Security indicator lightHow to activate the theft warning
system
1. Close all windows.
The system can be activated even if the
windows are open.
2. Remove the key from the ignition switch.
3. Close and lock all doors, hood and trunk lid.
The doors can be locked either with or
without the key.
Multi-remote controller equipped models:
Close and lock all doors, hood and trunk lid.
Lock all doors by the key or pressing the
button on the multi-remote controller.
At this time, the hazard indicators flash
twice to indicate all doors are locked.
4. Confirm that the SECURITY indicator light
comes on. The SECURITY light glows for
about 30 seconds and then begins to flash
once every 3 seconds. The system is now
activated. If, during this 30 second time
period, the door is unlocked by the key or
the multi-remote controller, or the ignition
key is turned to ACC or ON, the system will
not activate.
IIf the key is turned slowly toward the
front of the vehicle when locking the
door, the system may not activate. If thekey is returned beyond the vertical po-
sition toward the rear of the vehicle to
remove the key, the system may be
deactivated. If the indicator light fails to
glow for 30 seconds, unlock the door
once and lock it again.
IEven when the driver and/or passengers
are in the vehicle, the system will acti-
vate with all doors, hood and trunk lid
locked and ignition key off. Turn the
ignition key to ACC to turn the system
off.
Theft warning system operationThe warning system will give the following
alarm:
IThe headlights blink and the horn sounds
intermittently. In addition, the starter motor
will not operate.
IThe alarm automatically turns off after 2 to
3 minutes. However, the alarm reactivates
if the vehicle is tampered with again. The
alarm can be shut off by unlocking a door or
trunk lid with the key, or by pressing the
button on the multi-remote controller.
The alarm is activated by:
IOpening the door or trunk lid without using
the key (even if the door is unlocked by
SIC0175
2-12
Instruments and controls
Z
01.1.31/A32-D
X

11 Index
A
ABS ................................................................. 5-18
Adjusting the time ........................................... 2-25
Adjustment
Front manual seat ....................................... 1-2
Front power seat ......................................... 1-4
Head restraint .............................................. 1-5
Shoulder belt ............................................. 1-22
Air bag
System....................................................... 1-12
System, Side ............................................. 1-13
Warning label ............................................ 1-15
Warning light ...................................... 1-15, 2-8
Air cleaner....................................................... 8-18
Air conditioner
Automatic..................................................... 4-9
Manual ......................................................... 4-3
Operation, Manual ....................................... 4-5
Servicing .................................................... 4-12
Specification label ................................... 10-11
Air conditioning system refrigerant and
lubricant recommendations ............................. 10-6
Aluminum alloy wheels, Cleaning ..................... 7-4
Anchor point location, Top strap..................... 1-35
Antenna........................................................... 4-25
Anti-freeze, Cold weather ............................... 5-19
Anti-lock Brake System (ABS) ........................ 5-18Appearance care
Exterior ........................................................ 7-2
Interior ......................................................... 7-4
Armrest ............................................................. 1-6
Ashtray ............................................................ 2-19
Audio system .................................................. 4-12
Automatic
Operation, Air conditioner ......................... 4-10
Sunroof, Operation .................................... 2-24
Transaxle fluid ........................................... 8-10
Transmission, Driving .................................. 5-7
Avoiding collision and rollover .......................... 5-3
B
Battery
Cold weather ............................................. 5-19
Maintenance .............................................. 8-14
Replacement, Multi-remote control ............. 3-7
Before starting the engine ................................ 5-6
Belt
Drive .......................................................... 8-15
Extender, Seat........................................... 1-25
Height adjustment, Shoulder ..................... 1-22
Maintenance, Seat .................................... 1-25
Seat ........................................................... 1-17
Brake
Booster ...................................................... 8-21
Fluid ........................................................... 8-12Parking ...................................................... 5-12
Pedal ......................................................... 8-20
System....................................................... 5-17
Warning light ............................................... 2-8
Break-in schedule ........................................... 5-14
Bulb
Checking...................................................... 2-7
Indicator ....................................................... 2-9
Replacement ............................................. 8-25
Warning light ............................................... 2-7
Buzzer ............................................................. 2-11
C
Capacities and recommended fuel/lubricant .. 10-2
Car phone ....................................................... 4-25
Carbon monoxide, Exhaust gas ....................... 5-2
Cassette tape player operation....................... 4-15
Cassette tape player operation, with compact disc
(CD) player type ............................................. 4-21
Catalytic converter, Three way catalyst............ 5-2
CB radio or car phone .................................... 4-25
Ceiling light ..................................................... 2-25
Certification label, F.M.V.S.S. ....................... 10-10
Chain, Tire ...................................................... 8-33
Changing
A flat tire ...................................................... 6-2
Engine coolant............................................. 8-6
Engine oil..................................................... 8-9
Engine oil filter........................................... 8-10
Z
01.1.31/A32-D
X

Fuel
Economy.................................................... 5-15
Filler cap .................................................... 3-12
Filler lid ...................................................... 3-11
Gauge .......................................................... 2-5
Recommendation ...................................... 10-2
Fuse ................................................................ 8-21
Fusible link ...................................................... 8-22
GGarage door opener, Integrated
HomeLink
...................................................... 2-27
Gas cap, Fuel filler ......................................... 3-12
Gas economy, Fuel ........................................ 5-15
