5.3 quarts)
Engine oil
(includes filter
change)Motorcraft
5W-30 Super
Premium Motor
OilZX2 4.25L
(4.5 quarts)
Sedan/wagon 3.8L
(4.0 quarts)
Fuel tank
capacityN/A All 48.5L
(12.8 gallons)
Power steering
fluidMotorcraft
MERCONtAT FAll Fill to line on
reservoir
Capacities and specifications
174
illuminated entry ......................58
locking/unlocking doors ......55,56
opening the trunk .....................56
panic alarm ...............................57
replacement/additional
transmitters ...............................58
replacing the batteries .............57
Roof rack ...................................104
Safety belts (see Safety
restraints) ................10,65,66,67,68
Safety Compliance
Certification Label ....................180
Safety defects, reporting ..........193
Safety restraints ...........65,66,67,68
cleaning the safety belts ...70,173
extension assembly ..................69
for adults ..............................66,67
for children ..........................75,76
lap belt ......................................68
warning light
and chime .....................8,10,69,70
Safety seats for children ............77
Seat belts
(see Safety restraints) ...............65
Seats ............................................61
child safety seats ......................77
cleaning ...................................173
Servicing your vehicle ..............123
Spark plugs,
specifications ...............174,176,177
Specification chart,
lubricants ............................175,176
Speed control ..............................44
Speedometer ...............................13
Starting your vehicle .............83,86
jump starting ..........................117
Steering wheel
tilting .........................................48
Tachometer .................................13
Tilt steering wheel ......................48
Tires .............................113,148,149changing ...........................113,114
checking the pressure ............149
replacing ..................................150
rotating ....................................149
snow tires and chains ............151
tire grades ...............................149
treadwear ................................148
Towing
wrecker ....................................122
Transaxle .....................................92
automatic operation .................95
fluid, refill capacities ..............174
lubricant specifications ..........176
manual operation ......................92
Transmission
fluid, checking and adding
(automatic) .............................141
fluid, checking and adding
(manual) .................................143
Trip odometer .............................13
Trunk
remote release .....................15,56
Turn signal ...............................9,43
Vehicle dimensions ...................177
Vehicle Identification Number
(VIN) ..........................................180
Vehicle loading ..........................100
Ventilating your vehicle .............88
Warning chimes ...........................10
Warning lights (see Lights) .........6
Washer fluid ..............................136
Water, Driving through .............102
Windows
power .........................................53
rear wiper/washer .....................50
Windshield washer fluid and
wipers
checking and cleaning ............147
operation ...................................49
replacing wiper blades ...........147
Wrecker towing .........................122
Index
197
