8W-39 VEHICLE THEFT SECURITY SYSTEM
Component Page
Cylinder Lock Switch-Driver........... 8W-39-5
Data Link Connector................. 8W-39-3
Door Lock Motor/Ajar Switch-Driver..... 8W-39-5
Door Lock Motor/Ajar Switch-Left Rear . . . 8W-39-5
Door Lock Motor/Ajar Switch-Passenger . . 8W-39-4
Door Lock Motor/Ajar Switch-Right Rear . . 8W-39-4
Front Control Module................. 8W-39-3
Fuse 15............................ 8W-39-3
Fuse 23............................ 8W-39-2
Fuse 45............................ 8W-39-3
Fuse 50............................ 8W-39-2Component Page
G104.............................. 8W-39-3
G105.............................. 8W-39-3
G201.............................. 8W-39-2
G301............................ 8W-39-4, 5
Headlamp-Left...................... 8W-39-3
Headlamp-Right..................... 8W-39-3
Horn Relay......................... 8W-39-3
Instrument Cluster............... 8W-39-2, 4, 5
Integrated Power Module............ 8W-39-2, 3
Park Lamp Relay.................... 8W-39-3
Sentry Key Immobilizer Module......... 8W-39-2
DR8W-39 VEHICLE THEFT SECURITY SYSTEM 8W - 39 - 1

8W-40 INSTRUMENT CLUSTER
Component Page
A/C-Heater Control.................. 8W-40-12
Brake Transmission Shift Interlock
Solenoid........................ 8W-40-10
Center High Mounted Stop Lamp/Cargo
Lamp........................ 8W-40-5, 11
Clockspring..................... 8W-40-10, 14
Cylinder Lock Switch-Driver........... 8W-40-6
Data Link Connector................. 8W-40-5
Dome Lamp....................... 8W-40-11
Door Ajar Switch-Driver.............. 8W-40-13
Door Ajar Switch-Left Rear........... 8W-40-13
Door Ajar Switch-Passenger........... 8W-40-13
Door Ajar Switch-Right Rear.......... 8W-40-13
Door Lock Motor/Ajar Switch-Driver..... 8W-40-7
Door Lock Motor/Ajar Switch-Left Rear . . . 8W-40-7
Door Lock Motor/Ajar
Switch-Passenger................ 8W-40-6, 8
Door Lock Motor/Ajar
Switch-Right Rear............... 8W-40-7, 8
Door Lock Switch-Passenger........... 8W-40-6
Driver Door Module.................. 8W-40-8
Fog Lamp Relay..................... 8W-40-3
Fog Lamp-Left...................... 8W-40-3
Fog Lamp-Right..................... 8W-40-3
Fuse 18............................ 8W-40-5
Fuse 22............................ 8W-40-5Component Page
Fuse 41............................ 8W-40-3
G201........................... 8W-40-3, 12
G202............................. 8W-40-10
G301....................... 8W-40-2, 6, 7, 13
Glove Box Lamp And Switch.......... 8W-40-12
Headlamp Switch.................... 8W-40-3
Heated Seat Switch-Driver.......... 8W-40-8, 12
Heated Seat Switch-Passenger....... 8W-40-8, 12
Horn Switch....................... 8W-40-14
Ignition Switch................... 8W-40-5, 14
Instrument Cluster........ 8W-40-2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12, 13, 14
Integrated Power Module........ 8W-40-2, 3, 5, 9
Multi-Function Switch................ 8W-40-4
Overhead Map/Reading Lamp......... 8W-40-11
Park Brake Switch.................. 8W-40-14
Powertrain Control Module........... 8W-40-14
PTCNo.2........................ 8W-40-2, 9
Radio.......................... 8W-40-9, 11
Remote Radio Switch-Left............ 8W-40-10
Remote Radio Switch-Right........... 8W-40-10
Seat Belt Switch-Driver............... 8W-40-2
Seat Belt Tensioner Reducer........... 8W-40-2
Transfer Case Selector Switch.......... 8W-40-9
Transmission Range Sensor............ 8W-40-5
DR8W-40 INSTRUMENT CLUSTER 8W - 40 - 1

