1998 DODGE RAM 1500 Alignment

ADJUSTMENTS
ADJUSTMENT
(1) Locate access hole and remove the mylar tape
covering it. (Fig. 8)
(2) Insert a 5/32-inch hex-wrench through hole and
into adjustment screw. Loosen screw.
(3) Operate outside handle several times to release
any restriction because of mis-alignment.
(4) Tighten adjustment screw to 3 N´m (30 in.
lbs.).
(5) Test handle for proper operation.
LATCH STRIKER
REMOVAL
(1) Using a grease pencil or equivalent, mark the
position of the striker.
(2) Remove the bolts and remove the striker.
INSTALLATION
(1) Install the striker and install the bolts.
(2) Tighten the bolts to 28 N´m (21 ft. lbs.).
(3) Adjust the striker if needed. (Refer to 23 -
BODY/DOOR - FRONT/LATCH STRIKER - ADJUST-
MENTS)
ADJUSTMENTS
ADJUSTMENT
(1) Using a grease pencil or equivalent, mark the
position of the striker to aid in adjustment.
(2) Loosen the striker bolts.
(3) Change the striker position to adjust the rear
gap and flush measurement. (Refer to 23 - BODY/BODY STRUCTURE/GAP AND FLUSH - SPECIFI-
CATIONS)
(4) Tighten the bolts to 28 N´m (21 ft. lbs.).
TRIM PANEL
REMOVAL
(1) Remove the window crank, if equipped. (Fig.
10)
(2) Remove the interior handle. (Refer to 23 -
BODY/DOORS - REAR/INSIDE HANDLE ACTUA-
TOR - REMOVAL)
(3) Remove the screw near the inside handle. (Fig.
9)
CAUTION: Trim panel is attached to the door using
hooks molded into the panel. Do not pull the trim
panel straight off or damage to the panel and/or
power switch assembly may occur.
(4) Lift the trim panel up off the belt seal and
attachment hooks and separate the panel from the
door slightly.
(5) Disconnect the power window switch electrical
connector, if equipped, and remove the trim panel.
INSTALLATION
(1) Position the trim panel onto the lower hooks
and connect the power window switch electrical con-
nector, if equipped.
(2) Position the remaining trim panel attachment
hooks into the door panel and seat the trim panel
into the belt seal fully.
(3) Install the screw near the inside handle.
Fig. 8 LATCH ADJUSTMENT SCREW - TYPICAL
1 - DOOR LATCH
2 - MYLAR TAPE
3 - ADJUSTMENT SCREW
Fig. 9 TRIM PANEL
1 - DOOR
2 - ELECTRICAL CONNECTOR
3 - ATTACHMENT HOOKS
4 - SCREW
5 - TRIM PANEL
DRDOORS - REAR 23 - 33
LATCH (Continued)

NOTE:
All measurements are in mm.
O/F = Over Flush
U/F = Under Flush
DIMENSION DESCRIPTION GAP FLUSH
*1 Bumper to grille 19.0   3.0 Ð
*2 Hood to grille 1.5   1.0
Parallel within 2.0U/F 0.75   1.75
*3 Fender to hood 6.0   2.0
Parallel within 1.0U/F 3.2   1.5
(Underflush from front of
hood to start of hockey
stick area only)
*4 Fender to hood
(Up/Down surface only)6.0   1.5
Parallel within 1.00.0   1.5
*5 Front door to windshield Ð O/F 20.5   1.5
(Base of windshield)
O/F 9.0   1.5
(Top of windshield)
*6 Roof to front door Ð U/F 6.0   1.5
Parallel within 1.5
7 Quarter to front door 5.0   1.5
Parallel within 1.00.0   1.5
8 Front door to quarter character line
alignmentÐ Up/Down 0.0   1.5
*9 Front door to fender character line
alignmentÐ Up/Down 0.0   1.5
*10 Front door to fender 5.0   1.5
Parallel within 1.00.0   1.5
*11 Bumper to fender 19.0   3.0
Parallel within 3.0O/F 5.0   5.0 (SLT)
O/F 14.0   5.0 (SPORT)
*12 Bumper to headlamp 19.0   4.0 Ð
* ALL MODELS
Fig. 1 GAP & FLUSH - STANDARD CAB
23 - 96 BODY STRUCTUREDR
GAP AND FLUSH (Continued)

