DRIVER AIRBAG
DESCRIPTION
The color-keyed, injection molded, thermoplastic
driver airbag protective trim cover is the most visible
part of the driver airbag (Fig. 21). The driver airbag
is located in the center of the steering wheel, where
it is secured with two screws to the armature of the
four-spoke steering wheel. All models have a chrome
Dodge Ram emblem in the center of the trim cover.
Concealed beneath the driver airbag trim cover are
the horn switch, the folded airbag cushion, the airbag
cushion retainer, the airbag housing, the airbag infla-
tor, and the retainers that secure the inflator to the
airbag housing.
The airbag cushion, housing, and inflator are
secured within an integral receptacle molded into the
back of the trim cover. The four vertical walls of this
receptacle have a total of twelve small windows with
blocking tabs that are engaged by twelve hook forma-
tions around the perimeter of the airbag housing.
Each hook is inserted through one of the windows
and the blocking tab in each window keeps the hook
properly engaged with the trim cover, locking the
trim cover securely into place on the airbag housing.
The resistive membrane-type horn switch is
secured with heat stakes to the inside surface of the
driver airbag trim cover, between the trim cover and
the folded airbag cushion. The horn switch ground
pigtail wire has an eyelet terminal connector that is
captured beneath a flanged nut on the upper right
inflator mounting stud on the back of the housing
(Fig. 22). The horn switch feed pigtail wire has a
black, molded plastic insulator that is secured by an
integral retainer in a locator hole near the upper
right corner of the airbag housing and is connected tothe vehicle electrical system through a dedicated
take out and connector of the steering wheel wire
harness. Both horn switch wires are routed through
an integral notch in the center of the upper edge of
the airbag housing stamping.
The airbag used in this model is a multistage, Next
Generation-type that complies with revised federal
airbag standards to deploy with less force than those
used in some prior models. A 71 centimeter (28 inch)
diameter, radial deploying fabric cushion with inter-
nal tethers is used. The airbag inflator is a dual-ini-
tiator, non-azide, pyrotechnic-type unit with four
mounting studs and is secured to the stamped metal
airbag housing by four flanged hex nuts. Two keyed
and color-coded connector receptacles on the driver
airbag inflator connect the two inflator initiators to
the vehicle electrical system through two yellow-jack-
eted, two-wire pigtail harnesses of the clockspring.
The driver airbag unit cannot be repaired, and
must be replaced if deployed or in any way damaged.
The driver airbag trim cover and horn switch unit
may be disassembled from the driver airbag unit,
and is available for separate service replacement.
OPERATION
The multistage driver airbag is deployed by electri-
cal signals generated by the Airbag Control Module
(ACM) through the driver airbag squib 1 and squib 2
circuits to the two initiators in the airbag inflator. By
using two initiators, the airbag can be deployed at
multiple levels of force. The force level is controlled
Fig. 21 Driver Airbag Trim Cover
1 - STEERING WHEEL
2 - TRIM COVER
Fig. 22 Driver Airbag Housing
1 - HORN SWITCH FEED WIRE
2 - HORN SWITCH GROUND WIRE
3 - INFLATOR
4 - TRIM COVER
5 - HOUSING
DRRESTRAINTS 8O - 23

WARNING: TO AVOID PERSONAL INJURY OR
DEATH, THE DRIVER AIRBAG TRIM COVER MUST
NEVER BE PAINTED. REPLACEMENT TRIM COV-
ERS ARE SERVICED IN THE ORIGINAL COLORS.
PAINT MAY CHANGE THE WAY IN WHICH THE
MATERIAL OF THE TRIM COVER RESPONDS TO AN
AIRBAG DEPLOYMENT. FAILURE TO OBSERVE
THIS WARNING COULD RESULT IN OCCUPANT
INJURIES UPON AIRBAG DEPLOYMENT.
(1) Disconnect and isolate the battery negative
cable. Wait two minutes for the system capacitor to
discharge before further service.
(2) Remove the driver airbag from the steering
wheel (Refer to 8 - ELECTRICAL/RESTRAINTS/
DRIVER AIRBAG - REMOVAL).
(3) Place the driver airbag on a suitable clean and
dry work surface with the trim cover facing down. If
the trim cover will be reused, be certain to take the
proper precautions to prevent the trim cover from
receiving cosmetic damage during the following pro-
cedures.
(4) Carefully pry the horn switch feed pigtail wire
connector away from the back of the driver airbag
housing far enough to disengage the integral connec-
tor retainer from the locator hole just above the
upper right inflator mounting stud (Fig. 25).
(5) Remove the nut that secures the horn switch
ground pigtail wire eyelet terminal to the upper rightinflator stud on the back of the driver airbag hous-
ing.
(6) Remove the horn switch ground pigtail wire
eyelet terminal from the upper right inflator stud on
the back of the driver airbag housing.
(7) Disengage each of the twelve hooks of the air-
bag housing from the twelve windows in the vertical
walls of the trim cover, one wall at a time. Start by
disengaging the upper wall, then do each of the two
side walls, and finish with the lower wall. To disen-
gage the hooks, use hand pressure to push firmly
and evenly downward into the receptacle on the adja-
cent edge of the airbag housing, while at the same
time pushing outward on the upper edge of the
receptacle wall.
(8) With all of the hooks disengaged, lift the hous-
ing, inflator, and cushion as a unit from the recepta-
cle on the back of the driver airbag trim cover.
ASSEMBLY
The following procedures can be used to replace
the driver airbag trim cover and horn switch unit for
service. If the driver airbag is faulty or deployed, the
entire driver airbag, trim cover and horn switch must
be replaced as a unit.
WARNING: TO AVOID PERSONAL INJURY OR
DEATH, ON VEHICLES EQUIPPED WITH AIRBAGS,
DISABLE THE SUPPLEMENTAL RESTRAINT SYS-
TEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, AIRBAG, SEAT BELT
TENSIONER, IMPACT SENSOR, OR INSTRUMENT
PANEL COMPONENT DIAGNOSIS OR SERVICE.
DISCONNECT AND ISOLATE THE BATTERY NEGA-
TIVE (GROUND) CABLE, THEN WAIT TWO MINUTES
FOR THE SYSTEM CAPACITOR TO DISCHARGE
BEFORE PERFORMING FURTHER DIAGNOSIS OR
SERVICE. THIS IS THE ONLY SURE WAY TO DIS-
ABLE THE SUPPLEMENTAL RESTRAINT SYSTEM.
