1999 CHEVROLET METRO turn signal bulb

yellowblue
2-24
Horn
Your can sound the horn by pressing one of the horn
symbols on your steering wheel.
Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes your:

Turn Signal and Lane Change Indicator

Headlamp High/Low Beam Changer

Flash
-to-Pass
Turn Signal and Lane Change Indicator
The turn signal has two upward (for right) and two
downward (for left) positions. These positions allow you
to signal a turn or a lane change.
To signal a turn, move the lever all the way up or
down. When the turn is finished, the lever will
return automatically.
An arrow on the instrument
panel will flash in the
direction of the turn or
lane change.
To signal a lane change, just raise or lower the lever
until the arrow starts to flash. Hold it there until you
complete your lane change. The lever will return by
itself when you release it.
As you signal a turn or a lane change, if the arrows don't
flash but just stay on, a signal bulb may be burned out
and other drivers won't see your turn signal.
If a bulb is burned out, replace it to help avoid an
accident. If the arrows don't go on at all when you
signal a turn, check for burned
-out bulbs and check the
fuse (see ªFuses and Circuit Breakersº in the Index).

yellowblue
6-38
4. Turn the turn signal bulb or sidemarker socket
counterclockwise and pull it out.
5. Pull the old bulb straight up to remove it.
6. Reverse the steps with the new bulb.
Rear Combination Lamps
To remove the rear combination bulbs:
1. Remove the two screws from the combination lamps
on the outside of the vehicle.
2. Pull back the cover on the inside of the trunk and use
a 10 mm wrench to remove the nut.
3. Pull the assembly out far enough to reach the
bulb socket.
4. Turn the socket counterclockwise and pull it out.
5. Disconnect the bulb from its socket by twisting and
then pulling the bulb out.
6. Reverse the steps to install a new bulb.

yellowblue
6-60
Replacement Bulbs
Lamps Bulb Number. . . . . . . . . . . . . . . . . . . . . . . . .
Back
-Up 921. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GM Part No. 96059983 or equivalent
Center High
-Mounted Stoplamp 921. . . . . . . . . . . . .
GM Part No. 96059983 or equivalent
Dome GM Part No. 94153335. . . . . . . . . . . . . . . . . . .
Front Parking and Sidemarker 168. . . . . . . . . . . . . . .
GM Part No. 96053293 or equivalent
Headlamp (Halogen) GM Part No. 9441731 . . . . . . .
or GM Part No. 91171148 or equivalent
License Plate 168. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Sidemarker 194. . . . . . . . . . . . . . . . . . . . . . . . .
Rear Stop/Tail 1157. . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signal and Hazard (Front and Rear) 1156. . . . .
Capacities and Specifications
The following approximate capacities are given in U.S.
and metric conversions. Please refer to ªRecommended
Fluids and Lubricantsº in the Index for more information.
Automatic Transaxle
Drain and Refill 1.6 quarts (1.5 L)**. . . . . . . . . . . . .
Manual Transaxle2.5 quarts (2.4 L)** . . . . . . . . . .
Cooling System
Automatic Transaxle
VIN Engine Code 2 5.0 quarts (4.7 L). . . . . . . . . . . .
Manual Transaxle
VIN Engine Code 6 4.1 quarts (3.9 L). . . . . . . . . . . .
VIN Engine Code 2 4.9 quarts (4.6 L). . . . . . . . . . . .
Crankcase
(With Filter Change)3.5 quarts (3.3 L)* . . . . . . .
Fuel Tank10.6 gallons (40.0 L) . . . . . . . . . . . . . . . . .
Wheel Nut Torque45 lb
-ft (60 N´m) . . . . . . . . . . . .
Air Conditioning

See the refrigerant information label under the hood.

See ªAir Conditioning Refrigerantsº later in
this section.

yellowblue
9-2
Brakes, Anti-Lock 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking in Emergencies 4-9 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Break-In, New Vehicle 2-9 . . . . . . . . . . . . . . . . . . . . . . . . . . .
BTSI 2-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BTSI Check 7-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-34, 6-60 . . . . . . . . . . . . . . . . . . . . . . . . .
Center High-Mounted Stoplamp 6-39 . . . . . . . . . . . . . . . . .
Dome Lamp 6-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Parking 6-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Sidemarker 6-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Turn Signal 6-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Combination Lamp 6-38 . . . . . . . . . . . . . . . . . . . . . . .
Rear Parking Lamp 6-39 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Sidemarker 6-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Canadian Roadside Assistance 8-7 . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications 6-60 . . . . . . . . . . . . . . . . . . . . . .
Carbon Monoxide 2-22, 2-23, 4-29 . . . . . . . . . . . . . . . . . . . .
Cargo Cover 2-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Deck Service 7-38 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Player Care 3-16 . . . . . . . . . . . . . . . . . . . . . . . .
Certification Label 4-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains, Tire 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a Flat Tire 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System Light 2-38 . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking Your Restraint Systems 1-48 . . . . . . . . . . . . . . . . . .
Chemical Paint Spotting 6-54 . . . . . . . . . . . . . . . . . . . . . . . . . .
Child Restraints 1-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Securing in the Rear Seat Position 1-40 . . . . . . . . . . . . . . . .
Securing in the Right Front Seat Position 1-43 . . . . . . . . . .
Top Strap 1-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Where to Put 1-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cigarette Lighter 2
-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Circuit Breakers and Fuses 6-57 . . . . . . . . . . . . . . . . . . . . . . .
Cleaner, Air 6-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning
Exterior Lamps/Lenses 6
-52 . . . . . . . . . . . . . . . . . . . . . . . .
Fabric/Carpet 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glass 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside of Your Vehicle 6-48 . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Plastic Components 6-50 . . . . . . . . . . . . . . . . . . . . .
Outside of Your Vehicle 6-52 . . . . . . . . . . . . . . . . . . . . . . . .
Special Problems 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stains 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vinyl 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield and Wiper Blades 6-51 . . . . . . . . . . . . . . . . . . .
Climate Control System 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock, Setting the 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clutch Adjustment 6-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Comfort Controls 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compact Disc Care 3-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compact Disc Player Care 3-17 . . . . . . . . . . . . . . . . . . . . . . . .
Compact Spare Tire 5-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control, Loss of 4-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control of a Vehicle 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convex Outside Mirror 2-29 . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant 6-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recovery Tank 5-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling System 5-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Courtesy Transportation 8-8 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cupholder 2-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Customer Assistance for Text Telephone Users 8-4 . . . . . . . . .
Customer Assistance Information 8-1 . . . . . . . . . . . . . . . . . . .
Customer Satisfaction Procedure 8-2 . . . . . . . . . . . . . . . . . . . .
