1998 Volvo S90
the above illustration.
The starting (ignition) switches must be ON
(position II) for the electrically operated windows
to function. The window is lowered if the rear part
of the switch is pressed and raised if the front part
of the switch is pressed.
NOTE: Driver's window only (AUTO): The
window can be opened completely by pressing the
rear part of the switch lightly and releasing it
immediately. The window can be stopped by
pressing the button again. If the button is held
down, the window will be lowered until the button
is released.
WARNING!Remove the starting (ignition)
key when children are left unattended in the
vehicle.
Make sure that children's hands are clear
before raising the windows. is positioned 90° in relation to the other switches.
ON The rear door windows can be raised or
lowered with the respective door switch as well as
the switch on the driver's door.
OFF The rear door windows cannot be raised or
lowered with the respective door switch but
instead only with the corresponding switch on the
driver's door.

NOTE: The power window motors have an
overload protecting circuit breaker which is
activated when an object blocks a window.
Should this occur, remove the object and wait 20
seconds for the circuit breaker to reset. The power
windows should then function.
Parking brake, Cigarette lighter, Ashtrays pg. 30


Parking brake (hand brake)

The lever is situated between
the front seats. The brake is
applied to the rear wheels.


Cigarette lighter/ashtrays

To operate, depress the knob
fully. When the knob
automatically releases, the
cigarette lighter is ready for use.
The starting (ignition) switch
must be switched on (to position
I or II) for the cigarette lighter
to function.

"OBD II"

A connector for on-board
diagnostics ("OBD II") is located
to the right of the parking brake.
This connector is intended for
use by authorized service
technicians only.
file:///K|/ownersdocs/1998/1998_SV90/98S90_028.htm (2 of 3)12/30/2006 \
1:52:38 PM

1998 Volvo S90
Chapter 10 - (cont.)
Cassette deck
pg. 138
A- Cassette slot

The cassette is inserted with the
open side to the right (side 1 or
A of the cassette upwards).
When the cassette is inserted,
the radio is disengaged and the
cassette will start to play
automatically.
"TAPE
"or "TAPE "is
displayed to indicate which side
of the tape is being played.
When one side of the tape has
been played the unit will
automatically play the other side
(auto-reverse). The cassette can
be inserted or ejected even when
the unit is switched off. B- Reversing the tape
(PROG)

Press the button to play the
other side of the tape.
The side of the tape being
played will be displayed.

C- Fast winding

The tape is advanced with "

"and rewound with "
".
Fast winding can be stopped by
pressing either the button again
or the "TAPE" button. D- Dolby B NR button

Press this button when you use
tapes recorded with the Dolby B
noise reduction system. The
Dolby Symbol
will be
indicated in the display.
Cassette deck (cont) pg. 139
file:///K|/ownersdocs/1998/1998_SV90/98S90_138.htm (1 of 6)12/30/2006 \
1:52:52 PM

1998 Volvo S90
A- Next selector

Press the "
"button and the
tape will automatically advance
to the next song. There must be
a pause of approx. 5 seconds
between songs for this function
to operate.

B- Previous selector

Press the "
"button and the
tape will automatically rewind
to the previous song. There
must be a pause of approx. 5
seconds between the songs for
this function to operate. C- Pause

If you press the "volume" knob
the tape is stopped, the unit is
silent and "PAUSE" is
displayed. To restart the tape
press the knob again.
D- Scan

Press this button to listen to the
first five seconds of each song.
Press this button or the "TAPE"
button to stop scanning. During
scanning "SCAN" will be
displayed. There must be a gap
(no audio sound) of approx. 5
seconds between songs for this
function to operate.
Cassette deck (cont) pg. 140
A- Cassette eject

If the button is pressed the tape
will stop and the cassette will be
ejected. The radio will be
automatically engaged. The
radio or CD will engage
automatically (depending on
which mode was activated
before the tape was played). B- To re-enter Radio mode

Push one of the waveband
selector buttons
When the unit re-enters Radio
mode, the cassette will not be
ejected.

C- To re-enter Tape mode

If the Tape function has been
disconnected and the cassette
has not been ejected, the Tape
mode can re-entered by pressing D- To re-enter CD changer
mode

If the CD changer function has
been disconnected, the CD
changer mode can re-entered by
pressing the "CHGR" button.
file:///K|/ownersdocs/1998/1998_SV90/98S90_138.htm (2 of 6)12/30/2006 \
1:52:52 PM

1998 Volvo S90
Chapter 10 - (cont.)
Cassette deck
pg. 151
A- Cassette slot

The cassette is inserted with the
open side to the right (side 1 or
A of the cassette upwards).
When the cassette is inserted,
the radio is disengaged and the
cassette will start to play
automatically. "TAPE
"or
"TAPE
"is displayed to
indicate which side of the tape
is being played. When one side
of the tape has been played the
unit will automatically play the
other side (auto-reverse). The
cassette can be inserted or
ejected even when the unit
switched off. B- Reversing the tape
(PROG)

Press the button to play the
other side of the tape.

