ªVORTECº 5000 and 5700 V8 Engine
ªVORTECº 5700 engine shown, locations for other engines similar. When you lift up the hood you'll see:
A. Battery
B. Engine Air Cleaner/Filter
C. Radiator Cap
D. Coolant Recovery Tank
E. Air Filter Restriction Indicator
F. Engine Oil DipstickG. Automatic Transmission
Dipstick (If Equipped)
H. Fan
I. Power Steering Fluid Reservoir
J. Engine Oil Fill
K. Brake Fluid ReservoirL. Clutch Fluid Reservoir
(If Equipped)
M. Windshield Washer Fluid
Reservoir
N. Fuse/Relay Center

yellowblue
6-11
ªVORTECº 7400 V8 Engine
A. Battery
B. Coolant Recovery Tank
C. Engine Air Cleaner/Filter
D. Radiator Cap
E. Air Filter Restriction Indicator
F. Engine Oil DipstickG. Automatic Transmission
Dipstick (If Equipped)
H. Engine Oil Fill
I. Fan
J. Power Steering Fluid Reservoir
K. Brake Fluid ReservoirL. Clutch Fluid Reservoir
(If Equipped)
M. Windshield Washer
Fluid Reservoir
N. Fuse/Relay Center

yellowblue
6-72
Fuse/Circuit
Breaker Usage
3 Courtesy Lamps, Cargo Lamp,
Glove Box Lamp, Dome/Reading
Lamps, Vanity Mirrors,
Power Mirrors
4 Instrument Cluster, DRL Relay,
Lamp Switch, Keyless Entry,
Low Coolant Module, Illuminated
Entry Module,
DRAC (Diesel Engine)
5 Not Used
6 Cruise Control
7 Auxiliary Power Outlet
8 Crank
9 License Lamp, Parking Lamps,
Taillamps, Roof Marker Lamps,
Tailgate Lamps, Front
Sidemarkers, Fog Lamp Relay,
Door Switch Illumination,
Fender Lamps, Headlamp
Switch IlluminationFuse/Circuit
Breaker Usage
10 Not Used
11 Wiper Motor, Washer Pump
12 A/C, A/C Blower,
High Blower Relay
13 Power Amp, Cigarette Lighter,
Door Lock Relay,
Power Lumbar Seat
14 4WD Indicator, Cluster, Comfort
Controls, Instrument Switches,
Radio Illumination,
Chime Module
15 DRL Relay, Fog Lamp Relay
16 Front and Rear Turn Signals,
Back
-Up Lamps, BTSI Solenoid
17 Radio (Ignition)
18 4WAL/VCM, ABS,
Cruise Control
19 Radio (Battery)

yellowblue
6-73
Fuse/Circuit
Breaker Usage
20 PRNDL, Automatic Transmission,
Speedometer, Check Gages
Warning Light
21 Security/Steering
22 Not Used
23 Not Used
24 Front Axle, 4WD Indicator Lamp,
TP2 Relay (Gasoline Engine)
A Power Door Lock, Six
-Way Power
Seat, Keyless Entry Module
B Power WindowsUnderhood Fuse/Relay Center
The underhood fuse/relay center is located in the rear of
the engine compartment near the brake fluid reservoir.
Move the retainer clips for the cover to access the
fuse block.
You can remove fuses with a fuse extractor. The fuse
extractor is mounted to the interior fuse block. To
remove fuses if you don't have a fuse extractor, hold the
end of the fuse between your thumb and index finger
and pull straight out.

yellowblue
6-74
Name Usage
ECM
-B Fuel Pump, PCM/VCM
RR DEFOG Rear Window Defogger
IGN
-E Auxiliary Fan Relay Coil,
A/C Compressor Relay,
Hot Fuel Module, Dual Tanks
HORN Horn, Underhood Lamps
AUX FAN Auxiliary FanName Usage
ECM
-1 Injectors, PCM/VCM, Fuel
Solenoid (Diesel Engine, Fuel
Control Module (Diesel Engine)
HTD ST
-FR Not Used
A/C Air Conditioning
HTD MIR Not Used
ENG
-1 Ignition Switch, EGR, Canister
Purge, EVRV Idle Coast Solenoid,
MAF, Heated O
2,
Fuel Heater (Diesel Engine),
Water Sensor (Diesel Engine),
Boost Solenoid (Diesel Engine),
EPR (Diesel Engine)
HTD ST
-RR Not Used
LIGHTING Headlamp and Panel Dimmer
Switch, Fog and Courtesy Fuses
BATT Battery, Fuse Block Busbar
IGN
-A Ignition Switch
IGN
-B Ignition Switch
ABS Anti
-Lock Brake Module
BLOWER High Blower Relay
STOP/HAZ Stoplamps
HEATED SEATS Not Used

