1998 VOLVO V90 warning light

1998 Volvo S90
Anti-lock Brake
System (ABS)

If the warning lamp lights up
there is a malfunction of the
ABS system (the standard
braking system will however
function). The vehicle should be
driven to a Volvo retailer for
inspection.
See page 67 for additional
information.
Canadian models are equipped
with this warning light:


Mode "W" engaged

The lamp will light up when the
Winter/Wet mode is engaged.
If the warning lamp begins to
flash,this means that there is a
fault in the automatic gearbox.
Contact your Volvo retailer.
Supplemental
Restraint System

If the light comes on (or stays
on after the vehicle has started),
the SRS diagnostic system has
detected a fault. Drive to an
authorized Volvo retailer for an
inspection of the system. See
the SRS section for more
information.

Service reminder
indicator

This light will come on at
10,000 mile (16,000 km)
intervals. It is a reminder to the
driver that the 10,000 mile
(16,000 km) service interval has
been exceeded. The light will
stay on 2 minutes after start
until reset by the servicing
retailer.

Coolant level sensor

If the light comes on while
driving, the coolant level is low.
The coolant level in the
expansion tank should be
checked immediately and
topped off if necessary. The
cooling system should be
inspected by an authorized
Volvo retailer.
Turn signal indicators-
trailer (certain models)

When towing a trailer, this light
will flash simultaneously with
the turn signals on the trailer. If
the light does not flash when
signaling, neither the trailer's turn
signals nor the car's turn signals
are functioning.

Bulb failure warning
light

The light will come on if any of
the following bulbs are defective:
one of the low beam headlights
one of the tail lights
one of the brake lights when the
brake pedal is depressed.
Check the fuse and bulb.
See sections titled "Replacing
bulbs" and "Fuses".
Lighting, Turn signals pg. 20
file:///K|/ownersdocs/1998/1998_SV90/98S90_017.htm (3 of 7)12/30/2006 \
1:52:36 PM

1998 Volvo S90
position and switch A is in this position.
All lights off (daytime running light function
disabled)
Winshield wipers/washers, Ignition switch pg. 21


Windshield wipers/washers

1 Intermittent wiper.
With switch in this position, the wipers will
sweep approximately every seventh second.
2 "Single sweep" position.
Switch returns automatically when released
3 Wipers, low speed.
4 Wipers, high speed
5 Windshield wiper/washer, headlight
wiper/washer (certain models)
The wiper will make 2-3 complete sweeps
across the windshield and headlights after
lever is released.
Starting
(ignition)
switch/
steering
wheel lock

The steering
wheel lock
might be under
tension when
the car is
parked. Turn
the steering
wheel slightly
to free the ignition key.
In order to reduce car
theft, make sure the
steering wheel lock is
engaged before leaving
the car.
Achime will sound if the
starting key is left in the
ignition lock and the
front door on the driver's
side is opened. 0 Locked position:
remove the key to lock the
steering wheel.

WARNING:
Never turn the key to
position 0 while driving or
when the car is being
towed.

I Intermediate position:
Certain accessories/radio,
etc. on, daytime running
lights off.

II Drive position:
Key position when engine is
running.

III Starting position:
Release the key when the
engine start.
The key returns
automatically to the Drive
position.
*The gear selector must be
in the (P)ark position before
the key can be removed
from the ignition switch.
Fog lights, Instruments illumination, Steering wheel adjustment, Power antenna
pg. 22
file:///K|/ownersdocs/1998/1998_SV90/98S90_017.htm (5 of 7)12/30/2006 \
1:52:36 PM

1998 Volvo S90
A - Rear fog light*

The indicator light in the
instrument panel will light
up when the rear fog light
is on. This fog light is
considerably brighter than
the normal tail light and
should be used only when
the atmospheric
conditions, such as fog,
rain, snow, smoke or dust
reduce the daytime or
nighttime visibility of
other vehicles to less than
500 ft (150 meters).

*By design, there is one
rear fog light only, located
in the driver's side tail light
cluster.

B- Instrument
illumination

To increase the brightness,
rotate the switch upward.
To decrease the brightness,
rotate the switch
downward.

C- Front fog lights

The indicator light in the
switch will light up when
the front fog lights are on.
The front fog lights will
only function when the low
beam headlights are on.

NOTE:Local regulations
governing the use of fog
lights may vary.
D- Power antenna (sedans only)

This button can be used to lower the antenna
when, for example, you are listening to a tape or
CD, or when you are driving into a low-roof
garage or car wash. CAUTION: The antenna must be lowered
before washing the car in an automatic car wash. E- Steering
wheel adjustment

The steering wheel
can be adjusted to 3
different positions.
Move the control on
the left side of the
steering column
downward and hold
it in place. Adjust
the steering wheel
to the position
desired. Release the
control and check
that the steering
wheel is locked in
position.

