1997 TOYOTA CELICA service indicator

Publication No. OM20695U
Part No. 01999-20695
Printed in Japan 04- 9702- 02
Quick index

If a service reminder indicator or warning buzzer comes on 61 . . . . .

If your vehicle will not start 137 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

If your engine stalls while driving 140 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

If your vehicle overheats 140, 141 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

If you have a flat tire 142 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . .

If your vehicle needs to be towed 149 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Tips for driving during break- in period 115 . . . . . . . . . . . . . . . . . . . . . . . . .

How to start the engine 127 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .

General maintenance 164 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .

Complete index 213 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . .
Gas station information
Fuel type:
7A- FE engineÐUNLEADED gasoline, Research Octane Number 91 (Octane
Rating 87) or higher.
5S- FE engineÐUNLEADED gasoline, Research Octane Number 91 (Octane
Rating 87) or higher. For improved vehicle performance, the use of premium
unleaded gasoline with a Research Octane Number of 96 (Octane Rating
91) or higher is recommended.
See page 115 for detailed information.
Fuel tank capacity:
60 L (15.9 gal., 13.2 lmp. gal.)
Engine oil: API SH, ''Energy- Conserving II'' multigrade engine oil or ILSAC multigrade
engine oil is recommended.
See page 178 for detailed information.
Tire information: See pages 181 through 186.
Tire pressure: See page 208.
-8
c
ProCarManuals.com

4
1. Service reminder indicators or indicator lights
2. Tachometer
3. Odometer and two trip meters 4. Engine coolant temperature gauge
5. Fuel gauge
6. Trip meter
7. Trip meter reset knob
8. Speedometer
Instrument cluster overview
ProCarManuals.com

5
Anti-lock brake system warning light *1
Brake system warning light *1
Seat belt reminder light*1
Discharge warning light*1
Low oil pressure warning light*1
Malfunction indicator light*1
Low fuel level warning light *1
Open door warning light*1
SRS airbag warning light*1
Turn signal indicator lights
Headlight high beam indicator light
Over-drive indicator light
Cruise control indicator light*2
*1: For details, see Service reminder indicators and warning
buzzersº in Chapter 1-5.
*
2: If this light flashes, see Cruise controlº in Chapter 1-6.
Indicator symbols on the instrument panel
ProCarManuals.com

33
Do not perform any of the followingchanges without consulting your
Toyota dealer. Such changes caninterfere with proper operation ofthe SRS airbag system in somecases.
Installation of electronic itemssuch as a mobile two-way radio,
cassette tape player or compactdisc player
Modification of the suspension
system
Modification of the front endstructure
Attachment of a grille guard (bullbar, kangaroo bar, etc.), snow-
plow, winches or any other equip-ment to the front end
Repairs made on or near the frontend structure, console, steeringcolumn, steering wheel or dash-board near the front passenger
airbag
NOTICE
This SRS airbag system has a service re-
minder indicator to inform the driver of op-
erating problems. If either of the following
conditions occurs, this indicates a mal-
function of the airbags. Contact your To-
yota dealer as soon as possible to service
the vehicle.

The light does not come on when the
ignition key is turned to the ACCº or
ONº position, or remains on.

The light comes on while driving.In the following cases, contact your Toyo-
ta dealer as soon as possible:

The SRS airbags have been inflated.

The front part of the vehicle (shaded in
the illustration) was involved in an ac-
cident not of the extent to cause the
SRS airbags to inflate

The pad section of the steering wheel
or front passenger airbag cover
(shaded in the illustration) is scratched,
cracked, or otherwise damaged.
ProCarManuals.com

Part 1Fuel gauge59
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1-5
Gauges, Meters
and Service reminder
indicators

Fuel gauge

Engine coolant temperature
gauge

Tachometer

Odometer and trip meter

Service reminder indicators and
warning buzzers
The gauge works when the ignition
switch is on and indicates the approxi-
mate quantity of fuel remaining in the
tank.
Nearly fullÐNeedle at Fº
Nearly emptyÐNeedle at Eº
It is a good idea to keep the tank over 1/4
full.
This fuel gauge has a non-return type
needle wh ich remains at the last indicated
position when the ignition switch is turned
off.
If the level approaches Eº or the low fuel
level warning light comes on, fill the fuel
tank as soon as possible. If the fuel tank is completely empty, the
malfunction
indicator lamp comes on. Fill
the fuel tank immediately.
The indicator lamp goes off after driving
several times. If the indicator lamp does
not go off, contact your Toyota dealer as
soon as possible.
ProCarManuals.com

