1999 BUICK REGAL light

yellowblue
2-73 Cruise Light
The CRUISE light comes
on whenever you set your
cruise control. See ªCruise
Controlº in the Index.
Performance Shift Light (If Equipped)
The PERF SHIFT light
comes on when you press
the performance shift button
to indicate that your vehicle
is in performance shifting
mode. See ªPerformance
Shiftingº in the Index.
Service Vehicle Soon Light
The SERVICE VEHICLE
SOON light will come on if
you have certain
non
-emission related
vehicle problems.
These problems may not be obvious and may affect
vehicle performance or durability. Consult a qualified
dealership for necessary repairs to maintain top vehicle
performance. The light will come on briefly when your
ignition is turned on to show that it is working properly.
Low Washer Fluid Warning Light
The LOW WASH light will
come on when your
windshield washers are
working and the fluid
container is low.
The light will also come on briefly when your ignition is
turned on to show that it is working properly.
ProCarManuals.com

yellowblue
2-74 Door/Trunk Ajar Warning Light
The DOOR/TRUNK light
will come on if your trunk
or any door is not
completely closed.
Fuel Gage
Your fuel gage tells you
about how much fuel you
have left when the ignition
is on. When the indicator
nears EMPTY (E), you still
have a little fuel left, but
you should get more soon.Here are four things that some owners ask about. All
these things are normal and do not indicate that anything
is wrong with the fuel gage:

At the gas station, the pump shuts off before the gage
reads FULL (F).

It takes more (or less) fuel to fill up than the gage
reads. For example, the gage reads half full, but it
took more (or less) than half of the tank's capacity to
fill it.

The gage pointer may move while cornering, braking
or speeding up.

The gage may not indicate EMPTY (E) when the
ignition is turned off.
ProCarManuals.com

yellowblue
2-75 Low Fuel Light
If your fuel is low, a circular
light on your instrument
panel will come on and stay
on and a chime will sound
periodically until you
add fuel.
It will also come on for a few seconds when you first
turn on the ignition as a check to show you it's working.
If it doesn't come on then, have it fixed.
Driver Information Center (Option)
3800 V6 Supercharged Engine
ProCarManuals.com

yellowblue
2-76
3800 V6 Engine
Your Driver Information Center, (DIC) located below
the tachometer on the instrument panel cluster, gives
you important safety and maintenance facts. When you
turn the ignition on, the entire center lights up for just a
few seconds.
Control Buttons
The Driver Information Center has three buttons that
control its functions.
E/M, RESET AND MODE: The English/Metric
(E/M), RESET and MODE buttons for the Driver
Information Center are located to the left of the steering
wheel, just below the instrument panel cluster.
E/M: Press this button to change the display from
English to metric units or metric to English.
ProCarManuals.com

yellowblue
2-77
RESET: Press this button for one second to reset the
mode displayed.
MODE: Press this button to change the mode
being displayed.
Modes
AVG ECON: Shows your average fuel economy since
you last reset this mode. Average fuel economy is
viewed as a long term approximation of your overall
driving and driving conditions. To learn the average fuel
economy from a new starting point, press the RESET
button while the average fuel economy is displayed in
the DIC.
INSTANTANEOUS FUEL ECONOMY: Shows your
current fuel economy. Instantaneous fuel economy
varies with your driving conditions, such as
acceleration, braking and the grade of the road being
traveled. The instantaneous fuel economy display cannot
be reset, therefore the reset button has no effect while in
this mode.OIL LIFE MONITOR: Shows an estimate of the oil's
remaining useful life. When the oil life index is less than
10%, the CHANGE OIL SOON light will come on.
When you have the oil changed according to the
maintenance schedule (see ªMaintenance Scheduleº in
the Index), you will have to reset the oil life monitor. To
do this, press and hold the RESET button for more than
five seconds while the oil life monitor is being displayed
on the DIC. The oil life will change to 100%.
RANGE: Shows the approximate distance you can
drive without refueling. This is based on the amount of
fuel in the tank and on the fuel economy of the most
recent 25 miles (40 km). Pressing RESET while in this
mode will have no effect.
BOOST GAGE: If you have the supercharged engine,
this gage will show the amount of boost your engine is
receiving. Pressing RESET while in this mode will have
no effect.
ProCarManuals.com

