1999 CADILLAC DEVILLE stop start

yellowblue
4-38 Turn Signals When Towing a Trailer
When you tow a trailer, your vehicle may need a different
turn signal flasher and/or extra wiring. Check with your
dealer. The arrows on your instrument panel will flash
whenever you signal a turn or lane change. Properly
hooked up, the trailer lamps will also flash, telling other
drivers you're about to turn, change lanes or stop.
When towing a trailer, the arrows on your instrument panel
will flash for turns even if the bulbs on the trailer are burned
out. Thus, you may think drivers behind you are seeing your
signal when they are not. It's important to check occasionally
to be sure the trailer bulbs are still working.
Driving On Grades
Reduce speed and shift to a lower gear before you start
down a long or steep downgrade. If you don't shift
down, you might have to use your brakes so much that
they would get hot and no longer work well.
On a long uphill grade, shift down and reduce your
speed to around 45 mph (70 km/h) or less to reduce the
possibility of engine and transaxle overheating.
Parking on Hills
CAUTION:
You really should not park your vehicle, with a
trailer attached, on a hill. If something goes
wrong, your rig could start to move. People can
be injured, and both your vehicle and the trailer
can be damaged.
But if you ever have to park your rig on a hill, here's
how to do it:
1. Apply your regular brakes, but do not shift into
PARK (P).
2. Have someone place chocks under the trailer wheels.
3. When the wheel chocks are in place, release the
regular brakes until the chocks absorb the load.
4. Reapply the regular brakes. Then shift into
PARK (P) firmly and apply your parking brakes.
5. Release the regular brakes.

yellowblue
4-39 When You Are Ready to Leave After
Parking on a Hill
1. Apply your regular brakes and hold the pedal down
while you:

Start your engine;

Shift into a gear; and

Be sure the parking brake has released.
2. Let up on the brake pedal.
3. Drive slowly until the trailer is clear of the chocks.
4. Stop and have someone pick up and store the chocks.
Maintenance When Trailer Towing
Your vehicle will need service more often when you're
pulling a trailer. See the Maintenance Schedule booklet
for more on this. Things that are especially important in
trailer operation are automatic transaxle fluid (don't
overfill), engine oil, drive belt, cooling system and brake
system. If you're trailering, it's a good idea to review
this information before you start your trip.
Check periodically to see that all hitch nuts and bolts
are tight.
Engine Cooling When Trailer Towing
Your cooling system may temporarily overheat during
severe operating conditions. See ªEngine Overheatingº
in the Index.

yellowblue
5-18
5. Then replace the pressure cap. Be sure the arrows on
the pressure cap line up like this.
Start the engine and allow it to warm up. If the CHECK
COOLANT LEVEL message does not appear on the
Driver Information Center, coolant is at the proper fill
level. If a CHECK COOLANT LEVEL message does
appear, repeat Steps 1 to 3 and reinstall the pressure cap
or see your dealer.
If a Tire Goes Flat
It's unusual for a tire to ªblow outº while you're driving,
especially if you maintain your tires properly. If air goes
out of a tire, it's much more likely to leak out slowly.
But if you should ever have a ªblowout,º here are a few
tips about what to expect and what to do:
If a front tire fails, the flat tire will create a drag that
pulls the vehicle toward that side. Take your foot off the
accelerator pedal and grip the steering wheel firmly.
Steer to maintain lane position, and then gently brake to
a stop well out of the traffic lane.
A rear blowout, particularly on a curve, acts much like a
skid and may require the same correction you'd use in a
skid. In any rear blowout, remove your foot from the
accelerator pedal. Get the vehicle under control by
steering the way you want the vehicle to go. It may be
very bumpy and noisy, but you can still steer. Gently
brake to a stop
-- well off the road if possible.
If a tire goes flat, the next part shows how to use your
jacking equipment to change a flat tire safely.

