1999 CADILLAC DEVILLE warning light

yellowblue
4-25
Winter Driving
Here are some tips for winter driving:

Have your vehicle in good shape for winter.

You may want to put winter emergency supplies in
your trunk.
Include an ice scraper, a small brush or broom, a supply
of windshield washer fluid, a rag, some winter outer
clothing, a small shovel, a flashlight, a red cloth and a
couple of reflective warning triangles. And, if you will
be driving under severe conditions, include a small bag
of sand, a piece of old carpet or a couple of burlap bags
to help provide traction. Be sure you properly secure
these items in your vehicle.

yellowblue
5-2
Hazard Warning Flashers
Your hazard warning flashers let you warn others. They
also let police know you have a problem. Your front and
rear turn signal lamps will flash on and off.
Press the button in to make the front and rear turn signal
lamps flash on and off.
This light on the instrument
panel will flash, indicating
that the hazard warning
flashers are on.
The hazard warning flashers will work once the button
is pressed in regardless of the ignition key position.

yellowblue
5-8
Towing Your Vehicle
CAUTION:
To help avoid serious personal injury to you
or others:

Never let passengers ride in a vehicle that is
being towed.

Never tow faster than safe or posted speeds.

Never tow with damaged parts not
fully secured.

Never get under your vehicle after it has
been lifted by the tow truck.

Always secure the vehicle on each side with
separate safety chains when towing it.

Use only the correct hooks.
NOTICE:
Use the proper towing equipment to avoid
damage to the bumper, fascia or fog lamp areas
of the vehicle.
With current trends in automotive styles and design, it is
essential that the correct towing equipment is used to
tow a vehicle. Your vehicle can be towed with wheel
-lift
or car
-carrier equipment.
Consult your dealer or a professional towing service if
you need to have your vehicle towed. See ªRoadside
Assistanceº in the Index.
Engine Overheating
You will find an ENGINE COOLANT HOT, IDLE
ENGINE message or an ENGINE OVERHEATED,
STOP ENGINE message on the Driver Information
Center (DIC). You will also hear a chime. There is also
an engine temperature warning light and/or gage on the
instrument panel. See ªEngine Coolant Temperature
Warning Lightº or ªEngine Coolant Temperature Gageº
in the Index.

yellowblue
6-23
Engine Coolant
The cooling system in your vehicle is filled with
DEX
-COOL
engine coolant. This coolant is designed
to remain in your vehicle for 5 years or 150,000 miles
(240 000 km), whichever occurs first, if you add only
DEX
-COOL
extended life coolant.
The following explains your cooling system and how to
add coolant when it is low. If you have a problem with
engine overheating, see ªEngine Overheatingº in
the Index.
A 50/50 mixture of clean, drinkable water and
DEX
-COOL
coolant will:

Give freezing protection down to
-34F (-37C).

Give boiling protection up to 265F (129C).

Protect against rust and corrosion.

Help keep the proper engine temperature.

Let the warning lights and gages work as
they should.
NOTICE:
When adding coolant, it is important that you use
only DEX
-COOL (silicate-free) coolant.
If coolant other than DEX-COOL is added to the
system, premature engine, heater core or
radiator corrosion may result. In addition, the
engine coolant will require change sooner
-- at
30,000 miles (50 000 km) or 24 months,
whichever occurs first. Damage caused by the use
of coolant other than DEX
-COOL is not
covered by your new vehicle warranty.

yellowblue
6-29
There are only two reasons why the brake fluid level in the
reservoir might go down. The first is that the brake fluid
goes down to an acceptable level during normal brake
lining wear. When new linings are put in, the fluid level
goes back up. The other reason is that fluid is leaking out
of the brake system. If it is, you should have your brake
system fixed, since a leak means that sooner or later your
brakes won't work well, or won't work at all.
So, it isn't a good idea to ªtop offº your brake fluid.
Adding brake fluid won't correct a leak. If you add fluid
when your linings are worn, then you'll have too much
fluid when you get new brake linings. You should add
(or remove) brake fluid, as necessary, only when work is
done on the brake hydraulic system.
CAUTION:
If you have too much brake fluid, it can spill on the
engine. The fluid will burn if the engine is hot
enough. You or others could be burned, and your
vehicle could be damaged. Add brake fluid only
when work is done on the brake hydraulic system.
When your brake fluid falls to a low level, your brake
warning light will come on. See ªBrake System Warning
Lightº in the Index.

yellowblue
6-31 Brake Wear
Your vehicle has four-wheel disc brakes.
Disc brake pads have built
-in wear indicators that make a
high
-pitched warning sound when the brake pads are worn
and new pads are needed. The sound may come and go or
be heard all the time your vehicle is moving (except when
you are pushing on the brake pedal firmly).
CAUTION:
The brake wear warning sound means that soon
your brakes won't work well. That could lead to
an accident. When you hear the brake wear
warning sound, have your vehicle serviced.
NOTICE:
Continuing to drive with worn-out brake pads
could result in costly brake repair.
Some driving conditions or climates may cause a brake
squeal when the brakes are first applied or lightly
applied. This does not mean something is wrong with
your brakes.
Properly torqued wheel nuts are necessary to help
prevent brake pulsation. When tires are rotated, inspect
brake pads for wear and evenly torque wheel nuts in the
proper sequence to GM specifications.
Brake linings should always be replaced as complete
axle sets.
See ªBrake System Inspectionº in the Maintenance
Schedule booklet under Part C ªPeriodic
Maintenance Inspections.º
Brake Pedal Travel
See your dealer if the brake pedal does not return to
normal height, or if there is a rapid increase in pedal
travel. This could be a sign of brake trouble.
Brake Adjustment
Every time you apply the brakes, with or without the
vehicle moving, your brakes adjust for wear.