61
These meters show the running dis-
tance.
1 OdometerÐIt shows the total dis-
tance the vehicle has been driven.
2 Trip metersÐIt shows the distances
driven since the last time it was set to
zero.
The black digits on white indicate tenths of
kilometers or miles
3 Trip meter reset knobÐIt resets the
trip meter to zero,.
To reset the trip meter, push the knob.
Odometer and trip meterService reminder indicators
and warning buzzers
ProCarManuals.com

63
(e) Malfunction indicator lamp
This lamp comes on in the following
cases.
a. The fuel tank is completely empty.
(See Fuel gaugeº in Chapter 1-5 for in-
structions.)
b. There is a problem somewhere in
your engine or automatic transmission
electrical system.
If it comes on while you are driving in case
b, have your vehicle checked/repaired by
your Toyota dealer as soon as possible.
(f) Low Fuel Level Warning Light
This light comes on when the fuel level in
the tank becomes nearly empty. Fill up the
tank as soon as possible.
(g) ABSº Warning Light
This light warns that there is a problem
somewhere in your anti-lock brake sys-
tem.
If the light comes on while you are driving,
have your vehicle checked by your Toyota
dealer as soon as possible.
The light will come on when the ignition
key is turned to the ONº position. After
about 3 seconds, the light will go off. When the ABSº warning light is on (and
the brake system warning light is off), the
brake system
operates conventionally but
anti-lock brake system is not assisting
brake performance so that the wheels can
lock-up during sudden braking or braking
on slippery road surfaces.
(h) Open Door Warning Light
This light remains on until all the doors
and back door are completely closed.
(i) SRS Airbag Warning Light
This light will come on when the igni-
tion key is turned to the ACCº or ONº
position. After about 6 seconds, the
light w ill go off. This means the airbag
system is operating properly.
The warning light system monitors the
front airbag sensors, center airbag sensor
assembly, inflators, warning light, inter-
connecting wiring and power sources.
If either of the following conditions occurs,
this indicates a malfunction somewhere in
the parts monitored by the warning light
system. Contact your Toyota dealer as
soon as possible to service the vehicle.

The light does not come on when the
ignition key is turned to the ACCº or
ONº position or remains on.

The light comes on while driving. (j) Key Reminder Buzzer
This buzzer reminds you to remove the
key when you open the driver's door with
the ignition key in the ACCº or LOCKº
position.
CHECKING SERVICE REMINDER
INDI-
CATORS (except the low fuel level
warning light)
1. Apply the parking brake.
2. Open either side door or the back
door
The open door warning light should come
on.
3. Close the door.
The open door warning light should go off.
4. Turn the ignition key to ACCº.
The SRS airbag warning light should
come on. It goes off after about 6 sec-
onds.
5. Turn the ignition key to ONº, but do
not start the engine.
All the service reminder indicators except
the open door warning light and SRS air-
bag warning light should come on. The
ABSº warning light goes off after about 3
seconds.
If any service reminder indicator or warn-
ing buzzer does not function as described
above, either the bulb is burned out or the
circuit is in need of repair. Have it checked
by your Toyota dealer as soon as pos-
sible.
ProCarManuals.com

106
Air Intake selector
Press the button to select the air source.
An indicator light will illuminate to show
which air intake mode is being selected.
1 RecirculateÐRecirculates the air in-
side the vehicle.
2 Fresh ÐDraws outside air into the
system. A/Cº button
To turn on the air conditioning, press the
A/Cº button. The A/Cº button indicator
will come on. To turn the air conditioning
off, press the button again.
If the A/Cº button indicator flashes, there
is a problem in the air conditioning system
and the air conditioning automatically
shuts off. If this happens, take your ve-
hicle to a Toyota dealer for service.
