1998 TOYOTA TERCEL instrument panel

1
Part 1
OPERATION OF
INSTRUMENTS
AND CONTROLSÐ
Chapter 1- 1
Overview of instruments
and controls
Instrument panel overview
Instrument cluster overview
Indicator symbols on the
instrument panel

2
Instrument panel overview
1. Side vents
2. Instrument cluster
3. Center vents
4. Rear view mirror remote control levers
5. Glovebox
6. Power door lock switches
7. Power window switches
8. Parking brake lever
9. Automatic transmission selector lever ormanual transmission gear shift lever
10. Instrument panel light control knob 11. Hood lock release lever

6
Indicator symbols on the instrument panel

Brake system warning light *
Driver 's Seat belt reminder light *
Discharge warning light
*
Malfunction indicator lamp *
Low oil pressure warning light *
Anti-lock brake system warning light *
(type A)
(type B)
Open door warning light *
(type A)
(type B)
SRS airbag warning light*
Overdrive- off indicator light
Headlight high beam indicator light Turn signal indicator lights
The indicators marked with
*
are service reminder indicators.
For details, see ºService reminder indicators and warning buz zerº
in Chapter 1- 5.
Front passenger's seat belt reminder light *

19
Part 1
OPERATION OF
INSTRUMENTS
AND CONTROLSÐ
Chapter 1- 3
Seats, Seat belts
and Mirrors
Seats
Front seats
Fold- down rear seat
Head restraints
Seat belts

SRS driver and passenger
airbags

SRS driver airbag
Child restraint
Outside rear view mirrors
Anti- glare inside rear view
mirror
Seats
While the vehicle is being driven, all ve-
hicle occupants should have the seatback
upright, sit well back in the seat and prop-
erly wear the seat belts provided.
CAUTION
Do not drive the vehicle unless the
occupants are propery seated. Do
not allow sitting on top of a
folded- down seatback, or in the
luggage compartment. Persons not
properly seated and not properly re-
strained by seat belts can be se-
verely injured in the event of emer-
gency braking or a collision.
During driving, do not allow pas-
sengers to stand up or move
around between seats. Severe inju-
ries can occur in the event of emer-
gency braking or a collision.
Adjust the driver's seat so that the foot
pedals, steering wheel and instrument
panel controls are within easy reach of
the driver.
CAUTION
Adjustments should not be made
while the vehicle is moving, as the
seat may unexpectedly move and
cause the driver to lose control of
the vehicle.
When adjusting the seat, be careful
not to hit the seat against a pas-
senger or luggage.
After adjusting the seat position,
try sliding it forward and backward
to make sure it is locked in posi-
tion.
After adjusting the seatback, exert
body pressure to make sure it is
locked in position.
Do not put objects under the seats.
The objects may interfere with the
seat- lock mechanism or unexpect-
edly push up the seat position ad-
justing lever; the seat may suddenly
move, causing the driver to lose
control of the vehicle.
Front seatsÐ
ÐSeat adjustment
precautions

63
Part 1
OPERATION OF
INSTRUMENTS
AND CONTROLSÐ
Chapter 1- 4
Lights, Wipers and Defogger
Headlights and turn signals
Emergency flashers
Instrument panel light control
Interior light
Windshield wipers and washer
Rear window defogger
Headlights and turn signals
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1ÐParking, tail, license plate,
side marker and instrument panel lights
Position 2ÐHeadlights and all of the
above
If you remove the key with the headlights
left on, a buzzer reminds you to turn the
lights off when you open the driver 's door.
NOTICE
To prevent the battery from being dis-
charged, do not leave the lights onfor a long period when the engine is not running.
Daytime running light system (Canada
only)
The headlights turn on at reduced intensi-
ty when the parking brake is released with
the engine started, even with the light
switch in the ºOFFº position. They will not
go off until the ignition switch is turned
off.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
the position 1.
Twist the knob to the position 2 to turn
the headlights to full intensity for driving
at night.

64
High- Low beamsÐFor high beams, turn
the headlights on and push the lever away
from you (position 1). Pull the lever to-
ward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will
tell you that the high beams are on.
Flashing the high beam headlights
(position 3)ÐPull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights
with the knob turned to ºOFFº.TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position 1.
The key must be in the ºONº position.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out. Emergency flashersTo turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn
other drivers if your vehicle must be
stopped where it might be a traffic hazard.
Always pull as far off the road as pos-
sible.
The turn signal light switch will not work
when the emergency flashers are operat-
ing.

65
NOTICE
To prevent the battery from being dis-charged, do not leave the switch onlonger than necessary when the en-gine is not running.
Instrument panel light control
To adjust the brightness of the instru-
ment panel lights, turn the knob. Interior lightTo turn on the interior light, slide the
switch.
The interior light switch has the following
positions:
ºONºÐKeeps the light on all the time.
ºOFFºÐTurns the light off.
ºDOORºÐTurns the light on when any of
the door is opened. The light goes off
when all of the doors is closed.

84
When parking, firmly apply the parking
brake to avoid inadvertent creeping.
To set: Pull up the lever. For better hold-
ing power, first depress the brake pedal
and hold it while setting the parking
brake.
To release: Pull up the lever slightly,
press the thumb button, and lower.
To remind you that the parking brake is
set, the parking brake reminder light in
the instrument panel remains on until you
release the parking brake.
CAUTION
Before driving, be sure the parking
brake is fully released and the park-
ing brake reminder light is off.
