6-31 Brake Wear
Your vehicle has four-wheel disc brakes.
Disc brake pads have built
-in wear indicators that make a
high
-pitched warning sound when the brake pads are worn
and new pads are needed. The sound may come and go or
be heard all the time your vehicle is moving (except when
you are pushing on the brake pedal firmly).
CAUTION:
The brake wear warning sound means that soon
your brakes won't work well. That could lead to
an accident. When you hear the brake wear
warning sound, have your vehicle serviced.
NOTICE:
Continuing to drive with worn-out brake pads
could result in costly brake repair.
Some driving conditions or climates may cause a brake
squeal when the brakes are first applied or lightly
applied. This does not mean something is wrong with
your brakes.
Properly torqued wheel nuts are necessary to help
prevent brake pulsation. When tires are rotated, inspect
brake pads for wear and evenly torque wheel nuts in the
proper sequence to GM specifications.
Brake linings should always be replaced as complete
axle sets.
See ªBrake System Inspectionº in the Maintenance
Schedule booklet under Part C ªPeriodic
Maintenance Inspections.º
Brake Pedal Travel
See your dealer if the brake pedal does not return to
normal height, or if there is a rapid increase in pedal
travel. This could be a sign of brake trouble.
Brake Adjustment
Every time you apply the brakes, with or without the
vehicle moving, your brakes adjust for wear.

yellowblue
6-35
5. Reinstall the headlamp housing socket back into the
headlamp assembly.Headlamp Aiming
Your vehicle has a headlamp system equipped with
horizontal and vertical aim indicators. The aim has been
pre
-set at the factory and should need no further
adjustment. This is true even though your vertical and
horizontal aim indicators may not fall exactly on the ª0º
(zero) marks on their scales.
If your vehicle is damaged in an accident, the headlamp
aim may be affected. Aim adjustment may be necessary
if it is difficult to see lane markers (for horizontal aim),
or if oncoming drivers flash their high beams at you (for
vertical aim). If you believe your headlamps need to be
re
-aimed, we recommend that you take it to your dealer
for service; however, it is possible for you to re
-aim
your headlamps as described in the following procedure.
NOTICE:
To make sure your headlamps are aimed
properly, read all the instructions before
beginning. Failure to follow these instructions
could cause damage to headlamp parts.

yellowblue
6-46
When It's Time for New Tires
One way to tell when it's
time for new tires is to
check the treadwear
indicators, which will
appear when your tires have
only 1/16 inch (1.6 mm) or
less of tread remaining.
You need a new tire if any of the following statements
are true:

You can see the indicators at three or more places
around the tire.

You can see cord or fabric showing through the
tire's rubber.

The tread or sidewall is cracked, cut or snagged deep
enough to show cord or fabric.
The tire has a bump, bulge or split.

The tire has a puncture, cut or other damage that
can't be repaired well because of the size or location
of the damage.
Buying New Tires
To find out what kind and size of tires you need, look at
the Tire
-Loading Information label.
The tires installed on your vehicle when it was new had
a Tire Performance Criteria Specification (TPC Spec)
number on each tire's sidewall. When you get new tires,
get ones with that same TPC Spec number. That way
your vehicle will continue to have tires that are designed
to give proper endurance, handling, speed rating,
traction, ride and other things during normal service on
your vehicle. If your tires have an all
-season tread
design, the TPC number will be followed by an ªMSº
(for mud and snow).
If you ever replace your tires with those not having a
TPC Spec number, make sure they are the same size,
load range, speed rating and construction type (bias,
bias
-belted or radial) as your original tires.

