Page 92 of 368

yellowblue
2-32
The second override access slot is located on the upper
right hand side of the console shift panel. To use
this slot:
1. Verify that the shift lever is in PARK (P) and that the
shift knob button is fully released.
2. Locate the override access slot on the upper right
hand side of the shift panel.
3. Remove the override access slot cap, which will then
show the shift lock release button.
4. Insert a key or screwdriver into the access slot and
press in and hold the shift lock release button.
5. Press the shift knob button in and hold.
6. Remove the key or screwdriver from the slot.
7. Pull the shift lever into the desired gear position.
8. Replace the override access slot cap.
You will not be able to remove your key from the
ignition unless the shift lever is in PARK (P) with the
shift knob button fully released.Parking Over Things That Burn
CAUTION:
Things that can burn could touch hot exhaust
parts under your vehicle and ignite. Don't park
over papers, leaves, dry grass or other things that
can burn.
ProCarManuals.com
Page 104 of 368

yellowblue
2-44 Delayed Headlamp Illumination
Delayed Headlamp Illumination provides a period of
exterior lighting as you leave your vehicle's area. The
feature is activated when your vehicle's headlamps are
on due to the automatic headlamp control feature
described previously in this section, and when your
vehicle's ignition is turned off. Your headlamps will
then remain on until the headlamp switch is moved from
OFF to the parking lamp position or until a 90 second
lighting period has ended.
If you turn off the ignition with the headlamp switch in
the parking lamp or headlamp position, the Delayed
Headlamp Illumination cycle will not occur.
You can customize the vehicle to activate Delayed
Headlamp Illumination when your vehicle's ignition is
turned off under the conditions described above, or you
may choose not to activate this feature under any
conditions. You can turn the feature on and off when
you perform the following sequence with the doors
closed and the ignition key in RUN:
1. Press and hold the power door lock switch. While
holding the door lock switch, cycle the headlamp
switch on and then off two times.2. Release the power door lock switch. These
operations must be carried out in a time period of
less than 10 seconds, followed by a delay period of
no more than 10 seconds.
3. Then, press and hold the power door unlock switch.
While holding the door unlock switch, turn the
headlamp switch on and then off two times. Release
the courtesy door unlock switch. These steps must be
carried out in a time period of less than 10 seconds.
After releasing the door unlock switch, a single chime
will be heard if the Delayed Headlamp Illumination
function has been disabled; two chimes will be heard if
the feature has been enabled. Disconnecting the
vehicle's battery for up to a year will not change the
programmed operation of this feature.
ProCarManuals.com
Page 105 of 368

yellowblue
2-45 Fog Lamps
To turn the fog lamps on,
press the fog lamps switch
located below the headlamp
switch on the left side of the
steering column.
A light will glow on the switch to let you know that they
are on. (Your parking lamps or low
-beam headlamps
must be on or your fog lamps won't come on.) Press the
switch again to turn the fog lamps off. The fog lamps
will go off whenever you change to high
-beam
headlamps. When you return to low beams, the fog
lamps will come on again.
Cornering Lamps
The cornering lamps are designed to come on when you
signal a turn. This will provide more light for cornering
at night.
Interior Lamps
Instrument Panel Brightness Control
You can brighten or dim the instrument panel lights by
moving the LIGHTS dial. If you turn the dial past
MAX, your courtesy or interior lamps will come on.
Courtesy Lamps
When any door is opened, several lamps come on. These
lamps are courtesy lamps. They make it easy for you to
enter and leave your vehicle. You can also turn these
lamps on by twisting or turning the interior lights knob
all the way to the right.
Illuminated Entry
Your courtesy lamps will come on and stay on for a set
time whenever you press UNLOCK on the remote
keyless entry transmitter.
If you open a door, the lamps will stay on while it's open
and then turn off automatically about 25 seconds after
you close it. If you press UNLOCK and don't open a
door, the lamps will turn off after about 40 seconds.
ProCarManuals.com
Page 106 of 368