8W-50 FRONT LIGHTING
Component Page
Clearance Lamp No. 1................ 8W-50-6
Clearance Lamp No. 2................ 8W-50-6
Clearance Lamp No. 3................ 8W-50-6
Clearance Lamp No. 4................ 8W-50-6
Clearance Lamp No. 5................ 8W-50-6
Data Link Connector................. 8W-50-2
Fog Lamp Relay..................... 8W-50-5
Fog Lamp-Left...................... 8W-50-5
Fog Lamp-Right..................... 8W-50-5
Front Control Module........... 8W-50-2, 3, 4, 5
Fuse 15............................ 8W-50-4
Fuse 32............................ 8W-50-4
Fuse 34............................ 8W-50-4
Fuse 41............................ 8W-50-5Component Page
G104.......................... 8W-50-3, 4, 5
G105............................ 8W-50-3, 4
G201.............................. 8W-50-5
G202.............................. 8W-50-6
Headlamp Switch.................. 8W-50-2, 5
Headlamp-Left...................... 8W-50-3
Headlamp-Right..................... 8W-50-3
Instrument Cluster................. 8W-50-2, 5
Integrated Power Module........ 8W-50-2, 3, 4, 5
Multi-Function Switch................ 8W-50-2
Park Lamp Relay.................... 8W-50-4
Park/Turn Signal Lamp-Left Front....... 8W-50-4
Park/Turn Signal Lamp-Right Front..... 8W-50-4
DR8W-50 FRONT LIGHTING 8W - 50 - 1

Component Page
Fuel Pump Module.................. 8W-80-66
Fuel Pump Motor (Diesel)............ 8W-80-66
Generator......................... 8W-80-67
Glove Box Lamp And Switch.......... 8W-80-67
Hands Free Module (Telematics)....... 8W-80-67
Headlamp Switch................... 8W-80-68
Headlamp-Left..................... 8W-80-68
Headlamp-Right.................... 8W-80-68
Heated Seat Cushion-Driver........... 8W-80-68
Heated Seat Cushion-Passenger........ 8W-80-69
Heated Seat Switch-Driver............ 8W-80-69
Heated Seat Switch-Passenger......... 8W-80-69
Horn Switch....................... 8W-80-69
Horn-High Note.................... 8W-80-70
Horn-Low Note..................... 8W-80-70
Idle Air Control Motor (3.7L/4.7L)...... 8W-80-70
Ignition Switch..................... 8W-80-70
Inlet Air Temperature Sensor.......... 8W-80-71
Input Speed Sensor (45RFE).......... 8W-80-71
Instrument Cluster C1............... 8W-80-71
Instrument Cluster C2............... 8W-80-72
Instrument Cluster C3............... 8W-80-72
Intake Air Temperature Sensor (Gas).... 8W-80-73
Intake Air Temperature/Manifold Absolute
Pressure Sensor (Diesel)............ 8W-80-73
Integrated Power Module C1.......... 8W-80-73
Integrated Power Module C2.......... 8W-80-74
Integrated Power Module C3.......... 8W-80-74
Integrated Power Module C4.......... 8W-80-75
Integrated Power Module C5.......... 8W-80-75
Integrated Power Module C6.......... 8W-80-76
Integrated Power Module C7.......... 8W-80-76
Knock Sensor (3.7L)................. 8W-80-77
Knock Sensor-Left (5.7L)............. 8W-80-77
Knock Sensor-Right (5.7L)............ 8W-80-77
License Lamp-Left.................. 8W-80-77
License Lamp-Right................. 8W-80-77
Lift Pump Motor (Diesel)............. 8W-80-78
Line Pressure Sensor (NGC)........... 8W-80-78
Lumbar Motor-Driver................ 8W-80-78
Lumbar Motor-Passenger............. 8W-80-78
Manifold Absolute Pressure Sensor
(NGC).......................... 8W-80-79
Mode Door Actuator 1 (Panel To Floor) . . . 8W-80-79
Mode Door Actuator 2 (Defrost To Floor) . 8W-80-79
Multi-Function Switch............... 8W-80-79
Natural Vacuum Leak Detection Assembly
(NGC).......................... 8W-80-80
Output Speed Sensor (45RFE)......... 8W-80-80
Output Speed Sensor (47RE).......... 8W-80-80
Overhead Map/reading Lamp (Except
Base).......................... 8W-80-80
Oxygen Sensor 1/1 Upstream (NGC).... 8W-80-81
Oxygen Sensor 1/2 Downstream (NGC) . . 8W-80-81Component Page
Oxygen Sensor 2/1 Upstream (NGC).... 8W-80-81
Oxygen Sensor 2/2 Downstream (NGC) . . 8W-80-81
Park/Turn Signal Lamp-Left Front...... 8W-80-82
Park/Turn Signal Lamp-Right Front.... 8W-80-82
Passenger Blend Door Actuator (Dual-
Zone).......................... 8W-80-82
Passenger Lumbar Switch............ 8W-80-82
Power Mirror-Left................... 8W-80-82
Power Mirror-Right................. 8W-80-83
Power Outlet...................... 8W-80-83
Power Outlet-Console (Except Base)..... 8W-80-83
Power Seat Motor-Driver Front Vertical . . 8W-80-83
Power Seat Motor-Driver Horizontal.... 8W-80-84
Power Seat Motor-Driver Rear Vertical . . 8W-80-84
Power Seat Motor-Passenger Front
Vertical......................... 8W-80-84
Power Seat Motor-Passenger Horizontal . 8W-80-84
Power Seat Motor-Passenger Rear
Vertical......................... 8W-80-84
Power Seat Switch-Driver............ 8W-80-85
Power Seat Switch-Passenger.......... 8W-80-85
Power Steering Pressure Switch (NGC) . . 8W-80-85
Power Window Circuit Breaker........ 8W-80-86
Power Window Motor-Driver.......... 8W-80-86
Power Window Motor-Left Rear........ 8W-80-86
Power Window Motor-Passenger........ 8W-80-86
Power Window Motor-Right Rear....... 8W-80-87
Power Window Switch-Left Rear....... 8W-80-87
Power Window Switch-Passenger....... 8W-80-87
Power Window Switch-Right Rear...... 8W-80-87
Powertrain Control Module C1 (NGC) . . . 8W-80-88
Powertrain Control Module C2 (NGC) . . . 8W-80-89
Powertrain Control Module C3 (NGC) . . . 8W-80-90
Powertrain Control Module C4 (NGC) . . . 8W-80-91
Radio C1 (Except Infinity)............ 8W-80-92
Radio C1 (Infinity).................. 8W-80-92
Radio C2.......................... 8W-80-93
Recirculation Door Actuator........... 8W-80-93
Remote Radio Switch-Left............ 8W-80-93
Remote Radio Switch-Right........... 8W-80-93
Seat Belt Switch-Driver.............. 8W-80-94
Seat Belt Tensioner Reducer (Standard
Cab)........................... 8W-80-94
Seat Belt Tensioner-Driver............ 8W-80-94
Seat Belt Tensioner-Passenger......... 8W-80-94
Seat Heater Interface Module.......... 8W-80-94
Sentry Key Immobilizer Module (SKIM) . . 8W-80-95
Side Impact Sensor-Left.............. 8W-80-95
Side Impact Sensor-Right............. 8W-80-95
Speaker-Center Instrument Panel...... 8W-80-95
Speaker-Left Front Door.............. 8W-80-95
Speaker-Left Instrument Panel........ 8W-80-96
Speaker-Left Rear.................. 8W-80-96
Speaker-Right Front Door............ 8W-80-96
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 3

