1999 CHEVROLET LUMINA AUX

yellowblue
ii
GENERAL MOTORS, GM, the GM Emblem,
CHEVROLET, the CHEVROLET Emblem and the
name LUMINA are registered trademarks of
General Motors Corporation.
This manual includes the latest information at the time it
was printed. We reserve the right to make changes in the
product after that time without further notice. For
vehicles first sold in Canada, substitute the name
ªGeneral Motors of Canada Limitedº for Chevrolet
Motor Division whenever it appears in this manual.
Please keep this manual in your vehicle, so it will be
there if you ever need it when you're on the road. If you
sell the vehicle, please leave this manual in it so the new
owner can use it.
We support voluntary
technician certification.
For Canadian Owners Who Prefer a
French Language Manual:
Aux propri‡taires canadiens: Vous pouvez vous
procurer un exemplaire de ce guide en fran†ais chez
votre concessionaire ou au:
DGN Marketing Services Ltd.
1577 Meyerside Dr.
Mississauga, Ontario L5T 1B9
Litho in U.S.A.

Copyright General Motors Corporation 1998
Part No. 10285612 A First Edition All Rights Reserved

2-
yellowblue
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Keys
2
-4 Door Locks
2
-5 Remote Keyless Entry (If Equipped)
2
-9 Trunk
2
-10 Theft
2
-11 Pass-Key
II
2
-13 New Vehicle ªBreak-Inº
2
-13 Ignition Positions
2
-15 Starting Your V6 Engine
2
-17 Engine Coolant Heater (If Equipped)
2
-18 Automatic Transaxle Operation
2
-22 Parking Brake
2
-23 Shifting Into PARK (P)
2
-26 Shifting Out of PARK (P)
2
-27 Parking Over Things That Burn
2
-28 Engine Exhaust
2
-28 Running Your Engine While You're Parked
2
-29 Windows2
-30 Horn
2
-30 Tilt Wheel
2
-31 Turn Signal/Multifunction Lever
2
-36 Exterior Lamps
2
-37 Interior Lamps
2
-39 Mirrors
2
-40 Storage Compartments
2
-42 Ashtrays and Cigarette Lighter
2
-42 Sun Visors
2
-44 Auxiliary Power Connection
2
-45 Sunroof (Option)
2
-45 Cellular Telephone (Option)
2
-45 OnStar
(Option)
2
-46 The Instrument Panel -- Your
Information System
2
-48 Instrument Panel Cluster
2
-51 Warning Lights, Gages and Indicators

yellowblue
2-44
Usage

To remove the mat, pull up on the rear of the mat to
unsnap it from the locator post (see view B).

To r e
-install the mat, align the grommet in the mat
over the locator post and push down to snap the mat
into place (see view B).
Auxiliary Power Connection
Your vehicle is equipped
with auxiliary power leads.
These leads can be used
to power aftermarket
electrical equipment
added to your vehicle.They are located on the passenger's side of the vehicle,
below the glove box and behind what is referred to as a
ªhush panel.º For additional information on accessing
these leads and electrical hookup, please refer to the
service manual.
NOTICE:
Adding some electrical equipment to your vehicle
can damage it or keep other things from working
as they should. This wouldn't be covered by your
warranty. Check with your dealer before adding
electrical equipment, and never use anything that
exceeds the fuse rating.

yellowblue
3-2
Comfort Controls
Air Conditioning with Electronic Controls
With these systems, you can control the heating, cooling
and ventilation in your vehicle. The systems work best if
you keep your windows closed while using them.
Fan Knob
The right knob with the fan symbol controls the force of
air you want. To turn the fan off, turn the knob to ªO.º
Temperature Control
If your system does not have the auxiliary temperature
control option, the center knob changes the temperature
of the air coming through the system. Turn this knob
toward red (clockwise) for warmer air. Turn it toward
blue (counterclockwise) for cooler air.
If your system does have the auxiliary temperature
control option, the center levers change the temperature
of the air coming through the system. The DRIV lever
sets the temperature for the driver and rear seat
passengers, and the PASS lever sets the temperature for
the front seat passenger. For maximum defroster
performance, set the DRIV and PASS levers at
full warm.

yellowblue
3-12
AM-FM: Press this button to play the radio when a tape
is in the player.
TAPE AUX: Press this button to change to the tape
function when the radio is on. The tape symbol with an
arrow will appear on the display when the tape is active.
EJECT: Press this button to remove the tape. The radio
will play. EJECT may be activated with either the
ignition or radio off. Cassettes may be loaded with the
radio off if this button is pressed first. If you leave a
cassette tape in the player while listening to the radio, it
may become warm.
CLN: If this message appears on the display, the
cassette tape player needs to be cleaned. It will still play
tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index. After you clean
the player, press and hold EJECT for five seconds to
reset the CLN indicator. The radio will display
--- to
show the indicator was reset.CD Adapter Kits
It is possible to use a CD adapter kit with your cassette
tape player after activating the bypass feature on your
tape player.
To activate the bypass feature, use the following steps:
1. Turn the ignition to RUN or ACCESSORY.
2. Turn the radio off.
3. Press and hold the TAPE AUX button for five
seconds. The tape symbol on the display will flash
for two seconds, indicating the feature is active.
4. Insert the adapter. It will power up the radio and
begin playing.
This override routine will remain active until EJECT
is pressed.

