1999 BUICK LESABRE headlamp

yellowblue
6-35
The vehicle should be properly prepared as follows:

The vehicle must have all four tires on a perfectly
level surface.

If necessary, pads may be used on an uneven surface.

The vehicle should not have any snow, ice or mud
attached to it.

The vehicle should be fully assembled and all other
work stopped while headlamp aiming is being done.

There should not be any cargo or loading of the
vehicle, except it should have a full tank of fuel and
one person or 160 lbs. (75 kg) on the driver's seat.

Close all doors.

Tires should be properly inflated.

Rock the vehicle to stabilize the suspension.
The headlamp aiming devices are under the hood near
the headlamps.
A. Horizontal Aiming Screw
B. Vertical Aiming Screw
Start with the horizontal aim. The adjustment screws
can be turned with an E8 Torx
 socket or
T15 Torx screwdriver.
Once the horizontal aim is adjusted, then adjust the
vertical aim.

yellowblue
6-36
H±46±0860±X
1. Turn the horizontal
aiming screw (A) until
the indicator (C) is lined
up with zero.
A. Horizontal Aiming
Screw
C. Indicator
H±46±0862±X
B. Vertical Aiming Screw D. Level Bubble2. Turn the vertical aiming screw (B) until the level
bubble (D) is lined up with zero.
Front Turn Signal
The front turn signal bulbs can be accessed from under
the front of the vehicle. Reach up from under the vehicle
and, while pushing in the tab on the bulb assembly, turn
the assembly counterclockwise and remove. Remove the
old bulb by pulling it straight out of the retainer. Replace
the bulb and turn the bulb assembly back into place.
Cornering Lamps
Follow the same procedure as used for replacing the
headlamps. However, to remove the cornering lamp
bulb, turn the bulb assembly counterclockwise and pull
the bulb straight out.

yellowblue
6-47
Each new wheel should have the same load-carrying
capacity, diameter, width, offset and be mounted the
same way as the one it replaces.
If you need to replace any of your wheels, wheel bolts
or wheel nuts, replace them only with new GM original
equipment parts. This way, you will be sure to have the
right wheel, wheel bolts and wheel nuts for your vehicle.
CAUTION:
Using the wrong replacement wheels, wheel bolts
or wheel nuts on your vehicle can be dangerous.
It could affect the braking and handling of your
vehicle, make your tires lose air and make you
lose control. You could have a collision in which
you or others could be injured. Always use the
correct wheel, wheel bolts and wheel nuts
for replacement.
NOTICE:
The wrong wheel can also cause problems with
bearing life, brake cooling, speedometer or
odometer calibration, headlamp aim, bumper
height, vehicle ground clearance and tire or tire
chain clearance to the body and chassis.
See ªChanging a Flat Tireº in the Index for
more information.
Used Replacement Wheels
CAUTION:
Putting a used wheel on your vehicle is
dangerous. You can't know how it's been used or
how far it's been driven. It could fail suddenly
and cause an accident. If you have to replace a
wheel, use a new GM original equipment wheel.

yellowblue
6-58
Electrical System
Add-On Electrical Equipment
NOTICE:
Don't add anything electrical to your vehicle
unless you check with your dealer first. Some
electrical equipment can damage your vehicle
and the damage wouldn't be covered by your
warranty. Some add
-on electrical equipment
can keep other components from working as
they should.
Your vehicle has an air bag system. Before attempting to
add anything electrical to your vehicle, see ªServicing
Your Air Bag
-Equipped Vehicleº in the Index.
Headlamp Wiring
The headlamp wiring is protected by an internal circuit
breaker. An electrical overload will cause the lamps
to go on and off, or in some cases to remain off.
If this happens, have your headlamp system checked
right away.
Windshield Wipers
The windshield wiper motor is protected by an internal
circuit breaker and a fuse. If the motor overheats due to
heavy snow, etc., the wiper will stop until the motor
cools. If the overload is caused by some electrical
problem, be sure to have it fixed.
Power Windows and Other
Power Accessories
Circuit breakers in the fuse panel protect the power
windows and other power accessories. When the current
load is too heavy, the circuit breaker opens and closes,
protecting the circuit until the problem is fixed or
goes away.
Maxifuse
/Relay Center
To check the fuses in this underhood fuse center, turn
the two knobs one
-quarter turn counterclockwise and
loosen the metal wing nut on the passenger side of the
cover. Then remove the cover. The inside of the cover
has a chart that explains the features and controls
governed by each fuse and relay.