NOTE:
All measurements are in mm.
O/F = Over Flush
U/F = Under Flush
DIMENSION DESCRIPTION GAP FLUSH
1 Roof to rear door Ð U/F 6.0   1.5
Parallel within 1.5
2 Quarter to rear door 5.0   1.5
Parallel within 2.00.0   1.5
3 Rear door to quarter character line
alignmentÐ Up/Down 0.0   1.5
4 Rear door to front door character line
alignmentÐ Up/Down 0.0   1.5
5 Rear door to front door 5.0   1.5
Parallel within 2.00.0   1.5
Fig. 2 GAP & FLUSH - QUAD CAB
DRBODY STRUCTURE 23 - 97
GAP AND FLUSH (Continued)

NOTE:
All measurements are in mm.
O/F = Over Flush
U/F = Under Flush
DIMENSION DESCRIPTION GAP FLUSH
1 Tailgate to outer box
(Up/Down surface only)Ð 0.0   1.5
Parallel within 1.0
2 Cab Back to box front 31.0   5.0
Parallel within 3.0Ð
3 Fuel door to outer box 5.0   1.5
Parallel within 1.00.0   1.5
4 Cab to box side 31.0   5.0
Parallel within 3.04.0   2.5 (Standard Cab)
O/F 5.0   2.5 (Quad Cab)
5 Cab to box character line alignment Ð Up/Down 0.0   3.0
6 Tailgate to outer box 5.0   2.0
Parallel within 1.0U/F 1.5   1.5
7 Bumper to outer box 24.75   5.0 (F/A)
23.75   5.0 (C/C)
Parallel within 5.0Ð
8 Tailgate to outer box character line
adjustmentÐ Up/Down 0.0   1.5
9 Bumper to tailgate 30.25   3.0
Parallel within 4.0Ð
Fig. 3 GAP & FLUSH - PICKUP BOX
23 - 98 BODY STRUCTUREDR
GAP AND FLUSH (Continued)

5.7L V-8
The 5.7L V-8 engine is equipped with a closed
crankcase ventilation system and a Positive Crank-
case Ventilation (PCV) valve.
This system consists of:
²a PCV valve mounted into the top of the intake
manifold, located to the right / rear of the throttle
body (Fig. 12). The PCV valve is sealed to the intake
manifold with 2 o-rings (Fig. 13).
²passages in the intake manifold.
²tubes and hoses to connect the system compo-
nents.
5.9L V-8
The 5.9L V-8 engine is equipped with a closed
crankcase ventilation system and a positive crank-
case ventilation (PCV) valve.
This system consists of a PCV valve mounted on
the cylinder head (valve) cover with a hose extending
from the valve to the intake manifold (Fig. 14).
Another hose connects the opposite cylinder head
(valve) cover to the air cleaner housing to provide a
source of clean air for the system. A separate crank-
case breather/filter is not used.
Fig. 11 CRANKCASE BREATHERS (2) - 3.7L V-6 /
4.7L V-8
1 - CRANKCASE BREATHERS (2)
2 - REAR OF ENGINE
Fig. 12 LOCATION 5.7L PCV VALVE
1 - TOP OF INTAKE MANIFOLD
2 - THROTTLE BODY
3 - AIR RESONATOR
4 - P C V VA LV E
Fig. 13 5.7L PCV VALVE
1 - P C V VA LV E
2 - O-RINGS
3 - ALIGNMENT TABS
25 - 18 EVAPORATIVE EMISSIONSDR
PCV VALVE (Continued)
