COMPONENT LOCATION VIEWS







B6207
HOT FILM AIR
MASS METER
Y6101
CYL. 1 FUEL
INJECTION VALVE B6204
CAMSHAFT
POSITION SENSOR
(CYLINDER
IDENTIFICATION)
X6275
Y6102
CYL. 2 FUEL
INJECTION VALVE
Y6103
CYL. 3 FUEL
INJECTION VALVEY6104
CYL. 4 FUEL
INJECTION VALVE
Y6105
CYL. 5 FUEL
INJECTION VALVE
Y6106
CYL. 6 FUEL
INJECTION VALVE X6207
X6252X10094





Y6275
VARIABLE CAM-
SHAFT CONTROL
VALVE 1X10239




COMPONENT LOCATION VIEWS







T6151
CYL. 1 IGNITION
COIL
X10070
X10071
R6252
THROTTLE
POSITION SENSOR
X6252
T6152
CYL. 2 IGNITION
COIL
T6153
CYL. 3 IGNITION
COILT6154
CYL. 4 IGNITION
COIL
T6155
CYL. 5 IGNITION
COIL
T6156
CYL. 6 IGNITION
COIL








COMPONENT LOCATION VIEWS






Y199
CARBON
CANISTER VALVE Y198
EXHAUST GAS
FLAP VALVE
X13170
X13171
B72
FUEL TANK
PRESSURE
SENSOR
X13172







COMPONENT LOCATION VIEWS








Y6120
EVAPORATIVE
EMISSION VALVE
B13
OUTSIDE
TEMPERATURE
SENSOR
M30
BLOWER MOTORX62101
X6120



X62201




COMPONENT LOCATION VIEWS









B6231
OIL PRESSURE
SWITCH
R6252
THROTTLE
POSITION SENSOR
B6232
ENGINE COOLANT
TEMPERATURE
SENSOR
X6256
X6231
T6151
CYL. 1 IGNITION
COIL
T6152
CYL. 2 IGNITION
COILT6153
CYL. 3 IGNITION
COIL
T6154
CYL. 4 IGNITION
COIL
318i318i 318i







COMPONENT LOCATION VIEWS







M9
AUXILIARY FAN
MOTOR
B18
BRAKE FLUID
LEVEL SWITCH B6205
INTAKE AIR
TEMPERATURE
SENSOR
S123
ABS PEDAL TRAV-
EL SENSOR
X20
X69X111X1162
S63
ENGINE COOLANT
LEVEL SWITCH
X82
X112


318i
B6217
HOT FILM AIR
MASS METERX70
X6205X6217
M25
CRUISE CONTROL
ACTUATOR
(TEMPOMAT)






COMPONENT LOCATION VIEWS







M2
FUEL PUMP
X6120
X638X679
318iY6120
EVAPORATIVE
EMISSION VALVE

B21
ON–BOARD
COMPUTER
TEMPERATURE
SENSOR
X770






COMPONENT LOCATION VIEWS







B6
FUEL LEVEL
SENSOR
X13142X1241

M105
REAR WINDOW
BLOWER X273
X274
