Liftgate
*
[CF39400(ALL)01/96]
Liftgate opening procedure
[CF39500(ALL)01/96]1.
To open the liftgate, insert the door key into the lock and
turn it clockwise. You can also unlock the latch (but not
release it) with the power door lock system.
*
[CF39600(ALL)01/96]2.
Reach under the license plate light shield and release the
liftgate latch by squeezing the paddle handle rearward.
[CF39700(ALL)01/96]3.
To make the gate swing up to the fully opened position, pull
back and upward on the latch paddle handle under or
behind the license plate shield.
[CF39800(ALL)09/96]
13-1/2 pica
art:0050108-C
Opening the liftgate
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

Controls and Features
123
[CF39900(ALL)01/96]
Make certain that you close the liftgate door before driving your
vehicle. Possible damage may occur to the liftgate door lift
cylinders and attaching hardware if the liftgate door is not
closed prior to driving.
*
[CF40000(ALL)01/96]
RWARNING
Make sure that the liftgate door and/or window are
closed to prevent exhaust fumes from being drawn into
the vehicle. This will also prevent passengers and cargo
from falling out. If you must drive with the liftgate door
or window open, keep the vents open so outside air
comes into the vehicle.
*
[CF40100(ALL)01/96]
Liftgate closing procedure
*
[CF40200(ALL)01/96]1.
To make the liftgate swing downward, reach up and pull the
lower edge of the liftgate (or the loop handle on the inner
trim panel of vehicles with this option) and pull downward.
*
[CF40300(ALL)01/96]2.
When you have pulled down the liftgate enough so that you
can reach the license plate light shield, push the shield down
and forward to close the latch and liftgate. At this point, the
latch is not locked.
[CF40400(ALL)09/96]3.
You can lock the liftgate latch by pushing down the
night-lock button (located on the inside of the liftgate at the
bottom of the window) before you pull down and close the
liftgate. You can also lock the liftgate latch by inserting your
vehicle's door key and turning it counterclockwise after you
have closed the liftgate, by pressing LOCK on your
remote (if equipped), or by using the power door locks on
the front doors or the power lock switch in the cargo area.
*
[CF40500(ALL)01/96]
The liftgate area is only intended for cargo, not passengers. You
can open and close the liftgate from outside the vehicle. It
cannot be opened from inside the cargo area.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

126
%*
[CF44800(ALL)01/96]
Battery Saver
[CF44900(ALL)01/96]
When the ignition switch is turned to OFF, the vehicle will turn
off battery voltage to the interior lamps after 45 minutes. (The
exterior lamps are not affected.) The purpose is to minimize
extended battery drain if the lights have inadvertently been left
on or if a door or the glove box is not completely closed.
However, the timer will be immediately reset to another 45
minutes if any of the following occurs:
[CF45000(ALL)01/96]
n
any door is open or closed
[CF45100(ALL)01/96]
n
the front door handle is lifted (for Illuminated Entry only)
[CF45200(ALL)01/96]
n
taking the key IN or OUT of the ignition switch
[CF45300(ALL)01/96]
n
the Keyless Entry keypad is used
[CF45400(ALL)01/96]
n
the Remote Entry transmitter is activated
*
[CF45500(ALL)05/96]
Remote Entry System (If equipped)
[CF45600(ALL)08/96]
If your vehicle has the remote entry system, you can lock and
unlock the vehicle doors without using a key. The remote entry
system also has a personal alarm feature. The buttons that
control the system are located on the hand held transmitter that
comes with your vehicle.
*
[CF45700(ALL)05/96]
The system will work with up to four remotes. Your vehicle
came with two remotes. Additional remotes can be ordered
from your dealer.
*
[CF45800(ALL)01/96]
The remote entry features only operate with the ignition in the
OFF position.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

128
%*
[CF46600(ALL)03/96]
Activating the remote personal alarm
[CF46700(ALL)08/96]
If you wish to activate the remote personal alarm, press the
PANIC button. This will honk the horn and flash the tail lamps
and low beam headlamps for approximately two minutes and
forty-five seconds. You can turn it OFF by pressing the PANIC
button again on the same transmitter or by turning the ignition
key to the RUN position. If the alarm does not turn off, move
the transmitter closer to the vehicle and press the button again.
[CF46800(ALL)01/96]
When you use the remote entry UNLOCK, or PANIC buttons,
the illuminated entry system turns on the interior lights for 25
seconds. You can turn these lights off with the LOCK button or
by turning the ignition to the RUN position.
[CF46900(ALL)07/96]
Replacing the batteries
*
[CF47000(ALL)05/96]
The remote is powered by two coin type three-volt lithium 2016
batteries (included) that should last for several years of normal
use. If you notice a significant decrease in operating range, the
batteries should be replaced. Replacement batteries can be
purchased at most pharmacies, watch stores or at your Ford or
Lincoln-Mercury dealer.
*
[CF47100(ALL)01/96]
NOTE: The operating range of the remote entry system can
also be affected by weather conditions (such as very
cold temperatures) or structures around the vehicle
(buildings, other vehicles, radio towers, etc.). Typical
operating range will allow you to be up to 33 feet (10
meters) away from your vehicle.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