Gauge ............................................................... 2-3
Engine coolant temperature ........................ 2-5
Fuel.............................................................. 2-5
Speedometer and odometer ....................... 2-4
Tachometer ................................................. 2-4
General maintenance ................................ 9-2, 9-3
Glass, Cleaning ................................................ 7-3
Glove box........................................................ 2-22
H
Hazard warning flasher switch........................ 2-17
Head restraint adjustment ................................ 1-5
Headlamp, Replacement ................................ 8-25
Headlight
Replacement ............................................. 8-25
Switch ........................................................ 2-15
Heated seat .................................................... 2-18Heater and air conditioner
(Manual) ...................................................... 4-3
(Automatic) .................................................. 4-9
Heater operation
Manual air conditioner ................................. 4-4
HomeLink
...................................................... 2-27
Hood ................................................................. 3-9
Horn ................................................................ 2-17
How to stop alarm, Theft warning .................. 2-13
How to use multi-remote control system .......... 3-6
I
Identification, Vehicle ...................................... 10-9
Ignition switch ................................................... 5-4
Indicator light .................................................... 2-9
Infants and small children, Seat belt .............. 1-19
Information label, Emission........................... 10-10
Injured persons, Seat belt .............................. 1-19
Inside mirror .................................................... 3-13
Installing front license plate .......................... 10-11
Instrument panel ............................................... 2-2
Integrated HomeLink
transmitter .................. 2-27
Interior light ..................................................... 2-25
Replacement ............................................. 8-26
J
Jump starting .................................................... 6-7
KKey .................................................................... 3-2
Position, Ignition switch ............................... 5-6Key operation, Trunk lid ................................. 3-11
Keyless entry, Multi-remote control .................. 3-5
L
Label, Air bag warning .................................... 1-15
Lamp, Replacement ........................................ 8-24
Larger children, Seat belt ............................... 1-19
License plate, Installing ................................ 10-11
Light
Air bag warning ......................................... 1-15
Front fog light switch ................................. 2-16
Headlight replacement .............................. 8-25
Headlight switch ........................................ 2-15
Indicator ....................................................... 2-9
Interior ....................................................... 2-25
Personal .................................................... 2-26
Replacement ............................................. 8-25
Trunk ......................................................... 2-27
Vanity......................................................... 2-26
Warning ....................................................... 2-7
Loading information, Vehicle ........................ 10-12
Loading tips .................................................. 10-13
Lock, Door ........................................................ 3-2
Locking with
Inside lock knob .......................................... 3-3
Key .............................................................. 3-3
Power door lock switch ............................... 3-4
Low fuel warning light ....................................... 2-9
Lubricant, Capacities and recommended ....... 10-2
Z
01.1.31/A32-D
X
11-3

M
Maintenance
General ................................................ 9-2, 9-3
Item .................................................... 9-3, 9-10
Periodic........................................................ 9-5
Precaution ................................................... 8-2
Seat belt .................................................... 1-25
Manual
Front seat adjustment ................................. 1-2
Operation, Air conditioner ......................... 4-11
Transmission, Driving ................................ 5-10
Meter
And gauge ................................................... 2-3
Speedometer and odometer ....................... 2-4
Tachometer ................................................. 2-4
Mirror............................................................... 3-13
Inside ......................................................... 3-13
Outside ...................................................... 3-14
Multi-remote control system.............................. 3-5
NNew vehicle, Break-in ..................................... 5-14
OOdometer .......................................................... 2-4
Oil
Automatic transaxle ................................... 8-10
Brake ......................................................... 8-12
Engine ......................................................... 8-8
Filter recommendation............................... 10-4
Power steering .......................................... 8-12Opener operation
Fuel filler lid ............................................... 3-11
Trunk lid..................................................... 3-10
Operating tips, Automatic air
conditioner ........................................ 4-5, 4-6, 4-11
Operation, Cruise control ................................ 5-13
Outside mirror ................................................. 3-14
Overheat ........................................................... 6-9
P
Parking
Brake ......................................................... 5-12
Brake and brake pedal .............................. 8-20
Parking/parking on hills .................................. 5-16
Pedal
Brake ......................................................... 8-20
Clutch ........................................................ 8-21
Periodic maintenance ....................................... 9-5
Personal light .................................................. 2-26
Power
Front seat adjustment ................................. 1-4
Seat operating tips ...................................... 1-4
Steering ..................................................... 5-17
Steering fluid ............................................. 8-12
Window ...................................................... 2-22
Precaution
Maintenance ................................................ 8-2
On child restraint ....................................... 1-25
On cruise control ....................................... 5-13
On seat belt usage .................................... 1-17
On supplemental restraint system .............. 1-7
When starting and driving ........................... 5-2
