1998 DODGE RAM 1500 Control module

Component Page
Speaker-Right Instrument Panel....... 8W-80-96
Speaker-Right Rear................. 8W-80-96
Speed Control Servo (Diesel A/T/NGC) . . . 8W-80-97
Speed Control Switch-Left (ETC)....... 8W-80-97
Speed Control Switch-Left
(Except ETC).................... 8W-80-97
Speed Control Switch-Right (ETC)...... 8W-80-97
Speed Control Switch-Right (Except
ETC)........................... 8W-80-97
Tail/Stop/Turn Signal Lamp-Left....... 8W-80-98
Tail/Stop/Turn Signal Lamp-Right...... 8W-80-98
Tailgate Lamp..................... 8W-80-98
Throttle Position Sensor (3.7L)......... 8W-80-98
Throttle Position Sensor (4.7L)......... 8W-80-99
Tow/haul Overdrive Switch............ 8W-80-99
Trailer Tow Connector............... 8W-80-99
Trailer Tow Connector-Add On......... 8W-80-99
Transfer Case Control Module C1 (Electric
4x4).......................... 8W-80-100
Transfer Case Control Module C2 (Electric
4x4).......................... 8W-80-100Component Page
Transfer Case Control Module C3
(Electric 4x4)................... 8W-80-101
Transfer Case Mode Sensor.......... 8W-80-101
Transfer Case Selector Switch........ 8W-80-101
Transfer Case Shift Motor........... 8W-80-101
Transmission Range Sensor.......... 8W-80-102
Transmission Solenoid Assembly
(48RE)........................ 8W-80-102
Transmission Solenoid/TRS Assembly
(NGC)......................... 8W-80-102
Vacuum Pump (Diesel).............. 8W-80-103
Vistronic Fan Drive (Diesel).......... 8W-80-103
Washer Fluid Level Switch........... 8W-80-103
Washer Pump Motor-Front........... 8W-80-103
Water In Fuel Sensor............... 8W-80-103
Wheel Speed Sensor-Left Front....... 8W-80-104
Wheel Speed Sensor-Rear............ 8W-80-104
Wheel Speed Sensor-Right Front...... 8W-80-104
Wiper Motor...................... 8W-80-104
8W - 80 - 4 8W-80 CONNECTOR PIN-OUTSDR

ADJUSTABLE PEDAL SWITCH (EXCEPT MEMORY) - BLUE 6 WAY
CAV CIRCUIT FUNCTION
1 P206 18LG/LB ADJUSTABLE PEDALS MOTOR REVERSE
2 A72 18RD/OR ADJUSTABLE PEDAL RELAY OUTPUT
3- -
4 Z146 18BK GROUND
5 F504 20GY/PK FUSED IGNITION SWITCH OUTPUT (RUN)
6 P205 18LG/WT ADJUSTABLE PEDALS MOTOR FORWARD
AIRBAG CONTROL MODULE C1 - 24 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 D25 20WT/VT PCI BUS
4- -
5 Z104 18BK/LG GROUND
6 G104 20VT/GY PASSENGER AIRBAG INDICATOR DRIVER
7 R104 20LB/LG PASSENGER AIRBAG MUX SWITCH RETURN
8 R106 20LG/LB PASSENGER AIRBAG MUX SWITCH SENSE
9- -
10 - -
11 - -
12 - -
13 - -
14 - -
15 - -
16 - -
17 R43 20LG/BR DRIVER SQUIB 1 LINE 1
18 R45 20LG/OR DRIVER SQUIB 1 LINE 2
19 R44 20LB/OR PASSENGER SQUIB 1 LINE 2
20 R42 20LB/BR PASSENGER SQUIB 1 LINE 1
21 R61 20LG/VT DRIVER SQUIB 2 LINE 1
22 R63 20LG/WT DRIVER SQUIB 2 LINE 2
23 R64 20LB/WT PASSENGER SQUIB 2 LINE 1
24 R62 20LB/VT PASSENGER SQUIB 2 LINE 2
8W - 80 - 8 8W-80 CONNECTOR PIN-OUTSDR

