1998 FORD ESCORT octane

Your vehicle was not designed to
use fuel or fuel additives with
metallic compounds, including
manganese-based compounds
containing MMT.
Vehicles certified to California
emission standards (indicated on
the underhood Vehicle Emissions
Control Information label) are
designed to operate on California
reformulated gasolines. If
California reformulated gasoline is
not available when you refuel, your
vehicle can be operated on
non-California fuels. However, even
though your engine will perform
adequately on other gasolines, the
performance of the emission
control devices and systems may
be adversely affected.
Repair of damage caused by using
a fuel that your vehicle was not
designed for may not be covered
by your warranty.
Octane recommendations
Your vehicle is designed to use
regular unleaded with an (R+M)/2
octane rating of 87. We do not
recommend gasolines labeled as
ªregularº in high altitude areas that
are sold with octane ratings of 86
or even less.
Do not be concerned if your
vehicle sometimes knocks lightly.
However, if it knocks heavily under
most driving conditions on fuel
with the recommended octane, see
your dealer or a qualified service
87
Maintenance and care
157

FluidFord Part
Name or
EquivalentFord Part
NumberFord
Specification
Lock cylinder Penetrating
lubricantE8AZ-19A501-B N/A
Automatic
transmissionMotorcraft
MERCONtAT FXT-2-QDX MERCONt
Manual
transmissionMotorcraft
MERCONtAT FXT-2-QDX MERCONt
Engine oil Motorcraft 5W30
Super Premium
Motor OilXO-5W30-QSP WSS-M2C153-G
and API
Certification
Mark
Constant
velocity jointsCV Joint Grease
(High Temp.)E43Z-19590-A ESP-M1C207-A
Engine coolant Ford Premium
Cooling System
FluidE2FZ-19549-AA ESE-M97B44-A
Power steering
reservoirMotorcraft
MERCONtAT FXT-2-QDX MERCONt
ENGINE DATA
Engine 2.0L-2V engine 2.0L-4V Zetec engine
Cubic inches 121 121
Horsepower 110 @ 5000 rpm 130 @ 5750 rpm
Torque 125 lb. ft. @
3750 rpm127 lb-ft. @ 4250 rpm
Required fuel grade 87 octane 87 octane
Firing order 1-3-4-2 1-3-4-2
Spark plug gap 1.3-1.4 mm
(0.052-.056 inch)1.22-1.32 mm
(0.048-.052 inch)
Ignition system DIS DIS
Capacities and specifications
182

Air bag supplemental restraint
system ..........................................58
and child safety seats ..............60
description ................................59
disposal ......................................63
indicator light ...........................62
passenger air bag .....................61
Air cleaner filter .......................148
Air conditioning
manual heating and air
conditioning system ............21,24
Anti-lock brake system (ABS)
description ................................88
Anti-theft system ........................44
arming the system ....................44
disarming a triggered system ..46
disarming an untriggered
system .......................................45
Battery .......................................145
Brake fluid
checking and adding ..............136
Brakes ..........................................87
anti-lock .....................................87
anti-lock brake system (ABS)
warning light .............................88
fluid, checking and adding ....136
Break-in period .............................2
Bulbs, replacing ........................163
specifications ..........................172
Cargo cover .................................39
Changing a tire .........................113
Child safety seats ........................66
Chime
headlamps on ............................12
Cleaning your vehicle ...............175
built-in child seat ...................179
engine compartment ..............176
fabric ........................................178
instrument panel ....................178
plastic parts ............................177
safety belts ..............................179
tail lamps .................................178washing ....................................175
waxing .....................................175
wheels ......................................176
Clutch
fluid ..........................................137
Defrost
rear window ..............................25
Emission control system ..........160
Engine
service points ...................130,131
Engine block heater ...................84
Engine coolant
checking and adding .......138,139
disposal ....................................141
refill capacities ........................141
Engine oil ...........................132,134
changing oil and oil filter .......135
checking and adding .......132,134
Exhaust fumes ............................85
Floor mats ...................................38
Foglamps .....................................28
Fuel
calculating fuel economy .......159
improving fuel economy ........103
octane rating ...........................157
quality ......................................158
running out of fuel .................158
safety information relating to
automotive fuels .....................155
Fuel gauge ...................................14
Fuel pump shut-off switch ..39,104
Fuses ..............106,107,108,110,112
Gauges, Mechanical ....................13
engine coolant temperature
gauge .........................................14
Hazard flashers .........................104
Headlamps ...................................26
daytime running lights .............26
flashing ......................................27
high beam .................................27
Heating ........................................18
Index
188

Recommended fuel Unleaded fuel only - 87 octane
Fuel tank capacity 48.5L (12.8 gallons)
Engine oil Use Motorcraft 5W30 Super
Premium Motor Oil, Ford
Specification WSS-M2C153-G
Tire size and pressure Refer to Tire Pressure Decal on
passenger's door panel
Hood release Pull handle under the left side of
the instrument panel
Oil capacity (with filter change) Sedan/wagon-3.8L (4.0 quarts)
ZX2-4.25L (4.5 quarts)
Coolant capacity Automatic transaxle-6.0L
(6.3 quarts)
Manual transaxle-5.0L (5.3 quarts)
Power steering fluid capacity Fill to line on reservoir
Automatic transmission capacity 3.9L (4.1 quarts)
Manual transmission capacity 3.35L (3.55 quarts)
Filling station information
192