C- Fast winding

The tape is advanced with "

"and rewound with "
".
"FF" will be displayed while
advancing the tape. "REW" will
be displayed while rewinding
the tape.
Fast winding can be stopped by
pressing the tuning button or the
TAPE button again. D- Dolby B NR button

Press this button when you use
tapes recorded with the Dolby B
noise reduction system. The
Dolby symbol
will be
indicated in the display.
Cassette deck pg. 152
file:///K|/ownersdocs/1998/1998_SV90/98S90_151.htm (1 of 3)12/30/2006 \
1:52:54 PM

1998 Volvo S90
A- Next selector

Press the "
"button and the
tape will automatically advance
to next song. There must be a
pause of approx. 5 seconds
between songs for this function
to operate.

B- Previous selector

Press the "
"button and the
tape will automatically rewind
to the previous song. There
must be a pause of approx. 5
seconds between songs for this
function to operate. C- Pause

If you press the "volume" knob
the tape is stopped, the unit is
silent and "PAUSE" is
displayed. To restart the tape
press the knob again.
D- Scan

Press this button to listen to the
first five seconds of each song.
Press it again to stop scanning.
"SCAN" will be displayed. There
must be a gap (no udio sound) of
approx. 5 seconds between songs
for this function to operate.
Cassette deck pg. 153
file:///K|/ownersdocs/1998/1998_SV90/98S90_151.htm (2 of 3)12/30/2006 \
1:52:54 PM

1998 Volvo S90
Chapter 10 - (cont.)CD - Single
pg. 154
A- CD slot

With the audio system on, insert
a disc into the slot with the label
side up. When the CD is
inserted, the radio is disengaged
and the CD will start to play
automatically.
The CD can be inserted or
ejected even when the unit is
switched off.

When the CD has been inserted
into the player, the "DISC IN"
light will always be ON even if
the radio, tape deck or CD
changer are in use. B- CD mode selector

Press "CD" to actuate the CD
mode. The track last listened to
will continue to play. If the CD-
player is empty, "NO CD" will
be displayed.
C- CD eject

If the button is pressed the CD
will stop and the disc will be
ejected. The radio will be
automatically engaged. The
radio, tape or CD changer will
engage automatically (depending
on which mode was activated
before the CD was played).

NOTE: If the CD eject button is
pressed and the disc is not
removed within 12 seconds, the
disc will be drawn into the CD
player again.
CD - Single pg. 155
file:///K|/ownersdocs/1998/1998_SV90/98S90_154.htm (1 of 7)12/30/2006 \
1:52:55 PM

1998 Volvo S90
A- Random choice

Press "RND" to actuate the
random mode.
From a disc, tracks will be
played at random. "RND" will
be displayed when this function
is engaged.
the random function may cause
a disc to be played more than
once before playing through all
discs. B- Pause

If you press the "volume" knob
the disc is stopped, the unit is
silent and "PAUSE" is
displayed. To restart the disc
press the knob again.

C- To re-enter Radio mode

Push one of the waveband
selector buttons

D- To re-enter Tape mode

If a cassette is already inserted,
the tape deck will re-engage if
the "TAPE" button is pressed. E- To re-enter CD mode

If the CD function has been
disconnected and the CD has not
been ejected, the CD mode can
be re-entered by pressing the
"CD" button.

F- To re-enter CD changer
mode

If the CD changer function has
been disconnected, the CD
changer mode can be re-entered
by pressing the "CHGR" button.
CD - Changer (option) pg. 157
file:///K|/ownersdocs/1998/1998_SV90/98S90_154.htm (3 of 7)12/30/2006 \
1:52:55 PM

1998 Volvo S90
A- Random choice

Press "RND" to actuate the
random mode. From a disc
chosen at random, 4 tracks will
be played (also chosen at
random). A new disc will then
be played in the same way.
"RND" will be displayed when
this function is engaged.

B- Pause

If you press the "volume" knob
the disc is stopped, the unit is
silent and "PAUSE" is
displayed. To restart the disc
press the knob again. C- To re-enter Radio mode

Push one of the waveband
selector buttons

D- To re-enter Tape mode

If a cassette is already inserted,
the tape deck will re-engage if
the "TAPE" button is pressed.
E- To re-enter CD mode

If the CD function has been
disconnected and the CD has not
been ejected, the CD mode can
be re-entered by pressing the
"CD" button.

F- To re-enter CD changer
mode

If the CD changer function has
been disconnected, the CD
changer mode can be re-entered
by pressing the "CHGR" button.
Technical specifications(option) pg. 160
SC-816

Power output: 4x 25 W (10% dist.)
Output impedance: 4Ohms
System voltage: 12 Volts, negative ground


Radio

System: PLL (Phase Lock Loop) system with tuned RF (Radio Frequency)\
front and end automatic
wide band gain control.
Electronic suppression circuitry (noise killer).
The Radio is equipped with FM diversity.

Frequency range:
FM 87.9 - 107.9 MHz
AM 530 - 1710 kHz
Sensitivity
FM 1.1µV
AM 20µV
Stereo separation: 35 dB