AIRBAG CONTROL MODULE C2 - 32 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3- -
4- -
5- -
6- -
7- -
8- -
9 R53 20LG/YL DRIVER SEAT BELT TENSIONER LINE 2
10 R55 20LG/DG DRIVER SEAT BELT TENSIONER LINE 1
11 R56 20LB/DG PASSENGER SEAT BELT TENSIONER LINE 1
12 R54 20LB/YL PASSENGER SEAT BELT TENSIONER LINE 2
13 R1 18LB/WT (LIGHT DUTY) LEFT CURTAIN SQUIB 1 LINE 2
14 R3 18LB/OR (LIGHT DUTY) LEFT CURTAIN SQUIB 1 LINE 1
15 R4 18OR/LB (LIGHT DUTY) RIGHT CURTAIN SQUIB 1 LINE 1
16 R2 18WT/LB (LIGHT DUTY) RIGHT CURTAIN SQUIB 1 LINE 2
17 F201 18PK/OR FUSED IGNITION SWITCH OUTPUT (RUN-START)
18 F100 18PK/VT FUSED IGNITION SWITCH OUTPUT (RUN)
19 - -
20 - -
21 - -
22 - -
23 - -
24 - -
25 - -
26 - -
27 R14 20TN/LG (LIGHT DUTY) RIGHT SIDE IMPACT SENSOR 1 SIGNAL
28 R16 20BR/LG (LIGHT DUTY) RIGHT SIDE IMPACT SENSOR 1 GROUND
29 R15 20LG/BR (LIGHT DUTY) LEFT SIDE IMPACT SENSOR 1 GROUND
30 R13 20LG/TN (LIGHT DUTY) LEFT SIDE IMPACT SENSOR 1 SIGNAL
31 - -
32 - -
AIRBAG-LEFT CURTAIN - YELLOW 2 WAY
CAV CIRCUIT FUNCTION
1 R3 18LB/OR LEFT CURTAIN SQUIB 1 LINE 1
2 R1 18LB/WT LEFT CURTAIN SQUIB 1 LINE 2
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 9

C207 - (TRANSFER CASE CONTROL MODULE
SIDE)
CAV CIRCUIT
1 A34 16RD/WT
2 E11 20OR/DB
3 F21 20PK/DG
4 T315 16YL/BR
5 D25 20VT/DB
6 T885 20YL/GY
7 D200 20WT/LG
8 T316 16YL/GY
9 D202 20WT/VT
10 D201 20WT/DG
11 T41 20YL/DB
12 T313 20YL/LG
13 D203 20WT/BR
14 Z905 16BK
C216 - (CHASSIS SIDE)
CAV CIRCUIT
1 B4 18DG/GY
2 B3 18DG/YL
3 L678 18BR
4 L53 18DG/WT
5 L62 18WT/YL
6 K900 18DB/DG
8 L70 18WT/GY
C216 - (HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 B4 20DG/GY
2 B3 20DG/YL
3 L678 18BR
4 L53 18DG/WT
5 L62 18WT/YL
6 K900 20DB/DG
7 N4 18DB/WT
8 L70 18WT/GY
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 25

DRIVER DOOR MODULE C1 - BLUE 12 WAY
CAV CIRCUIT FUNCTION
1 Q612 14OR/DB RIGHT REAR WINDOW DRIVER (DOWN)
2 Q412 14OR/LB RIGHT REAR WINDOW DRIVER (UP)
3 Q16 14OR/TN MASTER WINDOW SWITCH RIGHT FRONT (UP)
4 Q411 14OR/WT LEFT REAR WINDOW DRIVER (UP)
5 Q11 14OR/LG LEFT FRONT WINDOW DRIVER (UP)
6 Q26 14OR/GY MASTER WINDOW SWITCH RIGHT FRONT (DOWN)
7 G161 20VT/DG DRIVER DOOR LOCK SWITCH MUX
8 Z421 14BK/BR GROUND
9 F30 14PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
10 Q611 14OR/GY LEFT REAR WINDOW DRIVER (DOWN)
11 Z941 20BK GROUND
12 Q21 14OR/WT LEFT FRONT WINDOW DRIVER (DOWN)
DRIVER DOOR MODULE C2 - BLUE 8 WAY
CAV CIRCUIT FUNCTION
1 P71 18TN/DG LEFT MIRROR UP DRIVER
2 P195 18LG/YL LEFT MIRROR COMMON DRIVER (RIGHT/DOWN)
3 A930 18RD FUSED B(+)
4 P74 18TN/OR RIGHT MIRROR LEFT DRIVER
5 Z461 20BK/DG GROUND
6 P75 18TN/LG LEFT MIRROR LEFT DRIVER
7 P72 18TN/GY RIGHT MIRROR UP DRIVER
8 Q15 14OR/LB POWER WINDOW SWITCH FEED
EGR SOLENOID (4.7L/5.7L)-6WAY
CAV CIRCUIT FUNCTION
1 K34 18DB/LG EGR SENSOR SIGNAL
2 F856 20YL/PK 5 VOLT SUPPLY
3 K900 20DB/DG SENSOR GROUND
4 Z335 18BK/WT GROUND
5- -
6 K35 18DB/VT EGR SOLENOID CONTROL
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 57