FAILURE TO TAKE THE PROPER PRECAUTIONS
COULD RESULT IN ACCIDENTAL AIRBAG DEPLOY-
MENT.
WARNING: TO AVOID PERSONAL INJURY OR
DEATH, SERVICE OF THIS UNIT SHOULD BE PER-
FORMED ONLY BY DAIMLERCHRYSLER-TRAINED
AND AUTHORIZED DEALER SERVICE TECHNI-
CIANS. FAILURE TO TAKE THE PROPER PRECAU-
TIONS OR TO FOLLOW THE PROPER
PROCEDURES COULD RESULT IN ACCIDENTAL,
INCOMPLETE, OR IMPROPER AIRBAG DEPLOY-
MENT AND POSSIBLE OCCUPANT INJURIES.
Fig. 25 Driver Airbag Disassembly
1 - HORN SWITCH FEED CONNECTOR
2 - HORN SWITCH GROUND EYELET TERMINAL
3 - HOUSING
4 - TRIM COVER
5 - HOOK (4 LOWER EDGE, 4 UPPER EDGE)
6 - HOOK (2 ON EACH SIDE)
8O - 26 RESTRAINTSDR
DRIVER AIRBAG (Continued)

WARNING: TO AVOID PERSONAL INJURY OR
DEATH, USE EXTREME CARE TO PREVENT ANY
FOREIGN MATERIAL FROM ENTERING THE DRIVER
AIRBAG, OR BECOMING ENTRAPPED BETWEEN
THE DRIVER AIRBAG CUSHION AND THE DRIVER
AIRBAG TRIM COVER. FAILURE TO OBSERVE THIS
WARNING COULD RESULT IN OCCUPANT INJURIES
UPON AIRBAG DEPLOYMENT.
WARNING: TO AVOID PERSONAL INJURY OR
DEATH, THE DRIVER AIRBAG TRIM COVER MUST
NEVER BE PAINTED. REPLACEMENT TRIM COV-
ERS ARE SERVICED IN THE ORIGINAL COLORS.
PAINT MAY CHANGE THE WAY IN WHICH THE
MATERIAL OF THE TRIM COVER RESPONDS TO AN
AIRBAG DEPLOYMENT. FAILURE TO OBSERVE
THIS WARNING COULD RESULT IN OCCUPANT
INJURIES UPON AIRBAG DEPLOYMENT.
(1) Place the driver airbag on a suitable work sur-
face with the airbag cushion facing up.
(2) Fold the two flaps of cushion material up
around the sides and over the top of the airbag cush-
ion retainer strap (Fig. 26).
(3) Position the new driver airbag trim cover over
the airbag cushion, then push the receptacle of the
trim cover down evenly over the cushion. Be certain
that the cushion material flaps remain oriented over
the cushion retainer strap as they were in Step 2.
(4) Turn the driver airbag and the new driver air-
bag trim cover over as a unit, and place the unit on a
suitable clean and dry work surface with the airbag
cushion facing down. Be certain to take the properprecautions to prevent the trim cover from receiving
cosmetic damage during the following procedures.
(5) Be certain that the horn switch feed and
ground pigtail wires are routed through the clearance
notch at the top of the airbag housing, between the
housing and the upper vertical wall of the trim cover
receptacle (Fig. 25).
(6) Work around the perimeter of the unit engag-
ing each of the twelve hooks on the driver airbag
housing through the windows in the walls of the trim
cover receptacle.
(7) After each of the twelve hooks on the driver
airbag housing has been engaged in a window of the
trim cover receptacle, try pulling the trim cover and
the airbag housing away from each other. This action
will fully seat the edges of the windows into the cra-
dles of the hooks.
(8) After all of the windows in the walls of the
trim cover receptacle have been fully seated in the
cradles of the hooks on the airbag housing, check
that the blocking tabs in each of the trim cover win-
dows is oriented over the airbag housing hooks as
shown in (Fig. 27).
(9) Install the horn switch ground pigtail wire eye-
let terminal over the upper right inflator stud on the
back of the driver airbag housing.
(10) Install and tighten the nut that secures the
horn switch ground pigtail wire eyelet terminal to
the upper right inflator stud on the back of the
Fig. 26 Driver Airbag Flaps
1 - FLAP (2)
2 - RETAINER STRAPFig. 27 Driver Airbag Trim Cover Blocking Tabs
1 - BLOCKING TAB (12)
2 - DRIVER AIRBAG TRIM COVER
3 - HORN SWITCH
4 - AIRBAG HOUSING HOOK (12)
DRRESTRAINTS 8O - 27
DRIVER AIRBAG (Continued)

WHEELS
DESCRIPTION
Original equipment wheels are designed for the
specified Maximum Vehicle Capacity.
All models use steel or aluminum drop center
wheels.
Aluminum wheels require special balance weights
and alignment equipment.
(1) On vehicles equipped with dual rear wheels,
The rim is an eight stud hole pattern wheel. The
wheels have a flat mounting surface (Fig. 18). The
slots in the wheel must be aligned to provide access
to the valve stem (Fig. 19).
OPERATION
The wheel (Fig. 20) has raised sections between
the rim flanges and the rim well. Initial inflation of
the tire forces the bead over these raised sections. In
case of tire failure, the raised sections hold the tire
in position on the wheel until the vehicle can be
brought to a safe stop.
DIAGNOSIS AND TESTING
WHEEL INSPECTION
Inspect wheels for:
²Excessive run out
²Dents or cracks
²Damaged wheel lug nut holes
²Air Leaks from any area or surface of the rim
NOTE: Do not attempt to repair a wheel by hammer-
ing, heating or welding.
If a wheel is damaged an original equipment
replacement wheel should be used. When obtaining
replacement wheels, they should be equivalent in
load carrying capacity. The diameter, width, offset,
pilot hole and bolt circle of the wheel should be the
same as the original wheel.
WARNING: FAILURE TO USE EQUIVALENT
REPLACEMENT WHEELS MAY ADVERSELY
AFFECT THE SAFETY AND HANDLING OF THE
VEHICLE. USED WHEELS ARE NOT RECOM-
MENDED. THE SERVICE HISTORY OF THE WHEEL
MAY HAVE INCLUDED SEVERE TREATMENT OR
VERY HIGH MILEAGE. THE RIM COULD FAIL WITH-
OUT WARNING.
