1998 FORD WINDSTAR load capacity

220
[GF08000(ALL)01/96]
The gearshift is securely latched in P (Park) if you can not
rotate it in a clockwise direction without pulling it toward you.
*
[GF08100(ALL)05/96]
RWARNING
Always set the parking brake fully and make sure the
gearshift is latched in P (Park). Turn off the ignition
whenever you leave your vehicle.
*
[GF08200(ALL)05/96]
RWARNING
Never leave your vehicle unattended while it is running.
*
[GF08300(ALL)05/96]
Forced Downshifts
[GF08400(ALL)01/96]
To gain extra acceleration in
j(Overdrive) (when passing
another vehicle) push the accelerator to the floor. The transaxle
will automatically downshift to the appropriate gear (third,
second or first).
*
[GF08500(ALL)01/96]
Vehicle Loading Information
*
[GF08600(ALL)01/96]
Your vehicle's load capacity is designated by weight, not
volume, so you cannot necessarily use all the available space.
Maximum safe vehicle weights as well as tire sizes, rim sizes
and inflation pressures are specified for your vehicle at the
assembly plant on the Safety Compliance Certification Label.
The certification label is located on the pillar in the driver's
door opening.
*
[GF08700(ALL)01/96]
Each additional item of equipment affects how much cargo a
vehicle can carry. If a vehicle is overloaded, performance will
suffer and service concerns may arise.
*
[GF08800(ALL)01/96]
NOTE: The vehicle must not be loaded to both the front and
rear GAWR because the GVWR will be exceeded. The
GAWR of the front and rear axles exceed the GVWR
when added together.
File:09wngfs.ex
Update:Mon Oct 7 11:46:08 1996

222
*
[GF10100(ALL)01/96]
Gross Vehicle Weight (GVW)
*
[GF10200(ALL)01/96]
The Gross Vehicle Weight (GVW) is the total weight of the
passengers, cargo and all equipment.
*
[GF10300(ALL)01/96]
It is important to remember that GVW is not a limit or a
specification, but actual weight. If an owner loads up the vehicle
and weighs it, that's the GVW at that moment. If the owner
adds on more of a load and weighs it again, that becomes the
GVW.
%*
[GF10400(ALL)01/96]
Gross Vehicle Weight Rating (GVWR)
[GF10500(ALL)01/96]
To avoid overloading your vehicle, never exceed the specified
Gross Vehicle Weight Rating for your vehicle. The GVWR is the
maximum allowable weight of the vehicle when fully loaded
including passengers, cargo and all equipment.
%*
[GF10600(ALL)01/96]
Gross Axle Weight Rating (GAWR)
*
[GF10700(ALL)01/96]
We have all seen a car or a truck that is loaded down in the
rear and riding high in the front. This is a dangerous condition
that usually means that the rear suspension components are
under severe strain and that vehicle handling is impaired. There
is more to carrying a load than just payload or GVWR.
[GF10800(ALL)01/96]
Your Safety Compliance Certification Label not only gives the
GVWR, it also gives the Gross Axle Weight Rating (GAWR)
which is the maximum weight allowed on the axle system.
*
[GF10900(ALL)01/96]
The rating is based on the carrying capacity of the weakest axle
and suspension component as well as other factors. This is why
it is so important to observe vehicle loading ratings.
Overloading a vehicle punishes components and can lead to
shortened service life or outright failure.
*
[GF11000(ALL)01/96]
The weakest link in the suspension system defines the GAWR,
and may be the tires. Tires are rated to carry a specific
maximum load at a specific tire pressure.
File:09wngfs.ex
Update:Mon Oct 7 11:46:08 1996