yellowblue
9-4
Easy Entry Seat 1-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Equipment, Adding 2-13, 3-27, 6-69 . . . . . . . . . . .
Electrical System 6-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrochromic Day/Night Rearview Mirror 2-45 . . . . . . . . . .
Engine 6-10, 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Cleaner/Filter 6-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant 6-28, 6-76, 7-48 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Heater 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Level Check 7-41 . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Temperature Gage 2-69 . . . . . . . . . . . . . . . . . . . . .
Cooling System Capacity 6-77 . . . . . . . . . . . . . . . . . . . . . . .
Exhaust 2-31, 4-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse Blocks 6-70, 6-73 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification 6-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Level Check 7-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overheating 5-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running While Parked 2-31 . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 6-76 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Underhood Fuse/Relay Center 6-73 . . . . . . . . . . . . . . . . . . .
Engine Oil 6-13, 7-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Additives 6-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pressure Gage 2-72 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Used 6-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When to Change 6-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust, Engine 2-30, 4-40 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fabric Cleaning 6-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fan Control, Climate Control System 3-2, 3-3 . . . . . . . . . . . .
Fender Marker Lamp Bulb Replacement 6-44 . . . . . . . . . . . . .
Filling a Portable Fuel Container 6-8 . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filter, Air 6-17, 6-78 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Finish Care 6-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Finish Damage 6-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flashers, Hazard Warning 5-2 . . . . . . . . . . . . . . . . . . . . . . . . .
Flat Tire, Changing 5-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Capacities 6-77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluids and Lubricants 7-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foreign Countries, Fuel 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Four-Wheel Drive 2-21, 6-26 . . . . . . . . . . . . . . . . . . . . . . . . .
French Language Manual ii. . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Axle 6
-27, 7-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Axle Locking Feature 2-22 . . . . . . . . . . . . . . . . . . . . . . .
Front Towing 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Turn Signal Lamp Bulb Replacement 6-41, 6-42 . . . . .
Fuel 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling a Portable Container 6-8 . . . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gage 2-75 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Foreign Countries 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tank Capacity 6-77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and Circuit Breakers 6-70 . . . . . . . . . . . . . . . . . . . . . . .
Fusible Links 6-70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-11
Traction 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Treadwear 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Uniform Quality Grading 6-56 . . . . . . . . . . . . . . . . . . . . . . .
Wear Indicators 6-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel Replacement 6-58 . . . . . . . . . . . . . . . . . . . . . . . . . . .
When It's Time for New 6-54 . . . . . . . . . . . . . . . . . . . . . . .
Top Strap 1-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Torque Lock 2-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Torque, Wheel Nut 5-28, 6-77 . . . . . . . . . . . . . . . . . . . . . . . . .
Towing a Trailer 4-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing, Recreational Vehicle 4-41 . . . . . . . . . . . . . . . . . . . . .
Towing Your Vehicle 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer
Brakes 4
-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving on Grades 4-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving with 4-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hitches 4-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance When Towing 4-59 . . . . . . . . . . . . . . . . . . . . .
Parking on Hills 4-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Chains 4-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tongue Weight 4-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Total Weight on Tires 4-55 . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing 4-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signals 4-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weight 4-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring Harness 4-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Transfer Case, Electronic 2
-24 . . . . . . . . . . . . . . . . . . . . . . . . .
Transfer Case Lubricant 6-25, 7-49 . . . . . . . . . . . . . . . . . . . . .
Transfer Case, Manual 2-22 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmission Fluid
Automatic 6
-20, 7-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual 6-23, 7-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmitters, Keyless Entry 2-6 . . . . . . . . . . . . . . . . . . . . . . . .
Transportation, Courtesy 8-8 . . . . . . . . . . . . . . . . . . . . . . . . . .
Trip Odometer 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TTY Users 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signal and Lane Change Signals 2-36 . . . . . . . . . . . . . . .
Turn Signal/Multifunction Lever 2-35 . . . . . . . . . . . . . . . . . . .
Turn Signals When Towing a Trailer 4-57 . . . . . . . . . . . . . . . .
Underbody Maintenance 6-67 . . . . . . . . . . . . . . . . . . . . . . . .
Underhood Fuse/Relay Center 6-73 . . . . . . . . . . . . . . . . . . . . .
Vehicle
Care/Appearance Materials 6-68 . . . . . . . . . . . . . . . . . . . . .
Control 4-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Damage Warnings iv. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification Number 6
-69 . . . . . . . . . . . . . . . . . . . . . . . . .
Loading 4-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage 6-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ventilation System 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Visors, Sun 2-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voltmeter 2-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