yellowblue
6-22 How to Reset Transaxle Fluid
Change Indicator
Your vehicle is equipped with a transaxle fluid change
indicator. A CHANGE TRANS FLUID message will
display on the Driver Information Center (DIC) when
the powertrain computer determines that the transaxle
fluid needs to be changed or at each 100,000 miles
(160 000 km) interval, whichever occurs first. When this
message appears, change the transaxle fluid and reset
the transaxle fluid life indicator as follows:
1. Turn the ignition on but do not start the engine.
2. Press and hold the OFF and rear defog buttons on the
climate control at the same time until the TRANS
FLUID RESET message appears on the DIC.
Surge Tank Pressure Cap
NOTICE:
The surge tank cap is a 15 psi (105 kPa)
pressure
-type cap and must be tightly installed to
prevent coolant loss and possible engine damage
from overheating. Be sure the arrows on the
cap line up.
If the surge tank pressure cap needs to be replaced, a
GM cap is recommended.
Thermostat
Engine coolant temperature is controlled by a thermostat
in the engine coolant system. The thermostat stops the
flow of coolant through the radiator until the coolant
reaches a preset temperature.
If your thermostat needs to be replaced, a GM
thermostat is recommended.

yellowblue
6-36
The vehicle should be properly prepared as follows:

The vehicle must have all four tires on a perfectly
level surface.

If necessary, pads may be used on an uneven surface.

The vehicle should not have any snow, ice or mud
attached to it.

The vehicle should be fully assembled and all other
work stopped while headlamp aiming is being done.

There should not be any cargo or loading of the
vehicle, except it should have a full tank of fuel and
one person or 160 lbs. (75 kg) on the driver's seat.

Close all doors.

Tires should be properly inflated.

Rock the vehicle to stabilize the suspension.
A. Horizontal Aiming Screw
B. Vertical Aiming Screw
Start with the horizontal aim. The adjustment screws can be
turned with an E8 Torx
 socket or T15 Torx screwdriver.
Once the horizontal aim is adjusted, then adjust the
vertical aim.

yellowblue
6-69
Replacement Bulbs
Application Number
Headlamps, Composite
Inner High Beam 9005. . . . . . . . . . . . . . . . . . . . . . .
Outer Low Beam 9006. . . . . . . . . . . . . . . . . . . . . . .
Front Turn Signal 3157 NA. . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stoplamp (CHMSL) 1156. . .
Rear Turn Signal and Taillamp 2057. . . . . . . . . . . . .
Capacities and Specifications
The following approximate capacities are given in
English and metric conversions. Please refer to
ªRecommended Fluids and Lubricantsº in the
Maintenance Schedule booklet for more information.
Engine Specifications
Displacement 279 cubic inches (4 565 cc). . . . . . . . .
Type 4.6L DOHC V8. . . . . . . . . . . . . . . . . . . . . . . . . .
VIN Engine Code
DeVille and DeVille d'Elegance Y. . . . . . . . . . . . . .
Concours 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Horsepower
DeVille and DeVille
d'Elegance 275 (bhp) @ 5600 rpm. . . . . . . . . . . . . .
205 (kW) @ 5600 rpm
Concours 300 (bhp) @ 6000 rpm. . . . . . . . . . . . . . .
224 (kW) @ 6000 rpm
Torque
DeVille and DeVille
d'Elegance 300 (lb
-ft) @ 4000 rpm . . . . . . . . . . . . .
407 (N´m) @ 4000 rpm
Concours 295 (lb
-ft) @ 4400 rpm . . . . . . . . . . . . . .
400 (N´m) @ 4400 rpm
Firing Order 1
-2-7-3-4-5-6-8 . . . . . . . . . . . . . . . . . . .
Thermostat Starts To Open 177
-184
F (81-85
C) . .