ELECTRIC BRAKE PROVISION-4WAY
CAV CIRCUIT FUNCTION
A A400 14TN/RD FUSED B(+)
B B40 14DG TRAILER TOW BRAKE B(+)
C L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
D Z998 18BK GROUND
ELECTRIC THROTTLE CONTROL MODULE - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 K22 18BR/OR TP NO. 1 SIGNAL
2 F855 18PK/YL 5 VOLT SUPPLY
3 K447 18TN/YL ETC MOTOR (+)
4 K122 18BR/DG TP NO. 2 SIGNAL
5 K448 18TN/OR ETC MOTOR (-)
6 K922 18BR/DB TP SENSOR RETURN
ENGINE CONTROL MODULE C1 (DIESEL) - 60 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3- -
4 D72 18WT/LB CCD BUS (+)
5 D71 18WT/DB CCD BUS (-)
6 K65 18BR/LB FUEL PUMP RELAY RETURN
7 K20 18BR/GY GEN FIELD CONTROL
8- -
9- -
10 - -
11 K2 18TN/BK (A/T) ECT SIGNAL
11 K2 18VT/OR (M/T) ECT SIGNAL
12 K181 18BR/YL FUEL PUMP DRIVER
13 - -
14 K22 18BR/WT (A/T) TP SIGNAL
14 K23 18DB/WT (M/T) APPS NO. 1 SIGNAL
15 K21 18DB/LG INTAKE AIR TEMPERATURE SENSOR SIGNAL
16 - -
16 K29 18WT/BR (M/T) APPS NO. 2 SIGNAL
17 - -
18 - -
19 K31 18BR FUEL PUMP RELAY CONTROL
20 - -
21 - -
22 K24 18LB/BR (A/T) CKP SIGNAL
22 K24 18BR/LB (M/T) CKP SIGNAL
23 K914 18RD/WT (A/T) SENSOR GROUND
23 K914 18BR/WT (M/T) SENSOR GROUND
24 K44 18DB/GY CMP SIGNAL
25 K668 18LG (A/T) SUPPLY VOLTAGE
25 K688 18BR (M/T) SUPPLY VOLTAGE
8W - 80 - 58 8W-80 CONNECTOR PIN-OUTSDR

ENGINE CONTROL MODULE C1 (DIESEL) - 60 WAY
CAV CIRCUIT FUNCTION
26 C918 18BK/LB A/C PRESSURE SENSOR GROUND
27 K853 18DB/BR 5 VOLT SUPPLY
28 - -
29 K690 18DG/YL (A/T) INLET AIR TEMPERATURE/PRESSURE RETURN
29 K690 18BR/YL (M/T) INLET AIR TEMPERATURE/PRESSURE RETURN
30 K11 16WT/DB (A/T) INJECTOR CONTROL NO. 1
30 K11 16BR/YL (M/T) INJECTOR CONTROL NO.1
31 G123 18VT/LG WATER IN FUEL SENSOR SIGNAL
32 K916 18BR/OR SENSOR GROUND
33 K922 18LG/OR (A/T) THROTTLE POSITION SENSOR RETURN
33 K167 18BR/YL (M/T) APPS NO. 1 RETURN
34 K565 18OR IDLE SWITCH
35 - -
36 K14 16BR/TN INJECTOR CONTROL NO. 4
37 - -
38 - -
39 - -
40 K13 16TN (A/T) INJECTOR CONTROL NO. 3
40 K13 16BR/LB (M/T) INJECTOR CONTROL NO.3
41 - -
42 K851 18VT/PK (A/T) 5-VOLT SUPPLY
42 K852 18BR/VT (M/T) APPS 1 5-VOLT SUPPLY
43 K37 18LB (A/T) BOOST PRESSURE SENSOR SIGNAL
43 K37 18BR/OR (M/T) BOOST PRESSURE SENSOR SIGNAL
44 K556 18OR/BR NOT IDLE SWITCH
45 N2 18DB/YL LIFT PUMP FEED
46 K58 16BR/VT INJECTOR CONTROL NO. 6
47 - -
48 - -
49 - -
50 K12 16BR/DB INJECTOR CONTROL NO. 2
51 - -
52 K975 18BR/BK (A/T) SENSOR GROUND
52 K975 18BR/OR (M/T) SENSOR GROUND
53 K915 18VT/RD FUEL RAIL SENSOR RETURN
54 F855 18PK/YL 5 VOLT SUPPLY
55 - -
56 K38 16GY (A/T) INJECTOR CONTROL NO. 5
56 K38 16BR/OR (M/T) INJECTOR CONTROL NO. 5
57 K229 16TN/PK (A/T) ENG-INJECTOR HIGH SIDE DRIVER-BANK 2
57 K229 16BR/LB (M/T) ENG-INJECTOR HIGH SIDE DRIVER-BANK 2
58 - -
59 K227 16BR/LG ENG-INJECTOR HIGH SIDE DRIVER-BANK 1
60 - -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 59