BRAKE TRANSMISSION SHIFT INTERLOCK SOLENOID - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K32 18DB/YL BRAKE TRANSMISSION SHIFT INTERLOCK SOLENOID
CONTROL
2 Z101 18BK/VT GROUND
C102 (NGC) - (AMBIENT TEMPERATURE SEN-
SOR SIDE)
CAV CIRCUIT
1 G31 20VT/LG
2 K900 20DB/DG
C103 - (HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 Z470 20BK/LB
2 A114 18GY/RD
C106 (5.7L A/T) - (ENGINE SIDE)
CAV CIRCUIT
1 K11 18BR/YL
2 K12 18BR/DB
3 K13 18BR/LB
4 K14 18BR/TN
5 K38 18BR/OR
6 K58 18BR/VT
7 K26 18BR/YL
8 K28 18BR/LB
9 K19 18DB/DG
10 K17 18DB/TN
11 K18 18DB/OR
12 K15 18DB/GY
13 K16 18DB/YL
14 K10 18DB/OR
15 K97 18BR
16 K98 18DB/YL
8W - 80 - 14 8W-80 CONNECTOR PIN-OUTSDR

C131 (3.7L/4.7L EXCEPT ELECTRONIC TRANS-
FER CASE) - (HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 D20 20WT/LG
2 D21 20WT/BR
3-
4-
C131 (3.7L/4.7L EXCEPT ELECTRONIC TRANS-
FER CASE) - DK GRAY (ENGINE SIDE)
CAV CIRCUIT
1 D20 18WT/LG
2 D21 18WT/BR
3-
4-
C131 (4.7L ELECTRONIC TRANSFER CASE) -
(ENGINE SIDE)
CAV CIRCUIT
1 T316 16YL/GY
2 D200 20WT/LG
3 T313 20YL/LG
4 D202 20WT/VT
5 T885 20YL/GY
6 D201 20WT/DG
7 D203 20WT/BR
8 T315 16YL/BR
9 D20 18WT/LG (4.7L)
10 D21 18WT/BR (4.7L)
11
12
8W - 80 - 20 8W-80 CONNECTOR PIN-OUTSDR