Fig. 18 FLAT FACE WHEEL
1 - FLAT FACE
2 - VALVE STEM
Fig. 19 DUAL REAR WHEELS
1 - WINDOW OPENINGS (5)
2 - INBOARD VALVE STEM
3 - OUTBOARD VALVE STEM
Fig. 20 Safety Rim
1 - FLANGE
2 - RIDGE
3 - WELL
DRTIRES/WHEELS 22 - 11

STATIONARY GLASS
TABLE OF CONTENTS
page page
BACKLITE
REMOVAL.............................86
INSTALLATION.........................86
BACKLITE VENT GLASS
REMOVAL.............................87
INSTALLATION.........................87WINDSHIELD
WARNING
WINDSHIELD SAFETY PRECAUTIONS.....88
REMOVAL.............................88
INSTALLATION.........................88
BACKLITE
REMOVAL
It is difficult to salvage the backlite during the
removal operation. The backlite is part of the struc-
tural support for the roof. The urethane bonding
used to secure the glass to the fence is difficult to cut
or clean from any surface. Since the molding is set in
urethane, it is unlikely it would be salvaged. Before
removing the backlite, check the availability from the
parts supplier.
The backlite is attached to the window frame with
urethane adhesive. The urethane adhesive is applied
cold and seals the surface area between the window
opening and the glass. The primer adheres the ure-
thane adhesive to the backlite.
(1) Roll down door glass.
(2) Remove headliner. (Refer to 23 - BODY/INTE-
RIOR/HEADLINER - REMOVAL).
(3) On standard cab models remove the upper
b-pillar trim. (Refer to 23 - BODY/INTERIOR/B-PIL-
LAR UPPER TRIM - REMOVAL)
(4) On quad cab models remove the upper c-pillar
trim. (Refer to 23 - BODY/INTERIOR/C-PILLAR
UPPER TRIM - REMOVAL)
(5) Bend backlite retaining tabs (Fig. 1) inward
against glass.
(6) Disconnect the rear window defogger electrical
connector, if equipped.
(7) Using a suitable pneumatic knife from inside
the vehicle, cut urethane holding backlite frame to
opening fence.
(8) Separate glass from vehicle.
INSTALLATION
(1) Clean urethane adhesive from around backlite
opening fence.
(2) If necessary, apply black-out primer to outer
edge of replacement backlite frame.(3) If black-out primer was pre-applied on backlite,
clean bonding surface with Isopropyl alcohol and
clean lint free cloth. Allow 3 minutes for drying time.
(4) Apply black-out primer to backlite opening
fence.
(5) Apply a 13 mm (0.5 in.) bead of urethane
around the perimeter of the window frame bonding
surface (Fig. 2).
(6) Set glass on lower fence and move glass for-
ward into opening (Fig. 3).
(7) Firmly push glass against rear window glass
opening fence.
(8) Bend tabs around edges of backlite opening
fence to retain glass.
(9) Clean excess urethane from exterior with
MOPARt, Super Clean or equivalent.
(10) Allow urethane to cure at least 24 hours (full
cure is 72 hours).
(11) Water test to verify repair before returning
vehicle to service.
(12) Connect the rear window defogger electrical
connector, if equipped.
Fig. 1 Backlite Tabs
1 - BACKLITE
2-TAB
23 - 86 STATIONARY GLASSDR

MODULE - INSTALLATION, FRONT
CONTROL........................8W-97-6
MODULE - INSTALLATION, FRONT
CONTROL...........................8E-5
MODULE - INSTALLATION, FUEL PUMP . . . 14-12
MODULE - INSTALLATION, FUEL TANK....14-64
MODULE - INSTALLATION, HANDS FREE . . . 8T-2
MODULE - INSTALLATION, HEATED SEAT . . . 8E-7
MODULE - INSTALLATION, HEATED SEAT . 8G-15
MODULE - INSTALLATION, INTEGRATED
POWER..........................8W-97-4
MODULE - INSTALLATION, REMOTE
KEYLESS ENTRY......................8N-8
MODULE - INSTALLATION, SENTRY KEY
IMMOBILIZER.......................8E-15
MODULE - INSTALLATION, WIPER.......8R-23
MODULE - OPERATION, AIRBAG
CONTROL..........................8O-11
MODULE - OPERATION, DRIVER DOOR....8N-5
MODULE - OPERATION, FRONT
CONTROL........................8W-97-5
MODULE - OPERATION, FRONT
CONTROL...........................8E-5
MODULE - OPERATION, FUEL PUMP.....14-11
MODULE - OPERATION, FUEL TANK......14-63
MODULE - OPERATION, HEATED SEAT.....8E-6
MODULE - OPERATION, HEATED SEAT....8G-14
MODULE - OPERATION, INTEGRATED
POWER..........................8W-97-3
MODULE - OPERATION, REMOTE
KEYLESS ENTRY......................8N-7
MODULE - OPERATION, SENTRY KEY
IMMOBILIZER.......................8E-13
MODULE - OPERATION, TRANSFER CASE
CONTROL..........................8E-16
MODULE - OPERATION, TRANSMISSION
CONTROL..........................8E-20
MODULE - OPERATION, WIPER.........8R-23
MODULE - REMOVAL, AIRBAG CONTROL . 8O-12
MODULE - REMOVAL, DRIVER DOOR.....8N-7
MODULE - REMOVAL, ENGINE CONTROL . . . 8E-4
MODULE - REMOVAL, FRONT CONTROL . 8W-97-6
MODULE - REMOVAL, FRONT CONTROL . . . 8E-5
MODULE - REMOVAL, FUEL PUMP.......14-12
MODULE - REMOVAL, FUEL TANK.......14-63
MODULE - REMOVAL, HANDS FREE.......8T-2
MODULE - REMOVAL, HEATED SEAT......8E-7
MODULE - REMOVAL, HEATED SEAT.....8G-15