ENGINE CONTROL MODULE C2 (DIESEL) - 50 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 K615 18VT/WT INLET AIR TEMPERATURE SENSE
3 K615 18BR/WT (M/T) INLET AIR TEMPERATURE SENSE
4 V35 18VT/OR (A/T) S/C VENT CONTROL
5 K176 18BR/OR INTAKE AIR HEATER RELAY NO 2 CONTROL
6 K174 18BR/YL INTAKE AIR HEATER RELAY NO 1 CONTROL
7 V32 18VT/YL (A/T) SPEED CONTROL SUPPLY
8- -
9 T41 18YL/DB (A/T) PARK/NEUTRAL POSITION SWITCH SENSE (T41)
10 K161 18BR/LB FAN SPEED SENSOR
11 B22 18DG/YL VEHICLE SPEED SENSOR SIGNAL NO. 1
12 G6 18VT/GY OIL PRESSURE SIGNAL
13 T6 18DG (A/T) TOW/HAUL OVERDRIVE OFF SWITCH SENSE
14 T118 18DG (A/T) GOVERNOR PRESSURE SOLENOID CONTROL
15 T9 18DG/TN (A/T) 3-4 SOLENIOD CONTROL
16 D21 18WT/BR SCI TRANSMIT (PCM)
16 D21 18PK (M/T) SCI TRANSMIT
17 - -
18 T38 18YL/BR (A/T) GOVERNOR PRESSURE SENSOR SIGNAL
19 D20 18WT/LG SCI RECEIVE (PCM)
20 A209 16RD FUSED B(+)
21 Z902 16BK GROUND
22 - -
23 F856 18YL/PK 5 VOLT SUPPLY
24 K900 18DB/DG SENSOR GROUND
25 T75 18YL/LB (A/T) TORQUE CONVERTER CLUTCH SOLENOID CONTROL
26 N4 18DB/WT FUEL LEVEL SENSOR SIGNAL
27 - -
28 D25 18WT/VT PCI BUS
29 T54 18DG/OR (A/T) TRANSMISSION TEMPERATURE SENSOR SIGNAL
30 A209 16RD FUSED B(+)
31 T515 18YL/DB (A/T) TRANSMISSION CONTROL RELAY CONTROL
32 F202 18PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START)
33 K854 18VT/BR (M/T) 5 VOLT SUPPLY
34 V36 18VT/YL (A/T) S/C VACUUM CONTROL
35 K616 18BR/YL INLET AIR PRESSURE SENSE
36 V32 18VT/YL (M/T) SPEED CONTROL SUPPLY
37 B29 18DG/WT BRAKE SWITCH SIGNAL
38 - -
39 - -
40 A209 16RD FUSED B(+)
41 C13 18LB/OR A/C CLUTCH RELAY CONTROL
42 - -
43 K160 18BR/OR PARK LOCKOUT SOLENOID CONTROL
44 T14 18DG/BR (A/T) OUTPUT SPEED SENSOR SIGNAL
45 T13 18DG/VT (A/T) SENSOR GROUND
46 V37 18VT S/C SWITCH NO. 1 SIGNAL
47 K25 18DB/VT BATT TEMP SIGNAL
48 K400 18BR/VT (M/T) APPS NO.2 RETURN
49 Z902 16BK GROUND
50 Z902 16BK GROUND
8W - 80 - 60 8W-80 CONNECTOR PIN-OUTSDR
