1998 DODGE RAM 1500 Sensor

ACCELERATOR PEDAL POSITION SENSOR (DIESEL M/T)-6WAY
CAV CIRCUIT FUNCTION
1 K29 20WT/BR APPS NO. 2 SIGNAL
2 K854 20VT/BR APPS NO. 2 5 VOLT SUPPLY
3 K852 20BR/LB APPS NO. 1 5 VOLT SUPPLY
4 K400 20BR/VT APPS NO. 2 RETURN
5 K23 20BR/WT APPS NO. 1 SIGNAL
6 K167 20BR/YL APPS NO. 1 RETURN
ACCELERATOR PEDEL POSITION SENSOR (DIESEL A/T)-6WAY
CAV CIRCUIT FUNCTION
1 K914 18RD/WT SENSOR GROUND
2 K556 18OR/BR NOT IDLE SWITCH
3 K22 18BR/WT TP SIGNAL
4 K922 18LG/OR THROTTLE POSITION SENSOR RETURN
5 K851 18VT/PK 5-VOLT SUPPLY
6 K565 18OR IDLE SWITCH
ADJUSTABLE PEDAL MOTOR (EXCEPT MEMORY)-2WAY
CAV CIRCUIT FUNCTION
1 P206 18LG/LB ADJUSTABLE PEDALS MOTOR REVERSE
2 P205 18LG/WT ADJUSTABLE PEDALS MOTOR FORWARD
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 7

AIRBAG CONTROL MODULE C2 - 32 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3- -
4- -
5- -
6- -
7- -
8- -
9 R53 20LG/YL DRIVER SEAT BELT TENSIONER LINE 2
10 R55 20LG/DG DRIVER SEAT BELT TENSIONER LINE 1
11 R56 20LB/DG PASSENGER SEAT BELT TENSIONER LINE 1
12 R54 20LB/YL PASSENGER SEAT BELT TENSIONER LINE 2
13 R1 18LB/WT (LIGHT DUTY) LEFT CURTAIN SQUIB 1 LINE 2
14 R3 18LB/OR (LIGHT DUTY) LEFT CURTAIN SQUIB 1 LINE 1
15 R4 18OR/LB (LIGHT DUTY) RIGHT CURTAIN SQUIB 1 LINE 1
16 R2 18WT/LB (LIGHT DUTY) RIGHT CURTAIN SQUIB 1 LINE 2
17 F201 18PK/OR FUSED IGNITION SWITCH OUTPUT (RUN-START)
18 F100 18PK/VT FUSED IGNITION SWITCH OUTPUT (RUN)
19 - -
20 - -
21 - -
22 - -
23 - -
24 - -
25 - -
26 - -
27 R14 20TN/LG (LIGHT DUTY) RIGHT SIDE IMPACT SENSOR 1 SIGNAL
28 R16 20BR/LG (LIGHT DUTY) RIGHT SIDE IMPACT SENSOR 1 GROUND
29 R15 20LG/BR (LIGHT DUTY) LEFT SIDE IMPACT SENSOR 1 GROUND
30 R13 20LG/TN (LIGHT DUTY) LEFT SIDE IMPACT SENSOR 1 SIGNAL
31 - -
32 - -
AIRBAG-LEFT CURTAIN - YELLOW 2 WAY
CAV CIRCUIT FUNCTION
1 R3 18LB/OR LEFT CURTAIN SQUIB 1 LINE 1
2 R1 18LB/WT LEFT CURTAIN SQUIB 1 LINE 2
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 9

AIRBAG-PASSENGER ON/OFF SWITCH-6WAY
CAV CIRCUIT FUNCTION
1 R106 20LG/LB PASSENGER AIRBAG MUX SWITCH SENSE
2 R104 20LB/LG PASSENGER AIRBAG MUX SWITCH RETURN
3 G104 20VT/GY PASSENGER AIRBAG INDICATOR DRIVER
4 F201 18PK/OR FUSED IGNITION SWITCH OUTPUT (RUN-START)
5- -
6- -
AIRBAG-PASSENGER SQUIB-4WAY
CAV CIRCUIT FUNCTION
1 R44 20LB/OR PASSENGER SQUIB 1 LINE 2
2 R42 20LB/BR PASSENGER SQUIB 1 LINE 1
3 R64 20LB/WT PASSENGER SQUIB 2 LINE 1
4 R62 20LB/VT PASSENGER SQUIB 2 LINE 2
AIRBAG-RIGHT CURTAIN - YELLOW 2 WAY
CAV CIRCUIT FUNCTION
1 R4 18OR/LB RIGHT CURTAIN SQUIB 1 LINE 1
2 R2 18WT/LB RIGHT CURTAIN SQUIB 1 LINE 2
AMBIENT TEMPERATURE SENSOR-2WAY
CAV CIRCUIT FUNCTION
1 G31 20VT/LG AAT SIGNAL
2 K900 20DB/DG SENSOR GROUND
8W - 80 - 10 8W-80 CONNECTOR PIN-OUTSDR

