1999 CHEVROLET VENTURE ECO mode

yellowblue
3-3
DEFOG: This setting directs air to the windshield
and through the floor ducts. This mode is particularly
useful during cold or inclement weather because of your
vehicle's larger windshield area.
DEFROST: This setting directs most of the air to
the windshield and side window vents.
Mode Buttons
RECIRCULATION: Press this button (the light
will glow) to limit the amount of fresh air entering your
vehicle by recirculating much of the air inside your
vehicle. You may use this setting to limit odors entering
your vehicle. Press the OUTSIDE AIR button (the light
on the RECIRCULATION button will go off) to let
outside air circulate into the vehicle.
OUTSIDE AIR: Press this button (the light will
glow) to send outside air into your vehicle. Using this
setting while trying to defrost or defog the windows will
help clear the vents of moisture. Press the
RECIRCULATION button (the light on the OUTSIDE
AIR button will go off) to limit outside air entering the
vehicle. When the DEFOG or DEFROST setting is
selected, the system will automatically go to
OUTSIDE AIR mode.
Air Conditioning
On very hot days, your vehicle will cool down more
quickly and economically if you open the windows long
enough to let hot, inside air escape. For all settings,
adjust the temperature control knob and fan speed
as desired.
To get maximum cooling or a quick cool
-down on very
hot days, press the A/C and RECIRCULATION buttons
(the lights will glow) and turn the temperature knob
counterclockwise (toward the blue area). Adjust the
mode knob to direct the air to the desired location.
This setting should not be used for long periods of time
because the air may become too cold and dry. Push the
A/C button again (the light will go off) to turn off the
air conditioning.
When the air conditioner compressor is on, you may
sometimes notice slight changes in your vehicle's engine
performance and power. This is normal. The system is
designed to help fuel economy while it maintains the
desired cooling level.
The air conditioner removes moisture from the air, so
you may sometimes notice water dripping from under
your vehicle's engine compartment when it is idling or
after it has been turned off. This is normal.

yellowblue
3-7
Turn the temperature knob counterclockwise (to the blue
area) for cooler air, or clockwise (to the red area) for
warmer air.
To maintain a comfortable temperature in the rear, use
either rear fan control to adjust the force of air coming
through the rear outlets.
Select the desired climate control mode using the
directional controls on the instrument panel (see ªMode
Knobº earlier in this section). The mode you choose will
regulate both the front and rear climate control systems.Rear Air Vents
To maximize airflow through the rear heater outlet,
place the left bucket seat in the second row in the
forward position (see ªAdjusting Rear Seatsº in
the Index).
The vent behind the left rear seat is the cold air return
vent. Be sure to keep it free of obstructions.
Keep the area around the base of the center instrument
panel console and between and under the front seats free
of objects that could obstruct airflow to the rear.

yellowblue
3-16
P.SCAN: Press this button to listen to each of your
favorite stations stored on your pushbuttons for a few
seconds. The radio will scan through each of the stations
stored on your pushbuttons, except those stations with
weak reception. The AUTO TONE setting stored for
that pushbutton will be automatically chosen. Press
P.SCAN or one of the pushbuttons again to stop
scanning. P.SCAN will be displayed whenever the tuner
is in the P.SCAN mode. The channel number (P1
-P6)
will appear momentarily just before the frequency is
displayed. In FM mode, this function will scan through
both FM1 and FM2 preset stations and FM1 or FM2 will
appear on the display.
Setting the Tone
BASS: Press this knob lightly so it extends. Turn the
knob clockwise to increase bass and counterclockwise to
decrease bass. When you use this control, the radio's
AUTO TONE setting will switch to manual and the
AUTO TONE display will go blank.
TREB: Press this knob lightly so it extends. Turn the
knob clockwise to increase treble and counterclockwise
to decrease treble. When you use this control, the radio's
AUTO TONE setting will switch to manual and the
AUTO TONE display will go blank. If a station is weak
or noisy, you may want to decrease the treble.Push these knobs back into their stored positions when
you're not using them.
AUTO TONE: This feature allows you to choose preset
bass and treble equalization settings designed for
country/western, classical, news, rock, pop and jazz
stations. C/W will appear on the display when you first
press AUTO TONE. Each time you press it, another
setting will appear on the display. Press it again after
JAZZ appears and the AUTO TONE display will go
blank. Tone control will return to the BASS and TREB
knobs. Also, if you use the BASS and TREB knobs,
control will return to them and the AUTO TONE display
will go blank. Use PUSHBUTTONS and AUTO TONE
button to program AUTO TONE for station presets.
Adjusting the Speakers
BAL: Press this knob lightly so it extends. Turn the
knob clockwise for the right speakers and
counterclockwise for the left speakers. The middle
position balances the sound between the speakers.
FADE: Press this knob lightly so it extends. Turn the
knob clockwise to adjust the sound to the front speakers
and counterclockwise for the rear speakers. The middle
position balances the sound between the speakers.
Push these knobs back into their stored positions when
you're not using them.

