42-78
Be careful not to damage the surface of the control arm Fig. 1 Attaching assembly device to control arm
- Attach 3292 assembly device with both sides of tool jaws between
bearing and control arm.
- Screw in spindle up to stop so that tool compresses rubber metal
bushing against eye in control arm eye.
Fig. 2 Attaching pressure piece to control arm and pressing out
bonded rubber bushing
- Secure 3292/2 to 3292 using bolts -a- (M10 x 80).
- Attach 3292/4
- Screw spindle into 3292 until bonded rubber bushing is pressed out.