AUTOMATIC DAY/NIGHT MIRROR C1 (EXCEPT BASE)-7WAY
CAV CIRCUIT FUNCTION
1 F21 20PK/DG FUSED IGNITION SWITCH OUTPUT (RUN-START)
2 Z13 20BK/WT GROUND
3 L1 20WT/LG BACKUP LAMP FEED
4- -
5- -
6- -
7- -
AUTOMATIC DAY/NIGHT MIRROR C2 (TELEMATICS) - 12 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3- -
4 X722 20LB/DG MICROPHONE 2 IN (+)
5 X735 20BR HANDSFREE MICROPHONE SHIELD
6 X712 20DG/LB MICROPHONE 1 IN (+)
7 X793 20DG/YL HANDSFREE MICROPHONE HSD FEED
8- -
9 X730 20GY/YL VOICE RECOGNITION/PHONE SWITCH SIGNAL
10 - -
11 X835 20OR/GY SENSOR GROUND
12 X792 20LB/DG MICROPHONE IN (-)
BACKUP LAMP SWITCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
A L1 18WT/LG BACKUP LAMP FEED
B L10 18WT/GY FUSED IGNITION SWITCH OUTPUT (RUN)
BATTERY TEMPERATURE SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K25 18DB/VT BATT TEMP SIGNAL
2 K900 20DB/DG SENSOR GROUND
8W - 80 - 12 8W-80 CONNECTOR PIN-OUTSDR

C328 (DUAL REAR WHEELS) - (DRW LAMP
SIDE)
CAV CIRCUIT
1 L70 18WT/YL
2 Z948 18BK
CAMSHAFT POSITION SENSOR (DIESEL)-3WAY
CAV CIRCUIT FUNCTION
1 F855 18PK/YL 5 VOLT SUPPLY
2 K916 18BR/OR SENSOR GROUND
3 K44 18DB/GY CMP SIGNAL
CAMSHAFT POSITION SENSOR (NGC) - GRAY 3 WAY
CAV CIRCUIT FUNCTION
1 K44 20DB/GY CMP SIGNAL
2 K900 20DB/DG SENSOR GROUND
3 F856 20YL/PK 5 VOLT SUPPLY
CAPACITOR (3.7L/4.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K342 16BR/WT AUTOMATIC SHUT DOWN RELAY OUTPUT
2- -
8W - 80 - 44 8W-80 CONNECTOR PIN-OUTSDR

CONDENSER FAN (NGC) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z823 16BK/DG GROUND
2 C123 16LB/WT CONDENSER FAN RELAY OUTPUT
CONTROLLER ANITLOCK BRAKE C1 - BLACK 14 WAY
CAV CIRCUIT FUNCTION
1 B4 20DG/GY REAR WHEEL SPEED SENSOR (+)
2 B222 20DG/WT (ETC) VEHICLE SPEED SIGNAL NO. 2
3 D25 20WT/VT PCI BUS
4 F500 20DG/PK FUSED IGNITION SWITCH OUTPUT (RUN)
5 B9 20DG/LG (ETC) LEFT FRONT WHEEL SPEED SENSOR (+)
6 Z107 12BK/DG GROUND
7 A111 14DG/RD FUSED B(+)
8 B3 20DG/YL REAR WHEEL SPEED SENSOR (-)
9 B29 20DG/WT BRAKE SWITCH SIGNAL
10 B8 20DG/TN (ETC) LEFT FRONT WHEEL SPEED SENSOR (-)
11 B20 20DG/OR BRAKE FLUID LEVEL SWITCH SENSE
12 B22 20DG/YL VEHICLE SPEED SIGNAL NO. 1
13 Z127 12BK/DG (ABS) GROUND
14 A111 14DG/RD (ABS) FUSED B(+)
CONTROLLER ANTILOCK BRAKE C2 (ABS) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 B9 20DG/LG LEFT FRONT WHEEL SPEED SENSOR (+)
2 B8 20DG/TN LEFT FRONT WHEEL SPEED SENSOR (-)
3 B6 20DG/WT RIGHT FRONT WHEEL SPEED SENSOR (-)
4 B7 20DG/VT RIGHT FRONT WHEEL SPEED SENSOR (+)
CRANKSHAFT POSITION SENSOR (3.7L)-3WAY
CAV CIRCUIT FUNCTION
1 K24 20BR/LB CKP SIGNAL
2 K900 20DB/DG SENSOR GROUND
3 F855 20PK/YL 5 VOLT SUPPLY
8W - 80 - 52 8W-80 CONNECTOR PIN-OUTSDR