MODULE - REMOVAL, INTEGRATED
POWER..........................8W-97-3
MODULE - REMOVAL, REMOTE KEYLESS
ENTRY..............................8N-7
MODULE - REMOVAL, SENTRY KEY
IMMOBILIZER.......................8E-15
MODULE - REMOVAL, WIPER...........8R-23
MODULE / SWITCH OPERATING MODES,
STANDARD PROCEDURE -
CONFIGURING A NEW.................8Q-3
MODULE LAMP REPLACEMENT -
STANDARD PROCEDURE...............8M-3
MODULE LENS REPLACEMENT -
STANDARD PROCEDURE...............8M-3
MODULE (SKIM) - DESCRIPTION,
SENTRY KEY IMMOBILIZER.............8Q-1
MODULE (SKIM) - OPERATION, SENTRY
KEY IMMOBILIZER
....................8Q-2
MOLDING - INSTALLATION, FRONT
DOOR INNER BELT
...................23-93
MOLDING - INSTALLATION, FRONT
DOOR OUTER BELT
...................23-93
MOLDING - INSTALLATION, REAR DOOR
INNER BELT
.........................23-94
MOLDING - INSTALLATION, REAR DOOR
OUTER BELT
........................23-94
MOLDING - REMOVAL, FRONT DOOR
INNER BELT
.........................23-93
MOLDING - REMOVAL, FRONT DOOR
OUTER BELT
........................23-92
MOLDING - REMOVAL, REAR DOOR
INNER BELT
.........................23-94
MOLDING - REMOVAL, REAR DOOR
OUTER BELT
........................23-93
MOLDINGS - INSTALLATION, BODY SIDE
. . 23-36
MOLDINGS - REMOVAL, BODY SIDE
.....23-36
MONITORED SYSTEMS - DESCRIPTION
....25-2
MONITORS - DESCRIPTION,
COMPONENT
.........................25-4MOTOR - DESCRIPTION, ADJUSTABLE
PEDAL...............................5-6
MOTOR - DESCRIPTION, BLOWER.......24-28
MOTOR - DESCRIPTION, DOOR LOCK.....8N-4
MOTOR - DESCRIPTION, IDLE AIR
CONTROL..........................14-28
MOTOR - DESCRIPTION, LUMBAR.......8N-18
MOTOR - DESCRIPTION, SHIFT . . 21-511,21-541,
21-575
MOTOR - DIAGNOSIS AND TESTING,
BLOWER...........................24-28
MOTOR - DIAGNOSIS AND TESTING,
DOOR LOCK.........................8N-4
MOTOR - DIAGNOSIS AND TESTING,
LUMBAR...........................8N-18
MOTOR - DIAGNOSIS AND TESTING,
STARTER ...........................8F-32
MOTOR - INSTALLATION, ADJUSTABLE
PEDAL...............................5-7
MOTOR - INSTALLATION, BLOWER......24-31
MOTOR - INSTALLATION, IDLE AIR
CONTROL..........................14-29
MOTOR - INSTALLATION, SHIFT . 21-511,21-541,
21-575
MOTOR - INSTALLATION, STARTER......8F-34
MOTOR - OPERATION, BLOWER.........24-28
MOTOR - OPERATION, DOOR LOCK.......8N-4
MOTOR - OPERATION, IDLE AIR
CONTROL..........................14-28
MOTOR - OPERATION, LUMBAR........8N-18
MOTOR - OPERATION, SHIFT.....21-511,21-541,
21-575
MOTOR - REMOVAL, ADJUSTABLE
PEDAL...............................5-7
MOTOR - REMOVAL, BLOWER..........24-31
MOTOR - REMOVAL, IDLE AIR CONTROL . . 14-29
MOTOR - REMOVAL, SHIFT.....21-511,21-541,
21-575
MOTOR - REMOVAL, STARTER..........8F-33
MOTOR - REMOVAL, WINDOW..........8N-20
MOTOR RELAY - DESCRIPTION,
STARTER ...........................8F-35
MOTOR RELAY - INSTALLATION,
STARTER ...........................8F-37
MOTOR RELAY - OPERATION, STARTER . . . 8F-36
MOTOR RELAY - REMOVAL, STARTER....8F-37
MOTOR RESISTOR BLOCK -
DESCRIPTION, BLOWER...............24-18
MOTOR RESISTOR BLOCK - DIAGNOSIS
AND TESTING, BLOWER...............24-19
MOTOR RESISTOR BLOCK -
INSTALLATION, BLOWER..............24-19
MOTOR RESISTOR BLOCK - OPERATION,
BLOWER...........................24-18
MOTOR RESISTOR BLOCK - REMOVAL,
BLOWER...........................24-19
MOTOR SWITCH - DESCRIPTION,
BLOWER...........................24-20
MOTOR SWITCH - DIAGNOSIS AND
TESTING, BLOWER...................24-20
MOTOR SWITCH - OPERATION, BLOWER . . 24-20
MOUNT - INSTALLATION, DISC BRAKE
CALIPER ADAPTER....................5-22
MOUNT - INSTALLATION, FRONT . . . 9-147,9-218,
9-287,9-59
MOUNT - INSTALLATION, REAR
....9-149,9-220,
9-288,9-61
MOUNT - REMOVAL, FRONT
. 9-146,9-217,9-286,
9-58
MOUNT - REMOVAL, REAR
. . 9-149,9-220,9-288,
9-61
MOUNTED STOP LAMP - INSTALLATION,
CENTER HIGH
.......................8L-11
MOUNTED STOP LAMP - REMOVAL,
CENTER HIGH
.......................8L-11
MOUNTED STOP LAMP UNIT -
INSTALLATION, CENTER HIGH
..........8L-11
MOUNTED STOP LAMP UNIT -
REMOVAL, CENTER HIGH
..............8L-11
MOUNTING - STANDARD PROCEDURE,
MATCH
.............................22-3
MUFFLER - 5.9L DIESEL - INSTALLATION
. 11-10
MUFFLER - 5.9L DIESEL - REMOVAL
.....11-10
MUFFLER - INSTALLATION
..............11-9
MUFFLER - REMOVAL
..................11-9
MULTI-FUNCTION SWITCH - DIAGNOSIS
AND TESTING
.......................8L-18MULTI-FUNCTION SWITCH -
INSTALLATION.......................8L-19
MULTI-FUNCTION SWITCH - REMOVAL . . . 8L-19
NAME PLATES - INSTALLATION,
EXTERIOR..........................23-38
NAME PLATES - REMOVAL, EXTERIOR....23-38
NATURAL VAC LEAK DETECTION ASSY -
DESCRIPTION.......................25-23
