1999 CHEVROLET S10 engine coolant

yellowblue
6-30
Windshield Washer Fluid
What to Use
When you need windshield washer fluid, be sure to read
the manufacturer's instructions before use. If you will be
operating your vehicle in an area where the temperature
may fall below freezing, use a fluid that has sufficient
protection against freezing.
Adding Washer Fluid
Open the cap labeled WASHER FLUID ONLY with
the washer symbol on it. Add washer fluid until the
tank is full.
NOTICE:

When using concentrated washer fluid,
follow the manufacturer's instructions for
adding water.

Don't mix water with ready
-to-use washer
fluid. Water can cause the solution to freeze
and damage your washer fluid tank and
other parts of the washer system. Also,
water doesn't clean as well as washer fluid.

Fill your washer fluid tank only
three
-quarters full when it's very cold.
This allows for expansion if freezing occurs,
which could damage the tank if it is
completely full.

Don't use engine coolant (antifreeze) in
your windshield washer. It can damage
your washer system and paint.

Short Trip/City Scheduled Maintenance
yellowblue
7-28
100,000 Miles (166 000 km)

Inspect spark plug wires.
An Emission Control Service.

Replace spark plugs.
An Emission Control Service.

If you haven't used your vehicle under severe service conditions listed
previously and, therefore, haven't changed your automatic transmission
fluid, change both the fluid and filter. Manual transmission fluid doesn't
require change.

4.3L V6 Engine Only: Inspect Positive Crankcase Ventilation (PCV) valve.
An Emission Control Service.
150,000 Miles (240 000 km)

Drain, flush and refill cooling system (or every 60 months since last service,
whichever occurs first). See ªEngine Coolantº in the Index for what to use.
Inspect hoses. Clean radiator, condenser, pressure cap and neck. Pressure test
cooling system and pressure cap.
An Emission Control Service.
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE

Long Trip/Highway Scheduled Maintenance
yellowblue
7-41
150,000 Miles (240 000 km)

Drain, flush and refill cooling system (or every 60 months since last service,
whichever occurs first). See ªEngine Coolantº in the Index for what to use.
Inspect hoses. Clean radiator, condenser, pressure cap and neck. Pressure test
the cooling system and pressure cap.
An Emission Control Service.ACTUAL
SERVICED BY:MILEAGE
DATE

yellowblue
7-42
Part B: Owner Checks and Services
Listed in this part are owner checks and services which
should be performed at the intervals specified to help
ensure the safety, dependability and emission control
performance of your vehicle.
Be sure any necessary repairs are completed at once.
Whenever any fluids or lubricants are added to your vehicle,
make sure they are the proper ones, as shown in Part D.
At Each Fuel Fill
It is important for you or a service station attendant to
perform these underhood checks at each fuel fill.
Engine Oil Level Check
Check the engine oil level and add the proper oil if necessary.
See ªEngine Oilº in the Index for further details.
Engine Coolant Level Check
Check the engine coolant level and add DEX
-COOL

coolant mixture if necessary. See ªEngine Coolantº in
the Index for further details.
Windshield Washer Fluid Level Check
Check the windshield washer fluid level in the windshield
washer tank and add the proper fluid if necessary. See
ªWindshield Washer Fluidº in the Index for further details.
At Least Once a Month
Tire Inflation Check
Make sure tires are inflated to the correct pressures.
See ªTiresº in the Index for further details.
Cassette Deck Service
Clean cassette deck. Cleaning should be done every
50 hours of tape play. See ªAudio Systemsº in the
Index for further details.
At Least Twice a Year
Restraint System Check
Make sure the safety belt reminder light and all your
belts, buckles, latch plates, retractors and anchorages are
working properly. Look for any other loose or damaged
safety belt system parts. If you see anything that might
keep a safety belt system from doing its job, have it
repaired. Have any torn or frayed safety belts replaced.
Also look for any opened or broken air bag coverings,
and have them repaired or replaced. (The air bag system
does not need regular maintenance.)