130
%*
[CF47800(ALL)01/96]
Illuminated Entry System (If equipped)
[CF47900(ALL)08/96]
This system will provide illumination of the vehicle's interior
courtesy lamps when the remote entry system is used to unlock
the door or sound the personal alarm. The system will
automatically turn off after approximately 25 seconds, when the
ignition is turned to the RUN or ACC position or when the lock
button on the transmitter is pressed.
[CF48000(ALL)01/96]
NOTE: The illuminated entry timer will not turn off the
courtesy lamps if they have been turned on by the
door and or dimmer switch.
% [CF48100(ALL)09/96]
Autolock
[CF48200(ALL)09/96]
The Autolock feature is part of your remote entry system and is
enabled at the factory. With the Autolock feature enabled, all of
the doors will automatically lock when:
[CF48300(ALL)09/96]
n
the vehicle doors and liftgate are closed
*
[CF48400(ALL)09/96]
n
the ignition key is turned to the ON position
[CF48500(ALL)09/96]
n
you shift into R (Reverse)
*
[CF48700(ALL)08/96]
n
one second has elapsed after the brake pedal is released
*
[CF48800(ALL)05/96]
The Autolock feature will repeat when:
[CF48900(ALL)01/96]
n
a door is opened and then all doors and the liftgate are
closed
[CF49000(ALL)08/96]
n
the brake pedal is released
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

132
% [CF50200(ALL)01/96]
Anti-Theft System (if equipped)
*
[CF50300(ALL)01/96]
When armed, this system helps protect your vehicle against
break-ins or theft.
%*
[CF50400(ALL)01/96]
When an unauthorized entry occurs, the system triggers and
will:
[CF50500(ALL)08/96]
n
flash the low beam headlamps, parking lamps, and alarm
indicator lamp
*
[CF50600(ALL)01/96]
n
honk the horn
*
[CF50700(ALL)01/96]
n
disable the starting circuit to prevent the vehicle from being
started
%*
[CF50800(ALL)07/96]
Arming the System
[CF50900(ALL)08/96]1.
Remove the key from the ignition.
[CF51100(ALL)08/96]2.
Lock the doors by using the power door lock switch. The
alarm indicator light will now glow steadily.
[CF51200(ALL)08/96]4.
Close all doors and liftgate. The alarm indicator light will
then remain on steadily for 30 seconds and then go out.
When the light starts flashing, the system is armed.
*
[CF51300(ALL)08/96]
NOTE: Be sure to close all doors completely. If not, the alarm
indicator light will remain on. Remember, your
anti-theft system is armed only after the alarm
indicator light remains on steadily for approximately
30 seconds after the last door is closed, and then goes
out.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

Controls and Features
133
[CF51400(ALL)08/96]
You can also arm the anti-theft system by following this
sequence:
*
[CF51500(ALL)08/96]1.
Remove the key from the ignition. The hood must be closed
to arm the system.
[CF51600(ALL)08/96]2.
Close all of the doors and liftgate.
[CF51700(ALL)08/96]3.
Press the remote entry transmitter LOCK button. The alarm
indicator will come on for 30 seconds to show the alarm is
arming and then flash to show that it has armed.
%*
[CF51900(ALL)03/96]
Disarming an Untriggered Anti-Theft System
[CF52000(ALL)01/96]
You can disarm the system by unlocking either front door or
the liftgate with your door key. Turn the key all the way to the
end of travel or the system will not disarm.
[CF52100(ALL)08/96]
You can also disarm the system by unlocking the driver's door
by using the UNLOCK button of the remote entry transmitter.
[CF52200(ALL)04/96]
If the system is armed and you remain in your vehicle, simply
insert the key into the ignition and turn it to ON. This disarms
the system and allows you to open the door and exit without
triggering the system.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

134
%*
[CF52300(ALL)03/96]
Disarming a Triggered System
*
[CF52400(ALL)01/96]
The alarm can be disarmed by:
[CF52500(ALL)04/96]
n
unlocking any door with the key, or
*
[CF52600(ALL)04/96]
n
using the UNLOCK control on the remote entry transmitter
[CF52700(ALL)08/96]
n
using the PANIC button of the remote entry transmitter
[CF52800(ALL)01/96]
NOTE: The flashing lights and honking horn will shut off
automatically approximately two minutes and 45
seconds after the system is triggered. It will trigger
again if another intrusion occurs. However, the starter
circuit remains disabled until the system is disarmed.