yellowblue
8-7
Instrument Panel 2-62 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning the Top 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clusters 2-64, 2-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Intensity/Brightness Control 2-46 . . . . . . . . . . . . . . . . . . . .
Interior Lamps 2-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jack, Tire 5-20, 5-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keyless Entry System, Remote 2-7 . . . . . . . . . . . . . . . . . . . .
Keys 2-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Labels
Certification 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Parts Identification 6-58 . . . . . . . . . . . . . . . . . . . . .
Tire-Loading Information 4-30 . . . . . . . . . . . . . . . . . . . . . .
Vehicle Identification Number 6-58 . . . . . . . . . . . . . . . . . . .
Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cornering 2
-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Courtesy 2-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime Running Lamps 2-43 . . . . . . . . . . . . . . . . . . . . . . .
Exterior 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog 2-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel Intensity/Brightness Control 2-46 . . . . . .
Interior 2-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Map 2-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reading 2-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Underhood 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Leaving Your Vehicle with the Engine Running 2
-30 . . . . . . .
Level Control, Electronic 4-31 . . . . . . . . . . . . . . . . . . . . . . . . .
Light Sensor 2-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lighted Visor Vanity Mirror 2-55 . . . . . . . . . . . . . . . . . . . . . .
Lighter 2-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lights
Air Bag Readiness 1
-23, 2-68 . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock Brake System Warning 2-71, 4-7 . . . . . . . . . . . .
Brake System Warning 2-69 . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System 2-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Coolant Temperature Warning 2-72 . . . . . . . . . . . . .
Interior 2-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Pressure 2-76 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking Brake Indicator 2-70 . . . . . . . . . . . . . . . . . . . . . . . .
Safety Belt Reminder 1-7, 2-68 . . . . . . . . . . . . . . . . . . . . . .
Service Engine Soon 2-73 . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction Control System Warning 2-72, 4-9 . . . . . . . . . . . .
Limiter, Engine Speed 2-67 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Limiter, Vehicle Speed 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loading Your Vehicle 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lock, Torque 2-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Locks 2-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lockout Feature 2-6 . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic Door 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door 2-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Door 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Programmable Automatic Door 2-5, 2-91 . . . . . . . . . . . . . .
Rear Door Security 2-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trunk Release 2-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lock/Unlock Confirmation 2-92 . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
8-9
Parking
At Night 2-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake 2-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake Indicator Light 2-70 . . . . . . . . . . . . . . . . . . . . . . . . . .
Lots 2-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Over Things That Burn 2-32 . . . . . . . . . . . . . . . . . . . . . . . .
With a Trailer on Hills 4-38 . . . . . . . . . . . . . . . . . . . . . . . . .
Parking Lamps 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Passenger 's Side Temperature Knob/Button 3-3, 3-6 . . . . . . .
Passing 4-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PASS-Key
II 2-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
People with Disabilities, GM Mobility Program 7-5 . . . . . . . .
Personalization Feature, Radio 3-36 . . . . . . . . . . . . . . . . . . . .
Phone Not Present Message 2-86 . . . . . . . . . . . . . . . . . . . . . . .
Playing a Cassette Tape 3-16, 3-19, 3-28 . . . . . . . . . . . . . . . .
Playing a Compact Disc 3-21, 3-30 . . . . . . . . . . . . . . . . . . . . .
Power
Accessory, Retained 2
-19 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Antenna Mast Care 3-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Locks 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Remote Control Mirror 2-51 . . . . . . . . . . . . . . . . . . . . . . . .
Seat 1-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering Fluid 6-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windows 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windows and Other Power Options 6-59 . . . . . . . . . . . . . . .
Pregnancy, Use of Safety Belts 1-20 . . . . . . . . . . . . . . . . . . . .
Problems on the Road 5-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Program Pass Key Message 2-86 . . . . . . . . . . . . . . . . . . . . . . .
Programmable Automatic Door Locks 2-5, 2-91 . . . . . . . . . .
Publications, Service and Owner 7-11, 7-12 . . . . . . . . . . . . . .
Pull-Down Feature, Automatic Trunk Lid 2-13 . . . . . . . . . . . .
Radios 3-14, 3-18, 3-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Data Systems (RDS) Program Type (PTY)
Selections 3
-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Personalization with Home and Away Feature 3-36 . . . . . .
Reception, Understanding 3-38 . . . . . . . . . . . . . . . . . . . . . .
Theft-Deterrent Feature 3-37 . . . . . . . . . . . . . . . . . . . . . . . .
Rain, Driving In 4-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rainsense Wipers 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RAP 2-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reading Lamps 2-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear
Compartment Fuse Block 6
-66 . . . . . . . . . . . . . . . . . . . . . . .
Door Security Locks 2-6 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lighted Visor Vanity Mirror 2-55 . . . . . . . . . . . . . . . . . . . . .
Lockout Windows 2-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside Seat Position 1-31 . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat Passengers 1-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Armrest 2-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signal Lamps, Bulb Replacement 6-40 . . . . . . . . . . . .
Window Defogger 3-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rearview Mirrors 2-49, 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recirculation 3-5, 3-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reclining Front Seatbacks 1-4 . . . . . . . . . . . . . . . . . . . . . . . . .
Recreational Vehicle Towing 4-29 . . . . . . . . . . . . . . . . . . . . . .
Refrigerants, Air Conditioning 6-70 . . . . . . . . . . . . . . . . . . . .
Remote
Fuel Door Release 6
-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keyless Entry 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recall Memory 2-93 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trunk Release 2-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Remove Key Message 2-86 . . . . . . . . . . . . . . . . . . . . . . . . . . .