NATURAL VAC LEAK DETECTION ASSY -
INSTALLATION.......................25-25
NATURAL VAC LEAK DETECTION ASSY -
OPERATION.........................25-23
NATURAL VAC LEAK DETECTION ASSY -
REMOVAL..........................25-24
NAVIGATION - INSTALLATION, ANTENNA . . . 8A-6
NAVIGATION - REMOVAL, ANTENNA......8A-6
NAVIGATION/TELECOMMUNICATION -
DESCRIPTION........................8T-1
NAVIGATION/TELECOMMUNICATION -
OPERATION..........................8T-1
NECK SEAL - DIAGNOSIS AND TESTING,
RADIATOR CAP-TO-FILLER..............7-58
NEW MODULE / SWITCH OPERATING
MODES, STANDARD PROCEDURE -
CONFIGURING A......................8Q-3
NIGHT MIRROR - DESCRIPTION,
AUTOMATIC DAY.....................8N-11
NIGHT MIRROR - DIAGNOSIS AND
TESTING, AUTOMATIC DAY.............8N-11
NIGHT MIRROR - OPERATION,
AUTOMATIC DAY.....................8N-11
NIGHT MIRROR - REMOVAL,
AUTOMATIC DAY......................8N-12
NOISE - DIAGNOSIS AND TESTING,
WIND...............................23-2
NOISE OR VIBRATION - DIAGNOSIS AND
TESTING, TIRE.......................22-7
NOISE SUPPRESSION GROUND STRAP -
DESCRIPTION, RADIO..................8A-9
NOISE SUPPRESSION GROUND STRAP -
INSTALLATION, RADIO................8A-10
NOISE SUPPRESSION GROUND STRAP -
OPERATION, RADIO...................8A-9
NOISE SUPPRESSION GROUND STRAP -
REMOVAL, RADIO.....................8A-9
NON-DEPLOYED SUPPLEMENTAL
RESTRAINTS - STANDARD
PROCEDURE, HANDLING...............8O-6
NON-MONITORED CIRCUITS -
OPERATION..........................25-8
NOZZLE - DESCRIPTION, WASHER......8R-11
NOZZLE - INSTALLATION, WASHER......8R-12
NOZZLE - OPERATION, WASHER........8R-12
NOZZLE - REMOVAL, WASHER..........8R-12
NUMBER - DESCRIPTION, VEHICLE
IDENTIFICATION....................Intro.-1
NV241 GENII - ASSEMBLY, TRANSFER
CASE.............................21-428
NV241 GENII - CLEANING, TRANSFER
CASE.............................21-426
NV241 GENII - DESCRIPTION, TRANSFER
CASE.............................21-415
NV241 GENII - DIAGNOSIS AND
TESTING, TRANSFER CASE............21-416
NV241 GENII - DISASSEMBLY,
TRANSFER CASE....................21-417
NV241 GENII - INSPECTION, TRANSFER
CASE.............................21-426
NV241 GENII - INSTALLATION,
TRANSFER CASE....................21-438
NV241 GENII - OPERATION, TRANSFER
CASE.............................21-415
NV241 GENII - REMOVAL, TRANSFER
CASE.............................21-417
NV241 GENII - TRANSFER CASE........21-438
NV241/NV243 - TRANSFER CASE.......21-439
NV243 - ASSEMBLY, TRANSFER CASE . . . 21-496
NV243 - CLEANING, TRANSFER CASE . . . 21-493
NV243 - DESCRIPTION, TRANSFER CASE . 21-482
NV243 - DIAGNOSIS AND TESTING,
TRANSFER CASE....................21-483
NV243 - DISASSEMBLY, TRANSFER
CASE
.............................21-484
NV243 - INSPECTION, TRANSFER CASE
. . 21-493
NV243 - INSTALLATION, TRANSFER
CASE
.............................21-505
NV243 - OPERATION, TRANSFER CASE
. . 21-483
NV243 - REMOVAL, TRANSFER CASE
....21-484
DRINDEX 21
Description Group-Page Description Group-Page Description Group-Page

RAIL - DESCRIPTION, FUEL INJECTOR....14-78
RAIL - INSTALLATION, FUEL............14-15
RAIL - INSTALLATION, FUEL INJECTOR . . . 14-78
RAIL - OPERATION, FUEL..............14-12
RAIL - OPERATION, FUEL INJECTOR.....14-78
RAIL - REMOVAL, FUEL...............14-13
RAIL - REMOVAL, FUEL INJECTOR.......14-78
RAIL REPAIR - STANDARD PROCEDURE,
HYDROFORM FENDER.................13-11
RAIL TIP REPLACEMENT - STANDARD
PROCEDURE, LIGHT DUTY FRONT
FRAME..............................13-4
RAIL WEATHERSTRIP - INSTALLATION,
DRIP..............................23-91
RAIL WEATHERSTRIP - REMOVAL, DRIP . . 23-91
RAIL WEATHERSTRIP RETAINER -
INSTALLATION, DRIP.................23-92
RAIL WEATHERSTRIP RETAINER -
REMOVAL, DRIP.....................23-92
RANGE SENSOR - DESCRIPTION,
TRANSMISSION...............21-263,21-405
RANGE SENSOR - INSTALLATION,
TRANSMISSION.....................21-266
RANGE SENSOR - OPERATION,
TRANSMISSION...............21-263,21-405
RANGE SENSOR - REMOVAL,
TRANSMISSION.....................21-265
RANGE SENSOR (TRS) - DIAGNOSIS
AND TESTING, TRANSMISSION........21-264
RATINGS, SPECIFICATIONS -
GENERATOR........................8F-20
RE TRANSMISSION, SPECIAL TOOLS....21-191
READING LAMP - DESCRIPTION.........8L-28
READING LAMP - INSTALLATION........8L-29
READING LAMP - OPERATION..........8L-28
READING LAMP - REMOVAL............8L-28
READING/COURTESY LAMP
REPLACEMENT - STANDARD
PROCEDURE.........................8M-3
REAR AXLE - 10 1/2 AA -
ADJUSTMENTS......................3-116
REAR AXLE - 10 1/2 AA - DIAGNOSIS
AND TESTING.......................3-112
REAR AXLE - 10 1/2 AA - INSTALLATION . . 3-116
REAR AXLE - 10 1/2 AA - REMOVAL.....3-115
REAR AXLE - 10 1/2 AA - SPECIAL
TOOLS.............................3-120
