1997 SKODA OCTAVIA engine

Downloaded from www.Manualslib.com manuals search engine Fuel Supply System20
Edition 08.96




Adjusting throttle cable
Notes:
The throttle cable is very sensitive to kinking
and should be treated with particular care
when installing.
A single slight kink can subsequently resultin the cable fracturing when driving. Throttle
cables which have been kinked, musttherefore not be installed.
When installing, ensure that the throttle cableis properly aligned between its supporting
points and the cable attachment points.
Special tools, testers and aids required Spring stretcher rod
Procedure
- Attach throttle cable to the accelerator pedal and to the cam of the throttle valve control unit.
- Pull off locking element for throttle cable at the detent.
- Depress accelerator pedal to full throttle position.
Note:
A second mechanic is required for this step ordepress accelerator pedal using spring stretcher
rod supported against steering wheel.
Models with manual gearbox
- Adjust throttle cable by repositioning the detent on the support bracket so that full throttle position is reached at the throttle
valve lever.
Models with automatic gearbox
- Adjust throttle cable by repositioning the detent on the support bracket so that the throttle valve has opened fully and the kickdown switch is heard to click.
For all models
- Release accelerator pedal or remove stretcher rod.
- After completing adjustment, check idling speed and full throttle stop of the throttle valve.