yellowblue
3-21
P.SCAN: Press this button to listen to each of your
favorite stations stored on your pushbuttons for a few
seconds. The radio will scan through each of the stations
stored on your pushbuttons, except those stations with
weak reception. The AUTO TONE setting stored for
that pushbutton will be automatically chosen. Press
P.SCAN or one of the pushbuttons again to stop
scanning. P.SCAN will be displayed whenever the tuner
is in the P.SCAN mode. The channel number (P1
-P6)
will appear momentarily just before the frequency is
displayed. In FM mode, this function will scan through
both FM1 and FM2 preset stations and FM1 or FM2 will
appear on the display.
Setting the Tone
BASS: Press this knob lightly so it extends. Turn the
knob clockwise to increase bass and counterclockwise to
decrease bass. When you use this control, the radio's
AUTO TONE setting will switch to manual and the
AUTO TONE display will go blank.
TREB: Press this knob lightly so it extends. Turn the
knob clockwise to increase treble and counterclockwise
to decrease treble. When you use this control, the radio's
AUTO TONE setting will switch to manual and the
AUTO TONE display will go blank. If a station is weak
or noisy, you may want to decrease the treble.Push these knobs back into their stored positions when
you're not using them.
AUTO TONE: This feature allows you to choose preset
bass and treble equalization settings designed for
country/western, classical, news, rock, pop and jazz
stations. C/W will appear on the display when you first
press AUTO TONE. Each time you press it, another
setting will appear on the display. Press it again after
JAZZ appears and the AUTO TONE display will go
blank. Tone control will return to the BASS and TREB
knobs. Also, if you use the BASS and TREB knobs,
control will return to them and the AUTO TONE display
will go blank. Use PUSHBUTTONS and AUTO TONE
button to program AUTO TONE for station presets.
Adjusting the Speakers
BAL: Press this knob lightly so it extends. Turn the
knob clockwise for the right speakers and
counterclockwise for the left speakers. The middle
position balances the sound between the speakers.
FADE: Press this knob lightly so it extends. Turn the
knob clockwise to adjust the sound to the front speakers
and counterclockwise for the rear speakers. The middle
position balances the sound between the speakers.
Push these knobs back into their stored positions when
you're not using them.

yellowblue
3-26
PREV (1): Press this button to go back to the start of
the current track if more than eight seconds have played.
Press PREV again to go to the previous track on
the disc.
NEXT (3): Press this button to advance to the next track
on the disc.
REV (4): Press and hold this button to quickly reverse
within a track. As the CD reverses, elapsed time will be
displayed to help you find the correct passage.
FWD (6): Press and hold this button to quickly advance
within a track. As the CD advances, elapsed time will be
displayed to help you find the correct passage.
SEEK: Press the left arrow while playing a CD to go
back to the start of the current track. It will go back to
the current track if more than eight seconds have played.
Press the left arrow again to go to previous tracks. Press
the right arrow to go to the next higher track on the disc.RANDOM: Press P.SCAN to enter the random play
mode. RANDOM will appear on the display. While in
this mode, the tracks on the disc will be played in
random order. If you press SEEK, PREV or NEXT
while in the random mode, the PREV or NEXT track
will be scanned randomly. Press P.SCAN again to turn
off RANDOM and return to normal operation.
RECALL: Press this button to see what track is
currently playing. Press RECALL again within five
seconds to see how long the track has been playing.
When a new track starts to play, the track number will
also appear. Press RECALL a third time and the time of
day will be displayed.
TAPE AUX: With a disc loaded in the player and the
radio playing, press this button once to play the compact
disc. To return to playing the radio, press AM
-FM. If
both a cassette tape and CD are loaded, press TAPE
AUX to switch between the tape and compact disc.
EJECT: Press this button on the remote player to eject a
compact disc.

yellowblue
5-12
If you get the overheat warning with no sign of steam,
try this for a minute or so:
1. If your air conditioner is on, turn it off.
2. Turn on your heater to full hot at the highest fan
speed and open the window as necessary.
3. If you're in a traffic jam, shift to NEUTRAL (N);
otherwise, shift to the highest gear while
driving
-- AUTOMATIC OVERDRIVE (D) or
THIRD (3).
If you no longer have the overheat warning, you can
drive. Just to be safe, drive slower for about 10 minutes.
If the warning doesn't come back on, you can
drive normally.
If the warning continues, pull over, stop, and park your
vehicle right away.
If there's still no sign of steam, idle the engine for three
minutes while you're parked. If you still have the
warning, turn off the engine and get everyone out of the
vehicle until it cools down. Also, see ªOverheated
Engine Protection Operating Modeº listed previously in
this section.
You may decide not to lift the hood but to get service
help right away.
Cooling System
When you decide it's safe to lift the hood, here's what
you'll see:
A. Radiator Pressure Cap
B. Electric Engine Cooling Fans
C. Coolant Recovery Tank
CAUTION:
An electric engine cooling fan under the hood can
start up even when the engine is not running and
can injure you. Keep hands, clothing and tools
away from any underhood electric fan.