yellowblue
6-63
Fuse Usage
1 Door Locks
2 Trunk Release, RAC
3 Horns
4 Not Used
5 Miscellaneous Engine Controls (OBD II)
6 Fuel Pump
7 Injectors
8 Powertrain Control Module
9 Not Used
10 Not Used
11 A/C Programmer
12 Not UsedReplacement Bulbs
Front Outside Lamps Bulb
Cornering Lamps 3156. . . . . . . . . . . . . . . . . . . . . .
Halogen Headlamps
Low Beam 9006. . . . . . . . . . . . . . . . . . . . . . . . . .
High Beam 9005. . . . . . . . . . . . . . . . . . . . . . . . . .
Parking/Turn Signal Lamps 3057. . . . . . . . . . . . . .
Rear Outside Lamps
Back
-Up Lamps 3156. . . . . . . . . . . . . . . . . . . . . . .
Tail 194. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tail/Stop/Turn Signal lamps 3357. . . . . . . . . . . . . .
For service information on other bulbs, contact your
dealer's service department.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
9-5
Gages
Engine Coolant Temperature 2-64 . . . . . . . . . . . . . . . . . . . .
Engine Oil Pressure 2-67 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 2-70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GAWR 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gear Positions, Automatic Transaxle 2-24 . . . . . . . . . . . . . . . .
Glove Box 2-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gross Axle Weight Rating 4-30 . . . . . . . . . . . . . . . . . . . . . . . .
Gross Vehicle Weight Rating 4-30 . . . . . . . . . . . . . . . . . . . . . .
Guide en Fran†ais ii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GVWR 4
-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Halogen Bulbs 6-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hazard Warning Flashers 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Head Restraints 1-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamps 2-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aiming 6-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High/Low Beam Changer 2-35 . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring 6-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hearing Impaired, Customer Assistance 8-4 . . . . . . . . . . . . . .
Heating 3-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High-Beam Headlamps 2-35 . . . . . . . . . . . . . . . . . . . . . . . . . .
Highway Hypnosis 4-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hill and Mountain Roads 4-23 . . . . . . . . . . . . . . . . . . . . . . . . .
Hitches, Trailer 4-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hood
Checking Things Under 6
-8 . . . . . . . . . . . . . . . . . . . . . . . . .
Release 6-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 2-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hydroplaning 4-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Positions 2-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Transaxle Lock Check 7-36 . . . . . . . . . . . . . . . . . . . .
Illuminated Entry 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation, Tire 6-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Day/Night Rearview Mirror 2-46 . . . . . . . . . . . . . . . . .
Inspections 7-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake System 7-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Caliper/Knuckle 7-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Cooling System 7-37 . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust System 7-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Drive Axle Boot 7-37 . . . . . . . . . . . . . . . . . . . . . . . . .
Front Drive Axle Seal 7-37 . . . . . . . . . . . . . . . . . . . . . . . . .
Steering 7-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suspension 7-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Throttle System 7-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 2-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brightness Control 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cluster 2-56, 2-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Lamps 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jack, Tire 5-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key Lock Cylinders Service 7-34 . . . . . . . . . . . . . . . . . . . . .
Key Reminder Warning 2-21 . . . . . . . . . . . . . . . . . . . . . . . . . .
Keyless Entry System 2-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Personal Choice Features 2-10 . . . . . . . . . . . . . . . . . . . . . . .
Remote 2-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keys 2-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
9-12
Warning Devices 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning Lights, Gages and Indicators 2-59 . . . . . . . . . . . . . . .
Warranty Information 8-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Washer Fluid, Windshield 6-26 . . . . . . . . . . . . . . . . . . . . . . . .
Washing Your Vehicle 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weatherstrips 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel
Alignment 6
-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Nut Torque 5-29, 6-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel Cover Removal 5-23 . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel Nut Cap Removal 5-23 . . . . . . . . . . . . . . . . . . . . . . .
Wire Wheel Cover Removal 5-24 . . . . . . . . . . . . . . . . . . . .
Wrench 5-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Window Lock 2-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Windows 2
-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Express-Down 2-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power 2-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Washer 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Level Check 7-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Wiper 2-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blade Cleaning 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blade Replacement 6-40 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses 6-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Winter Driving 4-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper Blade Check 7-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper Blades, Cleaning 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring, Headlamp 6-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wrecker Towing 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wrench, Wheel 5-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