REAR AXLE - 10 1/2 AA -
SPECIFICATIONS.....................3-120
REAR AXLE - 11 1/2 AA -
ADJUSTMENTS......................3-144
REAR AXLE - 11 1/2 AA - DIAGNOSIS
AND TESTING.......................3-140
REAR AXLE - 11 1/2 AA - INSTALLATION . . 3-144
REAR AXLE - 11 1/2 AA - REMOVAL.....3-143
REAR AXLE - 11 1/2 AA - SPECIAL
TOOLS.............................3-148
REAR AXLE - 11 1/2 AA -
SPECIFICATIONS.....................3-148
REAR AXLE - 9 1/4 - ADJUSTMENTS......3-83
REAR AXLE - 9 1/4 - DIAGNOSIS AND
TESTING............................3-80
REAR AXLE - 9 1/4 - INSTALLATION......3-83
REAR AXLE - 9 1/4 - REMOVAL..........3-83
REAR AXLE - 9 1/4 - SPECIAL TOOLS.....3-90
REAR AXLE - 9 1/4 - SPECIFICATIONS.....3-90
REAR BEARING - INSTALLATION,
OUTPUT SHAFT.....................21-217
REAR BEARING - REMOVAL, OUTPUT
SHAFT............................21-216
REAR BRAKE HOSE - INSTALLATION......5-12
REAR BRAKE HOSE - REMOVAL..........5-11
REAR BUMPER - INSTALLATION..........13-4
REAR BUMPER - REMOVAL.............13-3
REAR CAB BACK PANEL TRIM -
INSTALLATION.......................23-69
REAR CAB BACK PANEL TRIM -
REMOVAL..........................23-68
REAR CABLE - INSTALLATION, LEFT......5-39
REAR CABLE - INSTALLATION, RIGHT.....5-38
REAR CABLE - REMOVAL, LEFT..........5-38
REAR CABLE - REMOVAL, RIGHT
.........5-37
REAR CENTER SEAT BELT &
RETRACTOR - INSTALLATION
...........8O-45
REAR CENTER SEAT BELT &
RETRACTOR - REMOVAL
..............8O-44
REAR CLUTCH - ASSEMBLY
...........21-249
REAR CLUTCH - CLEANING
...........21-248REAR CLUTCH - DESCRIPTION.........21-247
REAR CLUTCH - DISASSEMBLY........21-248
REAR CLUTCH - INSPECTION..........21-248
REAR CLUTCH - OPERATION..........21-248
REAR DOOR GLASS RUN
WEATHERSTRIP - INSTALLATION........23-93
REAR DOOR GLASS RUN
WEATHERSTRIP - REMOVAL............23-93
REAR DOOR INNER BELT MOLDING -
INSTALLATION.......................23-94
REAR DOOR INNER BELT MOLDING -
REMOVAL..........................23-94
REAR DOOR OUTER BELT MOLDING -
INSTALLATION.......................23-94
REAR DOOR OUTER BELT MOLDING -
REMOVAL..........................23-93
REAR DOOR SILL TRIM COVER -
INSTALLATION.......................23-71
REAR DOOR SILL TRIM COVER -
REMOVAL..........................23-71
REAR DRUM IN HAT BRAKE - CLEANING . . . 5-39
REAR DRUM IN HAT BRAKE -
INSPECTION.........................5-39
REAR DUAL WHEELS - INSTALLATION.....5-35
REAR DUAL WHEELS - REMOVAL........5-34
REAR FENDER - INSTALLATION.........23-44
REAR FENDER - REMOVAL.............23-44
REAR FRAME H-SECTION REPLACEMENT
- STANDARD PROCEDURE.............13-13
REAR MOUNT - INSTALLATION....9-149,9-220,
9-288,9-61
REAR MOUNT - REMOVAL . . . 9-149,9-220,9-288,
9-61
REAR OIL SEAL RETAINER -
INSTALLATION, CRANKSHAFT......9-210,9-277
REAR OIL SEAL RETAINER - REMOVAL,
CRANKSHAFT..................9-209,9-277
REAR OUTBOARD SEAT BELT &
RETRACTOR - INSTALLATION...........8O-47
REAR OUTBOARD SEAT BELT &
RETRACTOR - REMOVAL..............8O-46
REAR PARK BRAKE CABLE -
INSTALLATION........................5-38
REAR PARK BRAKE CABLE - REMOVAL....5-37
REAR PROPELLER SHAFT -
INSTALLATION.........................3-8
REAR PROPELLER SHAFT - REMOVAL......3-8
REAR SEAL AREA LEAKS - DIAGNOSIS
AND TESTING..............9-137,9-209,9-65
REAR SERVO - ASSEMBLY............21-251
REAR SERVO - CLEANING............21-251
REAR SERVO - DESCRIPTION..........21-251
REAR SERVO - DISASSEMBLY.........21-251
REAR SERVO - OPERATION...........21-251
REAR TUBE / HOSE ASSEMBLY -
INSTALLATION........................5-13
REAR TUBE / HOSE ASSEMBLY -
REMOVAL...........................5-12
REAR VIEW MIRROR - REMOVAL........23-69
REAR VIEW MIRROR SUPPORT
BRACKET - INSTALLATION.............23-70
REAR WHEEL ANTILOCK - DIAGNOSIS
AND TESTING
........................5-48
REAR WHEEL INSTALLATION -
STANDARD PROCEDURE, DUAL
.........22-12
REAR WHEEL SPEED SENSOR -
DIAGNOSIS AND TESTING
..............5-49
REAR WHEEL SPEED SENSOR -
INSTALLATION
........................5-48
REAR WHEEL SPEED SENSOR -
REMOVAL
...........................5-48
REAR WHEELHOUSE SPLASH SHIELD -
INSTALLATION
.......................23-41
REAR WHEELHOUSE SPLASH SHIELD -
REMOVAL
..........................23-41
REAR WINDOW DEFOGGER RELAY -
DESCRIPTION
........................8G-2
REAR WINDOW DEFOGGER RELAY -
INSTALLATION
.......................8G-4
REAR WINDOW DEFOGGER RELAY -
OPERATION
..........................8G-3
REAR WINDOW DEFOGGER RELAY -
REMOVAL
...........................8G-3
REAR WINDOW DEFOGGER SWITCH -
DESCRIPTION
........................8G-4
REAR WINDOW DEFOGGER SWITCH -
OPERATION
..........................8G-4REAR WINDOW DEFOGGER SYSTEM -
DIAGNOSIS AND TESTING..............8G-2
RECEIVER - INSTALLATION, ASH........23-51