yellowblue
8-2
Battery 6-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Not Charging Message 2-82 . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement, Remote Keyless Entry 2-8 . . . . . . . . . . . . . . .
Savers 2-46, 2-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voltage High Message 2-83 . . . . . . . . . . . . . . . . . . . . . . . . .
Voltage Low Message 2-83 . . . . . . . . . . . . . . . . . . . . . . . . .
Warnings 5-3, 5-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BBB Auto Line 7-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Better Business Bureau Mediation 7-3 . . . . . . . . . . . . . . . . . . .
Blade Replacement, Windshield Wipers 6-41 . . . . . . . . . . . . .
Blizzard 4-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake
Adjustment 6
-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Master Cylinder 6-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking 2-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pedal Travel 6-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing System Parts 6-32 . . . . . . . . . . . . . . . . . . . . . . . .
System Warning Light 2-69 . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer 4-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Shift Interlock (BTSI) 2-31 . . . . . . . . . . . . . . . . .
Vacuum Problem Message 2-83 . . . . . . . . . . . . . . . . . . . . . .
Wear 6-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brakes, Anti-Lock 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking in Emergencies 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . .
Break-In, New Vehicle 2-18 . . . . . . . . . . . . . . . . . . . . . . . . . .
Brightness Control 2-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BTSI 2-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Bulb Replacement 6
-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High-Mounted Stoplamp 6-39 . . . . . . . . . . . . . . . . .
Front Turn Signal Lamps 6-38 . . . . . . . . . . . . . . . . . . . . . . .
Headlamps 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Turn Signal Lamp 6-40 . . . . . . . . . . . . . . . . . . . . . . . .
Taillamps 6-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications 6-69 . . . . . . . . . . . . . . . . . . . .
Carbon Monoxide 2-33, 4-28, 4-35 . . . . . . . . . . . . . . . . . . . .
Carpet Cleaning 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Player Care 3-39 . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Players 3-16, 3-19, 3-28 . . . . . . . . . . . . . . . . . .
CD Adapter Kits 3-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CD Changer, Trunk-Mounted 3-32 . . . . . . . . . . . . . . . . . . . . .
Cellular Telephone 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center Console Storage 2-53 . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High-Mounted Stoplamp, Bulb Replacement 6-39 . . .
Center Passenger Position 1-29 . . . . . . . . . . . . . . . . . . . . . . . .
Central Door Unlocking System 2-5 . . . . . . . . . . . . . . . . . . . .
Certification Label 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains, Safety 4-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains, Tire 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Change Engine Oil Message 2-83 . . . . . . . . . . . . . . . . . . . . . .
Change Trans Fluid Message 2-84 . . . . . . . . . . . . . . . . . . . . . .
Changing a Flat Tire 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System Light 2-69 . . . . . . . . . . . . . . . . . . . . . . . . . .
Check
Brake Fluid Message 2
-84 . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Level Message 2-84 . . . . . . . . . . . . . . . . . . . . . . . .
Fuel Gauge Message 2-84 . . . . . . . . . . . . . . . . . . . . . . . . . .
Gas Cap Message 2-84 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Level Message 2-84 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Washer Fluid Message 2-84 . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
8-5
Engine 6-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Cleaner/Filter 6-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant 6-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Heater 2-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Hot, Idle Engine Message 2-85 . . . . . . . . . . . . . . .
Coolant Temperature Gage 2-73 . . . . . . . . . . . . . . . . . . . . .
Coolant Temperature Warning Light 2-72 . . . . . . . . . . . . . .
Exhaust 2-33, 4-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification 6-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Misfire, Ease Off Gas Pedal Message 2-85 . . . . . . . . . . . . .
Overheated, Stop Engine Message 2-85 . . . . . . . . . . . . . . . .
Overheating 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Reduced Message 2-85 . . . . . . . . . . . . . . . . . . . . . . .
Running While Parked 2-33, 4-28 . . . . . . . . . . . . . . . . . . . .
Specifications 6-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your 2-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Cooling When Trailer Towing 4-39 . . . . . . . . . . . . . . .
Engine Hot - A/C Off Message 2-85 . . . . . . . . . . . . . . . . . . . .
Engine Oil 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Additives 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Used 6-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What Kind of Oil to Use 6-13 . . . . . . . . . . . . . . . . . . . . . . .
When to Change 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Speed Limiter 2-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
English/Metric Button 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ethanol 6-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust, Engine 2-33, 4-28 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Express-Down Window 2-35 . . . . . . . . . . . . . . . . . . . . . . . . . . Extender, Safety Belts 1
-53 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior Lamps 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior Lighting Battery Saver 2-46 . . . . . . . . . . . . . . . . . . . .
Fabric Cleaning 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fan Button 3-2, 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling a Portable Fuel Container 6-8 . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filter, Engine Air Cleaner 6-16 . . . . . . . . . . . . . . . . . . . . . . . .
Finish Care 6-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Finish Damage 6-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
First Gear, Automatic Transaxle 2-25 . . . . . . . . . . . . . . . . . . .
Flashers, Hazard Warning 5-2 . . . . . . . . . . . . . . . . . . . . . . . . .
Flash-To-Pass 2-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flat Tire, Changing 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor Mats 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid
Automatic Transaxle 6
-19 . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake 6-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Capacities 6-70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Steering 6-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Washer 2-39, 6-27 . . . . . . . . . . . . . . . . . . . . . .
Fog Lamps 2-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foreign Countries, Fuel 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Freeway Driving 4-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
French Language Manual ii. . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Storage Area 2
-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Turn Signal Lamps, Bulb Replacement 6-38 . . . . . . . . .
