1999 CHEVROLET LUMINA remote start

2-
yellowblue
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Keys
2
-4 Door Locks
2
-5 Remote Keyless Entry (If Equipped)
2
-9 Trunk
2
-10 Theft
2
-11 Pass-Key
II
2
-13 New Vehicle ªBreak-Inº
2
-13 Ignition Positions
2
-15 Starting Your V6 Engine
2
-17 Engine Coolant Heater (If Equipped)
2
-18 Automatic Transaxle Operation
2
-22 Parking Brake
2
-23 Shifting Into PARK (P)
2
-26 Shifting Out of PARK (P)
2
-27 Parking Over Things That Burn
2
-28 Engine Exhaust
2
-28 Running Your Engine While You're Parked
2
-29 Windows2
-30 Horn
2
-30 Tilt Wheel
2
-31 Turn Signal/Multifunction Lever
2
-36 Exterior Lamps
2
-37 Interior Lamps
2
-39 Mirrors
2
-40 Storage Compartments
2
-42 Ashtrays and Cigarette Lighter
2
-42 Sun Visors
2
-44 Auxiliary Power Connection
2
-45 Sunroof (Option)
2
-45 Cellular Telephone (Option)
2
-45 OnStar
(Option)
2
-46 The Instrument Panel -- Your
Information System
2
-48 Instrument Panel Cluster
2
-51 Warning Lights, Gages and Indicators

yellowblue
2-11 Parking Lots
If you park in a lot where someone will be watching
your vehicle, it's best to lock it up and take your keys.
But what if you have to leave your ignition key?

If possible, park in a busy, well lit area.

Put your valuables in a storage area, like your
trunk or glove box. Be sure to close and lock the
storage area.

Close all windows.

Lock the glove box.

Lock all the doors except the driver's.

Then take the door key and remote keyless entry
transmitter with you.
PASS-Key II
Your vehicle is equipped
with the PASS
-Key II
(Personalized Automotive
Security System)
theft
-deterrent system.
PASS
-Key II is a passive
theft
-deterrent system.
It works when you insert
or remove the key from
the ignition.
PASS
-Key II uses a resistor pellet in the ignition key
that matches a decoder in your vehicle.
When the PASS
-Key II system senses that someone is
using the wrong key, it shuts down the vehicle's starter
and fuel systems. For about three minutes, the starter
won't work and fuel won't go to the engine. If someone
tries to start your vehicle again or uses another key
during this time, the vehicle will not start. This
discourages someone from randomly trying different
keys with different resistor pellets in an attempt to make
a match.

yellowblue
2-37
When the DRL are on, only your reduced intensity
high
-beam headlamps will be on. The taillamps,
sidemarker and other lamps won't be on. Your
instrument panel won't be lit up either.
When it's dark enough outside, your DRL will turn off
and your low
-beam headlamps will illuminate. The
other lamps that come on with your headlamps will also
come on.
When it's bright enough outside, the low
-beam
headlamps will go out, and DRL illuminates your
high
-beam headlamps at reduced intensity.
To idle your vehicle with the DRL off, set the parking
brake while the ignition is in OFF or LOCK. Then start
your vehicle. The DRL will stay off until you release the
parking brake.
As with any vehicle, you should turn on the regular
headlamp system when you need it.
Interior Lamps
Instrument Panel Brightness Control
You can brighten or dim the instrument panel lamps by
moving the dial (A), located next to the exterior lamps
controls. If you turn the dial all the way up, your
courtesy or interior lamps will come on.
Courtesy Lamps
When any door is opened, several lamps will come on.
These lamps are courtesy lamps. They make it easy for
you to enter and leave your vehicle. You can also turn
these lamps on by moving the dial near the headlamp
knob all the way up.
Some of the lamps have switches so you can turn them
on even when the doors are closed. These lamps are
reading lamps. To avoid draining your battery, be sure to
turn off all the reading lamps when leaving your vehicle.
Sustained Interior Illumination
Your courtesy lamps will come on and stay on for a set
time whenever you:

Open a door.

Press UNLOCK on the remote keyless entry
transmitter (if equipped).

Press LOCK on the remote keyless entry transmitter
(if equipped).