RECEIVER - REMOVAL, ASH............23-50
RECIRCULATION DOOR - INSTALLATION . . 24-40
RECIRCULATION DOOR - REMOVAL......24-39
RECIRCULATION DOOR ACTUATOR -
DESCRIPTION.......................24-24
RECIRCULATION DOOR ACTUATOR -
INSTALLATION.......................24-25
RECIRCULATION DOOR ACTUATOR -
OPERATION.........................24-24
RECIRCULATION DOOR ACTUATOR -
REMOVAL..........................24-24
RECOVERY - STANDARD PROCEDURE,
REFRIGERANT.......................24-47
RECOVERY CONTAINER- GAS ENGINES -
DESCRIPTION, COOLANT...............7-33
RECOVERY CONTAINER- GAS ENGINES -
INSTALLATION, COOLANT...............7-33
RECOVERY CONTAINER- GAS ENGINES -
OPERATION, COOLANT.................7-33
RECOVERY CONTAINER- GAS ENGINES -
REMOVAL, COOLANT..................7-33
REDUCER - DESCRIPTION, SEAT BELT
TENSION...........................8O-53
REDUCER - DIAGNOSIS AND TESTING,
SEAT BELT TENSION..................8O-54
REDUCER - OPERATION, SEAT BELT
TENSION...........................8O-54
REFACING - STANDARD PROCEDURE . 9-202,9-28
REFACING - STANDARD PROCEDURE,
CYLINDER BLOCK....................9-264
REFILLING COOLING SYSTEM - ALL GAS
ENGINES - STANDARD PROCEDURE......7-18
REFILLING COOLING SYSTEM 5.9L
DIESEL ENGINE - STANDARD
PROCEDURE.........................7-19
REFRIGERANT - DESCRIPTION..........24-67
REFRIGERANT - OPERATION............24-67
REFRIGERANT LINE - DESCRIPTION......24-42
REFRIGERANT LINE COUPLER -
DESCRIPTION.......................24-67
REFRIGERANT LINE COUPLER -
INSTALLATION.......................24-68
REFRIGERANT LINE COUPLER -
OPERATION.........................24-67
REFRIGERANT LINE COUPLER -
REMOVAL..........................24-68
REFRIGERANT LINES - OPERATION......24-42
REFRIGERANT OIL - DESCRIPTION......24-68
REFRIGERANT OIL - OPERATION........24-69
REFRIGERANT OIL LEVEL - STANDARD
PROCEDURE........................24-69
REFRIGERANT RECOVERY - STANDARD
PROCEDURE........................24-47
REFRIGERANT SYSTEM CHARGE -
STANDARD PROCEDURE...............24-47
REFRIGERANT SYSTEM EVACUATE -
STANDARD PROCEDURE...............24-47
REFRIGERANT SYSTEM LEAKS -
DIAGNOSIS AND TESTING.............24-44
REFRIGERANT SYSTEM SERVICE
EQUIPMENT - STANDARD PROCEDURE . . . 24-46
REGULATOR - DESCRIPTION, FUEL
FILTER/PRESSURE.....................14-5
REGULATOR - DESCRIPTION, VOLTAGE . . . 8F-25
REGULATOR - MANUAL - INSTALLATION,
WINDOW......................23-27,23-35
REGULATOR - MANUAL - REMOVAL,
WINDOW......................23-26,23-35
REGULATOR - OPERATION, FUEL
FILTER/PRESSURE.....................14-6
REGULATOR - OPERATION, VOLTAGE.....8F-25
REGULATOR - POWER - INSTALLATION,
WINDOW......................23-26,23-34
REGULATOR - POWER - REMOVAL,
WINDOW......................23-25,23-34
RELAY - DESCRIPTION, A/C
COMPRESSOR CLUTCH...............24-13
RELAY - DESCRIPTION, FOG LAMP......8L-12
RELAY - DESCRIPTION, FUEL HEATER
....14-52
RELAY - DESCRIPTION, FUEL PUMP
.....14-27
RELAY - DESCRIPTION, INTAKE AIR
HEATER
............................14-82
RELAY - DESCRIPTION, PARK LAMP
.....8L-20
RELAY - DESCRIPTION, REAR WINDOW
DEFOGGER
..........................8G-2
26 INDEXDR
Description Group-Page Description Group-Page Description Group-Page

WATER PUMP BYPASS - DESCRIPTION....7-59
WATER PUMP BYPASS - OPERATION......7-60
WATER SEPARATOR - DESCRIPTION,
FUEL FILTER........................14-50
WATER SEPARATOR - INSTALLATION,
FUEL FILTER........................14-50
WATER SEPARATOR - OPERATION, FUEL
FILTER.............................14-50
WATER SEPARATOR - REMOVAL, FUEL
FILTER.............................14-50
WATER TO OIL COOLER - REMOVAL......7-69
WATERDAM - INSTALLATION......23-25,23-34
WATERDAM - REMOVAL..........23-25,23-34
WATER-IN-FUEL INDICATOR -
DESCRIPTION.......................8J-45
WATER-IN-FUEL INDICATOR -
OPERATION.........................8J-45
WATER-TO-AIR COOLER - INSTALLATION . . 7-70
WEAR - STANDARD PROCEDURE,
MEASURING TIMING CHAIN............9-167
WEAR INDICATORS - DIAGNOSIS AND
TESTING, TREAD......................22-8
WEAR PATTERNS - DIAGNOSIS AND
TESTING, TIRE.......................22-8
WEAR, STANDARD PROCEDURE -
MEASURING TIMING CHAIN.............9-77
WEATHERSTRIP - INSTALLATION, DRIP
RAIL..............................23-91
WEATHERSTRIP - INSTALLATION, FRONT
DOOR GLASS RUN...................23-92
WEATHERSTRIP - INSTALLATION, REAR
DOOR GLASS RUN.....................23-93
WEATHERSTRIP - REMOVAL, DRIP RAIL . . 23-91
WEATHERSTRIP - REMOVAL, FRONT
DOOR GLASS RUN...................23-92
WEATHERSTRIP - REMOVAL, REAR
DOOR GLASS RUN...................23-93
WEATHERSTRIP RETAINER -
INSTALLATION, A-PILLAR..............23-91
WEATHERSTRIP RETAINER -
INSTALLATION, DRIP RAIL.............23-92
WEATHERSTRIP RETAINER - REMOVAL,
A-PILLAR...........................23-91