8-yellowblue
8-1
Section 8 Index
A
BS 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adapter Kits, CDs 3-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding Engine Oil 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding Equipment to the Outside of Your Vehicle 6-3 . . . . . .
Aiming Headlamps 6-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Bag 1-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How Does it Restrain 1-27 . . . . . . . . . . . . . . . . . . . . . . . . . .
How it Works 1-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Location 1-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Readiness Light 1-23, 2-68 . . . . . . . . . . . . . . . . . . . . . . . . .
Servicing 1-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What Makes it Inflate 1-26 . . . . . . . . . . . . . . . . . . . . . . . . . .
What Will You See After it Inflates 1-27 . . . . . . . . . . . . . . .
When Should it Inflate 1-26 . . . . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning 3-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning Refrigerants 6-70 . . . . . . . . . . . . . . . . . . . . .
Air Control, Climate Control System 3-3, 3-6 . . . . . . . . . . . . .
Alarm, Theft-Deterrent 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . .
Alignment and Balance, Tire 6-49 . . . . . . . . . . . . . . . . . . . . . .
Aluminum Wheels, Cleaning 6-55 . . . . . . . . . . . . . . . . . . . . . .
Analog Cluster Climate Control Panel 3-6 . . . . . . . . . . . . . . . .
Analog Control Buttons 2-81 . . . . . . . . . . . . . . . . . . . . . . . . . .
Antenna, Power 3-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Antifreeze 6-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Anti
-Lock
Brake System Warning Light 2-71, 4-7 . . . . . . . . . . . . . . . .
Brakes 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lockout Feature 2-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Anti-Theft, Radio 3-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appearance Care 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appearance Materials, Vehicle Care 6-57 . . . . . . . . . . . . . . . .
Apply Brake To Shift Message 2-82 . . . . . . . . . . . . . . . . . . . .
Arbitration Program 7-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Armrest, Storage 2-53, 2-54 . . . . . . . . . . . . . . . . . . . . . . . . . .
Ashtrays 2-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Assist Handles 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio Equipment, Adding 3-39 . . . . . . . . . . . . . . . . . . . . . . . .
Audio Steering Wheel Controls 3-37 . . . . . . . . . . . . . . . . . . . .
Audio System, Tips 3-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio Systems 3-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic Door Locks 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic Pull-Down Feature, Trunk Lid 2-13 . . . . . . . . . . . .
Automatic Transaxle
Overdrive 2
-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your Engine 2-20 . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 2-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shifting 2-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
8-2
Battery 6-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Not Charging Message 2-82 . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement, Remote Keyless Entry 2-8 . . . . . . . . . . . . . . .
Savers 2-46, 2-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voltage High Message 2-83 . . . . . . . . . . . . . . . . . . . . . . . . .
Voltage Low Message 2-83 . . . . . . . . . . . . . . . . . . . . . . . . .
Warnings 5-3, 5-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BBB Auto Line 7-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Better Business Bureau Mediation 7-3 . . . . . . . . . . . . . . . . . . .
Blade Replacement, Windshield Wipers 6-41 . . . . . . . . . . . . .
Blizzard 4-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake
Adjustment 6
-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Master Cylinder 6-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking 2-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pedal Travel 6-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing System Parts 6-32 . . . . . . . . . . . . . . . . . . . . . . . .
System Warning Light 2-69 . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer 4-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Shift Interlock (BTSI) 2-31 . . . . . . . . . . . . . . . . .
Vacuum Problem Message 2-83 . . . . . . . . . . . . . . . . . . . . . .
Wear 6-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brakes, Anti-Lock 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking in Emergencies 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . .
Break-In, New Vehicle 2-18 . . . . . . . . . . . . . . . . . . . . . . . . . .
Brightness Control 2-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BTSI 2-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Bulb Replacement 6
-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High-Mounted Stoplamp 6-39 . . . . . . . . . . . . . . . . .
Front Turn Signal Lamps 6-38 . . . . . . . . . . . . . . . . . . . . . . .
Headlamps 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Turn Signal Lamp 6-40 . . . . . . . . . . . . . . . . . . . . . . . .
Taillamps 6-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications 6-69 . . . . . . . . . . . . . . . . . . . .
Carbon Monoxide 2-33, 4-28, 4-35 . . . . . . . . . . . . . . . . . . . .
Carpet Cleaning 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Player Care 3-39 . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Players 3-16, 3-19, 3-28 . . . . . . . . . . . . . . . . . .
CD Adapter Kits 3-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CD Changer, Trunk-Mounted 3-32 . . . . . . . . . . . . . . . . . . . . .
Cellular Telephone 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center Console Storage 2-53 . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High-Mounted Stoplamp, Bulb Replacement 6-39 . . .
Center Passenger Position 1-29 . . . . . . . . . . . . . . . . . . . . . . . .
Central Door Unlocking System 2-5 . . . . . . . . . . . . . . . . . . . .
Certification Label 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains, Safety 4-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains, Tire 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Change Engine Oil Message 2-83 . . . . . . . . . . . . . . . . . . . . . .
Change Trans Fluid Message 2-84 . . . . . . . . . . . . . . . . . . . . . .
Changing a Flat Tire 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System Light 2-69 . . . . . . . . . . . . . . . . . . . . . . . . . .
Check
Brake Fluid Message 2
-84 . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Level Message 2-84 . . . . . . . . . . . . . . . . . . . . . . . .
Fuel Gauge Message 2-84 . . . . . . . . . . . . . . . . . . . . . . . . . .
Gas Cap Message 2-84 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Level Message 2-84 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Washer Fluid Message 2-84 . . . . . . . . . . . . . . . . . . . . . . . . .