WARNING!Do
not adjust the
steering wheel
while driving.

file:///K|/ownersdocs/1998/1998_SV90/98S90_017.htm (6 of 7)12/30/2006 \
1:52:36 PM

1998 Volvo S90
Chapter 2 - (cont.)
Sun roof, Hazard warning flasher, Tailgate wiper/washer, heated rear window
pg. 23
C- Heated rear window,
heated side-door mirrors
(certain models)

Depress the switch to start
heating of rear window and side
mirrors. Both orange control
lights in the switch will
illuminate. A timer switches off
the side mirror heating after
approx. 6 minutes and the rear
window demister after 12
minutes. The control lights go
out correspondingly.

D- Hazard warning flasher

The four-way flasher should be
used to indicate that the vehicle
has become a traffic hazard.

NOTE:Regulations regarding the
use of the hazard warning flasher
may vary from state to state.

E-Central lock switch

Press the switch to lock/unlock
the doors and trunk/tailgate.
Lock: press the lower section of
the switch
Unlock: press the upper section
of the switch.

NOTE: The lock function only
operates if the doors are closed.
file:///K|/ownersdocs/1998/1998_SV90/98S90_023.htm (1 of 7)12/30/2006 \
1:52:37 PM

1998 Volvo S90
the above illustration.
The starting (ignition) switches must be ON
(position II) for the electrically operated windows
to function. The window is lowered if the rear part
of the switch is pressed and raised if the front part
of the switch is pressed.
NOTE: Driver's window only (AUTO): The
window can be opened completely by pressing the
rear part of the switch lightly and releasing it
immediately. The window can be stopped by
pressing the button again. If the button is held
down, the window will be lowered until the button
is released.
WARNING!Remove the starting (ignition)
key when children are left unattended in the
vehicle.
Make sure that children's hands are clear
before raising the windows. is positioned 90° in relation to the other switches.
ON The rear door windows can be raised or
lowered with the respective door switch as well as
the switch on the driver's door.
OFF The rear door windows cannot be raised or
lowered with the respective door switch but
instead only with the corresponding switch on the
driver's door.

NOTE: The power window motors have an
overload protecting circuit breaker which is
activated when an object blocks a window.
Should this occur, remove the object and wait 20
seconds for the circuit breaker to reset. The power
windows should then function.
Parking brake, Cigarette lighter, Ashtrays pg. 30


Parking brake (hand brake)

The lever is situated between
the front seats. The brake is
applied to the rear wheels.


Cigarette lighter/ashtrays

To operate, depress the knob
fully. When the knob
automatically releases, the
cigarette lighter is ready for use.
The starting (ignition) switch
must be switched on (to position
I or II) for the cigarette lighter
to function.

"OBD II"

A connector for on-board
diagnostics ("OBD II") is located
to the right of the parking brake.
This connector is intended for
use by authorized service
technicians only.
file:///K|/ownersdocs/1998/1998_SV90/98S90_028.htm (2 of 3)12/30/2006 \
1:52:38 PM

1998 Volvo S90


Rear-view mirror

A Normal position
B Night position,
reduces glare from
following headlights


Electrically-operated side-view
mirrors

The control switches are located in the
driver's door armrest.
A Horizontal adjustment
B Vertical adjustment
CAUTION: Never use ice scrapers
made of metal as they can easily
scratch the mirror surface.
WARNING!The mirrors should
always be adjusted prior to driving.
Objects seen in the wide-angle right
side-view mirror are closer than they
appear to be.

Vanity mirrors

The vanity mirrors are located on both
front sun visors.
The lamps light up when the covers are
opened.
Interior light, Rear reading lights pg. 36
file:///K|/ownersdocs/1998/1998_SV90/98S90_031.htm (5 of 6)12/30/2006 \
1:52:39 PM

1998 Volvo S90


Interior light

1 Lights always on.
2 Lights always off.
3 Light is on when either of the
front or the rear doors are opened.

Atime-delay device keeps the
interior illuminated for approx. 30
seconds after closing the driver's
door. This facilitates finding the
starting (ignition) switch, etc., at
night.


Rear reading lights

Rear seat passengers can turn the
rear reading lights on or off by
using the adjacent switches. A ON
B OFF

To avoid battery drain

The interior light and the warning
lights in the rear of the doors come
on when a door is opened.
To avoid battery drain when the
doors are opened for prolonged
periods, these lights can be
switched off by pushing in and
turning the door light switches
slightly clockwise. When the door
is closed the switch will return to
its normal position.




Contents | Top of Page
file:///K|/ownersdocs/1998/1998_SV90/98S90_031.htm (6 of 6)12/30/2006 \
1:52:39 PM

1998 Volvo S90
Hood pg. 39





To open the hood

Pull the release handle (located under the left side
of the dash).
Lift the hood slightly, insert a hand under the
center line of the hood and depress the safety
catch handle. Open the hood.
WARNING!
Check that the hood locks properly when
closed.





The hood opens normally to an angle of
approximately 55°. To open it to a completely
vertical position, press both red catches upward as
shown in the illustration. Make sure that the
catches return to their normal position. When
closing the hood, lift it slightly first and then press
the catches downward.
Ensure adequate clearance in low-roof garages to
avoid damaging the hood.
Trunk light, Spare tire (sedan) pg. 40
file:///K|/ownersdocs/1998/1998_SV90/98S90_037.htm (2 of 4)12/30/2006 \
1:52:39 PM