yellowblue
3-16
RDM (2): Press this button to hear the tracks in random,
rather than sequential, order. RANDOM will show on
the display. Press RDM again to turn off random play.
RDM is reset to off when the disc is ejected.
NEXT (3): Press this button or the right SEEK arrow to
go to the next track. If you hold the button or press it
more than once, the player will continue moving
forward through the disc. The sound will mute
while seeking.
REV (4): Press and hold this button to quickly reverse
within a track. Release it to play the passage. You can
use the counter reading on the display to locate a
passage easily.
FWD (6): Press and hold this button to advance quickly
within a track. Release it to resume playing. You can
use the counter reading on the display to locate a
passage easily.
RECALL: Press this button to see which track is
playing. Press it again within five seconds to see how
long it has been playing (elapsed time). The track
number also appears when you change the volume or
when a new track starts to play.AM-FM: Press this button to play the radio when a disc
is in the player. The letters CD will go off the display.
CD AUX: Press this button to change to the disc
function when the radio is on. A CD icon will appear on
the display when the disc is in the player, whether it is
active or not.
EJECT: Press this button to remove the disc. The radio
will play. The disc will start at the first track when you
reinsert it.
If you turn off the ignition or radio with a disc in the
player, it will stay in the player. When you turn on the
ignition or system, the disc will start playing where it
was stopped. If you press EJECT but don't remove the
disc, the player will pull the disc back in to protect it
after about one minute. If you leave a compact disc
in the player while listening to the radio, it may
become warm.

yellowblue
3-21 Care of Your Cassette Tape Player
A tape player that is not cleaned regularly can cause
reduced sound quality, ruined cassettes or a damaged
mechanism. Cassette tapes should be stored in their
cases away from contaminants, direct sunlight and
extreme heat. If they aren't, they may not operate
properly or may cause failure of the tape player.
Your tape player should be cleaned regularly after every
50 hours of use. Your radio may display CLN to indicate
that you have used your tape player for 50 hours without
resetting the tape clean timer. If this message appears on
the display, your cassette tape player needs to be
cleaned. It will still play tapes, but you should clean it as
soon as possible to prevent damage to your tapes and
player. If you notice a reduction in sound quality, try a
known good cassette to see if it is the tape or the tape
player at fault. If this other cassette has no improvement
in sound quality, clean the tape player.
The recommended cleaning method for your cassette
tape player is the use of a scrubbing action,
non
-abrasive cleaning cassette with pads which scrub
the tape head as the hubs of the cleaner cassette turn.
The recommended cleaning cassette is available through
your dealership (GM Part No. 12344789).When using a scrubbing action, non
-abrasive cleaning
cassette, it is normal for the cassette to eject because
your unit is equipped with a cut tape detection feature
and a cleaning cassette may appear as a broken tape. To
prevent the cleaning cassette from being ejected, use the
following steps.
1. Turn the ignition to RUN or ACCESSORY.
2. Turn the radio off.
3. Press and hold the TAPE AUX button for five
seconds. The tape symbol on the display will flash
for two seconds.
4. Insert the scrubbing action cleaning cassette.
5. Eject the cleaning cassette after the manufacturer's
recommended cleaning time.
When the cleaning cassette has been ejected, the cut tape
detection feature is active again.
You may also choose a non
-scrubbing action, wet-type
cleaner which uses a cassette with a fabric belt to clean
the tape head. This type of cleaning cassette will not
eject on its own. A non
-scrubbing action cleaner may
not clean as thoroughly as the scrubbing type cleaner.
The use of a non
-scrubbing action, dry-type cleaning
cassette is not recommended.

9-
yellowblue
9-1
Section 9 Index
A
dding Equipment to the Outside of Your Vehicle 6-3 . . . . .
Air Bag 1-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How Does it Restrain 1-25 . . . . . . . . . . . . . . . . . . . . . . . . . .
How it Works 1-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Location 1-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Readiness Light 1-22, 2-52 . . . . . . . . . . . . . . . . . . . . . . . . .
Servicing 1-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What Makes it Inflate 1-24 . . . . . . . . . . . . . . . . . . . . . . . . . .
What Will You See After it Inflates 1-25 . . . . . . . . . . . . . . .
When Should it Inflate 1-24 . . . . . . . . . . . . . . . . . . . . . . . . .
Air Bag System 1-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning 3-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning Refrigerants 6-65 . . . . . . . . . . . . . . . . . . . . .
Alignment and Balance, Tire 6-45 . . . . . . . . . . . . . . . . . . . . . .
Aluminum Wheels, Cleaning 6-52 . . . . . . . . . . . . . . . . . . . . . .
AM-FM Stereo 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AM-FM Stereo with Cassette Tape Player and
Automatic Tone Control 3-8 . . . . . . . . . . . . . . . . . . . . . . . . .
AM-FM Stereo with Compact Disc Player and
Automatic Tone Control 3-13 . . . . . . . . . . . . . . . . . . . . . . . .
Antenna, Fixed Mast 3-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Antifreeze 6-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Anti
-Lock
Brake System Active Light 2-55, 4-9 . . . . . . . . . . . . . . . . .
Brake System Warning Light 2-54, 4-8 . . . . . . . . . . . . . . . .
Brakes 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Anti-Theft, Radio 3-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appearance Care 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Arbitration Program 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Armrest, Storage 2-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ashtrays 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio Equipment, Adding 3-20 . . . . . . . . . . . . . . . . . . . . . . . .
Audio Steering Wheel Controls 3-19 . . . . . . . . . . . . . . . . . . . .
Audio System, Tips 3-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio Systems 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Auto-Down Window 2-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic
Overdrive (
)2
-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Check 7-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Fluid 6-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Operation 2-18 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Auxiliary Power Connection 2-44 . . . . . . . . . . . . . . . . . . . . . .
