If you perform maintenance by yourself,
be sure to follow the correct procedure
given in this part.
You should be aware that improper or in-
complete servicing may result in operating
problems.
Performing do- it- yourself maintenance
during the warranty period may affect your
warranty coverage. Read the separate
Toyota Warranty statement for details and
suggestions.
This part gives instructions only for those
items that are relatively easy for an owner
to perform. As explained in Part 6, there
are still a number of items that must be
done by a qualified technician with special
tools.
For information on tools and parts for do-
it- yourself maintenance, see ºParts and
toolsº.
Utmost care should be taken when work-
ing on your vehicle to prevent accidental
injury. Here are a few precautions that
you should be especially careful to ob-
serve:CAUTION
When the engine is running, keep
hands, clothing, and tools away
from the moving fan and engine
drive belts. (Removing rings,
watches, and ties is advisable.)
Right after driving, the engine
compartmentÐthe engine, radiator,
exhaust manifold, power steering
fluid reservoir and spark plug
boots, etc.Ðwill be hot. So be care-
ful not to touch them. Oil, fluids
and spark plugs may also be hot.
If the engine is hot, do not remove
the radiator cap or loosen the drain
plugs to prevent burning yourself.
Do not smoke, cause sparks or al-
low open flames around fuel or the
battery. Their fumes are flammable.
Be extremely cautious when work-
ing on the battery. It contains poi-
sonous and corrosive sulfuric acid.
Do not get under your vehicle with
just the body jack supporting it. Al-
ways use automotive jack stands or
other solid supports.
Do- it- yourself service
precautions

'98 TERCEL (U)177
CAUTION
Do not mix radial, bias belted, or
bias- ply tires on your vehicle. It
can cause dangerous handling char-
acteristics, resulting in loss of con-
trol.
Do not use tires or wheels other
than the manufacturer 's recom-
mended size.
Toyota recommends all four tires, or at
least both of the front or rear tires be
replaced at a time as a set.
See ºIf you have a flat tireº in Part 4 for
tire change procedure.
When a tire is replaced, the wheel
should always be balanced.
An unbalanced wheel may affect vehicle
handling and tire life. Wheels can get out
of balance with regular use and should
therefore be balanced occasionally.
When replacing a tubeless tire, the air
valve should also be replaced with a
new one. Rotating tires
To equalize tire wear and help extend
tire life, Toyota recommends that you
rotate your tires approximately every
12000 km (7500 miles). However, the
most appropriate timing for tire rotation
may vary according to your driving hab-
its and road surface conditions.
See ºIf you have a flat tireº in Part 4 for
tire change procedure.
When rotating tires, check for uneven
wear and damage. Abnormal wear is usu-
ally caused by incorrect tire pressure, im-
proper wheel alignment, out- of- balance
wheels, or severe braking.
CAUTION
Do not include a compact spare tire
when rotating the tires. It is designed
for temporary use only.

'98 TERCEL (U)
192
Fuel
Fuel type:
Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or higher
Fuel tank capacity, L (gal., Imp. gal.): 45 (11.9, 9.9) Service specifications
ENGINE
Valve clearance (engine cold), mm (in.):
Intake 0.15Ð0.25 (0.006Ð0.010)
Exhaust 0.31Ð0.41 (0.012Ð0.016)
Spark plug type: DENSO K16TR11
NGK BKR5EKB11
Spark plug gap, mm (in.): 1.1 (0.043)
Drive belt tension measured with Borroughs
drive belt tension gauge No.BT- 33- 73F
(used belt), Ibf: 100 20
ENGINE LUBRICATION
Oil capacity (drain and refill), L (qt., Imp. qt.):
With filter 2.8 (3.0, 2.5)
Without filter 2.6 (2.7, 2.3)
Oil grade: API grade SH, ºEnergy-Conserving IIº or
SJ, Energy- Conservingº multigrade en-
gine oil or ILSAC multigrade engine oil
is recommended. Recommended oil viscosity (SAE):
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.):
Automatic transmission Vehiecles sold in Puerto Rico
4.8 (5.1, 4.2)
Vehiecles sold outside Puerto Rico 5.3 (5.6, 4.7)
Manual transmission 4.9 (5.2, 4.3)
Coolant type: With ethylene- glycol antifreeze
(Do not use alcohol type.)