yellowblue
5-13
If the coolant inside the coolant recovery tank is boiling,
don't do anything else until it cools down.
The coolant level should be at or above the FULL
COLD mark. If it isn't, you may have a leak in the
radiator hoses, heater hoses, radiator, water pump or
somewhere else in the cooling system.
CAUTION:
Heater and radiator hoses, and other engine
parts, can be very hot. Don't touch them. If you
do, you can be burned.
Don't run the engine if there is a leak. If you run
the engine, it could lose all coolant. That could
cause an engine fire, and you could be burned.
Get any leak fixed before you drive the vehicle.
NOTICE:
Engine damage from running your engine
without coolant isn't covered by your warranty.
See ªOverheated Engine Protection Operating
Modeº in the Index.

yellowblue
9-7
Oil Pressure 2-98 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PASS-Key III Security 2-100 . . . . . . . . . . . . . . . . . . . . . . . .
Power Sliding Door Light 2-99 . . . . . . . . . . . . . . . . . . . . . .
Safety Belt Reminder 1-23, 2-88 . . . . . . . . . . . . . . . . . . . . .
Service Engine Soon 2-95 . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction Control System Warning 2-92, 4-10 . . . . . . . . . . .
Loading Your Vehicle 4-29 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lockout Deterrent 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Locks
Automatic Door 2
-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Canceling the Sliding Door Security 2-31 . . . . . . . . . . . . . .
Cylinders 7-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door 2-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Transaxle Check 7-33 . . . . . . . . . . . . . . . . . . . . . . .
Key Lock Cylinder Service 7-31 . . . . . . . . . . . . . . . . . . . . .
Last Door Closed Locking 2-6 . . . . . . . . . . . . . . . . . . . . . . .
Lockout Deterrent 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Door 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sliding Door 2-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sliding Door Child Security 2-29 . . . . . . . . . . . . . . . . . . . . .
Sliding Door Delayed Locking 2-6 . . . . . . . . . . . . . . . . . . .
Loss of Control 4-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Coolant Warning Light 2-94, 6-24 . . . . . . . . . . . . . . . . .
Low Fuel Warning Light 2-101 . . . . . . . . . . . . . . . . . . . . . . . .
Low Oil Level Light 2-99, 6-11 . . . . . . . . . . . . . . . . . . . . . . .
Low Traction Light 2-93, 4-9 . . . . . . . . . . . . . . . . . . . . . . . . .
Lubricants and Fluids 7-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubrication Service, Body 7-31 . . . . . . . . . . . . . . . . . . . . . . . .
Luggage Carrier 2-75 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lumbar Control 1-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance, Normal Replacement Parts 6-65 . . . . . . . . . . .
Maintenance Record 7-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . Maintenance Schedule 7
-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How This Section is Organized 7-2 . . . . . . . . . . . . . . . . . . .
Long Trip/Highway Definition 7-6 . . . . . . . . . . . . . . . . . . .
Long Trip/Highway Intervals 7-7 . . . . . . . . . . . . . . . . . . . . .
Owner Checks and Services 7-30 . . . . . . . . . . . . . . . . . . . . .
Periodic Maintenance Inspections 7-34 . . . . . . . . . . . . . . . .
Recommended Fluids and Lubricants 7-35 . . . . . . . . . . . . .
Scheduled Maintenance Services 7-4 . . . . . . . . . . . . . . . . . .
Short Trip/City Definition 7-5 . . . . . . . . . . . . . . . . . . . . . . .
Short Trip/City Intervals 7-5 . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance, Underbody 6-54 . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance When Trailer Towing 4-39 . . . . . . . . . . . . . . . . .
Malfunction Indicator Lamp 2-95 . . . . . . . . . . . . . . . . . . . . . .
Matching Transmitters to Your Vehicle 2-10 . . . . . . . . . . . . . .
Mirrors 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convex Outside 2-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heated Outside 2-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Day/Night Rearview 2-66 . . . . . . . . . . . . . . . . . . . . .
Power Remote Control 2-67 . . . . . . . . . . . . . . . . . . . . . . . . .
Visor Vanity 2-79 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mountain Roads 4-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Multifunction Alarm Locks and Lighting Choices 2-13 . . . . .
Arming and Disarming the Content
Theft
-Deterrent System 2-21 . . . . . . . . . . . . . . . . . . . . . . .
Automatic Door Locks 2-15 . . . . . . . . . . . . . . . . . . . . . . . . .
Content Theft-Deterrent System 2-19 . . . . . . . . . . . . . . . . .
Delayed Illumination and Exit Lighting 2-14 . . . . . . . . . . .
Entering Programming Mode 2-14 . . . . . . . . . . . . . . . . . . . .
Exiting Programming Mode 2-23 . . . . . . . . . . . . . . . . . . . . .
Last Door Closed Locking and Lockout Prevention 2-16 . . . .
Remote Driver's Unlock Control 2-17 . . . . . . . . . . . . . . . . .
Remote Lock and Unlock Confirmation 2-18 . . . . . . . . . . .
Multifunction Lever 2-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