yellowblue
2-46
Illuminated Entry includes a feature called Theater
Dimming. With Theater Dimming, the lamps don't just
turn off at the end of the delay time. Instead, they slowly
dim after the delay time until they go out. The delay
time is canceled if you turn the ignition key to RUN or
START, so the lamps will dim right away.
When the ignition is on, Illuminated Entry is inactive,
which means the courtesy lamps won't come on unless a
door is opened.
Delayed Entry Lighting
Delayed Entry Lighting lights your vehicle's interior for
a period of time after all the doors have been closed.
The ignition must be off for Delayed Entry Lighting to
work. Just after all the doors have been closed, the
Delayed Entry Lighting feature will continue to
work until:
the ignition is in RUN, or
the doors are locked or
an illumination period of 25 seconds has elapsed.
If during the illumination period a door is opened, the
timed illumination period will be canceled and the
interior lamps will remain on since a door is open.
Delayed Exit Lighting
This feature illuminates your vehicle's interior for a
period of time after the ignition key is removed from
the ignition.
The vehicle's ignition must be off for Delayed Exit
Lighting to work. When the ignition key is removed,
interior illumination will activate and remain on until:
the ignition is in RUN or,
the power door locks are activated or
an illumination period of 25 seconds has elapsed.
If during the illumination period a door is opened, the
timed illumination period will be canceled and the
interior lamps will remain on since a door is open.
Perimeter Lighting
Perimeter lighting provides a period of exterior vehicle
lighting as the driver and passengers approach the
vehicle. Perimeter lighting is only activated when the
function is enabled, the doors are closed, the ignition is
in OFF and the security feedback feature is in Mode 3 or
4. (See ªSecurity Feedbackº in the Index for more
information.) The vehicle headlamps and back
-up lamps
are then activated for a period of 15 seconds or until the
vehicle ignition switch is turned to RUN.
ProCarManuals.com
Page 107 of 368

yellowblue
2-47
You may enable or disable the perimeter lighting feature
when the driver performs the following sequence with
the engine not running, the doors closed and the ignition
key in RUN:
1. Apply your brakes.
2. Press and hold the power door lock switch. While
holding the door lock switch press and release the
remote alarm button on the remote keyless entry
transmitter. This will initialize the customization
mode. While in the customization mode, the feature
will sound the number of chimes corresponding to
the current mode: In Mode 1, one chime means the
feature is disabled. In Mode 2, two chimes signal
that the perimeter lighting feature is enabled. Each
additional press will advance the mode by one,
starting from the current mode. During this
procedure, the feature will sound the number of
chimes corresponding to the mode. When the lock
switch is released, the vehicle will remain in the
last mode.
Disconnecting the vehicle's battery for up to a year will
not change the programmed operation of this feature.Rearview Mirror Reading Lamps
Use the switch next to each lamp to turn them on
and off.
Dome Lamp (If Equipped)
The dome lamp will come on when you open the doors.
ProCarManuals.com
Page 108 of 368

yellowblue
2-48 Battery Rundown Protection
Your vehicle has a feature to help prevent you from
draining the battery in case you accidentally leave the
interior courtesy lamps, reading/map lamps, visor vanity
lamps, trunk lamp, underhood lamp or glove box lamps
on. If you leave any of these lamps on, they will
automatically turn off after 20 minutes, if the ignition is
in OFF. The lamps won't come back on again until you:
turn the ignition on,
turn the lamp switch off, then on, or
open a door.
Note that if your vehicle has less than 15 miles (25 km)
on the odometer, the battery saver will turn off the lamps
after only three minutes.
Retained Accessory Power
With retained accessory power, your power windows,
audio system and sunroof will continue to work up to
10 minutes after the ignition key is turned to OFF and
before any of the doors are opened.
Mirrors
Adjust all the mirrors so you can see clearly when you
are sitting in a comfortable driving position.
Electrochromic Automatic Dimming
Rearview Mirror (If Equipped)
Your vehicle may have an electrochromic day/night
rearview mirror. Push the button in the center of the
mirror to turn this feature on. The mirror will darken
gradually to reduce glare from headlamps behind you.
This may take a few moments.
The mirror's two outer buttons operate the lights on the
bottom sides of the mirror.
One photocell on the front of the mirror senses when it
is becoming dark outside. Another photocell, facing
rearward, senses headlamps behind you. To turn the
electrochromic feature off, press the button in the center
of the mirror again.
ProCarManuals.com
Page 110 of 368
yellowblue
2-50 Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.
Storage Compartments
Glove Box
Use the door key to lock and unlock the glove box. To
open, lift the latch.
Center Console
The console has cupholders, a cassette tape storage area
and a coinholder. To open the console's storage area,
press the latch located toward the front of the console lid
on the driver's side of the vehicle and pull up.
ProCarManuals.com
Page 111 of 368
yellowblue
2-51
To access the cupholders, press on the top of the
cupholder door, located just behind the console shift
lever. Two cupholders will pop into an upright position.
Rear Seat Pass-Through (If Equipped)
If your vehicle has this feature, you may access your trunk
by pulling down the center back seat cushion
-- this gives
you access to the pass
-through door. The door can only be
unlocked using your door key. Once this door is unlocked,
you will then have access to the trunk area.
To access the rear cupholders, once again, pull down on
the strap located toward the top of your center back
seat cushion. You will then have access to the dual
oversized cupholders.