Driving
223
*
[GF11100(ALL)01/96]
When passenger car tires are installed on light trucks and
multipurpose passenger vehicles, they are rated at a 10% lower
load carrying capacity due to the differences in vehicle usages.
*
[GF11200(ALL)01/96]
With the tires inflated to the specified pressure, the total weight
of your vehicle must not exceed the GVWR and GAWR
specified on the Safety Compliance Certification Label. This
includes full fuel tank(s), vehicle equipment, and occupants, as
well as the cargo load.
*
[GF11300(ALL)01/96]
Gross Combined Weight Rating (GCWR)
*
[GF11400(ALL)01/96]
The GCWR is the maximum allowable weight of the towing
vehicle and the loaded trailer (including all cargo and
passengers).
%*
[GF11500(ALL)01/96]
Calculating the Payload for Your Vehicle
*
[GF11600(ALL)01/96]
To know how much weight your vehicle can carry:
*
[GF11700(ALL)01/96]1.
Obtain the GVWR and GAWR from your Safety Compliance
Certification Label.
[GF11800(ALL)01/96]
Ð If you do not plan to pull a trailer, do not include these
ratings into your calculations.
*
[GF11900(ALL)01/96]2.
Fill the fuel tank.
*
[GF12000(ALL)01/96]3.
Weigh your vehicle without cargo.
*
[GF12100(ALL)01/96]4.
Subtract vehicle actual weight from the GVWR to find out
how much more weight your vehicle can carry.
*
[GF12200(ALL)01/96]5.
Weigh the vehicle again once it is loaded to make sure that
the GVWR and front and rear GAWR's are not exceeded.
File:09wngfs.ex
Update:Mon Oct 7 11:46:08 1996

Driving
233
[GF20800(ALL)04/96]
Do not rock the vehicle for more than a few minutes. This may
overheat the engine, damage the transaxle, or damage the tires.
%*
[GF20900(ALL)01/96]
Driving With a Heavy Load
*
[GF21000(ALL)01/96]
The Safety Compliance Certification Label, located on the
driver's door pillar, provides important information regarding
the weight limits your vehicle can safely carry or tow. The total
weight of your vehicle, including the weight of the passengers
and cargo, should never be more than the Gross Vehicle Weight
Rating (GVWR). Also, the weight that your vehicle carries on
the front axle and rear axle should never be more than the
Gross Axle Weight Rating (GAWR) for the respective axle.
*
[GF21100(ALL)01/96]
The load capacities of your vehicle's tires affect the GVWR or
GAWR limitations. Using replacement tires with a higher weight
limit than the originals does not increase GVWR or GAWR.
Using lower capacity replacement tires may lower GVWR and
GAWR limitations.
*
[GF21200(ALL)01/96]
RWARNING
Do not exceed the GVWR or the GAWR specified on the
Safety Compliance Certification Label.
*
[GF21300(ALL)03/96]
Vehicle/Trailer Loads
[GF21400(ALL)01/96]
Your vehicle may tow a Class I trailer up to 2,000 lbs. (907 kgs)
or 3,500 lbs. (1,587 kgs) with Trailer Tow Package provided the
Gross Vehicle Weight (GVW) is less than the GVWR shown on
the Safety Compliance Certification Label.
File:09wngfs.ex
Update:Mon Oct 7 11:46:08 1996

296
%*
[MC18800(ALL)01/96]
Replacing the Tires
*
[MC18900(ALL)01/96]
Replace tires that show wear bands. When your tire shows a
wear band, it has only 1/16 of an inch (1.59 mm) of tread left.
*
[MC19000(ALL)01/96]
7-1/2 pica art:0040200-A
A worn-out tire
*
[MC19100(ALL)02/96]
Because your vehicle's tires may wear unevenly, you may need
to replace them before a wear band appears across the entire
tread.
*
[MC19200(ALL)01/96]
RWARNING
When replacing full size tires, never mix radial,
bias-belted, or bias-type tires. Use only the tire sizes that
are listed on the tire pressure decal. Make sure that all
tires are the same size, speed rating, and load-carrying
capacity. Use only the tire combinations recommended on
the decal. If you do not follow these precautions, your
vehicle may not drive properly and safely.
*
[MC19300(ALL)03/96]
RWARNING
Make sure that all replacement tires are of the same size,
type, load-carrying capacity, and tread design (e.g. ºAll
Terrainª, etc.), as originally offered by Ford.
File:11wnmcs.ex
Update:Tue Oct 8 10:24:50 1996