Pregnant women, Seat belt ............................ 1-19Push starting ..................................................... 6-9
R
Radio............................................................... 4-12
With cassette player .................................. 4-13
With cassette player and compact disc (CD)
player ......................................................... 4-19
Readiness for inspection/maintenance (I/M) test
(US only) ....................................................... 10-18
Rear
Door lock, Child safety ................................ 3-4
Window and outside mirror defogger
switch......................................................... 2-14
Recommended
Fuel/lubricant ............................................. 10-2
SAE viscosity number ............................... 10-6
Recovery, Freeing a stuck vehicle ................. 6-12
Refrigerant, air conditioning ............................ 10-6
Registering your vehicle in another country ... 10-9
Release
Hood ............................................................ 3-9
Trunk lid....................................................... 3-9
Remote keyless entry, Multi-remote
control ............................................................... 3-5
Reporting safety defects (US only)............... 10-18
Restraint, Child ............................................... 1-25
Rollover ............................................................. 5-3
Rotation, Tire .................................................. 8-33
SSafety
Belt ............................................................ 1-17
Z
01.1.31/A32-D
X
11-4

Child seat belt ........................................... 1-18
Defects, Reporting................................... 10-18
Towing ..................................................... 10-14
Seat................................................................... 1-2
Heated ....................................................... 2-18
Seat adjustment
Front manual ............................................... 1-2
Front power ................................................. 1-4
Seat belt.......................................................... 1-17
Cleaning ...................................................... 7-5
Extender .................................................... 1-25
Maintenance .............................................. 1-25
Operation, Three-point .............................. 1-21
Precautions................................................ 1-17
Warning light and buzzer ............................ 2-8
With retractor, Three-point ........................ 1-20
Without retractor, Two-point ...................... 1-23
Selecting correct set of seat belt .................... 1-23
Servicing air conditioner ................................. 4-12
Setting, Clock.................................................. 2-25
Shoulder belt height adjustment (For front
seats) .............................................................. 1-22
Side air bag system ........................................ 1-13
Sound system, Audio system ......................... 4-12
Sound, Buzzer ................................................ 2-11
Spark plug....................................................... 8-16
Specifications .................................................. 10-7
Speedometer and odometer ............................. 2-4
Starting
Automatic transmission ............................... 5-4
Jump ............................................................ 6-7
Manual transmission ................................... 5-5
Precaution ................................................... 5-2
Push ............................................................ 6-9The engine .................................................. 5-6
Steering
Power ........................................................ 5-17
Wheel ........................................................ 3-13
Storage ........................................................... 2-19
Stuck, Vehicle recovery .................................. 6-12
Sun shade....................................................... 2-24
Sunroof ........................................................... 2-24
Supplemental
Air bag system .......................................... 1-12
Air bag warning label ................................ 1-15
Air bag warning light .......................... 1-15, 2-8
Restraint system.......................................... 1-7
Restraint system, Precautions .................... 1-7
Side air bag system .................................. 1-13
Switch
Front fog light ............................................ 2-16
Hazard warning ......................................... 2-17
Headlight ................................................... 2-15
Ignition ......................................................... 5-4
Rear window and outside mirror
defoggor .................................................... 2-14
Turn signal................................................. 2-16
T
Tachometer ....................................................... 2-4
Temperature gauge, Engine coolant ................ 2-5
Theft warning .................................................. 2-11
Three way catalyst ............................................ 5-2
Three-point type seat belt with retractor......... 1-20
Tire .................................................................. 8-31
Chain ......................................................... 8-33
Changing ................................................... 8-33Equipment, Cold weather .......................... 5-20
Flat............................................................... 6-2
Placard .................................................... 10-11
Pressure .................................................... 8-31
Quality grading ........................................ 10-17
Rotation ..................................................... 8-33
Type........................................................... 8-32
Tires, Specifications ........................................ 10-8
Top strap child restraint .................................. 1-34
Towing
A trailer .................................................... 10-13
Safety ...................................................... 10-14
Your vehicle............................................... 6-10
Trailer, Towing .............................................. 10-13
Transmitter
Integrated HomeLink
............................... 2-27
Multi-remote control..................................... 3-5
Traveling or registering your vehicle in another
country ............................................................ 10-9
Tray ................................................................. 2-19
Trunk
Lid ................................................................ 3-9
Light ........................................................... 2-27
Turn signal switch ........................................... 2-16
Two-point type seat belt without retractor (Center
of rear seat) .................................................... 1-23
Type of tire...................................................... 8-32
U
Underbody, Cleaning ........................................ 7-3
Unfastening the seat belt
Three-point ................................................ 1-21
Two-point ................................................... 1-24
Z
01.1.31/A32-D
X
11-5