Press the trunk symbol on the remote keyless entry
transmitter (if equipped).

yellowblue
2-38
If you open a door, the lamps will stay on while it's open
and then turn off automatically about 18 seconds after
you close it. If you don't open a door, the lamps will
turn off after about 18 seconds, unless you press
UNLOCK or the trunk symbol on the remote keyless
entry transmitter. If you press UNLOCK or the trunk
symbol and don't open a door, the lamps will turn off
after about 55 seconds. If you press LOCK on the
remote keyless entry transmitter the lamps will turn off
about 17 seconds after all the doors are closed.
Sustained Interior Illumination includes a feature called
Theater Dimming. With Theater Dimming, the lamps
don't just turn off at the end of the delay time. Instead,
they slowly dim during the delay time until they go out.
The delay time is canceled if you turn the ignition key to
RUN or START, so the lamps will go out right away.
When the ignition is on, Sustained Interior Illumination
is inactive, which means the courtesy lamps won't
come on.Rearview Mirror Reading Lamps
These lamps go on when you open the doors. When
the doors are closed, turn the lamps on and off with
the switches.

yellowblue
5-5
5. Find the positive (+) and negative (-) terminals on
each battery. Your vehicle has a remote positive (+)
jump starting terminal. The terminal is on the same
side of the engine compartment as your battery. You
should always use the remote positive (+) terminal
instead of the positive (+) terminal on your battery.
To uncover the remote positive (+) terminal, lift the
red plastic cap.
CAUTION:
Using a match near a battery can cause battery
gas to explode. People have been hurt doing this,
and some have been blinded. Use a flashlight if
you need more light.
Be sure the battery has enough water. You don't
need to add water to the ACDelco Freedom

battery installed in every new GM vehicle. But if
a battery has filler caps, be sure the right amount
of fluid is there. If it is low, add water to take care
of that first. If you don't, explosive gas could
be present.
Battery fluid contains acid that can burn you.
Don't get it on you. If you accidentally get it in
your eyes or on your skin, flush the place with
water and get medical help immediately.

yellowblue
5-7
8. Don't let the other end
touch metal. Connect it
to the positive (+)
terminal of the good
battery. Use a remote
positive (+) terminal if
the vehicle has one.
9. Now connect the black
negative (
-) cable to
the good battery's
negative (
-) terminal.
Don't let the other end
touch anything until
the next step. The other
end of the negative (
-)
cable doesn't go to the
dead battery.
It goes to a heavy, unpainted, metal part on the engine of
the vehicle with the dead battery.10. Attach the cable at least 18 inches (45 cm) away
from the dead battery, but not near engine parts that
move. The electrical connection is just as good
there, but the chance of sparks getting back to the
battery is much less.11. Now start the vehicle with the good battery and run
the engine for a while.
12. Try to start the vehicle with the dead battery.
If it won't start after a few tries, it probably
needs service.

yellowblue
9-2
Back-Up Lamp Bulb Replacement 6-37 . . . . . . . . . . . . . . . .
Battery 6-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement, Remote Keyless Entry 2-7 . . . . . . . . . . . . . . .
Saver 2-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warnings 5-3, 5-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BBB Auto Line 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Better Business Bureau Mediation 8-4 . . . . . . . . . . . . . . . . . . .
Blizzard 4-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake
Adjustment 6
-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Master Cylinder 6-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking 2-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pedal Travel 6-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing System Parts 6-32 . . . . . . . . . . . . . . . . . . . . . . . .
System Warning Light 2-53 . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer 4-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Shift Interlock (BTSI) 2-26 . . . . . . . . . . . . . . . . .
Transaxle Shift Interlock Check 7-15 . . . . . . . . . . . . . . . . . .
Wear 6-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brakes, Anti-Lock 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking in Emergencies 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . .
Break-In, New Vehicle 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . .
Brightness Control 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BTSI 2-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BTSI Check 7-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Canadian Roadside Assistance 8-7 . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications 6-63 . . . . . . . . . . . . . . . . . . . . . .
Carbon Monoxide 2-9, 2-27, 4-29 4-35 . . . . . . . . . . . . . . . . .
Cassette
Deck Service 7
-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tape Player 3-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tape Player Care 3-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cellular Telephone 2-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High-Mounted Stoplamp Bulb Replacement 6-36 . . . .
Center Passenger Position 1-27 . . . . . . . . . . . . . . . . . . . . . . . .
Certification Label 4-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains
Safety 4
-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Change Oil Soon Light 2-61 . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a Flat Tire 5-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System Light 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking Your Restraint Systems 1-52 . . . . . . . . . . . . . . . . . .
Chemical Paint Spotting 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . .
Child Restraints 1-36, 1-40, 1-49 . . . . . . . . . . . . . . . . . . . . . .
Securing in a Rear Outside Seat Position 1-42 . . . . . . . . . . .
Securing in the Center Rear Seat Position 1-44 . . . . . . . . . .
Securing in the Right Front Seat Position 1-46 . . . . . . . . . .
Top Strap 1-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Where to Put 1-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette Lighter 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Circuit Breakers and Fuses 6-56 . . . . . . . . . . . . . . . . . . . . . . .
Cleaner, Air 6-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