yellowblue
7-48
Part D: Recommended Fluids
and Lubricants
NOTE: Fluids and lubricants identified below by name,
part number or specification may be obtained from
your dealer.
USAGE
FLUID/LUBRICANT
Engine OilEngine Oil with the American
Petroleum Institute Certified For
Gasoline Engines ªStarburstº
symbol of the proper viscosity. To
determine the preferred viscosity
for your vehicle's engine, see
ªEngine Oilº in the Index.
Engine Coolant50/50 mixture of clean, drinkable
water and use only GM
Goodwrench

DEX-COOL
or
Havoline
DEX-COOL

Coolant. See ªEngine Coolantº in
the Index.
Hydraulic Brake
SystemDelco Supreme 11
Brake Fluid
(GM Part No. 12377967 or
equivalent DOT
-3 Brake Fluid).
USAGEFLUID/LUBRICANT
Windshield
Washer SolventGM Optikleen
Washer
Solvent (GM Part No. 1051515)
or equivalent.
Hydraulic Clutch
SystemHydraulic Clutch Fluid (GM Part
No. 12345347 or equivalent
DOT
-3 Brake Fluid).
Power Steering
SystemGM Power Steering Fluid
(GM Part No. 1052884
- 1 pint,
1050017
- 1 quart, or equivalent).
Manual
Transmission
with V6 EngineSynchromesh Transmission Fluid
(GM Part No. 12345349 or
equivalent).
Manual
Transmission
with L4 EngineFriction Modified Synchromesh
Transmission Fluid (GM Part
No. 12377916).
Automatic
TransmissionDEXRON
-III Automatic
Transmission Fluid.
Key Lock
CylindersMulti-Purpose Lubricant,
Superlube
(GM Part No.
12346241 or equivalent).

