'98 TERCEL (U)
138
If you have a flat tireÐ
1. Reduce your speed gradually, keeping a straight line. Move cautiously off the
road to a safe place well away from
the traffic. Avoid stopping on the center
divider of a highway. Park on a level
spot with firm ground.
2. Stop the engine and turn on your emergency flashers.
3. Firmly set the parking brake and put the transmission in ºPº (automatic) or
reverse (manual).
4. Have everyone get out of the vehicle on the side away from traffic.
5. Read the following instructions thor- oughly.
CAUTION
When jacking, be sure to observe the
following to reduce the possibility of
personal injury: Follow jacking instructions.
Do not start or run the engine while
your vehicle is supported by the
jack.
Stop the vehicle on a level firm
ground, firmly set the parking brake
and put the transmission in ºPº
(automatic) or reverse (manual).
Block the wheel diagonally opposite
to the one being changed if neces-
sary.
Make sure to set the jack properly
in the jack point. Raising the ve-
hicle with jack improperly posi-
tioned will damage the vehicle or
may allow the vehicle to fall off the
jack and cause personal injury.
Never get under the vehicle when
the vehicle is supported by the jack
alone.
Use the jack only for lifting your
vehicle during wheel changing.
Do not raise the vehicle with some-
one in the vehicle.
When raising the vehicle, do not
put an object on or under the jack.
Raise the vehicle only high enough
to remove and change the tire.NOTICE
Do not continue driving with a de-
flated tire. Driving even a short dis-tance can damage a tire beyond re- pair.
'98 TERCEL (U)
196
27. DIMMER 30 A:
ºHEAD RL (LWR)º,
ºHEAD LL (LWR)º, ºHEAD RH (UPR)º
and ºHEAD LH (UPR)º fuses
28. MAIN 30 A: Starter system
29. DEF 30 A: Rear window defogger
30. PWR 30 A: Power windows, power
door lock system
Fuses (type C)
31. ABS 60 A: Anti- lock brake system
32. AM1 50 A: ºDEFº, ºWIPERº, ºGAUGEº,
ºECU- IGº, ºTURNº, ºIGNº, ºPWRº
and CIG/RADIOº fuses
33. ALT 100 A: ºABSº, ºSTOPº, ºTAILº,
ºECU- Bº, ºDEFº, ºAM1º, ºWIPERº,
ºGAUGEº, ºECU- IGº, ºTURNº, ºPWRº
and CIG/RADIOº fuses