C131 (4.7L ELECTRONIC TRANSFER CASE) -
(HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 T316 16YL/GY
2 D200 20WT/LG
3 T313 20YL/LG
4 D202 20WT/VT
5 T885 20YL/GY
6 D201 20WT/DG
7 D203 20WT/BR
8 T315 16YL/BR
9 D20 20WT/LG (4.7L)
10 D21 20WT/BR (4.7L)
11
12
C131 (5.7L/DIESEL) - GRAY (ENGINE SIDE)
CAV CIRCUIT
A1 T316 16YL/GY (ELECTRONIC TRANS-
FER CASE)
A2 D200 20WT/LG (ELECTRONIC TRANS-
FER CASE)
A3 T313 20YL/LG (ELECTRONIC TRANS-
FER CASE)
A4 D202 20WT/VT (ELECTRONIC TRANS-
FER CASE)
A5 T885 20YL/GY (ELECTRONIC TRANS-
FER CASE)
A6 D201 20WT/DG (ELECTRONIC TRANS-
FER CASE)
A7 D203 20WT/BR (ELECTRONIC TRANS-
FER CASE)
A8 T315 16YL/BR (ELECTRONIC TRANS-
FER CASE)
B1 -
B2 D20 20WT/LG
B3 D21 20WT/BR
B4 V32 20VT/YL (DIESEL)
B5 T117 20DG/YL (DIESEL A/T)
B6 V36 20VT/YL (DIESEL A/T)
B7 T917 20YL/TN (DIESEL A/T)
B8 -
C1 A961 14RD (DIESEL)
C2 B22 20DG/WT (5.7L)
C3 F855 18PK/YL (5.7L)
C3 B29 20DG/WT (DIESEL)
C4 F856 18YL/PK (5.7L)
C5 K160 18BR/OR (DIESEL)
C6 K161 18BR/LB (DIESEL)
C7 V37 20VT (DIESEL)
C8 K25 18DB/VT (DIESEL)
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 21

C131 (5.7L/DIESEL) - GRAY (HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
A1 T316 16YL/GY (ELECTRONIC TRANS-
FER CASE)
A2 D200 20WT/LG (ELECTRONIC TRANS-
FER CASE)
A3 T313 20YL/LG (ELECTRONIC TRANS-
FER CASE)
A4 D202 20WT (ELECTRONIC TRANSFER
CASE)
A5 T885 20YL/GY (ELECTRONIC TRANS-
FER CASE)
A6 D201 20WT/DG (ELECTRONIC TRANS-
FER CASE)
A7 D203 20WT/BR (ELECTRONIC TRANS-
FER CASE)
A8 T315 16YL/BR (ELECTRONIC TRANS-
FER CASE)
B1 -
B2 D20 20WT/LG
B3 D21 20WT/BR
B4 V32 20VT/YL (DIESEL)
B5 T117 20DG/YL (DIESEL A/T)
B6 V36 20VT/YL (DIESEL A/T)
B7 T917 20YL/TN (DIESEL A/T)
B8 -
C1 A961 14RD (DIESEL)
C2 B22 20DG/WT (5.7L)
C2 V35 20VT/OR (DIESEL A/T)
C3 F855 20PK/YL (5.7L)
C3 B29 20DG/WT (DIESEL)
C4 F856 20YL/PK (5.7L)
C4 F856 18YL/PK (DIESEL)
C5 K160 18BR/OR (DIESEL)
C6 K161 18BR/LB (DIESEL)
C7 V37 20VT (DIESEL)
C8 K25 18DB/VT (DIESEL)
C200 - (HVAC SIDE)
CAV CIRCUIT
1 C70 10DB/YL
2 C34 20DB/LB
3 C71 16DB/BR
4 C32 20DB/TN
5 C73 14DB/VT
6 C72 16DB/OR
7 C7 10DB
8 C29 20DB
9 C21 20DB/LG (EXCEPT BASE A/C)
10 C121 20DB/DG
11 C33 20LB/BR
12 C61 20DB/LG
12 C33 20LB/BR (DUAL ZONE)
13 C801 20DB/OR
8W - 80 - 22 8W-80 CONNECTOR PIN-OUTSDR