WEATHERSTRIP RETAINER - REMOVAL,
DRIP RAIL..........................23-92
WELD LOCATIONS - SPECIFICATIONS . . . 23-120
WELD PROCESS - SPECIFICATIONS......13-15
WHEEL - INSTALLATION, STEERING
......19-15
WHEEL - REMOVAL, STEERING
.........19-15
WHEEL ALIGNMENT - DESCRIPTION
.......2-1
WHEEL ALIGNMENT - OPERATION
.........2-2
WHEEL ALIGNMENT, SPECIAL TOOLS
......2-7
WHEEL ANTILOCK - DIAGNOSIS AND
TESTING, REAR
.......................5-48
WHEEL BALANCE - STANDARD
PROCEDURE, TIRE
....................22-4
WHEEL COVER - REMOVAL
............22-14WHEEL INSPECTION, DIAGNOSIS AND
TESTING...........................22-11
WHEEL INSTALLATION - STANDARD
PROCEDURE, DUAL REAR.............22-12
WHEEL REPLACEMENT - STANDARD
PROCEDURE........................22-12
WHEEL RUNOUT - DIAGNOSIS AND
TESTING, TIRE.......................22-1
WHEEL SPEED SENSOR - DESCRIPTION,
FRONT..............................5-47
WHEEL SPEED SENSOR - DIAGNOSIS
AND TESTING, REAR...................5-49
WHEEL SPEED SENSOR -
INSTALLATION, FRONT.................5-48
WHEEL SPEED SENSOR -
INSTALLATION, REAR..................5-48
WHEEL SPEED SENSOR - OPERATION,
FRONT..............................5-47
WHEEL SPEED SENSOR - REMOVAL,
FRONT..............................5-48
WHEEL SPEED SENSOR - REMOVAL,
REAR...............................5-48
WHEEL WITH MATCHING TIRE -
DESCRIPTION, FULL SIZE, SPARE.......22-15
WHEELHOUSE SPLASH SHIELD -
INSTALLATION, FRONT................23-41
WHEELHOUSE SPLASH SHIELD -
INSTALLATION, REAR.................23-41
WHEELHOUSE SPLASH SHIELD -
REMOVAL, FRONT....................23-41
WHEELHOUSE SPLASH SHIELD -
REMOVAL, REAR.....................23-41
WHEELS - DESCRIPTION..............22-11
WHEELS - INSTALLATION, REAR DUAL....5-35
WHEELS - OPERATION................22-11
WHEELS - REMOVAL, REAR DUAL........5-34
WIND NOISE - DIAGNOSIS AND TESTING . . 23-2
WINDOW DEFOGGER RELAY -
DESCRIPTION, REAR..................8G-2
WINDOW DEFOGGER RELAY -
INSTALLATION, REAR..................8G-4
WINDOW DEFOGGER RELAY -
OPERATION, REAR....................8G-3
WINDOW DEFOGGER RELAY -
REMOVAL, REAR.....................8G-3
WINDOW DEFOGGER SWITCH -
DESCRIPTION, REAR..................8G-4
WINDOW DEFOGGER SWITCH -
OPERATION, REAR....................8G-4
WINDOW DEFOGGER SYSTEM -
DIAGNOSIS AND TESTING, REAR.........8G-2
WINDOW MOTOR - REMOVAL..........8N-20
WINDOW REGULATOR - MANUAL -
INSTALLATION..................23-27,23-35
WINDOW REGULATOR - MANUAL -
REMOVAL.....................23-26,23-35
WINDOW REGULATOR - POWER -
INSTALLATION..................23-26,23-34WINDOW REGULATOR - POWER -
REMOVAL.....................23-25,23-34
WINDOW SWITCH - DIAGNOSIS AND
TESTING...........................8N-20
WINDOW SWITCH - INSTALLATION......8N-21
WINDOW SWITCH - REMOVAL..........8N-20
WINDOWS - DESCRIPTION, POWER.....8N-19
WINDOWS - DIAGNOSIS AND TESTING,
POWER............................8N-19
WINDOWS - OPERATION, POWER.......8N-19
WINDSHIELD SAFETY PRECAUTIONS,
WARNING..........................23-88
WIPER & WASHER SYSTEM - CLEANING . . 8R-6
WIPER & WASHER SYSTEM -
DIAGNOSIS AND TESTING..............8R-6
WIPER & WASHER SYSTEM -
INSPECTION.........................8R-7
WIPER ARM - DESCRIPTION...........8R-17
WIPER ARM - INSTALLATION...........8R-18
WIPER ARM - OPERATION.............8R-18
WIPER ARM - REMOVAL..............8R-18
WIPER BLADE - DESCRIPTION..........8R-18
WIPER BLADE - INSTALLATION.........8R-20
WIPER BLADE - OPERATION...........8R-19
WIPER BLADE - REMOVAL.............8R-19
WIPER HIGH/LOW RELAY -
DESCRIPTION.......................8R-20
WIPER HIGH/LOW RELAY - DIAGNOSIS
AND TESTING.......................8R-21
WIPER HIGH/LOW RELAY -
INSTALLATION......................8R-22
WIPER HIGH/LOW RELAY - OPERATION . . 8R-20
WIPER HIGH/LOW RELAY - REMOVAL....8R-21
WIPER MODULE - DESCRIPTION........8R-22
WIPER MODULE - INSTALLATION.......8R-23
WIPER MODULE - OPERATION..........8R-23
WIPER MODULE - REMOVAL...........8R-23
WIPER ON/OFF RELAY - DESCRIPTION . . . 8R-24
WIPER ON/OFF RELAY - DIAGNOSIS AND
TESTING...........................8R-25
WIPER ON/OFF RELAY - INSTALLATION . . . 8R-26
WIPER ON/OFF RELAY - OPERATION.....8R-25
WIPER ON/OFF RELAY - REMOVAL......8R-26
WIPERS/WASHERS - DESCRIPTION
.......8R-1
WIPERS/WASHERS - OPERATION
........8R-4
WIRE SPLICING - STANDARD
PROCEDURE
.....................8W-01-15
WIRING - DESCRIPTION, TRAILER TOW
. . 8L-24
WIRING DIAGRAMS - DESCRIPTION,
HOW TO USE
.....................8W-01-1
WIRING HARNESS - DIAGNOSIS AND
TESTING
.........................8W-01-7
WIRING/TERMINAL, SPECIAL TOOLS
. . 8W-01-10
WORN THREADS - STANDARD
PROCEDURE, REPAIR
DAMAGED OR
...........9-190,9-240,9-9,9-94
DRINDEX 37
Description Group-Page Description Group-Page Description Group-Page