CRANKSHAFT POSITION SENSOR (4.7L)-3WAY
CAV CIRCUIT FUNCTION
1 K24 20BR/LB CKP SIGNAL
2 K900 20DB/DG SENSOR GROUND
3 F855 20PK/YL 5 VOLT SUPPLY
CRANKSHAFT POSITION SENSOR (5.7L)-3WAY
CAV CIRCUIT FUNCTION
1 F855 20PK/YL 5 VOLT SUPPLY
2 K900 20DB/DG SENSOR GROUND
3 K24 20BR/LB CKP SIGNAL
CRANKSHAFT POSITION SENSOR (DIESEL)-3WAY
CAV CIRCUIT FUNCTION
1 K853 18DB/BR 5 VOLT SUPPLY
2 K975 18BR/BK SENSOR GROUND
2 K975 18BR/OR SENSOR GROUND
3 K24 18BR/LB CKP SIGNAL
3 K24 18LB/BR CKP SIGNAL
CYLINDER LOCK SWITCH-DRIVER (PREMIUM)-2WAY
CAV CIRCUIT FUNCTION
1 G163 20VT/LB DRIVER CYLINDER LOCK SWITCH MUX
2 Z463 20BK/LB GROUND
DATA LINK CONNECTOR - BLACK 16 WAY
CAV CIRCUIT FUNCTION
1- -
2 D25 20WT/VT PCI BUS
3- -
4 Z11 18BK/LG GROUND
5 Z111 18BK/WT GROUND
6- -
7 D21 18WT/BR SCI TRANSMIT (PCM)
8- -
9 D16 18WT/OR SCI RECEIVE (TCM)
10 - -
11 - -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 53

DRIVER DOOR MODULE C1 - BLUE 12 WAY
CAV CIRCUIT FUNCTION
1 Q612 14OR/DB RIGHT REAR WINDOW DRIVER (DOWN)
2 Q412 14OR/LB RIGHT REAR WINDOW DRIVER (UP)
3 Q16 14OR/TN MASTER WINDOW SWITCH RIGHT FRONT (UP)
4 Q411 14OR/WT LEFT REAR WINDOW DRIVER (UP)
5 Q11 14OR/LG LEFT FRONT WINDOW DRIVER (UP)
6 Q26 14OR/GY MASTER WINDOW SWITCH RIGHT FRONT (DOWN)
7 G161 20VT/DG DRIVER DOOR LOCK SWITCH MUX
8 Z421 14BK/BR GROUND
9 F30 14PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
10 Q611 14OR/GY LEFT REAR WINDOW DRIVER (DOWN)
11 Z941 20BK GROUND
12 Q21 14OR/WT LEFT FRONT WINDOW DRIVER (DOWN)
DRIVER DOOR MODULE C2 - BLUE 8 WAY
CAV CIRCUIT FUNCTION
1 P71 18TN/DG LEFT MIRROR UP DRIVER
2 P195 18LG/YL LEFT MIRROR COMMON DRIVER (RIGHT/DOWN)
3 A930 18RD FUSED B(+)
4 P74 18TN/OR RIGHT MIRROR LEFT DRIVER
5 Z461 20BK/DG GROUND
6 P75 18TN/LG LEFT MIRROR LEFT DRIVER
7 P72 18TN/GY RIGHT MIRROR UP DRIVER
8 Q15 14OR/LB POWER WINDOW SWITCH FEED
EGR SOLENOID (4.7L/5.7L)-6WAY
CAV CIRCUIT FUNCTION
1 K34 18DB/LG EGR SENSOR SIGNAL
2 F856 20YL/PK 5 VOLT SUPPLY
3 K900 20DB/DG SENSOR GROUND
4 Z335 18BK/WT GROUND
5- -
6 K35 18DB/VT EGR SOLENOID CONTROL
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 57
