1998 MITSUBISHI MONTERO jacking points

* PLEASE READ FIRST *
NOTE: Following illustrations are given to provide reference
points only. Illustrations do not represent exact structure
of vehicle frame, underbody or body outline.
EMERGENCY JACKING
Points on outline of body were designated to be used
specifically with vehicle jack. See Fig. 2. If using floor jack or
hoist at these points, use extreme care to avoid damaging outer body
shell.
FLOOR JACK & HOIST
Following illustrations indicate points for jacking and
hoisting vehicle. These points are indicated by shaded areas on frame
and underbody. See Figs. 3-5.
Fig. 2: Identifying Jacking & Hoisting Points (Typical)

Fig. 3: Identifying Jacking & Hoisting Points (Except Montero,
Montero Sport & 3000GT)
Courtesy of Mitsubishi Motor Sales of America.

Fig. 4: Identifying Jacking & Hoisting Points (Montero & Montero
Sport)
Courtesy of Mitsubishi Motor Sales of America.
Fig. 5: Identifying Jacking & Hoisting Points (3000GT AWD Shown; FWD
Is Similar)
Courtesy of Mitsubishi Motor Sales of America.