yellowblue
3-3
NORM: This setting brings in outside air and sends it
through the instrument panel outlets. The air
conditioning compressor will run automatically in this
setting unless the outside temperature is below 40
F
(4
C). (Even when the compressor is running, you can
control the temperature.)
BI
-LEV: This setting brings in outside air and directs it
two ways. Half of the air is directed through the
instrument panel outlets. Most of the remaining air is
directed through the floor ducts and a little to the defrost
and side window vents. The air conditioning compressor
will run automatically in this setting unless the outside
temperature is below 40
F (4
C). (Even when the
compressor is running, you can control the temperature.)
VENT: This setting brings in outside air and directs it
through the instrument panel outlets.
HTR: This setting sends most of the air through the
ducts near the floor. The rest comes out of the defroster
and side window vents.
BLEND: This setting allows half of the air to go to the
floor ducts and half to the defroster and side window
vents. The air conditioning compressor will run
automatically in this setting unless the outside
temperature is below 40
F (4
C). (Even when the
compressor is running, you can control the temperature.)
FRONT: This setting directs most of the air
through the defroster and side window vents. Some of
the air goes to the floor ducts and the side window vents.
The air conditioning compressor will run automatically
in this setting unless the outside temperature is below
40
F (4
C). (Even when the compressor is running, you
can control the temperature.)
Air Conditioning
On very hot days, open the windows long enough to let
hot, inside air escape. This reduces the time for the
vehicle to cool down.
For a quick cool
-down on very hot days, use MAX with
the temperature knob and lever all the way in the blue
area. If this setting is used for long periods of time, the
air in your vehicle may become too dry.
For normal cooling on hot days, use NORM with the
temperature knob and lever in the blue area. The system
will bring in outside air and cool it.
On cool, but sunny days, the sun may warm your upper
body, but your lower body may not be warm enough.
You can use BI
-LEV and set the temperature knob to a
comfortable setting. The system will bring in outside air
and direct it to your upper body, while sending slightly
warmed air to your lower body. You may notice this
temperature difference more at some times than others.
ProCarManuals.com

yellowblue
3-5
Temperature Control
The TEMP switch sets the temperature for the entire
system when the light on the DUAL button isn't lit. If
the DUAL button light is lit, this master temperature
control sets the temperature for the driver only. Press the
up arrow to raise the temperature and press the down
arrow to lower the temperature. The display will show
your selection for a few seconds, then the outside
temperature will be displayed. If you push the AUTO
button, the system will control the fan speed and airflow.
Passenger's Temperature Control
The PASSENGER CONTROL buttons with the arrows
adjust the temperature on the passenger's side so it is
warmer or cooler than the temperature set by the driver.
Push the DUAL button so that the indicator light is lit.
Press the right arrow button to raise the temperature.
Press the left arrow button to lower the temperature. The
display will not show the passenger's temperature, only
that of the driver. Indicators in the passenger control
section will show passenger temperature relative to the
driver's set temperature.

The amber light indicates the same temperature as
set for the driver.

The red lights indicate a warmer temperature than
that of the driver.
The blue lights indicate a cooler temperature than
that of the driver.
Manual Control
If you prefer to manually control the heating, cooling
and ventilation in your vehicle, you can select airflow
direction, fan speed, outside or recirculated air and air
compressor operation with the following buttons:
AIR FLOW: This control has several settings to control
the direction of airflow when the system is not in AUTO.
To access the various modes available, continue to press
the AIR FLOW rocker button up or down until the
desired mode appears in the display:

WINDSHIELD/FLOOR: This setting directs half
of the air to the floor ducts and half to the defroster
and side window vents.

MID/FLOOR: This setting directs half of the air
through the instrument panel outlets. Most of the
remaining air is directed through the floor ducts and
a little to the defroster and side window vents.

MID: This setting directs air through the instrument
panel outlets.

FLOOR: This setting sends most of the air through
the ducts near the floor. The rest comes out of the
defroster and side window vents.
ProCarManuals.com

yellowblue
3-6
FRONT: This setting brings in outside air and
directs most of the air through the defrost vent. Some of
the air also goes to the floor ducts and the side window
defogger outlets. The indicator on the button will light
and WINDSHIELD will be lit in the display. The air
conditioning compressor will run automatically in
this setting unless the outside temperature is below
40
F (4
C).
VENT: This pushbutton turns the air conditioning
compressor on and off. The indicator is lit when the
compressor is turned off. Recirculation is not permitted
when the compressor is off. The system will try to
control the temperature automatically, but without
the compressor.
VENT is not permitted in FRONT defrost mode. If the
VENT button is pushed while in FRONT defrost mode,
the indicator will light for one second and then turn off.
RECIRC: This setting recirculates much of the air
inside your vehicle. This setting is not permitted in
FRONT defrost mode and is only permitted in WINDSHIELD/FLOOR mode if the compressor is
turned on. The indicator light will be lit when
recirculation is engaged, but will light for one second
and then turn off if selected when not permitted.
Heating (Engine Coolant Heater)
If your vehicle has an engine coolant heater, you can use
it to help your system provide warm air faster when it's
cold outside
-- 0
F (-18
C) or lower. An engine
coolant heater warms the coolant your engine and
heating system use to provide heat. See ªEngine Coolant
Heaterº in the Index.
Defogging and Defrosting
Your system has two settings for clearing the front and
side windows. To defrost the windows quickly, press the
FRONT button; set the temperature to 90
F (32
C),
select high fan speed and turn the DUAL button off. To
warm passengers while keeping the windows clear, push
the AIR FLOW button until WINDSHIELD/FLOOR
appears in the display. Select fan speed for comfort and
windshield clearing performance.
ProCarManuals.com
