144
[SS04300(ALL)01/96]
Seat/Bed Conversion (If equipped)
[SS04310(ALL)10/96]
The head restraints must be removed before converting the seat
to a bed. To remove the head restraints, pull the head restraints
all the way up, then push the buttons on the head restraint
guides and lift the head restraints out.
[SS04320(ALL)10/96]
7-1/2 pica
art:0051050-A[SS04400(ALL)01/96]
2nd Row Seat
[SS04500(ALL)01/96]
To convert the seat to a bed:
[SS04600(ALL)01/96]1.
Unlatch the seat/bed lever, located on the right-hand side of
the seat cushion by pushing down.
[SS04700(ALL)01/96]2.
Push the seatback down and rearward by applying pressure
at the top of the seatback until it latches.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996