'98 TERCEL (U)
194
Tires
Tire size:
Spare tire T115/70D14 88M
T105/70D14 83M
Except spare tire 155/80R 79S 155SR13
P185/60R14 82H
P175/65R14 81S
Tire pressure, kPa (kgf/cm 2
or bar, psi):
Spare tire 420 (4.2, 60)
Except spare tire 155/80R 79S 155SR13 Front 240 (2.4, 34)
Rear 220 (2.2, 32)
P185/60R14 82H
180 (1.8, 26)
P175/65R14 81S 200 (2.0, 28)
Wheel size: Spare tire 14 y 4T
Except spare tire 155 SR13 13 y 4 1/2J
P185/60R14 82H 14 y 5 1/2J
P175/65R14 81S 14 y 5 1/2J
Wheel nut torque, N´m (kgf´m, ft´lbf):
103 (10.5, 76) Fuses
Engine compartment (U.S.A.)
Fuses (type A) 1. HEAD (LH) 10 A: Left- hand headlight
2. HEAD (RH) 10 A: Right- hand headlight
3. AM2 15 A: Ignition system, charging
system, multiport fuel injection sys-
tem/sequential multiport fuel injection
system, SRS airbag system, seat belt
pretensioners, starter system
4. HAZ- HORN 15 A: Horns, emergency
flashers, theft deterrent system
5. EFI 15 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
systemEngine compartment (Canada)
6. DOME 10 A: Interior lights, open door
warning light, clock, car audio system,
theft deterrent system, daytime running
light system
7. OBD- II 7.5 A: On- boad diagnosis sys-
tem
8. ALT- S 5 A: Charging system
9. DRL 5 A: Daytime running light system
10. HEAD (RH- LWR) 10 A: Right- hand
headlight (low beam)
11. HEAD (LH- LWR) 10 A: Left- hand
headlight (low beam)
12. HEAD (RH- UPR) 10 A: Right- hand
headlight (high beam)

'98 TERCEL (U)195
Engine compartment (Canada only)
13. HEAD (LH- UPR) 10 A: Left- hand
headlight (high beam)
14. STOP 10 A: Stop lights, high mounted
stoplight, anti- lock brake system, shift
lock control system
15. A/C 10 A: Air conditioning system
16. TAIL 15 A: Tail lights, parking lights,
license plate lights, instrument panel
lights, air conditioning system, emer-
gency flashers, air conditioning system,
rear window defogger, car audio sys-
tem, cigarette lighter, clockInstrument panel
17. GAUGE 10 A: Gauge and meters, ser-
vice reminder indicator (except head-
light high beam indicator) and warning
buzzers (except discharge, open door
and SRS warning lights), back- up
lights, rear window defogger, power
windows
18. TURN 7.5 A: Turn signal lights
19. WIPER 20 A: Windshield wipers and
washer
20. ECU- IG 5 A: Anti- lock brake system,
air conditioning system, shift lock con-
trol system, daytime running light sys-
temInstrument panel
21. CIG&RADIO 15 A: Cigarette lighter,
car audio system, clock, theft deterrent
system, shift lock control system, SRS airbag system, seat belt pretensioners
22. IGN 5 A: Charging system, discharge
warning light, multiport fuel injection
system/s equential multiport fuel injec-
tion system, SRS airbag system, seat
belt pretensioners
23. ECU- B 5 A: SRS airbag warning light
Fuses (type B)
24. CDS FAN 30 A: Electric cooling fans
25. RAD FAN 30 A: Electric cooling fans
26. HEATER 40 A: Air conditioning system,
``A/C'' fuses