yellowblue
9-4
Exhaust, Engine 2-31, 4-39 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exit Lighting 2-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Express-Down Window 2-33 . . . . . . . . . . . . . . . . . . . . . . . . . .
Extender, Safety Belt 1-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fabric Cleaning 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fifth Gear, Manual Transmission 2-22 . . . . . . . . . . . . . . . . . . .
Filling a Portable Fuel Container 6-7 . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filter
Air 6
-16, 6-70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Remote Oil 6-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Finish Care 6-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Finish Damage 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
First Gear
Automatic Transmission 2
-21 . . . . . . . . . . . . . . . . . . . . . . .
Manual Transmission 2-21 . . . . . . . . . . . . . . . . . . . . . . . . . .
Flashers, Hazard Warning 5-2 . . . . . . . . . . . . . . . . . . . . . . . . .
Flash-To-Pass Feature 2-36 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flat Tire, Changing 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluids and Lubricants 7-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog Lamp Switch 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foreign Countries, Fuel 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fourth Gear, Manual Transmission 2-22 . . . . . . . . . . . . . . . . .
Four-Wheel Drive 2-23, 6-23 . . . . . . . . . . . . . . . . . . . . . . . . .
French Language Manual ii. . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Axle 6
-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Map Lamps 2-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Storage Area 2-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling a Portable Container 6-7 . . . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Foreign Countries 6
-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gage 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel Tank Capacity 6-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse Block
Engine Compartment 6
-64 . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 6-62 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and Circuit Breakers 6-62 . . . . . . . . . . . . . . . . . . . . . . .
Gages
Engine Coolant Temperature 2-61 . . . . . . . . . . . . . . . . . . . .
Engine Oil Pressure 2-64 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voltmeter 2-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gas Cap 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GAWR 4-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gear Positions 2-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove Box 2-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GM Mobility for Persons with Disabilities 8-5 . . . . . . . . . . . .
Gross Axle Weight Rating 4-41 . . . . . . . . . . . . . . . . . . . . . . . .
Gross Vehicle Weight Rating 4-40 . . . . . . . . . . . . . . . . . . . . . .
Guide en Fran†ais ii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GVWR 4
-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Halogen Bulbs 6-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hazard Warning Flashers 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamp Replacement 6-36 . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamps 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High/Low Beam Changer 2-36 . . . . . . . . . . . . . . . . . . . . . .
Wiring 6-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamps On Reminder 2-42 . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-8
Rearview Mirror 2-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reclining Front Seatbacks 1-3 . . . . . . . . . . . . . . . . . . . . . . . . .
Recovery Hooks 5-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recovery Tank, Coolant 5-13, 6-26 . . . . . . . . . . . . . . . . . . . . .
Recreational Vehicle Towing 4-39 . . . . . . . . . . . . . . . . . . . . . .
Replacement Bulbs 6-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement Parts 6-70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement, Wheel 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reporting Safety Defects 8-10 . . . . . . . . . . . . . . . . . . . . . . . . .
Restraints
Check 7
-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking 1-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Child 1-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing Parts After a Crash 1-52 . . . . . . . . . . . . . . . . . . .
Retained Accessory Power 2-15 . . . . . . . . . . . . . . . . . . . . . . . .
Reverse
Automatic Transmission 2
-19 . . . . . . . . . . . . . . . . . . . . . . .
Manual Transmission 2-22 . . . . . . . . . . . . . . . . . . . . . . . . . .
Right Front Passenger Position 1-20 . . . . . . . . . . . . . . . . . . . .
Roadside Assistance 8-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Canadian 8-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rocking Your Vehicle 5-33 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rotation, Tires 6-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Belts 1-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adults 1-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Care 6-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center Passenger Position 1-31 . . . . . . . . . . . . . . . . . . . . . .
Children 1-34, 1-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driver Position 1-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Extender 1-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to Wear Properly 1-12 . . . . . . . . . . . . . . . . . . . . . . . . .
Label 1-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Lap Belt 1
-31, 1-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lap-Shoulder 1-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Questions and Answers 1-11 . . . . . . . . . . . . . . . . . . . . . . . .
Rear Seat Passengers 1-33 . . . . . . . . . . . . . . . . . . . . . . . . . .
Reminder Light 1-7, 2-55 . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing After a Crash 1-52 . . . . . . . . . . . . . . . . . . . . . . . .
Right Front Passenger Position 1-20 . . . . . . . . . . . . . . . . . .
Use During Pregnancy 1-19 . . . . . . . . . . . . . . . . . . . . . . . . .
Why They Work 1-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Chains 4-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Defects, Reporting 8-10 . . . . . . . . . . . . . . . . . . . . . . . .
Safety Warnings and Symbols iii. . . . . . . . . . . . . . . . . . . . . . .
Scheduled Maintenance Services 7
-4 . . . . . . . . . . . . . . . . . . . .
Seatback
Latches 1
-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reclining Front 1-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seats 1-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seats and Restraint Systems 1-1 . . . . . . . . . . . . . . . . . . . . . . . .
Second Gear
Automatic Transmission 2
-20 . . . . . . . . . . . . . . . . . . . . . . .
Manual Transmission 2-22 . . . . . . . . . . . . . . . . . . . . . . . . . .
Security Warning Light 2-64 . . . . . . . . . . . . . . . . . . . . . . . . . .
Service 4WD Light 2-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service and Appearance Care 6-1 . . . . . . . . . . . . . . . . . . . . . .
Service Engine Soon Light 2-61 . . . . . . . . . . . . . . . . . . . . . . .
Service Parts Identification Label 6-60 . . . . . . . . . . . . . . . . . .
Service Publications 8-12, 8-13 . . . . . . . . . . . . . . . . . . . . . . . .
Service Work, Doing Your Own 6-2 . . . . . . . . . . . . . . . . . . . .
Sheet Metal Damage 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shift Light 2-23, 2-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shifting 2-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Into Park 2-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Out of Park 2-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Side Access Panel 2-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
